EGO HT2400E User manual

WARNING: To reduce the risk of injury, the user must read and understand the
Operator’s Manual before using this product. Save these instructions for future reference.
OPERATOR’S MANUA
56 VOLT
LITHIUM-ION
CORDLESS
HEDGE TRIMMER
MODEL NUMBER HT2400E
NL Nederlands p. 185
PT Português p. 125
ES Español p. 93
IT Italiano p. 155
FR Français p. 63
DE Deutsch S. 31
14-1211_HT2400E EGO 56V Hedge Trimmer_manual_EU_7 lauguage_V0

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E2 3
EN EN
TABLE OF CONTENTS
Read All Instructions ......................................3
Safety Symbols ..........................................4
Safety Instructions.....................................5-12
Introduction ............................................13
Specications .......................................13-14
Assembly..............................................14
Packing List ............................................15
Description .........................................15-16
Operation...........................................17-22
Maintenance ........................................23-25
EC Declaration of Conformity...............................26
Troubleshooting......................................27-28
Warranty ..............................................29
Parts List ..............................................30
READ ALL INSTRUCTIONS!
This Hedge Trimmer has many features for making its use more pleasant and
enjoyable. Safety, performance, and dependability have been given top priority in the
design of this product making it easy to maintain and operate.
DANGER! People with electronic devices, such as pacemakers, should consult
their physician(s) before using this product. Operation of electrical equipment in close
proximity to a heart pacemaker could cause interference or failure of the pacemaker.
WARNING: To ensure safety and reliability, all repairs and replacements should
be performed by a qualied service technician.

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E4 5
EN EN
SAFETY SYMBOLS
The purpose of safety symbols is to attract your attention to possible dangers. The
safety symbols and the explanations with them deserve your careful attention and
understanding. The symbol warnings do not, by themselves, eliminate any danger.
The instructions and warnings they give are no substitutes for proper accident
prevention measures.
WARNING: Be sure to read and understand all safety instructions in this
Operator’s Manual, including all safety alert symbols such as “DANGER,” “WARNING,”
and “CAUTION” before using this tool. Failure to follow all instructions listed below may
result in electric shock, re, and/or serious personal injury.
SYMBOL MEANING
SAFETY ALERT SYMBOL: Indicates DANGER,WARNING, OR CAUTION.
May be used in conjunction with other symbols or pictographs.
WARNING! The operation of any power tools can result in
foreign objects being thrown into your eyes, which can result in
severe eye damage. Before beginning power tool operation, always
wear safety goggles or safety glasses with side shields and a full face
shield when needed. We recommend a Wide Vision Safety Mask for
use over eyeglasses or standard safety glasses with side shields.
SAFETY INSTRUCTIONS
This page depicts and describes safety symbols that may appear on this product. Read,
understand, and follow all instructions on the machine before attempting to assemble
and operate.
Safety Alert Indicates a potential personal injury hazard.
Read the Operator’s
Manual
To reduce the risk of injury, user must read
operator’s manual.
Do not expose to
rain
WARNING: Do not use in the rain or leave
outdoors while it is raining.
61cm Blade length The length of the blade
Ø 22mm Cutting capacity Max. Cutting capacity of the blade
V Volt Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
WWatt Power
min Minutes Time

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E6 7
EN EN
Alternating Current Type of current
Direct Current Type or a characteristic of current
n0No-Load Speed Rotational speed, at no load
... /min Per Minute Revolutions per minute
SPM Strokes Per Minute Stroke speed, at no load
GENERAL POWER TOOL SAFETY WARNINGS
WARNING: Read all safety warnings and instructions. Fail to follow the
warnings and instructions may result in electric shock, re and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power
tool or battery-operated (cordless) power tool.
WORK AREA SAFETY
 Keep work area clean and well lit. Cluttered or dark areas invite accidents.
 Do not operate power tools in explosive atmospheres, such as in the presence
of ammable liquids, gases or dust. Power tools create sparks which may ignite
the dust or fumes.
 Keep children and bystanders away while operating a power tool. Distractions
can cause you to lose control.
ELECTRICAL SAFETY
 Power tool plugs must match the outlet. Never modify the plug in any way. Do
not use any adapter plugs with earthed (grounded) power tools. Unmodied
plugs and matching outlets will reduce risk of electric shock.
 Avoid body contact with earthed or grounded surfaces, such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric shock if
your body is earthed or grounded.
 Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
 Do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. Keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
 When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
 If operating a power tool in a damp location is unavoidable, use a residual current
device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E8 9
EN EN
PERSONAL SAFETY
 Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the inuence
of drugs, alcohol or medication. A moment of inattention while operating power
tools may result in serious personal injury.
 Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce personal injuries.
 Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the
tool. Carrying power tools with your nger on the switch or energizing power
tools that have the switch on invites accidents.
 Remove any adjusting key or wrench before turning the power tool on. A
wrench or a key left attached to a rotating part of the power tool may result in
personal injury.
 Do not overreach. Keep proper footing and balance at all times. This enables
better control of the power tool in unexpected situations.
 Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry or long hair can be
caught in moving parts.
 If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust devices
can reduce dust-related hazards.
POWER TOOL USE AND CARE
 Do not force the power tool. Use the correct power tool for your application.
The correct power tool will do the job better and more safely at the rate for
which it was designed.
 Do not use the power tool if the switch does not turn it on and off. Any power
tool that cannot be controlled with the switch is dangerous and must be repaired.
 Disconnect the plug from the power source and/or the battery pack from the
power tool before making any adjustments, changing accessories, or storing
power tools. Such preventive safety measures reduce the risk of starting the
power tool accidentally.
 Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
 Maintain power tools. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tools
operation. If damaged, have the power tool repaired before use. Many
accidents are caused by poorly maintained power tools.
 Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are easier to control;
 Use the power tool, accessories, tool bits, etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended
could result in a hazardous situation.

