Instruction Manual
OSCI -MOTION
First we want to thank you for buying a quality product from
AMA / Ecosystem.
We have developed OSCI~MOTION for professional usage
in aquariums. The components comply to industry standards
and promise high durability. The plastic parts were milled on
CNC-machines to ensure stability.
With OSCI~MOTION you’re getting a high quality product
“Made in Germany “
We want to wish you a good start with the following instructions
Preface
Please read this instruction manual carefully
before operatingto avoid damage.

The speed can not be changed with the operating voltage.
If you want to change the speed , you will need to exchange
the transmission. (See “Accessories”)
The mounting can be assembled vertically or horizontally
1. Transformator
2. Speed Change
3. Assembly
Important
OSCI~MOTION may only be used with a 24 Volt
safety transformer
The mounting can be adjusted stepplesly by the oblong hole.
The position of the OSCI~MOTION can be changed by 15mm to ensure
the best operating position.

Parts 1-9 are already assembled by the manufacturer.
Fasten the mounting with the enclosed screws (M5 x 50 mm)
on your OSCI-MOTION.
Put the drive shaft ( ) and the pump mounting ( )in the hole
of the trick shaft ( ) and fasten it with the screw ( ).
The adjustment of the base direction and depth can also be changed
later.
If you’ll need to have a larger negative depth, you can insert
a extension shaft. (See”accessories”)
Now mount the pump on the pump shaft.
11 12
57
5
6
7
10
2
1
15
8
9
3
11
12
14
Motor
Getriebe
4
13
1Motorr 24 V AC and transmission
2 Body
3 Screw M 5 mit 2,5 mm Imbus
4 Drive pulley with eccentric screw
5 Shaft drive
6 Glas bearing
7 Clamping screw for depth and position
8 Eccentric adjustment for moving angle
9 Motor retaining plate
10 OSCI-MOTION push rod
11 Shaft
12 Pump mount
13 Aptitude adjust screw
14 Fastening Block
15 Plug 24 V AC

4 Settings
Position the eccentric screw (8) without the push bar/rod (10)
pointing forward by switching on the motor. (See Fig 1 or 2)
By unfastening the screw you can adjust the eccentric.
In the beginning don’t adjust a too large turn. Try to find out your
desired move in small steps.
The further you unfasten the screw the bigger the turn.
Position the screw of the trick-shaft and place the pump in a foreward
direction. Now the screw (7) is in front and can easily be adjusted.
Inclination may be changed with an adjustment screw.
OSCI-MOTION and the pump may not be blocked by obstacles
to avoid damage !
Be prepared to switch the power off if the movement of
OSCI~MOTION is blocked. Be sure to switch the power
off when you change position or turn.
OSCI MOTION
OSCI MOTION
Fig. 1 Fig. 2Fig. 2
555
888
10 1010

Fig. 1 Fig. 2
OSCI MOTION
OSCI MOTION
OSCI MOTION
OSCI MOTION
5 Dual Mode
If you’re using a second OSCI~MOTION you’ll have a synergistic
effect. This means that two OSCI~MOTIONs increase the effect
by factor four.
When you do this the turning movements are never absolutely
synchronized (see Fig.1and 2).This results that the backflow is also
accelerated and this will reduce sedimentation.
Where the flow of both OSCI~MOTION will hit each other
there will be a down swirl.
The points where both flows will hit each other change all the time,
so there are no unwanted dead points.
The swirl are not only produced in the middle of your aquarium,
but also in the outer areas.
This effect can be increased by using a 1:5000 transmission
(see assecories)

Fig. 2
OSCI MOTION
OSCI MOTION
Fig. 3
Fig. 4 shows some possible points where swirls will be produced,
depending on the timing where and when the flows
will hit each other

6 Maintenance
7 Accessories
Transmission
1:250
1:500 (Standard)
1:5000
1:30000
Extension for drive shaft
Through ist robust construction OSCI-MOTION is designed
for low maintenance operation. Nevertheless the
glass ball bearingsshould be checked if it’s turning easily.
If you’re doing this take off the push bar and turn the drive shaft
manually. If the bearing has to be cleaned , take it out
and wash it with fresh water.
