Instruction to Install Thermal Printer
on iM8s/iM9s
Ver. 1.0
Howard Zhao
2014/1/27
This Guidance Is Available on: iM8s/iM9s

深圳市理邦精密仪器有限公司
EDAN INSTRUMENTS,INC.
Tel: [phone] Fax: [phone] w ww.edan. com.cn
Address:3/F-B,Nanshan Medical Equipments Part, Nanhai Rd 1019#, Nanshan,Shenzhen, 518067 P.R.China
1 Preparation
1.1 Tools and parts participate in the installation:
Thermal printer (with 2 screws attached)
Cross head screwdriver
Knife
2 Installation
2.1 You will find a thin gaps (as Fig.1 shows). Insert the knife into the gap, and pull the
shell out by raising the handle of the knife. Then the shell will separate from the
main unit, then you can pull it out.
Fig.1, Thin gap on the shell Fig.2, Pull out two cables

深圳市理邦精密仪器有限公司
EDAN INSTRUMENTS,INC.
Tel: [phone] Fax: [phone] w ww.edan. com.cn
Address:3/F-B,Nanshan Medical Equipments Part, Nanhai Rd 1019#, Nanshan,Shenzhen, 518067 P.R.China
2.2 Having opened the shell, you will see two cables inside, one is for communication
and other is for power supply (as Fig.4 shows). Then connect these 2 cables to the
relevant port on the printer
2.3 After the installation of the printer, reboot the Unit, and press Menu button on the
interface. Then select MAINTAIN. Input password 998 for the FAC KEY.
COMM Port
Power Supply Port
Fig.3, Connect two cables Fig.4, Fasten the screws
Fig.5, Select Maintain
Fig.6, Input password

深圳市理邦精密仪器有限公司
EDAN INSTRUMENTS,INC.
Tel: [phone] Fax: [phone] w ww.edan. com.cn
Address:3/F-B,Nanshan Medical Equipments Part, Nanhai Rd 1019#, Nanshan,Shenzhen, 518067 P.R.China
2.4 Select VECTOR for RECORDER, and then reboot the M3. The procedure finishes.
3 Press Record button to test the printing
Fig.8, Select MODULE SETUP
Fig.9, Mark RECORDER checkbox
Fig.9, Press Record button
