1.0 GENERAL DESCRIPTION
The Edgetech Instruments Model COM.AIR is a chilled mirror based hygrometer designed
especially to monitor the dew point in compressed air systems.
It is an integrated system including a microprocessor-based instrument, a chilled mirror dew
point sensor, a sample flow meter and valve, and associated tubing and fittings.
The wall mount enclosure is easily mounted to any vertical surface.
The Instrument includes:
An eight-digit, alphanumeric, LED display to report the dew point and system status.
Periodic sensor balance check.
Programmable Alarm Set Point with visual, audible, and contact closure alarm indications.
A SPDT (Form C) Alarm Relay.
A 4 to 20mA analog output.
2.0 INSTALLATION
2.1 MOUNTING
The COM.AIR can be installed on any flat vertical surface with four ¼ inch screws. See Figure
2-1 for dimensional information.
2.2 WIRING CONNECTIONS
The COM.AIR is designed to operate on AC voltages of 90 to 260 VAC with a maximum power
requirement of 40 Watts. The power entrance hole, located on the bottom of the enclosure, is
designed to accept a standard conduit, clamp type fitting or a compression type fitting
(supplied). The power line connections to the instrument are made using pigtail leads and wire
nuts.
Connect the power leads as follows:
1. Remove the three thumbscrews and the access cover as shown in Figure 2-2
2. Pull the three wires, black, white and green out of the wire box as shown in
Figure 2-3.
3. Insert the power line wires into the bottom of the enclosure and feed them up
through the wire box and out the access opening. Strip the wire ends back about
½". Using the three wire nuts, connect the wires black to black, white to white
and green to green. Tighten the wire nuts securely, making sure there are no
exposed wires.
4. Push the wires down into the wire box.
2.3 SAMPLE CONNECTIONS
The sample may be brought to the instrument with ¼" copper, stainless steel, or plastic tubing
and terminated in a ¼" female fitting.
Connect the sample supply line to the ¼" tubing fitting located on the top of the sensor. The
return line connect to the 1/4'” female fitting on the top of the enclosure Figure 2.2).
NOTE: The maximum inlet pressure is 150 PSIG.

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
5
2.4 ALARM RELAY CONNECTIONS
When the programmed Alarm Set Point is exceeded, the alarm relay will be energized. Before
connecting any device to the Alarm Relay contacts, check the contact ratings in the
Specifications section.
1. Remove the Access Panel as in Figure 2-2.
2. Referring to Figure 2-3, feed the wires to be connected to the relay through the “signals out”
fitting on the bottom of the enclosure and up to the PCB connector, marked P2, “ALARM
RELAY”.
NOTE: To connect a wire to the terminal, loosen the screw, insert the wire in the
opening, and tighten the screw.
3. Connect one of the signal wires to the CA (Center Arm) and the other wire to either the NO
(Normally Open) or NC (Normally Closed) terminal.
4. Replace the Access Cover.
2.5 ANALOG OUTPUT CONNECTIONS
1. Remove the Access Panel as in Figure 2-2.
2. Referring to Figure 2-3, feed the wires to be connected to the analog output through the
‘signals out’ fitting on the bottom of the enclosure and up to the PCB connector, P1, “4-20mA
out”.
NOTE: To connect a wire to the terminal, loosen the screw, insert the wire in the opening,
and tighten the screw.
3. Connect the high signal wire to the “+” terminal and the low side to the “-“ terminal.
4. Replace the Access Cover.
2.6 RS232 SERIAL(Optional)
1. For hygrometers equipped with optional RS232 only. The RS232 is 2 wire, Simplex,
RS232 serial output, data is transmitted at an interval of 1/sec, and is space delimited.
The BAUD rate is fixed at 19.2kbps. The protocol is N81(No Parity, 8 data bits, 1 stop
bit). The parameter sequence is “dew point ABC status.” (example:”xx.xC(or F)””
“’ABC on”)
2. For RS232 output connect to P11-1 for LO(-) and P11-2 for HI(+) located on the small
Pressure X-Ducer input/ Analog output/ RS232 PCB which is mounted parallel to the
main PCB.