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E10 11
EN EN
BATTERY TOOL USE AND CARE
Recharge only with the charger specied by the manufacturer. A charger that
is suitable for one type of battery pack may create a risk of re when used with
another battery pack.
Use power tools only with specically designated battery packs. Use of any
other battery packs may create a risk of injury and re.
When battery pack is not in use, keep it away from other metal objects, like
paper clips, coins, keys, nails, screws or other small metal objects that can
make a connection from one terminal to another. Shorting the battery terminals
together may cause burns or a re.
Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, ush with water. If liquid contact
eyes, additionally seek medical help. Liquid ejected from the battery may cause
irritation or burns.
SERVICE
Have your power tool serviced by a qualied repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
HEDGE TRIMMER SAFETY WARNINGS
Keep all parts of the body away from the cutter blade. Do not remove cut
material or hold material to be cut when blades are moving. Make sure the
switch is off when clearing jammed material.
A moment of inattention while operating the hedge trimmer may result in serious
personal injury.
Carry the hedge trimmer by the handle with the cutter blade stopped. When
transporting or storing the hedge trimmer always t the cutting device cover.
Proper handling of the hedge trimmer will reduce possible personal injury from
the cutter blades.
Hold the power tool by insulated gripping surfaces only, because the cutter blade
may contact hidden wiring. Cutter blades contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the operator an electric shock.
Keep cable away from cutting area. During operation the cable may be hidden in
shrubs and can be accidentally cut by the blade.
Check the hedge for foreign objects before operating, e.g. wire fences.
Only use the hedge trimmer with the guard properly assembled. The use of the
hedge trimmer without the proper guard may result in serious personal injury!
Use both hands when operating the hedge trimmer. Using one hand could
cause loss of control and result in serious personal injury.
WARNING: Check the hedge for foreign objects before operating, e.g. wire
fences Only use the hedge trimmer with the guard properly assembled. The use of
the hedge trimmer without the proper guard may result in serious personal injury!
IMPORTANT SAFETY INSTRUCTIONS
Do not use the battery-operated hedge trimmer in rain.
Do not charge the battery pack in rain or in wet locations.
Use only with the battery packs and chargers listed below:
BATTERY CHARGER
BA2240E, BA1120E, BA3360 CH5500E, CH2100E
Do not grasp the exposed cutting blades or cutting edges when picking up or
holding the hedge trimmer.
Do not use on a ladder, rooftop, tree, or other unstable support. Stable footing on a
solid surface enables better control of the hedge trimmer in unexpected situations.
Never allow children to operate the hedge trimmer.
Never remove or tamper with safety devices. Check their proper operation
regularly. Never do anything to interfere with the intended function of a safety
device or to reduce the protection provided by a safety device.
Never operate the hedge trimmer without proper guards, plates, or other safety
protective devices in place.

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E12 13
EN EN
Check damaged parts before further use of the hedge trimmer. A guard or other
part that is damaged should be carefully checked to determine that it will operate
properly and perform its intended function. Check for alignment of moving parts,
binding of moving parts, breakage of parts, mounting, and any other condition that
may affect its operation. A guard or other part that is damaged should be properly
repaired or replaced by an authorized service center unless indicated elsewhere
in this manual.
Check the blade and motor mounting bolts at frequent intervals for proper
tightness. Also, visually inspect blade for damage (e.g., bent, cracked, and worn).
Replace the blade only with a blade from EGOTM.
Replace the blade if it is bent or cracked. An unbalanced blade causes vibration
that could damage the motor drive unit or cause personal injury.
If the equipment should start to vibrate abnormally, stop the motor and check
immediately for the cause. Vibration is generally a warning of trouble.
The trimmer shall be used to cut stems less than (22mm) thick.
Trim only in daylight or in good articial light.
Remove or disconnect battery before servicing, cleaning, or removing material
from the hedge trimmer.
Do not wash with a hose; avoid getting water in motor and electrical connections.
When servicing use only identical replacement parts listed in this manual. Use
of parts which do not meet the original equipment specications may lead to
improper performance and compromised safety.
Follow instructions for lubricating and changing accessories.
Keep handles dry, clean and free from oil and grease.
Save these instructions. Refer to them frequently and use them to instruct others
who may use this tool. If you loan this tool to someone else, also loan these
instructions to them to prevent misuse of the product and possible injury.
SAVE THESE INSTRUCTIONS!
INTRODUCTION
Congratulations on your selection of a new generation of 56V Lithium-ion powered
hedge trimmer. It has been designed, engineered and manufactured to give you the
best possible dependability and performance.
Should you experience any problem you cannot easily remedy, please visit the website
egopowerplus.com and select “contact us” or contact the store where you purchased
the item.
This manual contains important information on to the safe assembly, operation and
maintenance of your hedge trimmer. Read it carefully before using the hedge trimmer.
Keep this manual handy so you can refer to it at any time.
SERIAL NUMBER _____________________ DATE OF PURCHASE _________________
YOU SHOULD RECORD BOTH SERIAL NUMBER AND DATE OF PURCHASE AND KEEP IN A SAFE
PLACE FOR FUTURE REFERENCE
SPECIFICATIONS
Voltage 56 V
No-Load Speed 1300 /min
Blade Length 61 cm
Cutting capacity 22 mm
Weight (Without battery pack, blade guard) 2.79 kg
Measured sound power level LWA 94 dB(A)
Sound pressure level at operator’s position LPA 83 dB(A) KPA=2.5 dB(A)
Guaranteed sound power level LWA
(measured according to 2000/14/EC) 94 dB(A)
Vibration ah
Rear handle 1.119 m/s2K=1.5 m/s2
Front handle 1.761 m/s2K=1.5 m/s2
The declared vibration total value has been measured in accordance with a
standard test method and may be used for comparing one tool with another;

