Educational Insights Artie 3000 User manual

EI-1125
codewithartie.com
Conforms to ASTM D4236
2.
1. 3.
4.
English
Esp
Eng
Fra
For multilingual instructions, visit:
CodeWithArtie.com/instructions

5. 7.
8.
6.
Artie
Artie 3000™
www.codewithartie.com
Toolbox
Move forward by 100mm
Turn
Drag functions from the left over here!
left by 90 degrees
Pen up
Pen down
Repeat 2times
Program
▶ Run Stop ✖ Clear
Simulate
Artie 3000™
www.codewithartie.com
Toolbox
Move forward by 100mm
Turn
Drag functions from the left over here!
left by 90 degrees
Pen up
Pen down
Repeat 2times
Program
▶ Run Stop ✖ Clear
Simulate

9.
10.
11.
12.

Developed in Southern California by Educational Insights.
All rights reserved. Made in China. ©Educational Insights, Gardena, CA, USA.
Learning Resources Ltd., Bergen Way, King’s Lynn, Norfolk, PE30 2JG, UK.
Please retain this guide for future reference. educationalinsights.com
FCC ID : MJO-EI-1125
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures: • Reorient or relocate the receiving antenna. • Increase the separation
between the equipment and receiver. • Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV
technician for help.
Note: The user is cautioned that changes and modications made to the equipment without the
approval of manufacturer could void the user’s authority to operate this equipment.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment.
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. End user must follow the specic operating instructions for satisfying RF exposure
compliance. This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
The portable device is designed to meet the requirements for exposure to radio waves established
by the Federal Communications Commission (USA). These requirements set a SAR limit of 1.6 W/
kg averaged over one gram of tissue. The highest SAR value reported under this standard during
product certication for use when properly worn on the body
English
Français
Deutsche
Español
All rights reserved. Made in China. ©Educational Insights, Gardena, CA, USA.• Learning Resources Ltd., Bergen Way, King’s Lynn,Norfolk, PE30 2JG, UK • educationalinsights .com
Hangman
Save
Save as...
New program
Delete Program
Download current program
Upload program
Open program:
First Lessons: Games! Hard
3
Remember
to place Artie
in the center of
the paper
Customize
this pattern to
add lines!
then click ▶
Run Stop ✖ Clear
Did you know that Artie has learned 4 different
games that t on an 8.5” x 11” or A4 piece of paper?
or
To have me draw this for
you, nd it in the menu!
Or code it yourself with
the steps on the other side!
English
Français
Deutsche
Español
All rights reserved. Made in China. ©Educational Insights, Gardena, CA, USA.• Learning Resources Ltd., Bergen Way, King’s Lynn,Norfolk, PE30 2JG, UK • educationalinsights .com
Save
Save as...
New program
Delete Program
Download current program
Upload program
Open program:
First Lessons: Coloring! Medium
2
Remember
to place Artie
in the center of
the paper
Mandala
then click ▶
Run Stop ✖ Clear
Did you know that Artie has learned 4 coloring
designs that t on an 8.5” x 11” or A4 piece of paper?
or
To have me draw this for
you, nd it in the menu!
Or code it yourself with
the steps on the other side!
English
Français
Deutsche
Español
All rights reserved. Made in China. ©Educational Insights, Gardena, CA, USA.• Learning Resources Ltd., Bergen Way, King’s Lynn,Norfolk, PE30 2JG, UK • educationalinsights .com
or
To have me draw this for
you, nd it in the menu!
Or code it yourself with
the steps on the other side!
Save
Save as...
New program
Delete Program
Download current program
Upload program
Open program:
First Lessons: Shapes! Easy
1
Remember
to place Artie
in the center of
the paper
Did you know that Artie has learned 4 different
shapes that t on an 8.5” x 11” or A4 piece of paper?
Square
then click ▶
Run Stop ✖ Clear
Developed in Southern California by Educational Insights.
All rights reserved. Made in China. ©Educational Insights, Gardena, CA, USA.
Learning Resources Ltd., Bergen Way, King’s Lynn, Norfolk, PE30 2JG, UK.
educationalinsights.com
Please retain the package for future reference.
Conserva el envase para futuras consultas.
Veuillez conserver l’emballage.
Bitte Verpackung gut aufbewahren.
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures: • Reorient or relocate the receiving antenna. • Increase the separation
between the equipment and receiver. • Consult the dealer or an experienced radio/TV
technician for help.
Note: The user is cautioned that changes and modications made to the equipment without the
approval of manufacturer could void the user’s authority to operate this equipment.
Cleaning Instructions
Clean the robot with a slightly damp cloth or dry
cloth. Do not immerse or spray any liquid or water on
the robot
Battery Information
• Do not mix old and new
batteries.
• Do not mix different types of
batteries: alkaline, standard
(carbon zinc) or rechargeable
(nickel-cadmium) batteries.
• Do not recharge non-
rechargeable batteries.
• Remove rechargeable
batteries from the toy
before recharging.
• Only charge rechargeable
batteries under
adult supervision.
• Only use batteries of the
same or equivalent type
as recommended.
• Insert batteries with the
correct polarity.
• Remove exhausted batteries
from the unit.
• Do not short circuit the
supply terminals.
• To prevent corrosion and
possible damage to the
product, we recommend
removing the batteries from
the unit if it will not be used for
more than two weeks.
13.
14.
English
www.CodeWithArtie.com

