EcoxGear SOUNDEXTREME SEI-INTRLED8KIT User manual

ExtremeStrip
INTERIOR LED LIGHT STRIPS
User Guide | Model: SEI-INTRLED8KIT
IMPORTANT:
· Please read the User Guide before installation and use.
· The ExtremeStrip is compatible with the ECOXGEAR audio and
LED lighting EcoSystem, which includes LEDCast and EcoCast
Innovations. Look for the LEDCast and EcoCast logos on the
growing family of ECOXGEAR and SoundExtreme audio and
lighting solutions.
· The ExtremeStrip must be controlled by a SoundExtreme
product with LEDCast technology (sold separately).
· Do NOT make modifications to the product connectors.
· Do NOT connect this product to any other manufacturers’
LED controller.
WARNING:
· Connecting this product to any other manufacturer’s product
may cause permanent damage to the product and shall void
the warranty.
· Do NOT overly bend the LED strips.

ExtremeStrip Layout*
*NOT TO SCALE
6
6
6
6
6
6
6
6 6
Interconnection
Cable  72 long
LED Control
Cable  48 long
LED Strip 
8 long

The ExtremeStrip LED strips come pre-connected by a 3-pin
connector. If the strips are disconnected or if you want to rearrange
the strips, please note that the strips are directional. (Additional strips
sold separately).
IMPORTANT: When reconnecting the strips, verify that the arrows on
each strip are facing the same direction AND ensure the arrows on
the strip are facing away from the controller. The arrows on the strip
MUST face away from the controller or other LEDCast product that
the strips are connected to, otherwise they will NOT function.
Mounting Instructions
Connections
1. Each LED segment has two options to mount the strip to your
vehicle’s body:
· 3M  double-sided tape
· Screw mounting holes at each end of the strip (screws included)
Arrows Must Face Away
From the Controller
Screw Mounting Hole 3M  Double-Sided Tape

2. The Interconnection Cable between two LED strip segments
may be longer than the installation requires. Do NOT cut the cable
and reconnect. Instead wrap the extra length on your vehicle and
fasten the cable with the included zip ties. Please ensure the cable
does NOT touch or drag on the ground AND is safely secured to
prevent it from coming into contact with any moving parts.
Wiring Instructions
1. Run the LED Control Cable to a SoundExtreme product with
LEDCast technology (sold separately), making sure the cable
does NOT touch any moving parts on the vehicle. If the cable is
longer than required do NOT cut the cable and reconnect. Instead
wrap the extra length on your vehicle and fasten the cable with the
included zip ties. Please ensure the cable does NOT touch or drag
on the ground AND is safely secured to prevent it from coming into
contact with any moving parts.
You can also use the provided Cable Clips to keep loose sections
of the cables from dangling. Mount the clip to your vehicle using
the adhesive backing.
2. Connect the 3-pin male connector on the LED Control
Cable to the LED control output 3-pin female connector on a
SoundExtreme product with LEDCast technology.

IMPORTANT: To avoid potential electric damage to your strips or
the LED controller, power o your SoundExtreme product with
LEDCast technology before you make the connection. Align the
arrow on both connectors, push-in, and screw the nut cap on the
female connector.
3. Once connected, you can change the ExtremeStrip lighting
eects via the connected SoundExtreme product, which can
be controlled by either a RF remote or the SoundExtreme
smartphone app.
Specifications
Total Length
___ in (___ cm)
Unit Weight
___ lbs (___ kg)
Maximum Working Current
1.0A (12V Power Supply)
Storage Temperature
-4°F to 122°F / -20°C to 50°C
Operating Temperature
23°F to 95°F / -5°C to 35°C