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E14 15
EN EN
The declared vibration total value may also be used in a preliminary assessment
of exposure.
NOTICE: The vibration emission during actual use of the power tool can differ from the
declared value in which the tool is used; In order to protect the operator, user should
wear gloves and ear protectors in the actual conditions of use.
ASSEMBLY
WARNING: If any parts are damaged or missing do not operate this product until
the parts are replaced. Use of this product with damaged or missing parts could result
in serious personal injury.
WARNING: Do not attempt to modify this product or create accessories not
recommended for use with this hedge trimmer. Any such alteration or modication is misuse
and could result in a hazardous condition leading to possible serious personal injury.
WARNING: To prevent accidental starting that could cause serious personal
injury, always remove the battery pack from the tool when assembling parts.
UNPACKING
This product has been shipped completely assembled.
Carefully remove the product and any accessories from the box. Make sure that
all items listed in the packing list are included.
 Inspect the tool carefully to make sure no breakage or damage occurred during shipping.
Do not discard the packing material until you have carefully inspected and
satisfactorily operated the tool.
 If any parts are damaged or missing, please return the product to the place of purchase.
PACKING LIST
PART NAME QUANTITY
Hedge Trimmer 1
Blade Guard 1
Operator’s manual 1
DESCRIPTION
KNOW YOUR HEDGE TRIMMER (Fig. 1)
WARNING: The safe use of this product requires an understanding of the
information on the tool and in this operator’s manual, as well as knowledge of the
project you are attempting. Before use of this product, familiarize yourself with all
operating features and safety rules.
Hand Guard
Helps protect hand from cutting and deect chips or other debris away from the
operator’s hands.
1
Blade
Blade Guard
Hand Guard
Front Handle
Front
Switch
Lever
Rear Handle
Battery-Release
Button
Electric
Contacts
Latch
Ejection Mechanism
Rear Switch
Lever
Mounting Slot
Tip Protector

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E16 17
EN EN
Front Handle
For easy control of the tool during cutting work.
Rear Handle
Ergonomic handle with overmold improves comfort and grip.
Front Switch Lever/Rear Switch Lever
The hedge trimmer can be started only if both of the switch levers (in rear and
front of the handle) are depressed simultaneously.
Blades
Steel blades for cutting hedges and shrubs.
Blade Guard
The blade guard keeps the operator from coming in contact with the sharp blades
when the tool is not in use. It also helps keep the blades from being nicked or
damaged when the tool is in storage.
Tip protector
Protecting the blade and protecting the special cutters from damage when cutting near
the ground or along walls.
Battery Release Button
Press to release the battery pack from the tool.
Latch
Locks the battery pack in place when installed on the tool.
Ejection Mechanism
Aids in removing the battery.
Mounting Slot
Guides the battery pack.
OPERATION
WARNING: Do not allow familiarity with this product to make you careless.
Remember that a careless fraction of a second is sufcient to inict serious injury.
WARNING: Always wear eye protection with side shields, along with hearing
protection. Failure to do so could result in objects being thrown into your eyes and other
possible serious injuries.
WARNING: Do not use any attachments or accessories not recommended by
EGOTM. The use of attachments or accessories not recommended can result in serious
personal injury.
Before each use, inspect the entire product for damaged, missing, or loose parts, such
as screws, nuts, bolts, caps, etc. Tighten securely all fasteners and caps and do not
operate this product until all missing or damaged parts are replaced.
APPLICATION
You may use this product for the purposes listed below:
Trimming and the forming of hedges, shrubs, and bushes with a branch diameter
of less than 22mm

