Eiki Brilliant LC-XNP4000 User manual

LC-XNP4000
OWNER'S MANUAL

About the Owner’s Manual
Features
Please read the owner’s manual thoroughly to ensure correct usage of the projector and its
features.
After reading, store the owner’s manual in a safe place for future reference.
1. Dress up Design
2. Designed for tough environment
3. Side change lamp
4. Side change filter
5. Quick power off
6. Advanced Anti-theft features
7. Five auto features (Auto Search, Auto Sync, Auto Ceiling, Auto Keystone and Auto
Filter Alert)
8. Seven display modes (Natural, Cinema, Daylight, Green board, White Board, Black
Board and User)
9. Built-in 8W speaker
10. Logo capture
11. Image freeze function
12. Digital zoom adjustment
Projector
The content of this manual is subject to change without prior notice.
All rights reserved.
Issue of edition 1009.01_00

Contents
1
Contents
About Owner’s Manual
Contents .....................................................................................................................1
Contents of Your Box................................................................................................ 3
Safety Instructions ....................................................................................................4
Safety Labels..............................................................................................................8
Part Names ................................................................................................................9
Projector.................................................................................................................. 9
Control Panel ........................................................................................................ 10
Rear........................................................................................................................11
Setting Up ................................................................................................................12
Arrangement ..........................................................................................................12
Power ON / OFF....................................................................................................13
Setting Up The Projector .......................................................................................14
Ceiling Mounted Installation Guide ......................................................................15
Adjusting The Projector’s Elevation .....................................................................16
How To Connect ....................................................................................................17
Remote Control .......................................................................................................19
Menu Operation......................................................................................................21
How To Operate On-Screen Display ......................................................................21
MENU (PC Mode)...................................................................................................22
Picture Menu (PC Mode)........................................................................................ 22
Audio Menu (PC Mode)......................................................................................... 23
Setting Menu (PC Mode)........................................................................................ 24
MENU (Video Mode)..............................................................................................25
Picture Menu (Video Mode).................................................................................... 25
Audio Menu (Video Mode) ..................................................................................... 26
Setting Menu (Video Mode).................................................................................... 27

2
Contents
MENU ......................................................................................................................28
Advanced Menu.....................................................................................................28
Presentation Menu .................................................................................................31
Security Menu........................................................................................................33
PIN Key In Operation............................................................................................36
Network Control Software Application ................................................................37
Before Use................................................................................................................38
Before Using Network Control Software ..............................................................38
Projector Auto Search............................................................................................39
Modify the Projector Setting .................................................................................40
Sorting the projectors.............................................................................................41
Registering And Configuring the Projector..........................................................42
Delete..................................................................................................................... 42
Projector Setting .................................................................................................... 43
System Setting........................................................................................................44
Monitor / Default Setting / Auto Scan Timer......................................................... 45
Saving the Project File........................................................................................... 46
Link........................................................................................................................ 47
Control Panel Window Introduction.....................................................................48
Power Control / Input Source / Function Key ........................................................48
Function Key / Projector Status..............................................................................49
Network Control Window Introduction..................................................................50
Maintenance Of Projector......................................................................................51
Filter / How to clean or replace the filiters ............................................................. 51
Lamp / Replacing New Lamp................................................................................. 53
Additional .............................................................................................................. 55
Troubleshooting.......................................................................................................56
Indicator.................................................................................................................. 56
Error For Machine Defects ..................................................................................... 57
List of Supported Monitor Displays ....................................................................... 59
Appendix

Contents of Your Box
Safety InstructionsContents of Your Box
Please make sure that following items are included in the box. If any items are missing, contact your
dealer please..
1. Projector
6. Remote control
2. Computer cable
3. Power cord 4. Quick Start Guide
5. Owner’s Manual CD
3-A

3
Safety InstructionsContents of Your Box
8. Soft Bag
7. USB Cable
3-B

4
Safety Instructions
The projector is designed and tested to meet the latest standards for safety of information
technology equipment. However, to ensure safe use of this product, it is important that you
follow the instructions mentioned in this manual and marked on the product.
This symbol indicates information that, if ignored, could possibly
result in personal injury or even death.
WARNING
This symbol indicates information that, if ignored, could result in
personal injury or physical damage.
CAUTION
Typical Symbols
This symbol indicates an additional warning (including cautions).
An illustration is provided to clarify the contents (for example: the
illustration to the left indicates danger of electrical shock).
This symbol indicates a prohibited action. The contents will be clearly
indicated in an illustration or description near the symbol (for example: the
symbol to the left indicates that disassembly is prohibited).
This symbol indicates a compulsory action. The contents will be clearly
indicated in an illustration or description near the symbol
(for example: the symbol to the left shows that the power plug should be
disconnected from the power outlet).