FCC STATEMENT:
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1.) This device may not cause harmful interference, and
2.) This device must accept any interference received, including interference that may cause undesired operation.
WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: FCC's RF Exposure guidelines, this equipment should be installed and operated with minimum distance
between 20cm the radiator to your body.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures: reorient or relocate the receiving antenna,
increase the separation between the equipment and receiver, connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected, consult the dealer or an experienced radio/TV technician for help.
RF WARNING STATEMENT:
The device has been evaluated to meet general RF exposure requirement. The device can be used in portable
exposure condition without restriction.
IC STATEMENT:
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions:
1.) This device may not cause interference, and
2.) This device must accept any interference, including interference that may cause undesired operation of the device.
PRODUCT USE AND PROTECTION:
Read and follow all instructions. Use only as intended.
The SoundExtreme unit is intended to be used indoors or outdoors and in land or water environments. The unit has
been tested to IP66 waterproofing standards, which means the unit can be exposed to dust and water, but should NOT
be submerged underwater.
To prevent fire or shock, do NOT attempt to power this unit if it is wet or you suspect water has entered the unit. In this
situation, please return the unit to SoundExtreme for a free assessment. If we have found that the unit has carried
water, we will repair or replace the unit free of charge.
SAFETY ADVISORY & WARNING:
Read and follow all instructions. Use only as intended.
CAUTION: Do NOT open to repair. A qualified technician must carry out repair work.
ATTENTION: Do NOT connect to a SoundExtreme product with LEDCast technology while the unit is wet. Make sure
all connections are dry BEFORE connecting to a power source. Failure to do so may result in electrical
damage to the unit and may void the warranty.
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
ATTENTION: Do NOT dispose of in a landfill. Contact SoundExtreme at www.gracesupport.com or a certified
recycling agent to dispose of the unit.
SAFETY:
This product has a limited life span of use and should be replaced when it shows obvious signs of wear.
Do not modify or remove any original component parts of the speaker. Doing so could cause damage to the unit,
allowing water to ingress. A unit with water ingress should not be charged due to potential risk of fire or shock.
Please exercise care and good judgment when using your SoundExtreme unit.
You should always
1.) Return the unit to SoundExtreme if you suspect water ingress into the unit or if the unit has experienced a severe
impact that may have aected the integrity of the unit to take on water.
You should never
1.) Never power your SoundExtreme unit if you suspect water has entered the device. Powering a device with water
inside could be potentially hazardous and cause fire or a spark.
2.) Never use your SoundExtreme unit if you have dropped it or thrown it against a hard surface which may have
destroyed the integrity of the housing. In the event of a severe impact to your unit, please return the unit to
SoundExtreme to review for potential damage.

3.)Never attempt to fix, repair your SoundExtreme unit . Please send it back to SoundExtreme for any assessments
and repairs.
CARE, MAINTENANCE & PRECAUTIONS:
1.)Do NOT apply excessive force to any surfaces of the unit.
2.)Do NOT use or store the unit in places with high temperature.
3.) AVOID prolonged exposure to ultraviolet radiation (UV sunlight) and strong magnetic fields.
LIMITED MANUFACTURER’S WARRANTY:
The ExtremeStrip is covered by a 1-year limited warranty that covers defects in workmanship and / or materials
for a period of 1 year from original purchase date. This warranty does not apply to any products which have been
abused, neglected, modified or used for a purpose other than the one for which they were manufactured. Please
refer to the above care and maintenance instructions for suggested care details. The warranty is valid only for the
original owner who purchases the unit from an authorized dealer. Transfers do not qualify for warranty protection.
SoundExtreme reserves the right to replace any out-of-stock or discontinued product with a comparable product.
Discontinued products may not be available for warranty replacement. Any contents are NOT covered by the limited
manufacturer’s warranty. Warranty terms may be revised without notification at the discretion of the manufacturer.
Please visit www.soundextreme.us for additional product & warranty information.
ExtremeStrip by SoundExtreme Inc., Houston, Texas.
Designed in Texas. Made in China.

What’s in the Box
Screws
Zip Ties
Interconnection Cable – 72 long
LED Control Cable – 48 long
Cable Clips
(3x) LED strips – 8 long
+ (2x) 6 Connection Cables
(1x) LED strip – 8 long
+ (1x) 6 Connection Cable
