EdgeStar CBR902SGDUAL User manual

ii
V2.0-08062018
Built-in Beverage Cooler
CBR902SG
Owner’s Manual
For more information on other great EdgeStar products on the web, go to http://www.edgestar.com
To use the EdgeStar self-diagnostic tool, go to https://support.edgestar.com

i
Important Safety Information
Improper handling can cause serious damage to the EdgeStar Beverage Cooler and / or injury
to the user. This Beverage Cooler is designed for domestic indoor use only. Do not use the
unit for industrial or commercial use. Any other use may invalidate the warranty. Please
review the ratings label located on the rear panel of the unit for electrical and other technical
data related to this unit. The unit must be used in a properly grounded wall outlet.
Please read and follow the safety information listed below to reduce the risk of fire,
electric shock, or injury.
Electrical Safety
Do not exceed the power outlet ratings.
It is recommended the Beverage Cooler be connected on its own circuit.
The unit must be installed in accordance with state and local electrical codes.
A standard electrical supply (115 V, 60Hz), that is properly grounded in accordance with the
National Electrical Code and local codes and ordinances is required.
Use outlets that cannot be turned off by a switch or pull chain.
Always turn the unit off and unplug it from the outlet when cleaning.
Unplug the unit if it is not going to be used for an extended period of time.
Do not operate the unit with a power plug missing the ground plug, a damaged cord, or a loose
socket.
Be sure the Beverage Cooler is properly grounded.
Never plug or unplug the unit with wet hands.
Do not bypass, cut, or remove the grounding plug.
Do not use extension cords or power strips with this unit. You may need to contact your
electrician if it is necessary to use a longer cord or if you do not have a grounded outlet. Do not
modify the power cord’s length or share the outlet with other appliances.
Do not start or stop the unit by switching the circuit’s power on and off.
If the power cord is damaged, it must be replaced by the manufacturer or a qualified technician.
Never repair the unit while it is plugged in.
Immediately unplug the unit if it makes strange sounds, emits smells, or smoke comes out of it,
and contact customer service.
Do not remove any part of the casing unless you are instructed to do so by an authorized
technician.
You should never attempt to repair the unit yourself.
Contact customer service for service options if the unit needs service.

ii
Note: This owner’s manual is provided for reference use only. Specifications may change
without prior notice. Refer to the product label on the back of your Beverage Cooler for the
latest technical information.
General Safety
To prevent back and other types of injuries, use at least two people to move and install the wine
cooler.
This appliance is not intended for use by persons, including children, with reduced physical,
sensory or mental capabilities, unless they have been given supervision or instruction concerning
the use of the appliance by the person(s) responsible for their safety.
Install the Beverage Cooler in a well-ventilated area where the ambient temperature is above 50°
F and below 95° F.
The temperature range for this cooler is optimized for wine storage. Perishable food items may
require a different storage environment.
Do not place hot or warm items into the cooler before they cool down to room temperature.
This unit is designed to be installed indoors, and protected from rain, sleet, snow, and / or
moisture.
This unit is not intended to be used by children.
Children should be supervised to ensure that they do not play with this product.
Never allow children to crawl inside the Beverage Cooler. If you are disposing of the unit, remove
the door.
Do not use this appliance near flammable gas or combustibles, such as gasoline, benzene,
thinner, etc.
Do not place the unit near heat sources such as ovens, grills, or direct sunlight.
Only use in an upright position on a flat, level surface and provide proper ventilation.
Do not pinch or kink the power supply line between the unit and cabinet.
Do not leave any cleaning solutions in the unit.
Do not use solvent-based cleaning agents or abrasive solutions to clean the unit as they may
damage the interior and exterior.
Do not place any other appliances on top of the unit.
Do not turn the unit upside down, on its side, or at an angle off level.
If your model of wine cooler is equipped with a lock, take care to keep the keys away from
children.
Do not move the unit without emptying the contents and securing the door in a closed position.
Note: Flammable Refrigerant Used! When handling, moving, and using the refrigerator, make
sure to avoid either damaging the refrigerant tubing, or increasing the risk of a leak.