All rights reserved. Made in China. ©Educational Insights, Gardena, CA, USA.• Learning Resources Ltd., Bergen Way, King’s Lynn, Norfolk, PE30 2JG, UK • educationalinsights.com
or
Save
Save as...
New program
Delete Program
Download current program
Upload program
Open program:
1
To have the robot draw this
for you, find it in the menu! Or code it yourself with the
steps on the other side!
First Lessons: Shapes! Easy
Remember
to place the
robot in the
center of
the paper
Did you know that the robot has learned 4 different shapes
that fit on an 8.5” x 11” or A4 piece of paper?
Square
Then click Run
English

Pen up
4.
Pen up
Move
forward by
60
mm
Turn
left by
90
degrees
Move
forward by
60
mm
Turn
right by
90
degrees
1.
Pen down
Repeat
4
times
Turn
right by
90
degrees
Move
forward by
120
mm
2.
3.
1
First Lessons: Shapes! Easy
You can help jumpstart the robots memory by following
the below code to create a Square!
Visit codewithartie.com for How-To
Videos, ideas, and Artie’s manual
•Then click Run
English
Hint!
This section
repeats
whatever is inside
it, it’s also called
a “loop”

All rights reserved. Made in China. ©Educational Insights, Gardena, CA, USA.• Learning Resources Ltd., Bergen Way, King’s Lynn, Norfolk, PE30 2JG, UK • educationalinsights.com
or
2
Save
Save as...
New program
Delete Program
Download current program
Upload program
Open program:
First Lessons: Colouring! Medium
Did you know that the robot has learned 4 colouring
designs that fit on an 8.5” x 11” or A4 piece of paper?
Mandala
To have the robot draw this
for you, find it in the menu! Or code it yourself with the
steps on the other side!
Remember
to place the
robot in the
center of
the paper
Then click Run
English

1.
2.
3.
Pen up
4.
Pen down
Repeat 6 times
Turn left by 60 degrees
Repeat 36 times
Move forward by 6 mm
Turn left by 10 degrees
2
First Lessons: Colouring! Medium
You can help jumpstart the robots memory by following
the below code to create a Mandala!
Visit codewithartie.com for How-To
Videos, ideas, and Artie’s manual
English
Hint!
This section
repeats
whatever is inside
it, it’s also called
a “loop”
Look!
Another
repeat inside
a repeat!
•Then click Run

All rights reserved. Made in China. ©Educational Insights, Gardena, CA, USA.• Learning Resources Ltd., Bergen Way, King’s Lynn, Norfolk, PE30 2JG, UK • educationalinsights.com
or
3
Save
Save as...
New program
Delete Program
Download current program
Upload program
Open program:
First Lessons: Games! Hard
Did you know that the robot has learned 3 different games
that fit on an 8.5” x 11” or A4 piece of paper?
Hangman
Customise
this pattern
to add lines!
To have the robot draw this
for you, find it in the menu! Or code it yourself with the
steps on the other side!
Remember
to place the
robot in the
center of
the paper
Then click Run
English

Pen up
Move
back by
50
mm
Turn
left by
90
degrees
Move
forward by
70
mm
1.
Move back by
30
mm
Pen down
2.
Move forward by
15
mm
Turn
right by
90
degrees
Pen up
3.
Move forward by
70
mm
Pen down
Repeat
2
times
Turn
right by
90
degrees
Move
forward by
20
mm
4.
Pen up
6.
Move forward by
50
mm
Move forward by
12.5
mm
Turn
left by
90
degrees
Pen up
5.
Repeat
5
times
Pen down
Pen up
Move
forward by
15
mm
Move forward by
5
mm
3
First Lessons: Games! Hard
You can help jumpstart the robots memory by following
the below code to create aHangman!
Visit codewithartie.com for How-To
Videos, ideas, and Artie’s manual
English
•Then click Run
Hint!
This
section repeats
the lines in the
hangman puzzle!

