Motion Sensor with Pet Immunity Installation Instructions
Product Overview
Z-Wave Plus enabled device which transmits upon detection of movement
Configurable to be less sensitive to the movement of small and medium size household pets
Reports tamper condition if cover is removed
Product Specifications
For indoor use only
Operating frequency: 868.42, 869.85 MHz
Operating range: Up to 100 feet (30.5 meters) line-of-sight
Operating temperature: 0˚C to 50˚C, 32˚F to 122˚F (ambient temperature)
Detection radius: Maximum 45 feet (see detection region diagram)
Detection angle: 45 degrees in either direction from the sensor’s center (see detection region diagram)
Battery type: 3V Lithium CR123A
Battery life: approximately 3 years
Passive Infrared (PIR) based technology
Network Inclusion
The sensor must be added to a Z-Wave network prior to use. To include the sensor in a network, both the sensor and the network
controller must be in inclusion mode at the same time. Refer to the instructions provided by the manufacturer of your specific controller
for details on initiating the controller’s inclusion mode.
STEP ONE Start by placing the controller into inclusion mode.
STEP TWO Activate inclusion mode for the sensor by removing the battery isolation pull tab, or by inserting the
battery (see next section for battery installation tips). When the inclusion process is complete the red LED
will turn on for approximately 10 seconds and then it will go out. If the LED continues to flash repeat the
inclusion process.

© 2018 Ecolink Intelligent Technology Inc. PN H214101 RevA
STEP THREE Test the motion sensor before mounting it. Place the sensor in an unoccupied room. Leave the room for
at least 4 minutes. Return to the room and pass in front of the sensor lens. The LED will flash once to
indicate that motion was detected.
Notes:
Sensor inclusion mode can also be initiated by inserting a pin or paper clip into the small round hole on the back side of the sensor.
The sensor also features a test mode so that motion detection can be tested without waiting 4 minutes. For more information refer to the “Test
Mode” section of these instructions.
Network Inclusion: Key Points to Remember
Controller inclusion mode must be activated BEFORE starting sensor inclusion mode.
The sensor can only be included into one controller network at a time, and must be excluded from one network before inclusion in another.
Removing the pull tab connects the battery and initiates sensor inclusion mode. Inclusion mode can also be initiated by removing the battery for at least 5 seconds,
reinstalling the battery, then replacing the sensor cover.
The plastic pull tab must be removed to enable sensor operation.
The sensor automatically enters inclusion mode at power-up.
Exclusion mode on the senor is initiated following the same exact procedure as inclusion.
Battery Installation Tips

© 2018 Ecolink Intelligent Technology Inc. PN H214101 RevA
Installation
The package contains the following:
1x Sensor
1x Sensor mounting bracket
4x screws
2x jumper
1x battery
3x pieces of adhesive tape
STEP ONE Mount bracket to wall
First attach the sensor mounting bracket to the wall using either adhesive tape OR screws (optional). For best performance mount
the bracket 6.5 to 7.5 feet above the floor (2 to 2.3 meters).
Corner Mount Flush Mount
Note: For best results, attach adhesive tape to bracket FIRST, then position on wall. Adhesive tape is VERY STRONG so moving the bracket after attaching will be
difficult.
Adhesive
Bracket
Screws
(Optional)

© 2018 Ecolink Intelligent Technology Inc. PN H214101 RevA
STEP TWO Attach Motion Detector to Bracket
ADDITIONAL NOTES AND SUMMARY:
BEFORE attaching the bracket to a surface note how the bracket will need to be oriented
in order for the tab to engage the sensor. The required orientation of the sensor determines
the bracket orientation. The large clip that holds the case together is located on the TOP.
Please be advised that adhesive tape may damage the surfaces to which it is attached and
then removed from.
The sensor slides onto the bracket until the tab engages and CLICKS.
The distribution pattern of the motion detector is approximately +/- 50 degrees left and right
of center and at maximum sensitivity will reach a maximum of approximately 45 feet. See
example distribution pattern below.
Once the mounting bracket is in place, align the holes on the
back of the motion detector with the key on the bracket. Slide the
sensor down on the keys until it snaps tight.
Motion Detector Distribution Pattern

© 2018 Ecolink Intelligent Technology Inc. PN H214101 RevA
Adjusting the Sensitivity of the Motion Sensor
The motion sensor has sensitivity adjustment via jumper placement on a pair of
pins on the circuit board of the sensor. Refer to the battery replacement section
to open the case and find the jumper pins inside the case.
Test Mode
The amount of time it takes for the sensor to reset after motion has been detected
can be shortened for quicker motion sensor testing. To enter test mode remove the
cover from the sensor. Find the pair of metal pins on the lower right hand side of the
circuit board labeled “TEST”. Connect these two pins together using the provided
jumper. Replace the sensor cover. After approximately ten seconds the red LED will
go out. The sensor is now in test mode. In test mode the LED will flash once when
motion is detected and again when motion detector is ready again. In this mode you
can wave your hand in front of the sensor or walk around the room and see where
motion is detected. Note that there must be a length of time without motion before
motion detect is enabled again. To restore normal operation, simply remove the test
jumper and replace the sensor cover.