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E18 19
EN EN
TO INSTALL/REMOVE BATTERY PACK (Fig. 2 & 3)
WARNING: Always remove the battery pack from the product when you are
assembling parts, making adjustments, cleaning, or when not in use. Removing the
battery pack will prevent accidental starting that could cause serious personal injury.
NOTE: Fully charge the battery pack before rst use.
TO INSTALL (Fig. 2)
Align the ribs of the battery pack
with the mounting slots in the hedge
trimmer’s battery port.
Press the battery pack down until it
snaps into position.
NOTE: Make sure that the latch on the
hedge trimmer snaps into place and the
battery pack is secured to the tool before
beginning operation.
TO REMOVE (Fig. 3)
WARNING: Always be aware for
the location of your feet, children, or pets
when pressing the battery-release button.
Serious injury could result if the battery
pack falls. NEVER remove the battery
pack at a high location.
Press the battery-release button,
the battery pack will disengage
from the latch.
Grasp the battery pack and remove it from the hedge trimmer.
HOLDING THE HEDGE TRIMMER
The unit has both a front and rear handle.
With the blade directed away from you,
hold the unit by both handles.
The front switch can be activated on
any of the three sides, giving you
many choices for a comfortable grip
when performing cutting operations
(Fig. 4, 5 & 6).
WARNING: Always keep both
hands on the hedge trimmer handles.
Never hold shrubs with one hand and
operate the hedge trimmer with the other.
Failure to heed this warning may result in
serious injury.
STARTING/STOPPING
THE HEDGE TRIMMER
Before starting the hedge trimmer:
Make sure you have a secure and
balance footing.
Stand upright and hold the hedge
trimmer in a relaxed position.
Remove the blade guard.
Make sure the cutting blade is not
touching the ground or any other objects.
Hold the unit with both hands: one hand on the rear handle and one hand on the
front handle.
2
Press to Release
3
4
5
6

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E20 21
EN EN
Before starting the hedge trimmer, maintain proper footing and balance and do
not overreach. Wear safety goggles, non-skid footwear and rubber gloves. Hold
the unit with both hands with the cutting blades directed away from you. Always
use the hedge trimmer properly.
Keep from trimming too much at one time. This can cause the blades to bind and
slow, reducing the cutting efciency.
Do not force the hedge trimmer through heavy shrubbery. This can cause the
blades to bind and slow down. If the blades slow down, reduce the pace of
your work.
When trimming new growth, use a wide sweeping action, so that the stems are
fed directly into the cutting blade. Older growth will have thicker stems and will
be trimmed most easily by using a sawing movement.
Always cut stems or twigs that are less than 22mm. thick. Use a non-powered
hand saw or pruning saw to trim large stems.
TOP CUTTING
Use a wide sweeping motion (see Fig. 7).
A slight downward tilt of the cutting
blades in the direction of motion gives
the best cutting results. If desired, you
can use a string to help guide you as you
cut your hedge level. Decide how high you
want the hedge. Then, stretch a piece of
string along the hedge at this height. Trim
the hedge just above this guide line.
TO START THE HEDGE TRIMMER
Your hedge trimmer is equipped with two switch levers. Both switch levers need to be
pressed for the hedge trimmer to start. Depress and hold the switch lever in the front
handle and press the switch lever in the rear handle to start the hedge trimmer.
TO STOP THE HEDGE TRIMMER
Move hedge trimmer away from cutting area, release one of the switch levers to stop
the hedge trimmer.
WARNING: Always remove the battery pack from the hedge trimmer during
work breaks and after nishing work.
USING THE HEDGE TRIMMER
WARNING: If the blade jams on any electrical cord or line, DO NOT TOUCH THE
BLADE! IT CAN BECOME ELECTRICALLY LIVE AND VERY DANGEROUS. Continue to hold
the hedge trimmer by the insulated rear handle or lay it down and away from you in
a safe manner. Disconnect the electrical service to the damaged line or cord before
attempting to free the blade from the line or cord. Failure to heed this warning will
result in serious personal injury or possible death.
WARNING: If any parts are missing, damaged or broken, do not operate your
trimmer until they have been replaced. Failure to do so could result in possibly serious
personal injury.
WARNING: To prevent serious personal injury, always use both the front handle
and the rear handle to hold the hedge trimmer during operation.
WARNING: To prevent serious personal injury, keep hands away from blades.
Do not attempt to remove cut material or hold material to be cut when the blades
are moving. Make sure that the blades have totally stopped and the battery pack is
removed before clearing jammed material from blades. Do not grasp the exposed
cutting blades or cutting edges when picking up or holding the unit.
WARNING: Clear the area to be cut before each use. Remove all objects, such
as cords, lights, wire, or string which can become entangled in the cutting blade and
create a risk of serious personal injury.
7

