PERFORMER-PLUS CAMSHAFT/LIFTERS/LUBE KIT
Part #2152
MODEL: 400, 425, & 455 c.i.d. Oldsmobile V8, 1967 & later
(except Toronado)
INSTRUCTIONS
• PLEASE study these instructions carefully before installing your new camshaft. If you have any questions, do not hesitate to call our Technical
Hotline at: 1-800-416-8628, Monday-Friday, Pacific Standard Time.
•CAMSHAFT: Edelbrock Performer-Plus camshafts are ground specifically for use with the corresponding Performer manifold #2151 on engines
operating from idle to 5500 rpm. The Performer Olds 455 manifold #2151 and Performer-Plus camshaft #2152 are designed to work as a team
to give you better driveability and performance. They are dyno-matched and street-proven. For best results, use the Edelbrock manifold/camshaft
package with the carburetor and headers we recommend.
NOTE: Maximum performance is achieved when the Edelbrock Performer Olds 455 Power Package components are used with the following
equipment:
• Performer Olds 455 manifold/camshaft/timing set/valve springs
• Original Equipment Quadrajet carburetor (w/electric choke) or Edelbrock carburetor #1407 or #1411
• 1-3/4" headers
• aftermarket/re-curved distributors
• any combination of the above
• IMPORTANT: This instruction sheet provides general installation guidelines which can affect your warranty. Read it carefully. It is not our intent
to cover each detail of installation here; a step-by-step procedure manual would be far too lengthy. We want to caution you that installing a
camshaft is a complicated procedure that requires a good general knowledge of automotive engines. If you are not confident that you can complete
the camshaft installation successfully, we suggest you consider having it installed by an experienced mechanic.
CAUTION: Improper installation will result in LOW MILEAGE, POOR PERFORMANCE, COSTLY REINSTALLATION, and ENGINE DAMAGE.
TO AVOID THESE PROBLEMS YOU MUST DO THE FOLLOWING:
• Carefully study and understand all instructions.
• Examine the camshaft for possible shipping damage (if damaged contact your dealer immediately).
• TOOLS AND EQUIPMENT
o Use the following checklist for items needed.
o box and open-end wrenches
o socket set
o distributor wrench
o pliers (channel locks & hose clamp)
o screw drivers (regular and phillips)
o torque wrench
o hammer
o gasket scraper or putty knife
o timing light
o vacuum gauge
o rags
o water bucket
o harmonic balancer puller
o crank gear puller
•HARDWARE & PARTS TO BUY
o gaskets- OEM valley pan or equivalent
o pipe plugs, if needed
o Edelbrock Gasgacinch, #9300
o RTV Silicone
o chalk
o paper and pencil
o radiator coolant
o teflon tape
o Edelbrock Performer-Link True Rolling Timing Chain and Gear
Set #7813
o New OEM Valve Springs or equivalent
PREPARATION CHECKLIST
©2009 Edelbrock Corp. Brochure #63-2152
Part #2152 Rev. 2/09 - AJ/mc
Page 1
IMPORTANT NOTE:
Proper installation is the responsibility of the installer. Improper installation will void warranty and
may result in poor performance and engine or vehicle damage.

INSTRUCTIONS FOR ENGINE PARTS REMOVAL
• BEFORE CAMSHAFT INSTALLATION
1. Disconnect battery.
2. For ease of installation, keep all parts in some sort of order.
WARNING: Do not remove radiator cap or radiator hose if engine is
hot.
3. Drain radiator coolant, move fan shroud back and remove fan and
spacer from water pump. Remove radiator and air conditioning
condenser if so equipped. In some cases, the front grille may have
to be removed. Measure distance from front cover to grille or
brackets that may interfere with camshaft against the length of the
camshaft.
4. Remove gas cap to relieve pressure. Disconnect fuel line at fuel
pump and plug. Replace gas cap.
5. Disconnect all linkage from carburetor such as throttle, throttle
springs, transmission, cruise control and automatic choke.
6. Tag and remove coil wires, sensor wires.and all vacuum lines.
7. Remove valve covers.
8. Remove distributor cap and wires, rotate engine until rotor points
towards number 1 terminal in cap and pointer on front cover is on
Top Dead Center (TDC) and remove distributor. Note the
approximate position of the vacuum advance canister in relation to
the manifold to assist in getting the distributor properly located
during re-installation.
9. Remove carburetor and intake manifold.
10. Remove rocker arms and pushrods. CAUTION: Rocker arms and
rocker arm pivots must be re-installed in their original positions.
11. Remove old valve lifters.
12. Remove crankshaft pulley and, using a suitable puller, crankshaft
dampener.