iii
Table of Contents
IMPORTANT SAFETY INFORMATION.....................................................................................................................I
TABLE OF CONTENTS ...........................................................................................................................................III
FIRST TIME OPERATING INSTRUCTIONS .........................................................................................................................4
INTRODUCTION........................................................................................................................................................4
PARTS IDENTIFICATION.........................................................................................................................................5
FRONT VIEW ................................................................................................................................................................5
BACK VIEW ..................................................................................................................................................................5
Carbon Filter .............................................................................................................................................................. 6
Internal Fan................................................................................................................................................................6
INSTALLING THE BEVERAGE COOLER................................................................................................................7
UNPACKING THE BEVERAGE COOLER ...........................................................................................................................7
TYPES OF INSTALLATION...............................................................................................................................................7
Free-standing Installation:..........................................................................................................................................7
Built-in Installation:..................................................................................................................................................... 7
INSTALLATION CLEARANCE REQUIREMENTS...................................................................................................................8
ELECTRICAL REQUIREMENTS ......................................................................................................................................10
Recommended Grounding Method..........................................................................................................................10
LEVELING THE BEVERAGE COOLER .............................................................................................................................10
INSTALLING THE DOOR HANDLE...................................................................................................................................11
INSTALLING AND REMOVING THE SHELVES...................................................................................................................11
To Install the Shelves:..............................................................................................................................................11
To Remove the Shelves...........................................................................................................................................11
REVERSING THE DOOR SWING....................................................................................................................................12
To Reverse the Door from Right Swing to Left Swing .............................................................................................12
REMOVING AND INSTALLING DECORATIVE PLUGS.........................................................................................................13
OPERATION............................................................................................................................................................ 14
INSTALLATION CHECK LIST BEFORE OPERATION..........................................................................................................14
USING THE TEMPERATURE CONTROL PANEL................................................................................................................15
NORMAL SOUNDS.......................................................................................................................................................16
Temperature Alarm ..................................................................................................................................................16
Door Ajar Alarm........................................................................................................................................................16
DEFROSTING..............................................................................................................................................................16
PREPARING THE BEVERAGE COOLER FOR STORAGE....................................................................................................17
CLEANING AND MAINTENANCE..........................................................................................................................17
EXTERIOR CLEANING..................................................................................................................................................17
INTERIOR CLEANING ...................................................................................................................................................17
TROUBLESHOOTING.............................................................................................................................................18
SPECIFICATIONS...................................................................................................................................................20
EDGESTAR LIMITED WARRANTY........................................................................................................................21

4
First Time Operating Instructions
Before use, make sure all packaging labels and materials are removed from the unit. Be sure
to keep track of all included parts and pieces before discarding the packaging materials. It is
advised that you keep the original box and packaging materials in case you ever need to move
or ship the appliance in the future.
Let the unit stand for at least 24 hours before you use it; this allows the cooling components
time to settle from transit. The instruction manual should be read before use.
Introduction
Thank you for purchasing this EdgeStar Beverage Cooler. We hope that this purchase will be
the beginning of a lasting and rewarding relationship between you and EdgeStar. We will
provide the customer support and exemplary products necessary to nurture that relationship.
This manual contains important information regarding the proper installation, use, and
maintenance of your Beverage Cooler. Following this manual will ensure that your product will
work at its peak performance and efficiency.
Please save the original product packaging in case you need to safely transport your Beverage Cooler.
For Your Records:
Please write down the model number and serial number below for future reference.
Both numbers are located on the ratings label on the back of your unit and are needed
to obtain warranty service. You may also want to staple your receipt to this manual as it
is the proof of your purchase, and is also needed for service under your warranty.
Model Number:
Serial Number:
Date of Purchase:
For a more efficient experience, please do the following before contacting customer service:
If you received a damaged product, immediately contact the retailer or dealer that sold you
the product.
Read and follow this instruction manual carefully to help you install, use, and maintain your
Beverage Cooler.
Read the troubleshooting section of this manual as it will help you diagnose and solve
common issues.
Visit us on the web at http:/www.edgestar.com to register your product, download product
guides, and access additional troubleshooting resources and up-to-date information. You
can also find an interactive self-diagnostic tool at https://support.edgestar.com
If you need warranty service, our friendly customer service representatives are available
via email at serv[email protected] or by telephone at 1 [phone].

