EFFEKTIV TurboVapor 1950X User manual

InstructIon
PLEASE READ THIS INSTRUCTION
CAREFULLY BEFORE FIRST USE AND
KEEP IT FOR FUTURE REFERENCE
TurboVapor
1950X
VERTICAL FABRIC STEAMER

2
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
CONTENTS:
Product introduction .........................................................................3
Notice.................................................................................................3
Using guidance..................................................................................4
Method of removing scale ................................................................4
Parts and Accessories ......................................................................5
Installation ......................................................................................6-7
Operation ......................................................................................8-11
Ironing methods ..............................................................................11
Drain the water reservoir and stow the machine...........................12
Troubleshoots..................................................................................13
Circuit diagram ................................................................................14
 Models&Specications .................................................................14
Warranty and Service ......................................................................15

3
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
PRODUCT INTRODUCTION
Thanks for choosing us! The working theory of this product is touching the fabric by
hotsteamat98°Ctosoftenthebers,tomakethefabricsmoothandneatbythe
movementsofpullandpress.Thefabricsteamercanclean,disinfectandremovethe
smell,itpopularlyusedinthegarmentshops,hotels,restaurants,home,etc,normally
withhanger andhook. Only 45 seconds forheat-up andsteam, ironto thefabric,
noneedironingboard,60minutescontinuoussteam,itdecreasemanytraditional
ironingsteps and savethe time.Please use our products without worry, we have
double safety protection device: auto power- off for over-heat or shortage of water!
Theproductis suitablefor the cleanse and ironing ofany bersof thegarments,
curtains,carpets,bed-sheets,etc,easy-operating,portableandtime-saving.
NOTICE
Danger
– Don’t wash under the tap and immerse the machine into water or any liquid;
– Becarefulwiththehotsteam,itmayburntheskin.
Caution
– Make sure the power supply accord with the power symbol on the product before
connectingthepowersupply,don’tuseitwithotherhighvoltageapplianceunder
the same power supply.
– Pleasestopusingthemachineifanyoneofpartsisobviousdamaged:theplug,
cord,airhose,waterreservoirorthemachine.
– Repair the machine in the designated service centre, not repair by yourself,
impropriate repair may result in leakage of electricity or other accident.
– Don’t walk away when the machine is working.
– Makesurethechildrenleaveitaway,don’ttouchheater.
– Thesprinklerwillgethotterandhotter,don’ttouchittoavoidburning.
– Don’t twist the hose and block the steam hole in case to avoid the accident due
to high air pressure.
– Please hold the heat insulation part when hose head is hot.
– Don’t insert hot water into the reservoir.
– Don’t mix any cleaner in water.
– Make sure the plug is off when cleaning or adding water.
Remark
– The outlet demands to connect the ground wire.
– Must be used on the level ground.
– ThesteamwillcooldownandcondensateinthehoseifthehoseisinUstatus,
the steam will be interrupted or water drop come out.
– Please power off and unplug after ironing, for cleaning or leaving awayfor a
short while.

4
bottom drain
Fig. 1
50%
water 50% vinegar
1
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
USING GUIDANCE
– Make sure the reservoir is full of water on the relative position.
– Controlling the angle of ironing steam by the handle which is the connection of
end of sprinkler and hose.
– Thesprinklerisintheheadofthehandle,whenplaced,pleaseputonthehook
and keep it upward to avoid hot steam condenses into water droplets. The hook
can hang the sprinkler as well as clothes to be ironed.
– Thesteamhoseisconnectedwiththemainbodyclosely,donotpullitvigorously,
otherwise it may cause damage and leakage of steam.
– The steam generator is in inner of the machine.
– Please raise up the sprinkler timely to stretch the hose if you hear grunt or you
see the steam is interrupted.
METHOD OF REMOVING SCALE
Becauseofthehighmineralcontentofwaterinmanyareas,thecommonproblem
ofgarmentsteamerissedimentaccumulation,whichremainsinhoseandcauses
steaming out irregular or even without steaming. So it’s needed to be removed
periodically(better15days),thefollowingisthemethod:
1. Mix the vinegar with water according to the ratio of 1:1 (Fig. 1-1).
2. Inject the mixture into the machine from hose connection kit (Fig. 1-2).
3. Inject the mixture until reaches the highest water level (Fig. 1-3).
4. Press“DESCALING”,themachinewillremovescaleautomatically.
5. Waitfor30min.
6. Discharge the mixture through the bottom drain (Fig. 1-4).