13. Loosen oil pan and remove water pump, fuel pump, and front cover.
NOTE: The front cover oil seal should be replaced before the front
cover iis re-installed.
14. Rotate engine until timing marks are aligned as shown in Figure 2.
15. Remove cam sprocket bolts. Slide sprocket and timing chain forward
to remove.
16. Remove camshaft. Using appropriate gear puller, remove crank
sprocket.
•VALVE SPRINGS
CAUTION: WARNINGS ABOUT YOUR WARRANTY
In order for this Performer-Plus cam and lifter kit to be covered under
ANY WARRANTY you MUST use the correct original equipment valve
springs or equivalent. Failure to install new Edelbrock valve springs
or OE equivalent with your new Performer-Plus cam could cause the
cam lobes to wear excessively and could cause additional engine
damage.
1. This camshaft is designed to function with stock valve springs. Do
not use dual valve springs with this camshaft.
2. When using stock valve springs, check and set spring height to
factory specifications for correct year and model.
NOTE: Due to various settings throughout the years, we advise
checking Motors, Chilton, or Oldsmobile service manuals or correct
spring height for your vehicle.
WARNING: Only use valve springs that are compatible with your
camshaft. The installed height minus the lift at the valve must be at
least .050” greater than the coil bind height of the spring. Failure to
verify this value can result in severe engine damage.
•VALVE ADJUSTMENT
1. Turn the engine over until the No. 1 cylinder is at Top Dead Center
(TDC) on the compression stroke (both lifters will be at the bottom of
their travel in the lifter bores). Install both intake and exhaust
pushrods, rocker arms, rocker arm pivot, and rocker arm bolts.
Carefully tighten bolts while feeling pushrods for vertical clearance.
As soon as all vertical clearance is gone from pushrods, count
number of turns until bolts bottom out. There should be 1/2 turn of
lifter pre-load. If vertical clearance exists after bolts bottom out,
longer-than-stock pushrods are required. If excessive lifter pre-load
exists, use shims under rocker arm pivots to achieve 1/2 turn pre-
load.
2. The above procedure assures correct lifter pre-load. Repeat this
procedure for each of the other seven cylinders by
rotating the engine 90° and following the firing order
(1-8-4-3-6-5-7-2).
3. Re-install front cover, fuel pump, water pump, and oil pan using new
gaskets.
4. Install intake manifold using new intake gasket set and torque
manifold bolts to 25 ft./lbs.
5. Install crankshaft dampener and torque to factory specs.
Page 2
•INSTALLING PUSHRODS AND ROCKER ARMS
After the cam is installed and timed correctly (see Figure 2), it will be
necessary to check each pushrod for correct lifter pre-load. Before
installation, be sure to coat friction surfaces of pushrods, rocker
arms and pivots with a suitable lubricant such as motor oil or
assembly lube.
•LIFTERS
1. New lifters must be used with a new camshaft. Use only the lifters
supplied with this kit.
2. Check to be sure that all lifters fit freely in the lifter bores.
CAUTION: Some engines use a .921" diameter lifter. If you have this
size lifter, you must purchase TRW VL-59, Speed-Pro #HT-957, or
contact Mondello Performance Products, phone # [phone].
•INSTALLATION INSTRUCTIONS
1. Coat cam lobes and bottoms of each lifter with MoS2 lube (supplied)
to prevent cam lobe and lifter wear from occurring during initial start-
up. Do not "pump up" lifters before installation!
2. Install new camshaft with new sprockets, timing chain and lifters.
CAUTION: Use Edelbrock Performer-Plus True Rolling Timing Chain
and Gear Set #7813. Do not use late model timing chain & gear sets
that are designed in a retarded position and are not recommended
for this camshaft installation. Edelbrock Timing Sets feature three
keyways for specific timing selection. Use locking compound
material on the bolt threads holding timing gear to cam. Torque to
factory recommendations specified in motor repair manual.
Install camshaft with timing marks lined up as recommended by
factory specifications. See Figure 2.
When using Performer-Plus Timing Chain and Gear Set #7813 with
Edelbrock cam and lifter kits, straight up timing alignment is
achieved. If any other timing gear set is used, it is necessary to check
cam position for correct timing alignment. This requires indexing the
camshaft with a degree wheel to verify timing alignment. O.E.M. or
non-Edelbrock timing gear sets are not recommended for use with
Edelbrock camshafts.
©2009 Edelbrock Corp. Brochure #63-2152
Part #2152 Rev. 2/09 - AJ/mc

• INSTALLING DISTRIBUTOR AND TIMING ENGINE
NOTE: Before installing your distributor, check the gear drive on the
distributor and oil pump for any signs of wear. If worn, be sure to
replace with new or you may wear out your camshaft prematurely.
