UNPACKING
Carefully remove the CD30 dehumidifier unit from its transit box and visually
check for signs of transit damage. If there is evidence of damage DO NOT
attempt to operate the unit, call your supplier for advice. Do not discard the
packing; it will be useful when transporting the dehumidifier unit in the future.
INTRODUCTION
Dehumidifiers remove moisture from the air that is circulating through the unit.
The resulting reduction of relative humidity helps prevent rust, rot, mould,
mildew and condensation within the room, or other enclosed spaces where
the dehumidifier is used.
A dehumidifier consists of a motor-compressor unit, a refrigerant condenser,
an air circulating fan, a refrigerated surface, a means of collecting and
disposing the condensed moisture and a cabinet to house these components.
The fan draws air through the refrigerated surface and cools it below its dew
point, removing moisture which is collected and led away. The cool air then
passes the hot condenser, where it is reheated. With the addition of other
radiated heat the air is discharged into the room at a higher temperature but
lower relative humidity than when the air entered the unit. Continuous
circulation of the room air through the dehumidifier unit gradually reduces the
relative humidity in the room.
The CD30 has been designed for the exacting conditions which can prevail in
offices, shops, houses, restaurants, public houses etc. It combines lightness
and compactness with high reliability and strength. The gas, which is used
inside the hermetically sealed refrigeration circuit is R134a and contains no
CFC’s and has therefore a zero ozone depletion factor.

Page 3 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
SPECIFICATIONS
"This product contains fluorinated greenhouse gases covered by the Kyoto Protocol. The
refrigeration system is hermetically sealed.
The Global Warming Potential (GWP) of refrigerants used in products manufactured by Ebac
Industrial Products Ltd is as follows
R134a – 1300
R407c – 1610
For type and weight of refrigerant contained in this unit, please refer to the product data label"
M ODEL :
CD30 CD30E
H EIGHT :
300mm 300mm
W IDTH :
304mm 350mm
L ENGTH :
550mm 550mm
W EIGHT :
23 Kg 25 Kg
A IRFLOW :
150 M
3
/Hr 150 M
3
/Hr
P OWER S UPPLY :
240V, 1 ph, 50Hz 240V, 1 ph, 50Hz
P OWER
360W (max) 460W (max)
F INISH :
grey epoxy coating grey epoxy coating
E FFECTIVE V OLUME :
85M
3
85M
3
R EFRIGERANT T YPE /Q TY :
R134a (170g) R134a (170g)

Page 4 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
INSTALLATION
POSITIONING:
Position the dehumidifier unit in the center of the room to be conditioned if at
all possible. However if a damp patch is particularly apparent the outlet grille
should be pointed towards it.
NOTE: Both inlet grille and outlet grille of the dehumidifier unit must have
clear space around them and not be obstructed in anyway.
WIRING:
Connect the power mains cable to a 5 or 13 Amp power supply. As follows:-
230V supply
Brown Live
Blue Neutral
Green/Yellow Earth (ground)
DRAINAGE:
Connect a 12.5mm inside diameter hose to the condensate outlet pipe
(positioned centrally, beneath the air inlet grille). Secure the hose using a
worm drive clip. The hose should at no point be raised higher than the outlet
pipe. Hose should be ran to a permanent drain. Failure to observe this
requirement will result in flooding of the dehumidifier.