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E22 23
EN EN
SIDE CUTTING
When trimming the sides of the hedge, begin at the bottom and cut upwards
(see Fig. 8). Trim the side of a hedge so that it will be slight narrower at the top.
This shape will expose more of the hedge, resulting in a more uniform growth.
SAWING FUNCTION
Although the blade gap allow wood to be
cut up to Ø 22mm, the tip of the blade is
designed to cut wood up to Ø 26mm
(see Fig. 9). If a radical cut is necessary,
cut a little at a time in several stages.
TIP PROTECTOR
The tip protector makes cutting near
the ground or along walls easier while
protecting the special cutters from damage.
MAINTENANCE
WARNING: When servicing, use only identical replacement parts. Use of any
other parts may create a hazard or cause product damage. To ensure safety and
reliability, all repairs should be performed by a qualied service technician.
CLEANING
WARNING: To avoid serious personal injury, always remove the battery pack
from the product when cleaning or performing any maintenance.
Use a soft brush to remove debris from all air intakes and cutting blade.
To remove pitch and other sticky residue, spray the blades with resin solvent.
Run the motor briey so that the solvent is event distributed.
Wipe the surface with a dry cloth.
WARNING: Never use water for cleaning your trimmer. Avoid using solvents
when cleaning plastic parts. Most plastics are susceptible to damage from various
types of commercial solvents. Use clean clothes to remove dirt, dust, oil, grease, etc.
SHARPENING THE CUTTING BLADE
1. Start and stop your hedge trimmer
until the cutter blade and the guard
are slightly offset (Fig.10). This will
allow clearance for the le between
cutter teeth and guard teeth.
2. Remove the battery pack from you
hedge trimmer.
3. Clamp the blade assembly in a vise
and le the exposed cutting surface
of each blade tooth. Remove as
little material as possible. Be sure to
retain the original angle of each tooth when ling.
4. Remove the hedge trimmer from the vise; restart it and stop it to expose the
unsharpened edges of the blade teeth.
5. Remove the battery pack and repeat the sharpening procedure above.
8
Ø 22 mm
Ø 26 mm
910
Guard Tooth
Cutter Tooth

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E24 25
EN EN
NOTE: Do not operate your hedge trimmer with dull or damaged cutting blades.
This may cause overload and will give unsatisfactory cutting results.
LUBRICATING THE BLADE (Fig. 11)
For best operation and longer blade life,
lubricate the hedge trimmer blade with
light weight machine oil before and after
each use.
1. Remove the battery pack from the
hedge trimmer.
2. Lay the hedge trimmer on a at
surface. Apply a light weight
machine oil along the edge of the
top blade. If you will be using the hedge trimmer for an extended period, it is
advisable to stop, remove the battery, and oil the blade during use.
NOTE: Do not oil while the hedge trimmer is running.
TRANSPORTING AND STORING
Always place the blade guard on the blade before storing or transporting the
hedge trimmer. Use caution to avoid the sharp teeth of the blade.
Clean the hedge trimmer thoroughly before storing.
Store the hedge trimmer indoors, in a dry place that is inaccessible to children.
Keep away from corrosive agents such as garden chemicals and deicing salts.
WARNING: Blades are sharp. When handling the blade assembly, wear
non-slip, heavy-duty protective gloves. Do not place your hand or ngers between
blades or in any position where they could get pinched or cut. NEVER touch blades
or service the unit with battery pack installed.
Protecting the environment
Do not dispose of electrical equipment, battery charger and batteries/
rechargeable batteries into household waste!
According to the European law 2012/19/EU, electrical and electronic
equipment that is no longer usable,and according to the European law
2006/66/EC, defective or used battery packs/batteries, must be collected
separately.
If electrical appliances are disposed of in landlls or dumps, hazardous
substances can leak into the groundwater and get into the food chain,
damaging your health and well-being.
11

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E26 27
EN EN
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Hedge trimmer doesn’t
work.
 The battery pack is not
attached to the hedge
trimmer.
 Attach the battery pack to the
hedge trimmer.
 No electrical contact between
the trimmer and battery
 Remove battery, check
contacts and reinstall the
battery pack.
 The battery pack is depleted.  Charge the battery pack.
 The battery pack is too hot.  Remove the battery pack from
the tool and allow it to cool
until the temperature drops
below 67°C.
 The hedge trimmer is too hot. Release both switch levers;
allow the trimmer to cool until
the temperature drops below
77°C.
 The two switch levers are not
depressed simultaneously.
 Depress the switch levers
on the front and rear handle
simultaneously.
 The blade is jammed.  Remove the battery pack
from the tool, remove the
obstruction carefully, then
reinsert the battery and restart
the tool.
EC DECLARATION OF CONFORMITY
We, CHERVON EUROPE LTD.
47 CASTLE STREET, READING, RG1 7SR, UNITED KINGDOM
Declare that the product 56V lithium-ion cordless hedge trimmer HT2400E,
Complies with the essential health and safety requirements of the following Directives:
2006/42/EC, 2006/95/EC, 2004/108/EC, 2011/65/EU, 2000/14/EC
Standards and technical specications referred to:
EN 60745-1, EN 60745-2-15, EN 55014-1, EN 55014-2
Measured Sound Power Level: 94dB(A), Guaranteed Sound Power Level: 94dB(A)
The conformity assessment followed was according to Annex V of the Directive
Peter Melrose Dong Jianxun
Vice President Of Chervon Europe Quality Manager Of Chervon
20/12/2014

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E 56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E28 29
EN EN
Excessive vibration or
noise.
 Dry or corroded blades.  Lubricate the blades,
following the section
“LUBRICATING THE BLADE”
found on page 24 in this
manual.
 Blades or blade support is
bent.
 Replace with a new blade or
support. Contact EGO service
center for blade or support
replacement service, found on
page 29.
 Bent or damaged teeth.  Replace with a new blade.
Contact EGO service center for
blade replacement
service, found on page 29.
 Loose blade bolts.  Tighten the blade bolts.
Using a wrench, turn the bolt
clockwise to tighten.
WARRANTY
EGO WARRANTY POLICY
Please visit the website egopowerplus.com for full terms and conditions of the EGO
Warranty policy.