Help if you get stuck
Q. Do I need WiFi to connect the robot?
A. No, The robot has his own built-in WiFi that works directly with
your device
Q. How do I know if the robot is connect to
my device?
A. You will know the robot is connected when the WiFi
icon is green
Simulate
Q. What if the robot won’t connect to my device?
A. Make sure the robots power switch is turned on and the
batteries are fresh. You can also reboot the robot by switching
him off, waiting 30 seconds, and powering him back on
Q. Can I use my phone to code with the robot?
A. The robot works best with a computer or tablet. The robot’s
interface works best with larger screens
Q. Where can the robot draw?
A. The robot draws only on one sheet of paper at a time. The
paper must be placed on a hard at surface. You can use tape
to hold the paper down. Always place the robot in the center
of the paper when you are ready to run a drawing program
Q. What kind of paper can I use with the robot?
A. The robots pre-programmed First Lessons need a minimum of
an 8.5” x 11” or A4 sized piece of plain paper, but you can
use as big as you like
Q. What if the robot slows down or takes breaks?
A. The robot may need new batteries. Replace his batteries by
following the battery installation instructions from the Quick
Start Guide
Q. The robot looks like he’s leaving ink blots,
what should I do?
A. Make sure to program the robot to move his pen up at the end
of your design. If the robot is leaving an ink blot when you
are placing him down on paper, re-align the marker using the
Marker-Parker
Q. What if the robots markers get on my clothes
or hard surface?
A. The robots markers are washable. Use mild soap and warm
water to soak and rinse clothing. Let clothing hang dry. If
markers get on your hard surface, be sure to use a paper towel
with mild soap and warm water to wipe it down
Q. Can I clean the robot?
A. Ever so carefully, use a damp cloth to wipe the robots surface
Q. The robots wheels seem stuck. What should
I do?
A. The robots wheels may need a quick cleaning. Use a damp
cloth to clean the treads on the wheels. Then, re-align the robots
Marker using the Marker-Parker
Q. Can the robot fall off the edge of a table?
A. Although the robot is clever, he does need someone to
re-direct him to ensure he does not fall off any edge.
While programming the robot, it is always important to
factor in measurement of space to keep him safe. Always
place the robot in the center of the paper when you run a
drawing program
Q. Can I use other markers with the robot?
A. Yes. The robot uses washable felt tip markers between 8mm
to 10.5mm diameter thickness. The length of the maker must
be 120mm or more. Measure here to check if your marker is
compatible with the robot
8
mm 10.5 mm
Smallest ----------------------------------------------------------- Largest
Always use washable markers
Frequently Asked Questions
English

Problem Solving
Problem Solving
Artie can draw anything you create in code, but
even with perfect code, your drawing may turn out
differently than expected. That is because there are
many factors in your environment that can affect
Artie. You may need to experiment to find the
best solution.
Once you have looked at all these factors,
it may be time to calibrate Artie. Not
all Arties need calibration, so double
check that you’ve taken the above
precautions first!
Learn more about how to calibrate
Artie at CodeWithArtie.com
Check Your Environment
RFirst, give Artie the opportunity to draw your picture
again. Simple things like someone bumping the table
can affect Artie’s drawings.
RCheck to see if your surface is perfectly level.
RTape all four corners of your paper to the table, and
make sure your paper is not textured or glossy (plain
computer paper works well!)
Check Artie
RWhen you have eliminated environmental
issues, take another look at your code. Can
you simplify? For example, try coding Artie to
draw backwards instead of turning all the way
around to draw forwards. Artie is built with
motors and gears, so the more steps and turns
in a drawing, the harder it will be for Artie to
stay precise.
RMake sure that the marker is positioned
correctly using the Marker Parker.
RArtie drawing himself off the edge of the table
may damage his gears, so always keep an eye
on him when you are drawing.
RArtie needs power, so if he slows down or takes
pauses, replace his batteries!
English