Page 5 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
OPERATION
The operation of the dehumidifier is to remove moisture from the air by having
it condense on the cold tubes of the evaporator coil. The air then passes over
the hot condenser coil and returns to the conditioned space slightly warmer
and dryer than when it entered the dehumidifier unit.
AIR MOVING SYSTEM:
Air is drawn in through the inlet grille at the rear of the dehumidifier (below the
handle) and over the two heat exchanges (evaporator/condenser coils) under
the influence of the axial fan, which is driven by the motor. The operation of
the fan is to run continuously whenever the power is supplied to the
dehumidifier. The fan motor used in the dehumidifier unit is induction
protected i.e. the motor is able to take stalled current without burning out the
motor windings.
DEFROST OPERATION:
Should the ambient temperature fall below 15°C the ice will form on the
evaporator coil as the air is passed over it, and in turn the efficiency of the unit
will drop. To prevent the build up of ice on the evaporator coil a timer is
incorporated to energize the hot-gas defrost valve every 55mins for a period
of 4mins. Operating the hot-gas valve causes the evaporator coil to defrost
and the water to drain down to the condensate pan and into the drainage
tube.
HIGH TEMPERATURE CUTTOUT:
The CD30 dehumidifier has been designed to work in ambient temperatures
between -5°C and +35°C. Should the temperature in the room become
excessive a thermostat within the compressor casing will open and
dehumidifying will stop, until the thermostat resets itself.
HUMIDISTAT CONTROL:
The CD30 is fitted with a control humidistat, which measures the relative
humidity of the air within the room to be conditioned. The humidistat
incorporates a pointer and scale, which can be adjusted, and set to a relative
humidity level that is acceptable to maintain the required conditions within the
room. The humidistat controls the on/off function of the dehumidifier, when
the relative humidity of the air in the room falls below the set point of the
humidistat the dehumidifier will switch off, but when the relative humidity of
the air starts to rise again and passes the set point the unit will switch on. The
humidistat is used for the on/off function as it is a cost effective method which
ensures power is only used when needed.

Page 6 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
WARNING:
•Due to the high pressures within the refrigeration circuit, under no
circumstances must direct heat be applied to the evaporator coil in an
attempt to remove the build up of ice.
•No attempt should be made to cut open any part of the refrigeration circuit
due to high pressures and gas involved.
•If the unit is switched off at the mains power supply for any reason, the unit
must be allowed to stand at rest for at least three minutes before
restarting. Failure to do so may cause the unit to blow the fuses owing to
the compressor due to there being a refrigerant imbalance.

Page 7 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
SPECIAL FEATURES (Where Fitted)
Temperature Controlled Defrost
The ‘CD30E’ Dehumidifier unit can be fitted with temperature sensitive
devices which will operate in conjunction with the defrost control. In normal
operation the defrost control will come into operation every 55minutes, this is
to ensure that there will be no build up of ice at lower temperatures, but where
year round conditions need to be maintained the dehumidifier will have to
operate across a wider range of temperatures. To ensure that the
dehumidifier operates most efficiently this temperature sensitive device will
restrict the operation to the times when the evaporator coil is at –2ºC.
Heated Condensate Drainage Tube
The ‘CD30E’ dehumidifier unit can be fitted with a heater tape, which will run
the length of the condensate drainage tube. The effect of this heated
condensate drainage tube will ensure that when the drainage point for the unit
is not in the same room, but is run outside the room and could fall below
freezing point, the tube will be warm enough to still allow the condensate to
flow. Ensure that the heater tape does not protrude past the condensate
drainage tube, if it does then the tape should be doubled up and fed back up
into the condensate tube.
Control Humidistat
This humidistat operates in the same way as the normal humidistat to control
the on/off function of the dehumidifier units, but is factory pre-set at 55% RH
to maintain the relative humidity air at the set point.
Alarm Humidistat
This humidistat, which has been factory pre-set at 70% RH, allows for
connection to an external warning system. This warning indicating system will
be monitored by the customer and will warn and indicate when the relative
humidity of the air within the room has risen above a warning level due to a
fault, either with the dehumidifier or due to some other circumstances and will
require a service engineer.
NOTE RATING OF ALARM HUMIDISTAT IS 3.5A @ 240V
Alarm Wiring: Plug L – Normally open contacts
Plug N – Close on humidity rise
Plug E – Earth