56V LITHIUM-ION CORDLESS HEDGE TRIMMER — HT2400E30
EN
WARNUNG: Um das Verletzungsrisiko zu verringern, muss der Benutzer die
Bedienungsanleitung vor der Verwendung des Gerätes gelesen und verstanden haben.
Heben Sie diese Anleitung zum späteren Nachschlagen auf!
GEBRAUCHSANWEISUNG
56 VOLT LITHIUM-IONEN
KABELLOSE HECKESCHERE
MODELLNUMMER HT2400E
PARTS LIST
56V LITHIUM-ION CORDLESS HEDGE TRIMMER
MODEL NUMBER HT2400E
The Model Number will be found on the Nameplate attached to the housing of the
hedge trimmer. Always mention the Model Number when ordering parts for this tool.
EXPLODED VIEW
1
2
3
PARTS LIST
INDEX NUMBER PART NO. DESCRIPTION QTY
1 3124359000 Blade Guard 1
2 2824143000 Nut and Washer Set (for blade) 8
3 2823057000 Guard and Screw Set 1

56 VOLT LITHIUM-IONEN KABELLOSE HECKESCHERE — HT2400E 56 VOLT LITHIUM-IONEN KABELLOSE HECKESCHERE — HT2400E 3332
DE DE
INHALTSVERZEICHNIS
Lesen Sie alle Anweisungen!...............................33
Sicherheitssymbole ......................................34
Sicherheitshinweise ..................................35-43
Einleitung..............................................44
Technische daten.....................................44-45
Montage...............................................45
Packliste ..............................................46
Beschreibung........................................46-47
Bedienung ..........................................48-53
Wartung............................................54-56
EG-Konformitätserklärung.................................57
Fehlerbehebung......................................58-59
Garantie ...............................................60
Teileliste ..............................................61
LESEN SIE ALLE ANWEISUNGEN!
LESEN UND BEACHTEN SIE DIE
BEDIENUNGSANLEITUNG
Diese Heckenschere hat viele Eigenschaften, die ihre Verwendung angenehmer und
erfreulicher machen. Der Sicherheit, der Leistungsfähigkeit und der Zuverlässigkeit
wurden bei der Konstruktion dieses Produktes höchste Prioritäten gegeben, wodurch es
einfach ist, die Heckenschere zu bedienen und zu warten.
VORSICHT! Menschen mit elektronischen Geräten, wie z. B. Herzschrittmachern,
sollten ihren Arzt konsultieren, bevor sie diese Heckenschere verwenden. Die
Bedienung von Elektrogeräten in unmittelbarer Nähe zu Herzschrittmachern kann zu
Interferenzen und Störungen des Schrittmachers führen.
WARNUNG: Um die Sicherheit und Zuverlässigkeit zu gewährleisten, sollten
alle Reparaturen und der Austausch von Teilen nur von qualizierten Servicetechnikern
durchgeführt werden.

56 VOLT LITHIUM-IONEN KABELLOSE HECKESCHERE — HT2400E 56 VOLT LITHIUM-IONEN KABELLOSE HECKESCHERE — HT2400E 3534
DE DE
SICHERHEITSSYMBOLE
Der Zweck von Sicherheitssymbolen besteht darin, Ihre Aufmerksamkeit auf mögliche
Gefahren zu lenken. Die Sicherheitssymbole und deren Erklärungen verdienen Ihre
vollste Aufmerksamkeit und ihr Verständnis. Die Warnsymbole beseitigen nicht von sich
aus die Gefahren. Ihre Anweisungen und Warnungen sind kein Ersatz für angemessene
Unfallverhütungsmaßnahmen.
WARNUNG: Achten Sie darauf, dass Sie, bevor Sie das Gerät benutzen, alle
Sicherheitsanweisungen dieser Bedienungsanleitung gelesen und verstanden haben,
einschließlich aller Gefahrenzeichen wie „VORSICHT“, „WARNUNG“und
„ACHTUNG“. Die Nichtbeachtung der unten angeführten Anweisungen kann zu
Stromschlägen, Feuer und/oder schweren Verletzungen führen.
SYMBOLBEDEUTUNG
SYMBOL FÜR SICHERHEITSWARNUNGEN: Weist auf GEFAHR,
WARNUNG oder VORSICHT hin. Kann zusammen mit anderen Symbolen oder Bildern
verwendet werden.
WARNUNG! Die Bedienung von Akku Geräten kann dazu
führen, dass Fremdkörper in Ihre Augen geschleudert werden und
Sie dadurch schwerwiegende Augenschäden davontragen.
Tragen Sie immer eine Schutzbrille, wenn möglich mit Seitenschutz,
oder, falls nötig, einen vollen Gesichtsschutz, bevor Sie mit der
Bedienung der
Akku Geräte beginnen. Wir empfehlen Ihnen, einen Gesichtsschutz
über Ihrer eigenen Brille oder eine Standardsicherheitsbrille mit
Seitenschutz zu tragen.
SICHERHEITSHINWEISE
Diese Seite zeigt und beschreibt die Sicherheitssymbole, die auf diesem Produkt
erscheinen können. Lesen, verstehen und befolgen Sie die Anweisungen auf der
Maschine, bevor Sie versuchen, die Maschine zusammenzubauen oder zu bedienen.
Sicherheitswarnung Weist auf mögliche Verletzungsgefahr
hin.
Lesen Sie die
Bedienungsanleitung
Um das Verletzungsrisiko zu
verringern, muss der Benutzer die
Bedienungsanleitung lesen.
Vor Regen schützen
WARNUNG: Nicht im Regen
verwenden, oder während des Regens
draußen liegen lassen.
61cm Messerlänge Die Länge des Messers.
Ø 22mm Mähkapazität Max. Mähkapazität des Messers.
V Volt Spannung
A Ampere Stromstärke
Hz Hertz Frequenz (Zyklen pro Sekunde)
WWatt Leistung
min Minuten Zeit
Wechselstrom Stromart