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
6
FIGURE 2-1 MOUNTING

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
7
FIGURE 2-2ACCESS PANEL REMOVAL

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
8
FIGURE 2-3WIRING CONNECTIONS

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
9
3.0 FUNCTIONAL DESCRIPTION
The front panel of the COM.AIR consists of an LED Display, an audible alarm, two push-button
switches, and a sample flow meter with valve.
3.1 Display
The eight character alphanumeric LED display is used to display dew point data
and status messages.
Dew point data is displayed as “DP 34.8 F”, with the units in degrees C or F. (See Set-Up
section)
When a status message is necessary, the display will alternate between the data and the
message at about 2 second intervals.
The possible status messages and their meanings are:
“ABC CYCL” : Indicates that an Automatic Balance Cycle is in progress.
During an ABC Cycle;
The mirror is heated above the ambient temperature for a period of 1 to 3
minutes as determined by the last measured dew point.
After sufficient time has elapsed to ensure that the mirror is dry, the reflected light level of
the mirror is measured and if necessary, adjusted to the reference level.
After the adjustment is made, the instrument will begin cooling and seeking the dew
point. When a stable lock on the dew point is achieved, the “ABC CYCL” message will
disappear, and normal operation will resume.
The analog output is held to the dew point value just before the cycle started until the
completion of the ABC cycle.
If an alarm condition is present when the ABC cycle begins, the audible alarm and the
ALARM display are disabled but the Alarm Relay remains energized.
“ ALARM ” : The Alarm Set Point has been exceeded. The Alarm Relay will be energized
and the audible alarm will sound. The audible alarm can be silenced for one hour by
depressing the “SILENCE” push-button.
“CLN MIRR” : During an ABC Cycle, the condition of the sensor mirror and optics are
analyzed and a correction is made for changes in the reflectivity since the last cycle. If the
mirror reflectivity has decreased beyond the automatic correction range, this message will
appear at the end of the ABC cycle and indicates that the sensor mirror needs a manual.
Perform the “Mirror Cleaning Procedure” in the MAINTENANCE and CALIBRATION
Section.
Note: The instrument may appear to operate normally with this message present, but
the data should not be relied upon, until the appropriate maintenance is performed.

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
10
3.0 FUNCTIONAL DESCRIPTION (CONTINUED)
“CHK SNSR” : If during the ABC Cycle, the reflectivity has increased significantly due to
excessive drift of the optics, or abnormal circuit performance, this message will appear. To
determine the cause, take the following steps.
-Clean the mirror.
-Initiate an MABC Cycle.
-Check the sample system for proper flow.
-Check for loose connections or components on the printed circuit board and sensor.
If the condition cannot be resolved with these checks, contact Edgetech for service
3.2 MABC Button
Pressing the MABC Button (Manual Automatic Balance Cycle) at any time will initiate an ABC
Cycle.
3.3 SILENCE Button
If the measured dew point exceeds the Alarm Set Point, the audible alarm will sound. Pressing
this button will silence or disable the audible alarm for a period of about 60 minutes. After the 60
minutes, the audible alarm will be automatically re-enabled. The alarm message on the display
and the alarm relay will remain on.
3.4 Flow Control Valve
The sample flow rate is adjusted using this valve. Although the sample flow rate is not critical for
proper operation, the recommended rate is 1 –2 SCFH (Standard Cubic Feet per Hour).
3.5 Alarm Relay Output
The Alarm Relay is a SPDT relay that is energized whenever the dew point exceeds the Alarm
Set Point.
During an ABC cycle, all alarm functions, including the relay, are disabled.
However, if an ABC Cycle is initiated when an alarm condition is present, the relay will remain
energized until the cycle is complete.
At the end of the cycle the relay will remain energized if the alarm condition is still present or be
de-energized if the alarm condition has passed.
3.6 Analog Output
The analog output is a 4 to 20 ma output, proportional to the dew point, and scaled at the
factory for –58 to 122 °F (-50 to 50 °C) for S1 and S2 Sensors; -103 to 167°F (-75 to 75°C) for
S3 sensors.
During an ABC Cycle, the output is “held” at the last dew point until the routine is completed.

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
11
4.0 SETUP
4.1 Alarm Set Point (Figure 4.1)
The alarm set point temperature is set by dip switch S2 as an integer. The switch setting
represents an eight bit binary number in degrees C with position 8 as the least significant bit
(LSB) and position 2 as the most significant bit (MSB). Position 1 is the sign bit.
An ‘open’ switch is a ‘1’ and ‘closed’ is a ‘0’.
If the desired set point is in degrees F, convert it to Celsius before proceeding.
Set the switches as follows:
1. Convert the desired set point temperature from degrees C to its eight bit binary equivalent
code. Table 4.1 is provided to convert F to C and the equivalent eight bit binary code.
2. Set S1-1 ‘closed’ and S1-2 ‘open’. The alarm temperature setting will be displayed in degrees
C.
NOTE: S1-1 determines whether C or F is displayed in both the measurement and alarm set
modes.
S1-2 will switch the display between the dew point and the Alarm Setting.
3. Set S2, positions 1 through 8 according to the eight bit binary number determined in step 1. A
‘1’ is ‘open’, and a ‘0’ is ‘closed’.
4. The display should now read the set point temperature in degrees Celsius.
5. If Fahrenheit units are desired, set S1-1 to ‘open’.
6. Return to dew point display by setting S1-2 ‘closed’.

