ecoStage PAR LED COB WW User manual

- 1 -
PAR LED COB WW
User Manual
Please read this manual carefully before use!

- 2 -
Thank you for purchasing our 100W COB WHITE LED PAR64. Please read user
guide for safety and operations before using. Keep this manual for future reference.
1. Safety Instructions
Please keep this User Manual for future consultation. If you sell the fixture to
another user, be sure that they also receive this intruction booklet.
Please unpack and check carefully there is no transportation damage before
using the fixture.
Please disconnect main power before servicing and mantenance.
The unit must be installed in a location with adequate ventilation, at least 50cm
from adjacent surfaces.Be sure that no ventilation slots are blocked.
The maximum ambient temperature is Ta:40°C. DO NOT operate it where the
temperature is higher than this.
DO NOT connect the device to any dimmer pack.
The housing must be replaced if they are visibly damaged.
Unit surface temperature may reach up to 85°C. Don’t touch the housing
bare-hand during its operation. Turn off the power and allow about 15 minutes for
the unit to cool down before replacing or serving.
There are no user serviceable parts inside the fixture. Do not open the housing or
attempt any repairs by yourself. In the unlikely event your fixture may require
service, please contact your nearest dealer.
In the event of serious operating problem, stop using the fixture
Immediately. Never try to repair the fixture by yourself. Repairs carried out by
unskilled people can lead to damage or malfunction. Please contact the nearest
authorized technical assistance center. Always use the same type spare parts.
2. Safety Instructions
1/2/3 Channel Mode;
Dimmer, Strobe;
Ideal for Professional stages, Concerts, Clubs, Discotheques, Mobile Djs, etc.
Input Voltage: AC100V~240V,50/60Hz
Total Power consumption: 115W
Beam Angle: Stepless manual zoom from 11°to 35°
IP rating: IP20

- 3 -
LED Sources: 100W White COB LED
CRI: 90Ra
Color Temperature: 3000K/4000K/5700K for option.
Product Dimension: 491x275x224mm
Weight(N.W)：3.4Kgs
3. Checking Parts
Please check if the following parts are included:
1pc x 100 par 64
1pc x Power cable
1pc x User manual
4. Installation and Connection
The unit should be mounted via its screw holes on the bracket. Always ensure that
the unit is firmly fixed to avoid vibration and slipping while operating. Always ensure
that the structure to which you are attaching the unit is secure and is able to support a
weight of 10 times of the unit’s weight. Also always use a safety cable that can hold
12 times of the weight of the unit when installing the fixture.
The equipment must be fixed by professionals. And it must be fixed at a place where
is out of the touch of people and has no one pass by or under it. The unit should be
mounted in the height of 0 to 30m.
5. How to set the unit
Rear Panel
①Display : Show the various menus and the selected functions;

- 4 -
②LED indicator:
POWER
On
Power On
DMX
On
DMX input present
③Button:
MENU
To select the programming functions
DOWN
To go forward in the selected functions
UP
To go backward in the selected functions
ENTER
To confirm the selected functions
④Main input/output: PowerCon
⑤DMX input/output: For DMX512 link, use 3-pin XLR plug cable to input
DMX signal, and to link the next unit.
The beam angle can be adjusted manually, stepless manual zoom from 11°to 35°
6. Main Function

- 5 -
To select any functions, press MENU button until the required one is shown on the
display. Select the fuction by ENTER button. Use DOWN and UP button to change
the mode. Once the required mode has been selected, press ENTER button to setup
or it will return to the main functions without any change after idling 8 seconds
automatically. Back to the functions without any change press MENU button.
The main function are shown below:
Main
Menu
Sub Menu
Operation
Function
Remarks
MENU
(Nenu)
Addr (set address)
enter
+/-
set address（001-512）
Press
ENTER
to
confirm
(save
and exit)
Chnd
(channel option)
enter
+/-
1Ch
2Ch
3Ch
Dind
(dimmer)
enter
+/-
stda (standard scene)
stge (stage scene)
tv (TV scene)
aral (building scene)
thal (theatre scene)
Freq (dimmer frequency)
enter
+/-
900Hz
1000Hz
1100Hz
1200Hz
1300Hz
1400Hz
1500Hz
2500Hz
4000Hz
5000Hz
10K
15K
20K
25K
Gamma correction
enter
+/-
NO
2
2.2
2.4
2.6
2.8
Slnd
enter
+/-
Mast (master)

- 6 -
MENU
(Nenu)
Sl 1 (slave)
Press
ENTER
to
confirm
(save
and exit)
Lost
enter
+/-
blac
hold
auto
Manu
enter
+/-
d000-d255
( manual dimmier 0-255)
Tenp (temperature)
enter
00C-90C
Led (set backlight）
enter
on
off
disp (display reverse)
enter
on
off
Fhrs (working hours)
enter
total working hour
Ver (software version)
enter
software version
defa (set default)
enter
default
7. DMX512 configuration
Channel Mode:
1 Channel Mode
Channel
Function
Value
Details
CH1
Dimmer
000-255
Master Dimmer 0-100%
2 Channel Mode
Channel
Function
Value
Details
CH1
Dimmer
000-255
Master Dimmer 0-100%
CH2
Strobe
000-015
Strobe on
016-095
Strobe （1HZ-25HZ Slow-Fast）
096-175
Strobe （1HZ Slow-Fast）
176-255
Random Strobe
3 Channel Mode

- 7 -
Channel
Function
Value
Details
CH1
Dimmer
000-255
Master Dimmer 0-100%
CH2
Dimmer_Fine
000-255
Fine dimmer
CH3
Strobe
000-015
Strobe on
016-095
Strobe （1HZ-25HZ Slow-Fast）
096-175
Strobe （1HZ Slow-Fast）
176-255
Random Strobe
8. Troubleshooting
Following are a few common problems that may occur during operation. Here are some
suggestions for easy troubleshooting:
A. The fixture does not work, no light
1. Check the connection of power and main fuse.
2. Measure the mains voltage on the main connector.
B. Not responding to DMX controller
1. DMX LED should be on. If not, check DMX connectors, cables to see if link properly.
2. If the DMX LED is on and no response to the channel, check the address settings and
DMX polarity.
3. If you have intermittent DMX signal problems, check the pins on connectors or on PCB of
the fixture or the previous one.
4. Try to use another DMX controller.
5. Check if the DMX cables run near or run alongside to high voltage cables that may cause
damage or interference to DMX interface circuit.
9. Fixture Cleaning
The cleaning of internal must be carried out periodically to optimize light output. Cleaning
frequency depends on the environment in which the fixture operates: damp, smoky or
particularly dirty surrounding can cause greater accumulation of dirt on the fixture’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 15 days. Clean the internal optics at least every
30/60 days.