5
Fig. 2
A: Sprinkler B: Hook C: Transverse bar
D: Telescopic rods E: Clip F: Water tank
G: Power line H: Main body I: Display screen
J: Steam hose K: Handle L: Integrated fabric brush
Fig. 3
The meaning of numbers in the display
screen are as following:
1 means: 1 gear – suitable for tulle material
2 means: 2 gear – suitable for silk material
3means:3gear–suitableforbrematerial
4 means: 4 gear – suitable for nylon material
5 means: 5 gear – suitable for polyester material
6 means: 6 gear – suitable for suede material
7 means: 7 gear – suitable for wool material
8 means: 8 gear – suitable for fabric material
9 means: 9 gear – suitable for linen material
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
PARTS AND ACCESSORIES

6
Fig. 4
A
fasten
fasten
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
INSTALLATION
Step 1 Install Telescopic Rods and Rook
1. Put the main body on the ground.
2. Loosentheclipinthesideofthemainbody,insertthetelescopicrodsintothe
groove and buckle closely (Fig. 4-D).
3. Theheightofrodsisadjustable:loosentheclip,adjustittothehighestposition
and buckle closely (Fig. 4-C).
4. Put the transverse bar into the telescopic rods. It’s well installed when you heard
a cracking sound (Fig. 4-A).
5. Insertthehooksinthetopofthetransversebar(thehookscan360°moveand
adjust the angle (Fig. 4-B).

7
Fig. 5
Fig. 6
Fig. 6
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
Step 2 Install the steam hose
1. Insertthehoseintothehole,rotateandtightenit.(Fig.5-1)
2. Put sprinkler on the hook. (Fig. 5-2)
Step 3 Install the brush/pant hook
Install integrated fabric brush or bottom bracket as following if needed:
1. Suit the fabric brush or bottom bracket on sprinkler (Fig. 6-1 and 6-2).
2. Use Demonstration
A. Iftheclotheshaswinkleorwithdust,canusefabricbrush.Donotbrushsoft
cloth,suchassilkorsatin(Fig.6-3).
B. Fixthepantsonthetransversebar,putthetrouserscreaseinthemiddleof
brush and sprinkler (Fig. 6-4).
C. Ironslowlyandpatientlywithonehandandtheotherstraightenedthepants,
so come out the crease.

8
Fig. 7
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
OPERATION
Step 1 Methods of filling up
1. Put the machine on the ground; take out the water tank (Fig. 7-1).
2. Unscrewthecaptollthetankwithwater(Fig.7-2and7-3).
3. Tightenthecapafterlledwithwater(Fig.7-4).
4. Putthefullwatertankontothemachine,anditsoutletshouldaimattheright
position.
NOTICE:1. Donotturnonthepowerbeforellingwithwater.
  2. Pleasecheckthebottomdrainwellclosedbeforerstuse.
Step 2 Start
1. Make sure the machine is power on.
2. Press the “ ”onthescreen,soturnonthelight.
3. Themachinestarttowork,steamingwillcomeoutwithin45s.
4. Press the “ ”onthescreenafterironing,andthenpulltheplug.

9
Fig. 8. Standby mode
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
Step 3 Notice for use
1. Power on:
The power light will flash and heard a sound of “bee” when plug in the product.
The screen will not light; meanwhile the machine is on standby mode.
2. Standby mode:
Press the “ ”onthescreen,heardasoundof“bee”,thepowerlight,mode
lightandgearlightturnon.Whenthewatertankisoutofwater,the“ ”
flashes,andthemachineisonstandbymode,willnotheatup.Thebuzzersounds
every5s,intotal10times.
— Defaultmode:ironingmode,withgear9.
— Press “MODE”, to choose “ ” , “ ” and “ ” circularly and
thecorrespondinglightturnon;Whenunder“IRONING”mode,thegearcanbe
selectedfrom1to9totdifferentuse.Whenunder“HEATING”mode,thegear
cannotbeselected,onlywithsounds“bee”.
— After3minshortageofwater,themachinewillauto-offandreturnstothepower
on mode.
3. Working mode.
A. When the machine turn on to the ‘IRONING’ mode and water tank has water
inside, the “ ” mark will keep lighting, the machine will automatically
the biggest power by default to heat up. When the “ ” lighting, only
thenumber of9 canbe lighted,when the‘Auto’lighting,the markof heatup
“
oooooooooo ” will on the loop.
B. Press key “ ” can change the power selection, and the mark of power
selectionwilllighting,themarkofheatup“
oooooooooo ” will on the loop in
quickly.
C. Chose the ‘HUMIDIFY’mode “ ”,themarkof“
oooooooooo ” will on the
loopinslowly,themachinewillHumidifyingwith300watts.
D. chose the ‘cleaning’ mode “ ” the mark of “
oooooooooo ” will on the
loopinslowly,themachinewillworkingwiththe1750W;
— inthismode,it’sshouldbehavesomewaterinwatertank,andaccordingtothe
1:1 rate to mix the white vinegar or the decontamination agent.

10
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
— Afterchosethe ‘cleaning’mode,the machinewillauto heat uptoreleasethe
steaming,afterMixtureinthewatertankonlyhavehalf,themachinewillauto
shut off.
— Pulloutthepowerline,after30min,pleasemakessurethatthemixtureinthe
water tank is poured out.
— Whenthemachinecontinueworkingover200hours,the“ ”willtwinkle,
its means the machine remind you need to clean the dirt in the machine. Push
the “ ” can cancel the cleaning remind.
IRONING HUMIDIFY DESCALING
Fig. 9
E. Shortage of water:
— The sign “ ” will flash to warn the shortage of water no matter in IRONING
MODEorHUMIDIFYMODE.Themachinewillremainapowerbetween100and
120Wtokeepwarm.Thebuzzersoundsevery5s,intotal10times.Ifaddwater
within1min,thelightof“ ” will turn off and continues working. If not add
waterin5min,themachinewillpoweroff.
Water shortage Water shortage Standby mode
in IRONING in HUMIDIFY
Fig. 10
4. Timer function:
Press the “ ”andthetimewillshowinthescreen,andwillbeonstandby
mode automatically after 5s. The operation time at mode “HUMIDIFY” and
“IRONING” can be adjust from 1 to 99 mins and auto-off for over time. Press the
bottomanothertime willcancelthe timerfunction,and returntotheworking
mode of last use.