5
Parts Identification
Front View
Back View
Note: The carbon filter
should be replaced
every 3-6 months
depending on the
unit’s exposure level
to odor. If the unit is
placed in the kitchen
regular replacement
every 3 months is
ideal.

6
Carbon Filter
A built-in carbon filter protects your beverages by acting as a natural barrier against harmful
odors.
Internal Fan
This is an air-cooled unit equipped with an internal fan that maintains a consistent internal
temperature.
Note: The Carbon filter should be replaced every 3 - 6 months depending on the unit’s
exposure level to odor. If the unit is placed in the kitchen, regular replacement every 3 months
is ideal.
Tip: Gather the model and serial number from the product label and write them down before
installing the Beverage Cooler.

7
Warning: Use two or more people to move and install the Beverage Cooler. Failure to do so
can result in back or other injury. Carefully remove the packaging materials. Remove any
shipping tape and glue from your Beverage Cooler before use. Do not use sharp instruments,
rubbing alcohol, flammable fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your Beverage Cooler.
Important: Do not remove any safety, warning, or product information labels from your
Beverage Cooler.
Installing the Beverage Cooler
The Beverage Cooler should be installed in accordance with local electrical code requirements.
The Beverage Cooler should also be placed in a location that is strong enough to support its
total weight, keeping in mind that it will weigh substantially more when fully loaded than when
empty. Before you plug the Beverage Cooler into a power supply, be sure to let it stand
upright for at least 24 hours to allow the compressor’s oils to settle.
Unpacking the Beverage Cooler
Types of Installation
This Beverage Cooler has been designed for free-standing or built-in installation. In each case,
there must be adequate ventilation and access for service.
Free-standing Installation:
A free-standing installation will allow you to install the Beverage Cooler in almost any place
you desire. You must follow the stated instructions for electrical requirements and leveling
the Beverage Cooler.
Built-in Installation:
A recessed installation will allow you to install the wine cooler under a counter or in a
kitchen cabinet as long as the required clearance space around the wine cooler is
provided. It is necessary to allow adequate ventilation space around the unit, including at
the back of the unit. The following additional items must be observed:
1. Place the Beverage Cooler in front of the installation location. Adjust the feet and
place the unit flat on the floor or on a platform depending on your installation
requirements.
2. If the electrical outlet for the Beverage Cooler is behind the cabinet, plug in the
Beverage Cooler.
3. Push the Beverage Cooler into position.
Tip: Gather the model
and serial number
from the product label
and write them down
before installing the
Beverage Cooler.
Warning: DO NOT install the Beverage Cooler behind a closed cabinet door.

8
Important Notes:
Choose a location that has ambient temperatures above 50° F and below 95° F. Operation outside
these temperatures may result in lowered efficiency or cause other adverse effects.
This unit MUST be installed in an area protected from the elements, e.g. wind, rain, water spray or
drips.
The Beverage Cooler should not be located next to ovens, grills, or other high heat sources.
Do not kink or pinch the power supply cord between the Beverage Cooler and the wall or cabinet.
Installation Clearance Requirements
When installing the Beverage Cooler under a counter, follow the recommended spacing
dimensions shown.
To ensure proper service access and ventilation, allow at least 1-2” of clearance at the
back, 1/4” at the top, and 1/4” at the sides. If the door side is against a wall, allow at least
2 3/8”of clearance. The installation should allow the unit to be pulled forward for servicing,
if necessary.
Important Notes:
• Choose a location that has
ambient temperatures above
50°F and below 95°F.
Operation outside these
temperatures may result in
lowered efficiency or cause

9
The Beverage Cooler should be installed on a firm and level surface that will be able to
support the entire weight of a fully loaded unit. It is important for the Beverage Cooler to
be level in order to work properly. If needed, you can adjust the height of the Beverage
Cooler by rotating the feet. See the “Leveling the Beverage Cooler” section.
A standard electrical supply (115 VAC only, 60 Hz), properly grounded in accordance with
National Electrical Code and local codes and ordinances, is required.