© 2018 Ecolink Intelligent Technology Inc. PN H214101 RevA
What is Z-Wave?
The Z-Wave protocol is an interoperable, wireless, RF-based communications technology designed specifically for control, monitoring and status reading
applications in residential and light commercial environments. Mature, proven and broadly deployed (with over 35 million products sold worldwide), Z-Wave is
by far the world market leader in wireless control, bringing affordable, reliable and easy-to-use 'smart' products to many millions of people in every aspect of
daily life. Certified Z-Wave devices regardless of manufacturer can work together to form a Z-Wave mesh network. Always on Z-Wave devices can act as
repeaters in the mesh increasing range and redundancy.
For a more complete look at Z-Wave technology for non-technologists, and to learn more about Z-Wave's role as a key enabling technology for the Internet of
Things and connected objects, please visit www.z-wave.com.
Z-Wave Device Class and Command Class Information
This Z-Wave sensor is a Z-Wave generic Device Class of GENERIC_TYPE_SENSOR_NOTIFICATION, and a specific device class of
SPECIFIC_TYPE_NOTIFICATION_SENSOR, and the supported command classes are COMMAND_CLASS_ZWAVEPLUS_INFO, COMMAND_CLASS_VERSION,
COMMAND_CLASS_MANUFACTURER_SPECIFIC, COMMAND_CLASS_POWERLEVEL, COMMAND_CLASS_BATTERY, COMMAND_CLASS_NOTIFICATION_V4,
COMMAND_CLASS_ASSOCIATION, COMMAND_CLASS_ASSOCIATION_GRP_INFO, COMMAND_CLASS_WAKE_UP, COMMAND_CLASS_SENSOR_BINARY,
COMMAND_CLASS_CONFIGURATION, COMMAND_CLASS_BASIC.
Manufacturer Specific
Manufacturer ID: 0x014A
Product Type: 4
Product ID: 1
Factory Default
To restore this sensor to factory default settings, follow the instructions in this manual to exclude this sensor from the Z-Wave network. Upon completion of
removal from the network the sensor will restore itself to factory default settings automatically. Use this procedure only in the event that the network primary
controller is missing or otherwise inoperable.
Keeping Awake for Testing and Configuration
To save power, this sensor sleeps most of the time and is therefore not awake to receive messages from a gateway for testing. Removing the top case from the
sensor will put in device into a tampered mode in which the sensor will stay awake and able to receive messages. Most of the time an end user would not do
this, but if the sensor needs to be configured after inclusion, an end user can follow the instructions below for sending Wake-Up notifications.

© 2018 Ecolink Intelligent Technology Inc. PN H214101 RevA
Association
This sensor has two Association groups of 5 nodes each. Group one is a lifeline group who will receive unsolicited messages relating to motion detection
notifications, case tampering notifications, low-battery notifications, and sensor binary reports. Group 2 is intended for devices that are to be controlled i.e.
turned on or off (on only by default) with a Basic Set. On inclusion the controller should put its node ID in group 1 but not group 2.
Network Wide Inclusion
This sensor also supports Network Wide Inclusion such that the Sensor can be included into the Z-Wave network over the mesh network and not directly near
the main controller. This mode is automatically activated after regular inclusion was not successful.
SENSOR CONDITION
COMMAND CLASS and VALUE
ASSOCIATION GROUP
CONFIGURABLE?
Motion Detected
Notification Report of Home Security (0x07),
Motion Detection
Unknown Location(0x08)
1
Yes via Notification Set of notificationType
(0x07) and status of 0x00: This type of
notification turned off
0xFF: This type of notification turned on
Sensor Binary Report of 0xFF
Sensor Type: 0xFF
1
Yes via Configuration Command Class
Parameter Number: 2
Size: 1
A Configuration Value: 0xFF (On) / 0x00 (Off)
Basic set of 0xFF (On)
2
No
No More Motion
Detected
Notification Report of Home Security (0x07), Event
inactive(0x00)
1
Yes via Notification Set of notificationType
(0x07) and status of 0x00: This type of
notification turned off
0xFF: This type of notification turned on
Sensor Binary Report of 0x00
Sensor Type: 0xFF
1
Yes via Configuration Command Class
Parameter Number: 2
Size: 1
A Configuration Value: 0xFF (On) / 0x00 (Off)
Basic Set of 0x00 (Off)
By factory default this feature is disabled and must
be enabled via Configuration Command Class.
2
Yes via Configuration Command Class
Parameter Number: 1
Size: 1
A Configuration Value: 0xFF (On) / 0x00 (Off)
Parameter Number: 2

