CS-402 Wireless Tilt Sensor
Installation Instructions & User Guide
Specifications
Frequency: 345MHz Operating Temperature: 32°-120°F (0°-49°C)
Battery: One 3Vdc lithium CR123A (1550 mAh) Operating Humidity: 5-95% RH non condensing
Battery life: up to 5 years Compatible with ClearSky receivers
Tilt Sensor Supervisory signal interval: 62 min (approx.)
Normally closed contact input terminals
Enrolling
To enroll the sensor, set ClearSky receiver into program mode, refer to your receiver manual for details on
these menus. There are two triggers on this device and each uses a unique loop number. The tilt sensor is
assigned to loop 2 and the external input is assigned to loop 1.
Tilt Sensitivity
The tilt sensor will activate when the device is approximately at a 45 degree angle. By moving the
actual ball sensor up or down you can adjust this angle by a few degrees.
Note that this device has a delay of approximately 1 second to eliminate false alarms cause by
wind and vibration commonly subjected to a large garage door.
Mounting
Included with this device are mounting screws and double sided tape. For reliable bonding with
the tape ensure the surface is clean and dry. Apply the tape to the sensor and then to the desired
location. Apply firm pressure for several seconds. It is not recommended to mount the tape at
temperatures below 50°F, although after 24 hours the bond will hold at low temperatures.
To auto enroll the tilt sensor, you must ensure the tilt is orientated in the up
position (refer to picture and note location of arrow on the plastics). When
prompted by the panel, move the device until its orientated in the horizontal
position.
To auto enroll the external contact input, trigger the sensor by closing the circuit
between the two terminal inputs when prompted by the panel. This can be done
with a piece of wire, or if using a hardwired contact, by applying the magnet to
that contact.
This serial number is printed on the device if manual enrollment is desired.
The tilt sensor can operate as an “exit / entry” zone or a “perimeter zone”. Set
the zone type for the wireless tilt sensor in your panel.
Disclaimer: The external contact terminals, while fully functional, have not been
submitted to UL / ETL laboratories for verification of compliance with applicable
standards. Operation of the external contacts is outside of the scope of the ETL
listing for this product.

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant
to Part 15 of the FCC Rules. This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation. These limits
are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Re-orient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment to an outlet on a different circuit from the receiver
•Consult the dealer or an experienced radio/TV contractor for help.
Warning: Changes or modifications not expressly approved by Ecolink Intelligent Technology Inc. could void the user’s
authority to operate the equipment.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired operation of the device.
C’et appareil est conforme la norme d'Industrie Canada exempts de licence RSS. Son fonctionnement est soumis aux deux
conditions suivantes:
(1) c’et appareil ne peut pas provoquer d'interférences, et
(2) c’et appareil doit accepter toute interférence, y compris les interférences qui peuvent causer un mauvais fonctionnement
de la dispositif.
FCC ID: XQC-CS402 IC: 9863B-CS402
Warranty
Ecolink Intelligent Technology Inc . warrants that for a period of 2 years from the date ofpurchase that this product isfree
from defects in material and workmanship. This warranty does notapply todamage caused by shipping orhandling, or
damage caused by accident, abuse, misuse, misapplication, ordinary wear, improper maintenance, failure tofollow
instructions orasa result ofany unauthorized modifications.
If there isa defect in materials and workmanship under normal usewithin the warranty period Ecolink Intelligent Technology
Inc. shall, at its option, repair orreplace the defective equipment upon return of
the equipment tothe original point ofpurchase.
The foregoing warranty shall apply only to the original buyer, and is and shall be in lieu of any and all other warranties,
whether expressed or impliedand ofall other obligations orliabilities onthe part ofEcolink Intelligent Technology Inc. neither
assumes responsibility for, nor authorizes any other person
purporting toact on its behalf tomodify ortochange this warranty, nor toassume for itany other warranty or liability
concerning this product.
The maximum liability for Ecolink Intelligent Technology Inc. under all circumstances for any warranty issue shall be limitedto
areplacement ofthe defective product . Itis recommended that the customer check their equipment on a regular basis for
proper operation.
© 2020 Ecolink Intelligent Technology Inc. PN CS402 R1.00REV
DATE: 12/19/2020
2055 Corte Del Nogal
Carlsbad, California 92011
1-855-632-6546
www.discoverecolink.com
