Edco Kit ah2 User manual

Original Instructions -Original Instructions -

CAUTION Read instructions before using the machine.CAUTION Read instructions before using the machine.

JVP 180-11

Kit AH2 (Australian)

Kit AH2

Assembly

Using your machine

LowLow

Start

123

4

1

2

5

Cleaning

Wand docking

1 2

3 4

Changing the Cable

7 8

65

TriTex Filter

604165 TriTex Filter

HepaFlo Dust Bags

604015 180 NVM 1CH Dust Bags (Pack of 10)

Replacement parts

Schematic Diagram

Tool Tidy

HO5-VV-F 10 m x 2 Core x 1.00 mm2

GTSA-2 10 m x 2 Core x 1.00 mm2(Socket + Plug)

Safety Critical Components

Mains leads:

Rating Label

About your machine (GB) 1.3

PPE (personal protective equipment). That may be required for certain operations.

Ear Protection Safety Footwear Head Protection Safety Gloves

Eye Protection Protective Clothing Dust / Allergens

Protection Hi Viz Jacket Caution Floor Sign

NOTE: A risk assessment should be conducted to determine which PPE should be worn.

1Company Name & Address

2Model

3Voltage / Alternating Current

4Frequency

5Rated Input Power

6Weight

7Protection Class 2 Symbol

8Approval Mark

9Machine yr/wk Serial Number

Maintenance

Daily

Keep the machine clean, including hoses and tubes.

Ensure the bag and  lter are  tted.

Regularly examine the power cord.

Check dust bag frequently.

Check  lters are clean.

Weekly - as daily and:-

Check for any worn or damaged parts and replace immediately.

1

2

3

4

5

6

7

8

9

Information for DRY use Vacuum cleaners 1.3

WARNING

Read the instruction manual before using the machine.

Operators shall be adequately instructed on the use of their machine.

As with all electrical equipment, care and attention must be exercised at all times during use, in addition to ensuring that

routine and preventative maintenance is carried out periodically to ensure safe operation.

Failure to carry out maintenance as necessary, including the replacement of parts to the correct standard could render

this equipment unsafe and the manufacturer can accept no responsibility in this respect.

Maintenance should only be carried out by a quali ed person.

This machine is for DRY USE only and must not be stored outside or used in wet conditions.

The machine shall be disconnected from the mains power by removing the plug from the power supply socket during

cleaning or maintenance and when replacing parts or converting the machine to another function.

Only use the socket outlet on the machine for purposes speci ed in the instructions (if  tted).

This machine is not to be used by children or persons with reduced physical, sensory or mental capabilities, or lack of

experience or knowledge.

This appliance is intended to be cleaned and maintained by an adult.

Children being supervised are not to play with the machine.

This machine is not a toy.

This machine is not suitable for picking up hazardous or explosive dust.

Contact your local distributor if you require a machine capable of performing these tasks.

CAUTION

Ensure that the  ltration system  tted to the machine is suitable for the material being collected.

This vacuum cleaner is intended for indoor use in the collection of dry materials.

This machine should be stored indoors only.

NOTES

The primary use for this machine is commercial, for example in hotels, schools, hospitals, factories, shops and oﬃ ces.

This product complies with the requirements of clause 20 of IEC/EN 60335-2-69 Stability and Mechanical Hazards.

This vacuum cleaner is  tted with a thermal protection device. If the vacuum cleaner stops working, remove the plug

from the wall before investigating where the fault lies.

If the vacuum cleaner has a blockage, switch oﬀ , remove the plug from the power socket, inspect the ﬂ oor tool, tubes

and hose for debris. If the ﬂ oor tool, tubes and hose are clear, replace the dust bag and clean the  lter.

The vacuum cleaner should be inspected after use for damage.

The vacuum cleaner should be stored in a dry place.

When moving from one place to another, consider the weight of the machine.

DO

• Keep your machine clean including hoses and tubes.

• Change dust bag frequently.

• Keep  lters clean.

• Keep diﬀ user  lter (where  tted) clean.

• Use  lter bags, they will enhance performance and help keep machine clean.

• Use a Numatic Original  lter bag under  ne dust conditions.

• Keep hoses and tubes clear.

• Replace any worn or damaged parts immediately.

• Only use the brushes provided with the machine. The use of other brushes may impair safety.

• Regularly examine the power cord. If damage is found such as cracking or ageing the power cord must be

replaced by a quali ed person.

• Only replace the power cord with the correct Numatic approved replacement part.

DO NOT

• Pull on the cable to unplug the machine from the power supply.