56 VOLT LITHIUM-IONEN KABELLOSE HECKESCHERE — HT2400E 56 VOLT LITHIUM-IONEN KABELLOSE HECKESCHERE — HT2400E 3736
DE DE
Gleichstrom Stromart oder Merkmal des Stroms
n0Leerlaufdrehzahl Drehzahl im Leerlauf
... /min pro Minute Umdrehungen pro Minute
SPM Hübe pro Minute Hubgeschwindigkeit im Leerlauf
ALLGEMEINE SICHERHEITSHINWEISE ZU EKTROWERKZEUGEN
WARNUNG: Lesen Sie alle Sicherheitshinweise und Anleitungen. Die
Nichtbeachtung der Warnhinweise und Anleitungen kann zu Stromschlägen, Feuer und/
oder schweren Verletzungen führen.
Bewahren Sie alle Warnhinweise und Anleitungen zum späteren Nachschlagen auf.
Der Begriff „Elektrowerkzeug“ in den Warnhinweisen bezieht sich auf Ihr
netzbetriebenes (kabelgebundenes) Elektrowerkzeug oder akkubetriebenes (kabelloses)
Elektrowerkzeug.
SICHERHEIT IM ARBEITSBEREICH
 Halten Sie den Arbeitsbereich stets sauber und gut beleuchtet. Nicht
aufgeräumte oder dunkle Bereiche können Unfälle provozieren.
 Verwenden Sie das Elektrowerkzeug nicht in explosionsgefährdeten
Umgebungen wie z. B. beim Vorhandensein von entzündlichen Flüssigkeiten,
Gasen oder Staub. Elektrowerkzeuge erzeugen Funken, die Staub oder Dämpfe
entzünden können.
 Halten Sie Umstehende und Kinder fern, während Sie das Elektrowerkzeug
benutzen. Ablenkungen können dazu führen, dass Sie die Kontrolle verlieren.
ELEKTRISCHE SICHERHEIT
 Die Stecker von Elektrowerkzeugen müssen zur Steckdose passen.
Modizieren Sie den Stecker in keiner Weise. Verwenden Sie keine
Adapterstecker mit geerdeten Elektrowerkzeugen. Nicht modizierte Stecker
und passende Steckdosen reduzieren die Stromschlaggefahr.
 Vermeiden Sie den Körperkontakt mit geerdeten Flächen wie zum Beispiel
Leitungen, Heizungen, Herde und Kühlschränke. Es besteht erhöhte
Stromschlaggefahr, wenn Ihr Körper geerdet ist.
 Setzen Sie Elektrowerkzeuge nicht bei Regen oder anderen feuchten
Bedingungen ein. Wasser, das in ein Elektrowerkzeug eindringt, erhöht das Risiko
für Stromschläge.
 Beanspruchen Sie das Kabel nicht übermäßig. Tragen oder ziehen Sie das
Werkzeug niemals am Kabel und ziehen Sie nicht am Kabel, um den Stecker
aus der Steckdose zu entfernen. Halten Sie das Kabel von Hitze, Öl, scharfen
Kanten oder beweglichen Teilen fern. Beschädigte oder verknotete Kabel
erhöhen die Stromschlaggefahr.