Edelbrock camshafts are designed to use OEM-type gears only.
1. Turn the engine over in the direction of rotation until the No. 1 intake
valve closes and continue until the pointer on the front cover is
approximately 5 degrees BTDC.
2. Re-install the distributor with the rotor pointing towards No. 1
terminal in the cap, and with the vacuum advance canister in its
original position.
3. Lightly tighten the hold-down clamp so that the distributor can still
be turned to determine final setting using a timing light with the
engine running.
4. Replace valve covers, carburetor linkage and remaining vacuum and
electrical connections.
5. Re-install air conditioner, if so equipped.
6. Refill radiator with coolant and re-connect battery.
7. Double check all connections, fuel lines, etc. before starting engine.
•CAMSHAFT/LIFTER RUN-IN
CAUTION: Change the engine oil and filter before start-up and again
after initial break-in. Do not allow the engine to run under 2000 rpm
for the first 1/2 hour. Vary engine speed between 2000 and 2500
rpm. Slow idle speeds may result in severe cam and lifter wear.
1. Start the engine and bring to break-in rpm.
IMPORTANT INSTRUCTIONS
AFFECTING YOUR WARRANTY
•CAM LOBE WEAR- Cam lobe wear is almost non-existent unless
mismatched parts are used or installation of the cam and lifters is
done improperly. Most cam damage is caused by the timing gear
coming loose due to improper torque on bolt. Bolts holding gear to
camshaft should be torqued carefully and a locking compound
applied to threads of bolts.
•CAM GEARS AND CAMSHAFT END PLAY- If cam gear becomes
loose, the cam will slide back in the block, causing the lifters to hit
the lobes next to them and also the cam bearing journals. If the
engine is run after this happens, the bottom of the lifters and the
sides of the lobes will become chipped.
When installing a camshaft, it is always important to check for proper
operating clearances, especially when high performance
components are used. Things to look for that can cause failure and
damaged parts are as follows:
1. Improper valve-to-piston clearance (this should be no less than
0.080”).
2. Rocker arm stud slot clearance (both ends; valve closed and open).
3. Proper spring settings (see dimensions with spring instruction sheet;
correct dimensions mean maximum performance and longer engine
life).
•SPECIAL INSTRUCTIONS
With the Edelbrock manifold and camshaft package plus a header
installation, a carburetor jet change may be required for best
performance. Due to the varied applications of year and model of
vehicles, no one combination could suffice for all installations. The
following procedure is only a guideline and in many cases, the
manufacturing specifications for recommended carburetors or timing
may be best.
• IGNITION TIMING
Ignition timing for this package may vary with each application. A
good starting figure would be between 10 degrees to 14 degrees
initial timing at idle with vacuum advance disconnected. Total
advance should not exceed 32 degrees to 34 degrees with initial and
centrifugal weights combined and should be at full advance at 3000-
3500 rpm. After timing is adjusted, re-connect the vacuum advance
line. NOTE: The best combination for any particular vehicle or
application must be determined by trial and error using the above
information as a guideline.
•HEADERS
For best performance, headers are recommended. For this
application, they should be 1-5/8" or 1-3/4" diameter, approximately
31" long and terminating into a 3" collector. The remainder of the
exhaust system should consist of dual exhaust and tail pipes, at least
2" diameter with low back-pressure mufflers.
•WARNING
In order for this Performer-Plus cam and lifter kit to be covered under
ANY WARRANTY you MUST use the correct Edelbrock Sure Seat
Valve Springs or original equipment equivalent. The end flap or label
from your Sure Seat Valve Spring box must be sent in with your
camshaft warranty card.
Failure to install new Edelbrock Sure Seat Valve Springs or
Performer-Plus cam and lifter kit could cause the cam lobes to wear
excessively and could cause additional engine damage. IF YOU HAVE
ANY QUESTIONS ABOUT THIS APPLICATION, PLEASE CONTACT OUR
TECHNICAL DEPARTMENT IMMEDIATELY.
Figure 1-
Oldsmobile 400-425-455 c.i.d. V8
Firing Order 1-8-4-3-6-5-7-2
Turn distributor clockwise to advance timing.
Page 3
Figure 2-
Timing Chain Sprocket Alignment
Timing
Marks
2
34
8
1
2
7
5
6
468
7
5
3
1
©2009 Edelbrock Corp. Brochure #63-2152
Part #2152 Rev. 2/09 - AJ/mc
Edelbrock Corporation • 2700 California St. • Torrance, CA 90503
Tech Line: 800-416-8628

• CAMSHAFT: Performer-Plus Olds 455
• PART #2152
• ENGINE: Oldsmobile 400/425/455 c.i.d. V8
• RPM RANGE: idle-5500
• CAUTION: Use only recommended stock replacement valve
springs or equivalent.