5
Safety Instructions
WARNING
If a problem should occur
If smoke or strange odors arise, continued use could result in fire or electrical shock. In
such case, immediately turn off the power switch and then disconnect the power plug
from the power outlet. After making sure that the smoke or odor has stopped, contact your
dealer for repairs. Never attempt to make repairs yourself because this is dangerous.
Do not use this projector if there is no image or sound, or if the sound is distorted.
Continued use could result in fire or electrical shock. In such case, immediately turn off
the power switch; disconnect the power plug from the power outlet and contact your
dealer.
If water would enter the inside of this projector, immediately turn off the power switch,
disconnect the power plug from the power outlet and contact your dealer.
Do not install on an unstable surface.
Do not install this projector on an unstable surface such as a wobbly
stand or incline because this could result in the projector falling and
causing injury.
Do not open the cabinet.
Never open the cabinet. There is high voltage inside which can cause
electrical shock. Contact your dealer for internal inspection, adjustment
and repair.
Do not modify.
Do not modify this projector because this could result in fire or
electrical shock.
Do not use in the bathroom or near water site.
Do not expose this unit to rain or use near water… for example, in the bathroom, a wet
basement, near a swimming pool, etc…
Do not insert objects into the Projector.
Do not insert metal objects through the ventilation openings, etc., of this projector or drop
such objects inside because this could result in fire or electrical shock.
If a foreign object should enter this projector, immediately turn off the power switch,
disconnect the power plug from the power outlet and contact your dealer.
Continued use could result in fire or electrical shock. Use special caution in household and
where children are present.
NO SIDEWARD
Do not place the projector upon
either side to project an image.

6
Safety Instructions
Do not look through the lens when the lamp is on.
Never look through the lens when the lamp is on. The powerful light could
adversely affect vision. Use special caution in households where children are
present.
Avoid shock or impact on the projector.
If the projector should fall, resulting in damage to the cabinet, immediately
turn off the power switch, disconnect the power plug from the power outlet
and contact your dealer.
Continued use could result in fire or electrical shock.
Do not place this projector in a container containing liquid. Do not place flower
vases, flowerpots, cups, cosmetics, liquids such as water, etc., on top of this projector.
Do not use any power cable except those supplied with the projector.
The use of any other power cable could result in fire or electrical shock.
Do not shine the laser beam onto yourself or other.
The laser pointer function of projector remote control emits class II laser beam.
Do not look directly into the laser beam outlet or direct the laser beam at other people.
Vision can be impaired if the laser beam enters the eyes. Especially pay attention if
children are present.
High temperatures are generated when the lamp is lit; so do not place objects in
front of the lens.
Allowing the proper amount of space on the top, sides, and rear of the projector cabinet is
critical for proper air circulation and cooling of the unit.
The dimension shown here indicate the minimum space required. If the projector is to
be built into a compartment or similarly enclosed, these minimum distances must be
maintained.
WARNING
Side and Top Rear

7
Safety Instructions
Placing heavy objects on top of this projector could result in loss of balance or
falling and cause personal injury or damage the projector.
Do not block the ventilation openings of this projector.
Blocking ventilation could lead to internal overheating which could result in fire.
Do not place this projector on its side during use or push it into a small, poorly ventilated
location.
Do not place this projector on a carpet or bedding or cover it with a tablecloth, etc.
Care and maintenance.
For safety purposes, disconnect the power plug from the power outlet before starting the
care and maintenance of this projector.
Battery usage.
Replace the batteries with the same type only.
Do not mix old and new batteries; this could result in fire or personal injury due to battery
cracking or leakage.
Make sure the plus and minus terminals are correctly aligned when loading the
batteries.
Incorrect loading could result in personal injury or contamination of
the surroundings due to battery cracking or leakage.
Have the projector interior cleaned regularly.
Contact your dealer to arrange for the service.
Accumulations of dust inside the projector can result in fire or malfunction if not cleaned
for an extended period.
Ask your dealer for details about internal cleaning.
CAUTION