© 2018 Ecolink Intelligent Technology Inc. PN H214101 RevA
Sensor Case Removed
Notification Report of Home Security (0x07),
Tampering product cover removed (0x03)
1
Yes via Notification Set of notification Type
(0x07) and status of 0x00: This type of
notification turned off
0xFF: This type of notification turned on
Sensor Case Fastened
Wake-Up Notification
1
Yes via Wake-Up Notification Command Class
Battery Level Dipped
Below 2.6v
Notification Report of Power Management (0x08),
Replace battery now (0x0B)
1
Yes via Notification Set of notification Type
(0x08) and status of 0x00: This type of
notification turned off
0xFF: This type of notification turned on
Wake-Up Notification
The sensor will wake up every so often and when the case is closed to send a Wake-Up Notification to allow the life line master node controller that the sensor is
now available for any queued messages that the controller may have for the sensor. The time between Wake-Up Notifications can be configured with the Wake-
Up Notification command class to be between 1 hour and 1 week with interval steps of 200 seconds.
Configuration
The sensor has two configuration parameters. Parameter 1 configures the sensor to send or not send Basic Set commands of 0x00 to nodes in Association group
2 turning the devices off when the sensor is in a restored state (i.e. motion not detected). By default the sensor does NOT send Basic Set commands of 0x00.
Parameter 2 configures the sensor to either to send or not to send Sensor Binary Report commands to Association Group 1 when the sensor is faulted and
restored. If the controller is fully compatible with the Notification Command Class thereby making the Sensor Binary Reports redundant, the controller can
disable the Sensor Binary Report Commands completely. The following table shows the values to enable and disable the two configuration parameters.
Configuration Set Values
Effect
Parameter Number: 1 Size: 1
Configuration Value: 0x00
(Default) Sensor does NOT send Basic Sets to Node IDs in Association Group 2 when the sensor is restored (i.e. Motion
Not Detected ).
Parameter Number: 1 Size: 1
Configuration Value: 0xFF
Sensor sends Basic Sets of 0x00 to nodes in Association Group2 when sensor is restored.
Parameter Number: 2 Size: 1
Configuration Value: 0x00
(Default) Sensor sends Sensor Binary Reports when sensor is faulted and restored for backwards compatibility in
addition to Notification Reports.
Parameter Number: 2 Size: 1
Configuration Value: 0xFF
Sensor will send only Notification Reports and NOT Sensor Binary Reports when the sensor is faulted and restored.

© 2018 Ecolink Intelligent Technology Inc. PN H214101 RevA
ENGLISH
GUARANTEE TERMS AND CONDITIONS
UNIVERSAL ELECTRONICS / ECOLINK warrants to the original purchaser that this product will be free from defects in materials and workmanship under normal
and correct use for a period of 2-year from the date of original purchase. This product will be repaired or if necessary replaced free of charge if it has been
proven to be defective within the 2-year warranty period. The forwarding costs are on the account of the owner; the costs of returning the product are on the
account of UNIVERSAL ELECTRONICS / ECOLINK.
This warranty does not cover damage or failures caused by products or services not supplied by UNIVERSAL ELECTRONICS / ECOLINK, or which result from not
mounting the product according to manual instructions. This also applies when the product has been modified / repaired by others than UNIVERSAL
ELECTRONICS / ECOLINK or if a fault is the result from accident, misuse, abuse, neglect, mishandling, misapplication, faulty installation, improper maintenance,
alteration, modifications, fire, water, lightning, natural disasters, wrong use or carelessness.
To obtain warranty service during the warranty period, please notice that we need your original purchase receipt so that we may establish your eligibility for
service. If you have bought this product for purposes which are not related to your trade, business or profession, please remind that you may have legal rights
under your national legislation governing the sale of consumer goods. This guarantee does not affect those rights.
• Please ensure a minimum distance of 5 cm around the apparatus for sufficient ventilation.
• Please ensure that the ventilation is not impeded by covering the product with items such as newspapers, tablecloths, curtains, etc.
• Do not place near naked flame sources, such as lighted candles.
• To reduce the risk of fire or electric shocks do not expose this apparatus to rain or moisture, dripping or splashing.
• Use the apparatus only in moderate climates (not in tropical climates).

© 2018 Ecolink Intelligent Technology Inc. PN H214101 RevA
CAUTION NOTICE
CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. ONLY USE THE SUPPLIED BATTERIES OR MAKE SURE THEY ARE
100% COMPATIBLE. DISPOSE OF USED BATTERIES OBSERVING ENVIRONMENTAL PROTECTION RULES.
DECLARATION OF CONFORMITY
Hereby, Universal Electronics BV declares that the radio equipment type XXXXXXX is in compliance with Directive 2014/53/EU. The full text of the
EU declaration of conformity is available at the following internet address: xxxxxxxxxxxxxxxx
RECYCLING / WEEE DIRECTIVE
This product bears the selective sorting symbol for waste electrical and electronic equipment (WEEE). This means that this product must be
handled pursuant to European directive 2012/19 / EU in order to be recycled or dismantled to minimize its impact on the environment. User has
the choice to give this product to a competent recycling organization or to the retailer when user buys a new electrical or electronic equipment.
Z-WAVE CERTIFICATION
This product is Z-Wave certified. The Z-Wave Certification # is ZCXX-XXXXXXX. For more information, please visit www.z-wave.com
This product is covered by one or more claims of patents found at: http://sipcollc.com/patent-list