Page 8 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
ROUTINE SERVICE
To ensure continued full efficiency of the dehumidifier, maintenance
procedures should be performed as follows:
Removal of the cover is achieved by means of four screws at the sides of the
unit at base level. With the cover removed all maintenance can be carried out.
1. Clean the surface of the evaporator and condenser coils by blowing
the dirt out from behind the fins with compressed air. Hold the
nozzle of the air hose away from the coil (approx 6”) to avoid
damaging the fins. Alternatively, vacuum clean the coils.
2. Check that the fan is firmly secured to the motor shaft and that the
fan rotates freely.
The motor is sealed for life and does not require any lubrication
3. To check the refrigerant charge, run the unit for 15 minutes and
briefly remove the cover. The evaporator coil should be evenly frost
coated across its surface. At temperatures above 25°C, the coil
may be covered with droplets of water rather than frost. Partial
frosting accompanied by frosting of the thin capillary tubes,
indicates loss of refrigerant gas or low charge.
4. Check all wiring connections.
I F ANY OF THE PRECEDING PROBLEMS OCCUR , CONTACT THE E BAC
S ERVICE C ENTER PRIOR TO CONTINUED OPERATION OF THE UNIT TO
PREVENT PERMANENT DAMAGE
.
WARNING:
ENSURE THAT THE POWER CORD TO THE MACHINE HAS
BEEN DISCONNECTED BEFORE CARRYING OUT ROUTINE
SERVICE. THE SERVICING AND REPAIR OF THIS UNIT
SHOULD ONLY BE CARRIED OUT BY A SUITABLY QUALIFIED
PERSON.
WARNING:
DO NOT STEAM CLEAN REFRIGERATION COILS

Page 9 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
REPAIRS
1. Should an electrical component fail, consult the Factory Service
Center to obtain the proper replacement part.
2. If refrigerant gas is lost from the machine, it will be necessary to use
a refrigeration technician to correct the fault. Contact the Factory
Service Center prior to initiating this action.
Any competent refrigeration technician will be able to service the
equipment. The following procedure must be used:
a. The source of the leak must be determined and corrected.
b. The machine should be thoroughly evacuated before
recharging.
c. The unit must be recharged with refrigerant measured
accurately by weight.
d. For evacuation and recharging of the machine, use the crimped
and brazed charging stub attached to the side of the refrigerant
compressor.
The charging stub should be crimped and rebrazed after
servicing. N EVER allow permanent service valves to be fitted to
any part of the circuit. Service valves may leak causing further
loss of refrigerant gas.
3. The refrigerant compressor fitted to the dehumidifier is a durable
unit that should give many years of service. Compressor failure can
result from the machine losing its refrigerant gas. The compressor
can be replaced by a competent refrigeration technician.
Failure of the compressor can be confirmed by the following
procedure:
a. Establish that power is present at the compressor terminals
using a voltmeter.
b. With the power disconnected, check the continuity of the internal
winding by using meter across the compressor terminals. An
open circuit indicates that the compressor should be replaced.
c. Check that the compressor is not grounded by establishing that
a circuit does not exist between the compressor terminals and
the shell of the compressor.

Page 10 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
TROUBLESHOOTING
S
YMPTOM
C
AUSE
R
EMEDY
Little or no airflow
1. Loose fan on shaft
2. Fan motor burnt out
3. Dirty refrigeration coils
4. Loose electrical wiring
5. Control humidistat either
set too high or
malfunctioning
1. Tighten fan
2. Replace the fan motor
3. See Routine Maintenance
Section
4. Check the wiring diagram
to find fault and repair
5. Adjust humidistat as
required or replace
Little or no water
extraction
1. Insufficient air flow
2. Compressor fault
3. Loss of refrigerant gas
1. Check all of the above
2. Contact the Factory
Service Center
3. Contact the Factory
Service Center
Little or no defrost
when required
1. Faulty Timer
2. Faulty bypass timer
1. Contact the Factory
Service Center
2. Contact the Factory
Service Center