11
Fig. 12
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
IRONING METHODS
– Leave the steam away to people.
– Don’ttouchsprinklerholeswhenthemachineworkslongtime,keep20cmaway
with body.
– Hosewillbegettinghotter,it’snormalduringironing.
– Easier removal for the fabric with less wrinkles.
– Level the fabric before starting.
– Fixthehangerorhookbeforeironingatowel,handkerchieforothersoftmaterial.
– Ironing repeatedly for thick fabric.
1. The key point of ironing: hold the bottom of the cloth with one hand and pull
downwithalittlestress,payattentiontomakethesurfaceflat,usingtheother
hand to press the cloth with steaming sprinkler. The winkle will be removed
immediately (Fig. 12-1 and 12-2).
2. Move the sprinkler upwards from the bottom of the pocket.
3. Whenironingthesleeves,straightenedandirondownwardsfromitstop.
4. It may take a longer time when ironing the collar. Please keep ironing up and
down with might.
5. Whenironingclothesedge,holdononecorner,straightened,andmoveupwards
the sprinkler.
NOTICE: Watch out from burning when ironing clothes edge.
IRONING TIMER Fig. 11 HUMIDIFY TIMER

12
Fig. 13
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
DRAIN THE WATER RESERVOIR
AND MACHINE STORE
1. Power off. It’s normal for steaming after power off for a short while.
2. Unplug from the outlet.
3. Coolingdownthemachinefor30minutesatleast.
4. Open the water reservoir cover and drain the water in the tank. (Fig. 13-1)
5. Loose the down locknut, take out the rods. Flexible rods length is easy for
storing up.
6. Loosethesteamhosefrontend,takeoutthehose.
7. Empty the rest water in the steam generator. (Fig. 13-2)
8. Stow the machine in safe and dry position.
Notice: clear and drain the water reservoir and steam generator twice a month.
Inordertoassuringsafeoperation,pleasecleanthemachineandkeepit
dry after using.

13
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
FAULT DIAGNOSIS
Inthispage,wehaveconcludedallproblemsprobablyhappened;pleasecheckthe
machine according to the information below (Tab. 1). If you can’t solve the problem
byyourself,pleasecontactwiththelocaldistributor.
Tab. 1
PROBLEM REASON SOLUTION
Fail to heat No power supply
Switch off
Cord loosen
Components broken
Connect power supply
Switch on
Check it out and fasten it
Replace components
No steam Lack of water Switchitoff,injectwater
Sprinkler drips water Condensation in the pipe
Sprinkler broken
Liftthesprinkler,
let the drips flow back to
the storage
Replace the sprinkler
Steampipebuzzes Pipe curls
Sprinkler is lower than
horizon
Straighten the pipe
Lift the sprinkler
Light problem Blow a fuse
Poor contact
Replace fuse
Check the plug and outlet
Intermittent steaming Has sediments Clear as this instruction

14
Fig. 14
Power panel
Heater
Low water level detector
Temperature
controler
Fuse
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
CIRCUIT DIAGRAM
MODELS & SPECIFICATIONS
You may nd the related product specications on the actual merchandise for
the model which is not included in this user’s manual.
Tab. 2
Model Voltage Frequence Power Storage Steam Output
TurboVapor
1950X 220-240V~ 50/60Hz 1750W 2L 40g/min
Main machine...........1Set
Rod ............................2Set
Sprinkler....................1Set
Brush.........................1Set
Hook..........................2Set
Instruction ................1Set
Transverse ban.........1Set
Packing List

15
Instruction
VERTICAL FABRIC STEAMER
TurboVapor 1950X
WARRANTY AND SERVICE
Guarantee Card
PURCHASING DATE: Y M D
CLIENT
NAME/WORK PLACE
PHONE
ADDRESS
MACHINE NO.
PURCHASING CITY
E-MAIL
RECORD
Please contact the distributor if more service or other information requested.
Warranty is only for the normal usage in warrantee time limit on the basis of the
buying receipt and warranty card. The terms and conditions above are not with
warranty:
1. Damage caused by the repairman not related to the warranty responsibility.
2. Man-made damage caused.
3. Damage caused by impropriate usage and maintenance.
4. Damage caused by fall-down, compression, immersion or other personal
mistake.
5. Damagecausedbyforcemajeuresuchasflood,re,etc.
6. Accident damage by purchaser.
7. Warrantycardisdemandedtoshownwhenrepairing,pleasekeepitwellwithout
anymodication.

Printed in Taiwan
www.effektiv.ie
TurboVapor
1950X