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
12
FIGURE 4-1SETUP

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
13
TABLE 4.1 SETUP
C F BINARY C F BINARY
-50.0 -58.0 10110010 0.0 32.0 00000000
-49.0 -56.0 10110001 1.0 33.0 00000001
-48.0 -54.0 10110000 2.0 35.0 00000010
-47.0 -52.0 10101111 3.0 37.0 00000011
-46.0 -50.0 10101110 4.0 39.0 00000100
-45.0 -49.0 10101101 5.0 41.0 00000101
-44.0 -47.0 10101100 6.0 42.0 00000110
-43.0 -45.0 10101011 7.0 44.0 00000111
-42.0 -43.0 10101010 8.0 46.0 00001000
-41.0 -41.0 10101001 9.0 48.0 00001001
-40.0 -40.0 10101000 10.0 50.0 00001010
-39.0 -38.0 10100111 11.0 51.0 00001011
-38.0 -36.0 10100110 12.0 53.0 00001100
-37.0 -34.0 10100101 13.0 55.0 00001101
-36.0 -32.0 10100100 14.0 57.0 00001110
-35.0 -31.0 10100011 15.0 59.0 00001111
-34.0 -29.0 10100010 16.0 60.0 00010000
-33.0 -27.0 10100001 17.0 62.0 00010001
-32.0 -25.0 10100000 18.0 64.0 00010010
-31.0 -23.0 10011111 19.0 66.0 00010011
-30.0 -22.0 10011110 20.0 68.0 00010100
-29.0 -20.0 10011101 21.0 69.0 00010101
-28.0 -18.0 10011100 22.0 71.0 00010110
-27.0 -16.0 10011011 23.0 73.0 00010111
-26.0 -14.0 10011010 24.0 75.0 00011000
-25.0 -13.0 10011001 25.0 77.0 00011001
-24.0 -11.0 10011000 26.0 78.0 00011010
-23.0 -9.0 10010111 27.0 80.0 00011011
-22.0 -7.0 10010110 28.0 82.0 00011100
-21.0 -5.0 10010101 29.0 84.0 00011101
-20.0 -4.0 10010100 30.0 86.0 00011110
-19.0 -2.0 10010011 31.0 87.0 00011111
-18.0 0.0 10010010 32.0 89.0 00100000
-17.0 1.0 10010001 33.0 91.0 00100001
-16.0 3.0 10010000 34.0 93.0 00100010
-15.0 5.0 10001111 35.0 95.0 00100011
-14.0 6.0 10001110 36.0 96.0 00100100
-13.0 8.0 10001101 37.0 98.0 00100101
-12.0 10.0 10001100 38.0 100.0 00100110
-11.0 12.0 10001011 39.0 102.0 00100111
-10.0 14.0 10001010 40.0 104.0 00101000
-9.0 15.0 10001001 41.0 105.0 00101001
-8.0 17.0 10001000 42.0 107.0 00101010
-7.0 19.0 10000111 43.0 109.0 00101011
-6.0 21.0 10000110 44.0 111.0 00101100
-5.0 23.0 10000101 45.0 113.0 00101101
-4.0 24.0 10000100 46.0 114.0 00101110
-3.0 26.0 10000011 47.0 116.0 00101111
-2.0 28.0 10000010 48.0 118.0 00110000
-1.0 30.0 10000001 49.0 120.0 00110001
0.0 32.0 00000000 50.0 122.0 00110010

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
14
4.2 ABC Interval
The ABC Interval is the time between the automatic initiation of ABC Cycles. In typical
applications, an interval of 24 hours is recommended and set at the factory. However, in cases
where ambient conditions are more variable, or the sample gas is higher in contaminants, a
shorter interval may be required.
The times listed below are approximate.
The interval is adjustable in 4 hour increments from 4 to 28 hours.
Switch positions S1-6, -7, and -8 represent a three bit binary code with a weight of 4 hrs. per
unit.
To set the interval, set S1-6, S1-7, and S1-8 according to the binary number from Table 4.2
below. The factory default is 24 hrs.
NOTE: ‘CLOSED’ is a zero and ‘OPEN’ is a one.
ABC
INTERVAL
S1- 6
S1- 7
S1- 8
OFF
0
0
0
4 hrs.
0
0
1
8 hrs.
0
1
0
12 hrs.
0
1
1
16 hrs.
1
0
0
10 hrs.
1
0
1
24 hrs.
1
1
0
28 hrs.
1
1
1
Table 4.2 converts the required interval in hours to a three bit binary number.