Page 11 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
CD30
SPARE PARTS LIST
Spare parts available online
www.EIPLDIRECT.com
D ESCRIPTION
P ART N UMBER
Product Part Number 1139500 1139525 1013700 1135400 1138100 1138600
Compressor 3022132 3022132 3022132 3022132 3022132 3022132
Compressor OH Protector 3021519 3021519 3021519 3021519 3021519 3021519
Compressor Relay 3021520 3021520 3021520 3021520 3021520 3021520
By-Pass Valve 3020811 3020811 3020811 3020811 3020811 3020811
Condenser Coil 3020740 3020740 3020740 3020740 3020740 3020740
Evaporator Coil 2013713 2013713 2013713 2013713 2013713 2013713
Filter Dryer 3020937 3020937 3020937 3020937 3020937 3020937
Fan Motor 3035752 3035752 3035752 3035752 3035752 3035752
Fan Blade 3040129 3040129 3040129 3040129 3040129 3040129
Control Humidistat 3035141 3035141 1132200 1132200 1132200 1132200
Warning Humidistat 3035141 3035141 - - - -
Frostat 3031516 - - 3031516 - -
Control Defrost Device 3031516 - - - - -
PCB Timer 1613700 1016900 1601900 1613700 1601900 1601900
Solenoid Coil 3030422 3030422 3030422 3030422 3030422 3030422
Humidistat Knob 3090611 3090611 - - - -
Control Knob - - 2019708 2019708 2019708 2019708
Control Knob Cap (black) 3090612 3090612 - - - -
Warning Knob Cap (orange) 3090645 3090645 - - - -
Panel Mounting Plug 3035997 3035997 - - - -
Free Socket 3035998 - - - - -
Feet 3100758 - 3100758 3100758 3100758 3100758
Mains Cable 3031225 3031225 2133711 2133711 2131145 2131144
Condensate Drain Tube 3014338 3014338 3014338 3014338 3014338 3014338
Worm Drive Clip 3086101 3086101 3086101 3086101 3086101 3086101
Cover fixing Clip Nut 3080507 3080507 3080501 3080501 3080501 3080501

Page 12 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
CD30I STAND & CD30I INDICATOR BOX
SPARE PARTS LIST
D ESCRIPTION P
ART
N UMBER
CD30I Stand 1139535
Adjustable Tilt Guide 3050305
CD30I Indicator Box 1139530
Red Neon Lamp 3032272
M16 Gland Type 3032512
Resistor 180K Ohms 3032883
Female Insert Contact Type 3033810
Hood 3033811
Cable Seal 3033813
Female Contact 3033815
Green Neon Indicator Lamp 3034584
Sealing Washer 3035423
6-way Terminal Block 3036810

Page 13 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
WARNINGS
This appliance can be used by children from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or instruction concerning
use of the application in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without
supervision.
If the SUPPLY CORD is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified person in order to avoid hazard.
This product contains fluorinated greenhouse gases covered by the Kyoto
Protocol. The refrigeration system is hermetically sealed.
The Global Warming Potential (GWP) of refrigerants used in products
manufactured by Ebac Industrial Products Ltd is as follows
R134a – 1300
R407c – 1610
For type and weight of refrigerant contained in this unit, please refer to the
product data label
Due to the high pressures within the refrigeration circuit, under no
circumstances must direct heat be applied to the evaporator coil in an attempt
to remove the build-up of ice.
No attempt should be made to cut open any part of the refrigeration circuit
due to high pressures and gas involved.
If the unit is switched off at the mains power supply for any reason, the unit
must be allowed to stand at rest for at least three minutes before restarting.

Page 14 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16

Page 15 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16

Page 16 of 16
Drawing : - TPC137
Issue : - 7
Date : - 23/11/16
UK Head Office
Ebac Industrial Products Ltd
St Helens Trading Estate
Bishop Auckland
County Durham
DL14 9AD
Tel: [phone]
Fax: [phone]
www.eipl.co.uk
[email protected]
American Sales Office
Ebac Industrial Products Inc
700 Thimble Shoals Blvd.
Suite 109, Newport News
Virginia, 23606-2575
USA
Tel: [phone]
Fax: [phone]
www.ebacusa.com
[email protected]
German Sales Office
Ebac Industrial Products Ltd.
Gartenfelder Str. 29-37
Gebäude 35
D-13599, Berlin
Germany
Tel: [phone]
Fax: [phone]
www.eip-ltd.de
[email protected]