• Use to suck up hot ashes or lighted cigarette ends.

• Use steam cleaners or pressure washers to clean the machine or use in the rain.

• Immerse in water for cleaning.

• Attempt machine maintenance or cleaning unless the power supply plug has been removed from the supply outlet.

• Use in wet environments or to collect wet materials.

• Under any circumstances place foreign objects including (but not limited to) air fresheners, air freshener capsules

or scented beads of any type into the top  lter of the machine. Doing so can be dangerous and risk damage to the

machine and may invalidate the machine warranty.

Data - Daten - Caractéristiques - Data - Dados - Dati - Datos

1 2 3 4 5 6

180 8 L 26.4 m 7 Kg LpA ≤ 70 dB (A) Class II 340 mm x 365 mm x 360 mm

1 2 3 4 5 6

Drum Size Cleaning Range Weight

(Ready to work)

Sound Pressure

(LpA)

Uncertainty (KpA)

Protection Class Dimensions

Notes

..........................................................................................................................

Notes

..................................................................................................................................

.................................................................................................................................

..................................................................................................................................

.................................................................................................................................

..................................................................................................................................

Warranty

NumaticInternationalLimitedwarranttotheoriginalpurchaserthatitsproductsarefreeofdefectsinboth

materialandworkmanshipfortheperiodshownbelow:

HomecareandProcareVacuumcleaners............................................2Years

RotaryFloorMachines...............................................................................1Year

TwintecAutoScrubberDryer.....................................................................1Year

VarioRideOnScrubberDryer....................................1Year/1500hours

Mopping,Compacts,VersacleanandVersacareProducts..............................1Year

IndividualAccessoriesandSpareParts.................................................6Months

Note:Thiswarrantyexpresslyexcludesconsumablepartssuchascarbonbrushes,floorbrushes,mops,batteriesetc,that

areconsideredreplaceablefromtimetotimeduringthenormalworkinglifeofthemachine.

OurgoodscomewithguaranteesthatcannotbeexcludedundertheAustralianConsumerLaw.Youareentitledtoa

replacementorrefundforamajorfailureandforcompensationforanyotherreasonablyforeseeablelossordamage.You

arealsoentitledtohavethegoodsrepairedorreplacedifthegoodsfailtobeofacceptablequalityandthefailuredoesnot

amounttoamajorfailure.

Thebenefitsunder(OurWarranty)areinadditiontootherrightsandremediesunderalawinrelationtothe

(goods/services)

A. Thewarrantyperiodcommencesfromthedatethegoodsarepurchased.Weadviseallpurchaserstoretaintheir

invoiceasproofofpurchase.

B. AllwarrantyclaimsmustbeprocessedthrougheithertheDealerfromwhomtheequipmentwasoriginallypurchasedor

anotherauthorisedEdgarEdmondsonPtyLtdAustraliadealer.TheDealerwillcooperatewiththepurchaserthroughout

thewarrantyclaimsprocedureandwillarrangeanynecessaryrepairsusinggenuineNumaticparts.

C. IftheoriginalDealerisnolongerabletofulfilhisobligationspleasecontactEdgarEdmondsonPtyLtdAustraliawithfull

detailsoftheclaimandproofofpurchasesothatthismaybeprocessedwithoutdelay.

D. Anywarrantyclaimcanonlyrelatetothespecificpartthatisproventobeatfaultandforwhichareplacementwillbe

suppliedbutcannotbeextendedtoconstituteaclaimagainstthecompletemachine.

E. EdgarEdmondsonPtyLtdAustraliawillsupplytheDealerwithanywarrantypartsrequired,subjecttotheclaimbeing

validated.

F. Claimswillnotbeacceptediftheyaretheresultoffairwearandtear,misuseorabuseofanykind.

G. Noreplacementwillbegivenunlesstheappropriateevidenceofthevalidityoftheclaimhasbeenprovidedtothe

satisfactionofEdgarEdmondsonPtyLtdAustralia.

H. EdgarEdmondsonPtyLtdAustraliareservetherighttochargeforanyworkcarriedoutasaresultofaninvalidclaim.

I. NovariationtothiswarrantymaybemadeorimpliedbyanymemberofEdgarEdmondsonPtyLtdAustraliaorits

DealersunlesssuchvariationisinwritingandauthorisedbytheCompany.

AustralianImporter.

24403010/21(A03)

910901 10/21 (A04)

Numatic International Limited.

Chard, Somerset TA20 2GB ENGLAND

Tel: 01460 68600 www.numatic.co.uk

Specication subject to change without prior notice

Distributed by:-

Australian Importer