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
15
5.0 MAINTENANCE
5.1 ROUTINE MAINTENANCE
To ensure the maximum in accurate and reliable operation of any optical chilled mirror system,
a periodic maintenance program should be established.
5.2 MIRROR CLEANING SCHEDULE
Over time, particulates and other matter present in the sample gas and not captured by filters,
build up on the mirror. The result of the buildup of contaminants on the mirror surface is reduced
dry mirror reflectivity and a change in the optical reference point. The ABC Cycle will
automatically readjust the optics to the reference point periodically, but eventually the
adjustment range will be exceeded and a manual cleaning of the mirror may be necessary.
When the contamination becomes too much to be adjusted automatically, an error will be
displayed at the end of the ABC Cycle.
Normally, intervals of 90 days between routine mirror cleanings can be easily achieved.
However, if the sample gas contaminants are particularly high, more frequent mirror cleanings
may be required.
5.3 MIRROR CLEANING PROCEDURE (Figure 5.1)
When mirror cleaning is required as a periodic maintenance item or the “CLN MIRR” or “CHK
SNSR” message appears on the display, proceed as follows.
1. Turn power off.
CAUTION
When operating with a pressurized sampling system, be sure to
remove pressure from the Sensor prior to removing the Sensor cover.
2. Remove the spin-off cover from the Sensor to expose the mirror.
3. Moisten a clean cotton swab with isopropyl alcohol. Cotton swabs and cleaner are provided in
the Cleaning Kit supplied with the system.
4. Wipe the mirror surface and the optics surface in a circular motion.
5. After cleaning the mirror surface, wipe the surfaces dry with a clean Q-tip.
6. Next, moisten a clean Q-tip with clean, preferably distilled water and wipe the
mirror and optics areas.
7. Dry these areas thoroughly with a clean, dry Q-tip.
8. Replace the sensor cover.
9. Re-establish sample pressure and flow.
10. Turn power on.

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
16
FIGURE 5.1 SENSOR COVER REMOVED FOR MIRROR CLEANING

COM.AIR
Dew Point Monitor
04/02/2015 Rev. B
17
6.0 SPECIFICATIONS
Measurement Range
-Dew/ Frost Point -58 to 122°F(–50 to 50 °C)(Optional S2Sensor)*
-103 to 167°F(–75 to 75 °C)(Optional S3Sensor)*
Measurement Accuracy
-Dew/ Frost Point (+0.28°C) ±0.5°F (Entire Range)
Functional
Power: 90-260VAC, 50-400Hz, 40 Watts
Operating Temperature:
Control Unit/Sensor 32 to 122°F (0 to 50°C)
Sample Connection: ¼ female compression tubing fitting
Sample Flow: 0.5 to 5.0scfh, Integral flow meter and valve
Sample Pressure: 0 to 150psig max.
Analog Output: 4 to 20mA,
Range: –58 to 122°F (–50 to 50 °C)
Compliance: 9.0 VDC, 450 ohms
Display: Eight Digit Alphanumeric LED, 0.5” High.
High dew point Alarm:
- Audible >98 dba at 2 ft
- Visual Flashing Message on Display
- Relay Contacts 1 Form C, non-latching,
10A @ 240VAC
8A @ 24 VDC
½ HP @ 240VAC
Physical
Dimensions: 14“ (35.6 cm)H, 10.7“ (27.18 Kg)W,
3.75“ (9.525 Kg)D.
Weight: 7 lbs. (3.18 Kg)
Mounting: Wall mount standard
Material: Aluminum
Standard Features
- Microprocessor Controlled.
- 8 Digit Alphanumeric LED Display.
- Automatic Balance Control (ABC)
- User settable high alarm limit.
- Alarm Relay, Form C.
- Analog Output, 4 –20mA.
- Integral flow meter and valve.
- Audible and visual alarms.
- Wall mountable.
Optional Accessories
Low Dew Point Kit: 2 or 3 stage sensor.
Filter Kit: In-line, particulate/coalescing filter.
Dual Alarms
RS232 (2-wire)