56 VOLT LITHIUM-IONEN KABELLOSE HECKESCHERE — HT2400E 56 VOLT LITHIUM-IONEN KABELLOSE HECKESCHERE — HT2400E 3938
DE DE
 Wenn Sie ein Elektrowerkzeug im Freien benutzen, verwenden Sie ein
Verlängerungskabel, das für den Gebrauch im Freien geeignet ist. Die
Verwendung eines für den Einsatz im Freien geeigneten Kabels reduziert die
Stromschlaggefahr.
 Wenn der Gebrauch eines Elektrowerkzeuges an einem feuchten Ort
unvermeidbar ist, benutzen Sie eine durch eine Fehlerstromschutzeinrichtung
(FI-Schalter) geschützte Stromquelle. Die Verwendung einer
Fehlerstromschutzeinrichtung reduziert die Stromschlaggefahr.
PERSONENSICHERHEIT
 Seien Sie wachsam, geben Sie darauf acht, was Sie tun, und benutzen
Sie Ihren gesunden Menschenverstand, wenn Sie das Elektrowerkzeug
verwenden. Betreiben Sie das Gerät nicht, wenn Sie müde oder unter dem
Einuss von Drogen, Alkohol oder Medikamenten stehen. Ein Moment der
Unachtsamkeit kann zu ernsthaften Verletzungen führen.
 Tragen Sie eine persönliche Schutzausrüstung. Tragen Sie immer einen
Augenschutz. Eine Schutzausrüstung wie eine Staubmaske, rutschfeste Schuhe,
Helm oder Gehörschutz, die unter geeigneten Bedingungen getragen wird,
reduziert die Gefahr von Verletzungen.
 Beugen Sie einem versehentlichen Starten vor. Stellen Sie sicher, dass der
Schalter in der Aus-Position steht, bevor Sie das Werkzeug mit der Stromquelle
und/oder dem Akku verbinden, es aufheben oder tragen. Das Tragen von
Elektrowerkzeugen mit dem Finger am Schalter oder das Verbinden des Steckers
bei betätigtem Schalter fördert Unfälle.
 Entfernen Sie alle Einstellschlüssel oder Schraubenschlüssel, bevor Sie das
Elektrowerkzeug einschalten. Ein Schraubenschlüssel oder ein Schlüssel, der
noch an einem beweglichen Teil des Elektrowerkzeuges befestigt ist, kann zu
Verletzungen führen.
 Lehnen Sie sich nicht zu weit nach vorn. Achten Sie stets auf einen festen
Stand und halten Sie das Gleichgewicht. Dies ermöglicht eine bessere Kontrolle
über das Elektrowerkzeug in unerwarteten Situationen.
 Tragen Sie angemessene Kleidung. Tragen Sie keine weite Kleidung oder
Schmuck. Halten Sie Ihr Haar, Ihre Kleidung und Handschuhe von den
beweglichen Teilen fern. Weite Kleidung, Schmuck oder langes Haar können sich
in den beweglichen Teilen verfangen.
 Wenn Geräte zum Anschließen zwecks Staubabsaugung und
Auffangvorrichtungen mitgeliefert werden, achten Sie darauf, dass diese
ordnungsgemäß befestigt und benutzt werden. Die Benutzung von Geräten zur
Staubabsaugung kann Gefahren durch Staub reduzieren.
GEBRAUCH UND PFLEGE DES ELEKTROWERKZEUGS
 Üben Sie keinen übermäßigen Druck auf das Elektrowerkzeug aus.
Verwenden Sie das richtige Elektrowerkzeug für Ihre Aufgabe. Das passende
Elektrowerkzeug wird die Aufgabe besser und auf sicherere Weise im Rahmen
des Wirkungsgrades erledigen, für den es entwickelt wurde.
 Verwenden Sie das Elektrowerkzeug nicht, wenn der Schalter sich nicht
ein- und ausschalten lässt. Ein Elektrowerkzeug, das sich nicht durch den
Schalter bedienen lässt, ist gefährlich und muss repariert werden.
 Ziehen Sie den Stecker aus der Netzsteckdose und/oder entfernen Sie den
Akkusatz aus dem Elektrowerkzeug, bevor Sie Einstellungen vornehmen,
Zubehör auswechseln oder das Elektrowerkzeug verstauen. Solche
vorsorglichen Sicherheitsmaßnahmen verringern die Gefahr, dass sich das
Elektrowerkzeug unbeabsichtigt einschaltet.
 Lagern Sie nicht benutzte Elektrowerkzeuge außer Reichweite von
Kindern und lassen Sie keine Personen, die mit dem Elektrowerkzeug oder
diesen Anleitungen nicht vertraut sind, das Elektrowerkzeug benutzen.
Elektrowerkzeuge sind gefährlich in den Händen ungeübter Benutzer.
 Warten Sie Elektrowerkzeuge. Achten Sie auf falsch ausgerichtete Teile
oder Behinderungen beweglicher Teile, auf Bruchstellen und alle anderen
Umstände, die die Funktion des Elektrowerkzeuges beeinträchtigen könnten.
Wenn es beschädigt ist, lassen Sie das Elektrowerkzeug reparieren, bevor Sie
es benutzen. Viele Unfälle entstehen durch schlecht gewartete Elektrowerkzeuge.
 Halten Sie Schneidwerkzeuge scharf und sauber. Sachgemäß gewartete
Schneidwerkzeuge mit scharfen Schneiden neigen weniger dazu, sich zu
verklemmen und sind einfacher zu kontrollieren.
 Benutzen Sie das Elektrowerkzeug, Zubehör, Werkzeugteile usw. gemäß
diesen Anleitungen und berücksichtigen Sie dabei die Arbeitsbedingungen und
die auszuführende Arbeit. Die Verwendung des Elektrowerkzeugs für Aufgaben,
die von seinem bestimmungsgemäßen Zweck abweichen, kann zu gefährlichen
Situationen führen.