Duration at .006" Lift: Intake 288° Exhaust 298°
Duration at .050" Lift: Intake 214° Exhaust 224°
Lift at cam: Intake .295" Exhaust .310"
Lift at valve: Intake .472" Exhaust .496"
Timing at .050 Lift: Open Close
Intake 0° ATDC 34° ABDC
Exhaust 49° BBDC 5° BTDC
• CENTERLINES
Lobe Separation angle: 112° Intake Centerline: 107°
• CAUTION: Use Edelbrock Performer-Link Timing Chain and Gear
Set #7813. Do not use late model timing chain and gear sets
that are designed for emission-controlled engines. These timing
sets are machined in a retarded position and are not
recommended for this camshaft installation. Edelbrock Timing
Sets feature three keyways for specified timing selection. Use
“0” position for most applications.
©2009 Edelbrock Corp. Brochure #63-2152C
Part #2152 Rev. 2/09 - AJ/mc
• CAMSHAFT: Performer-Plus Olds 455
• PART #2152
• ENGINE: Oldsmobile 400/425/455 c.i.d. V8
• RPM RANGE: idle-5500
• CAUTION: Use only recommended stock replacement valve
springs or equivalent.
Duration at .006" Lift: Intake 288° Exhaust 298°
Duration at .050" Lift: Intake 214° Exhaust 224°
Lift at cam: Intake .295" Exhaust .310"
Lift at valve: Intake .472" Exhaust .496"
Timing at .050 Lift: Open Close
Intake 0° ATDC 34° ABDC
Exhaust 49° BBDC 5° BTDC
• CENTERLINES
Lobe Separation angle: 112° Intake Centerline: 107°
• CAUTION: Use Edelbrock Performer-Link Timing Chain and Gear
Set #7813. Do not use late model timing chain and gear sets
that are designed for emission-controlled engines. These timing
sets are machined in a retarded position and are not
recommended for this camshaft installation. Edelbrock Timing
Sets feature three keyways for specified timing selection. Use
“0” position for most applications.
©2009 Edelbrock Corp. Brochure #63-2152C
Part #2152 Rev. 2/09 - AJ/mc
• CAMSHAFT: Performer-Plus Olds 455
• PART #2152
• ENGINE: Oldsmobile 400/425/455 c.i.d. V8
• RPM RANGE: idle-5500
• CAUTION: Use only recommended stock replacement valve
springs or equivalent.
Duration at .006" Lift: Intake 288° Exhaust 298°
Duration at .050" Lift: Intake 214° Exhaust 224°
Lift at cam: Intake .295" Exhaust .310"
Lift at valve: Intake .472" Exhaust .496"
Timing at .050 Lift: Open Close
Intake 0° ATDC 34° ABDC
Exhaust 49° BBDC 5° BTDC
• CENTERLINES
Lobe Separation angle: 112° Intake Centerline: 107°
• CAUTION: Use Edelbrock Performer-Link Timing Chain and Gear
Set #7813. Do not use late model timing chain and gear sets
that are designed for emission-controlled engines. These timing
sets are machined in a retarded position and are not
recommended for this camshaft installation. Edelbrock Timing
Sets feature three keyways for specified timing selection. Use
“0” position for most applications.
©2009 Edelbrock Corp. Brochure #63-2152C
Part #2152 Rev. 2/09 - AJ/mc
• CAMSHAFT: Performer-Plus Olds 455
• PART #2152
• ENGINE: Oldsmobile 400/425/455 c.i.d. V8
• RPM RANGE: idle-5500
• CAUTION: Use only recommended stock replacement valve
springs or equivalent.
Duration at .006" Lift: Intake 288° Exhaust 298°
Duration at .050" Lift: Intake 214° Exhaust 224°
Lift at cam: Intake .295" Exhaust .310"
Lift at valve: Intake .472" Exhaust .496"
Timing at .050 Lift: Open Close
Intake 0° ATDC 34° ABDC
Exhaust 49° BBDC 5° BTDC
• CENTERLINES
Lobe Separation angle: 112° Intake Centerline: 107°
• CAUTION: Use Edelbrock Performer-Link Timing Chain and Gear
Set #7813. Do not use late model timing chain and gear sets
that are designed for emission-controlled engines. These timing
sets are machined in a retarded position and are not
recommended for this camshaft installation. Edelbrock Timing
Sets feature three keyways for specified timing selection. Use
“0” position for most applications.
©2009 Edelbrock Corp. Brochure #63-2152C
Part #2152 Rev. 2/09 - AJ/mc
