Mycond TIBO 10 User manual

3
AIR DEHUMIDIFIER
USER’S MANUAL
TIBO 10

eng 4 eng
USER’S MANUAL
KEEP THIS MANUAL FOR FURTHER REFERENCE!
Thank you for selecting our super quality dehumidifier. Be sure to read this manual carefully
before using it. If you have any questions, contact the professional service for help. Keep the
manual for further reference.
The dehumidifier will remove excess moisture from the air, creating a comfortable
environment for your home and oce. Its compact design allows you to easily move it to any
room.

5
CONTENTS
CONTENTS ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 5
SAFETY NOTICES■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 6
OPERATION PANEL ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 8
SELECTING PROPER FUNCTIONS ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 9
SPECIFICATIONS ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■10
OPERATION AND EFFICIENCY ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 11
PARTS NAMES AND FUNCTIONS ■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 13
PREPARATIONS WHILE BEGINNING THE OPERATION ■■■■■■■■■■■■■■■■■■■■■■ 15
OPERATION MANUAL■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 16
MAINTENANCE NOTICES■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 17
MALFUNCTION DISPOSALS■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■■ 20

SAFETY NOTICES
eng 6 eng
Read the following notices carefully before operating this dehumidifier.
The warnings and notices must be observed effectively to ensure the safety of the operation.
1. If any abnormal phenomenon is detected, turn off the switch of the dehumidifier, pull out the power plug and contact the
dealer. (The abnormal operation may cause equipment failures, electric shock, fire or other similar accidents.)
2. Before turning off the dehumidifier, turn off its switch first. Don’t pull out the power plug directly.
3. Don’t refit the dehumidifier, don’t try to dismantle or repair the dehumidifier by yourself.
4. Keep your hands dry while plugging into or pulling off the plug to avoid electric shock.
5. AC220-240 volt of alternative current is applied to this equipment.
6. Clean the conductor of the plug and insert it into the socket firmly.
7. Don’t spray the dehumidifier or place flammables or chemical substances near it to avoid fire or explosion.
8. Don’t place the dehumidifier near a heating equipment to avoid the resin materials on the dehumidifier melt or ignite.
9. Don’t connect the dehumidifier to a socket with lower electric rating than the dehumidifier.
10. Don’t damage or refit the power cord. Don’t put heavy things or high-temperature objects on the power line. Don’t pull or
coil the power line while operating the dehumidifier.
11. Don’t catch the power cord in the door to avoid damaging it.
12. Since the fan blade in the dehumidifier can rotate at high speed, don’t insert sticks or other objects into the air outlet of the
dehumidifier, because the fan blade runs with high speed and may cause serious injury.
13. The water in the tank must be emptied out. (Drinking or using the water remained in the tank on other purposes may cause
disease or accident.)
14. The dehumidifier must be placed on a smooth and stable surface. Don’t spray or moisten the dehumidifier to avoid electric
shock.
15. Don’t use the dehumidifier outdoors. The direct exposure to the sun or rain may cause it superheated, get an electric shock
or fire.
16. Don’t place the objects, such as vases on the dehumidifier. (If they are overturned, the water entering the dehumidifier may
worsen the electrical insulation, which may cause electric shock, current leakage or fire.)

7
SAFETY NOTICES
17. Don’t use the dehumidifier for other purposes, such as keeping food or artwork, or it may cause quality deterioration.
18. Don’t use the dehumidifier in the places where oil or inflammable substances leakage might occur.
19. Don’t use the dehumidifier at the place with chemicals.
20. Notice not to make the wind from the dehumidifier blow to the heating equipment.
21. Don’t sit on the dehumidifier or trample it.
22. With safety consideration, pull out the power plug at idle time.
23. Hold the body of the plug while pulling it out from the socket or inserting it into the socket.
24. Keep the children away from the dehumidifier if it is used in the wardrobe.
25. Don’t disassemble the floating rod in the tank.
26. Don’t pull out the power cord while moving the dehumidifier to avoid damaging the power line.
27. Don’t block the air inlet or outlet of the dehumidifier. Don’t cover dehumidifier with moist things.
28. Take periodical inspection if the dehumidifier has operated for a long time. Pay special attention to the air filter, drainpipe
and other similar parts.
29. Turn off the power of the dehumidifier and pull out the power plug first before cleaning or maintaining.
30. Don’t spray or moisten the dehumidifier with water while cleaning to avoid electric shock.
32. Turn off the switch of the dehumidifier and empty out the water in the tank before moving the dehumidifier. The handles
must be held while moving.

eng 8
OPERATION PANEL
eng
Timer setting
TIMER
HUMIDITY
DEHUMIDIFICATION
ON/OFF
Humidity setting
Mode: Dehumidification or Ventilation
ON/OFF

9
SELECTING PROPER FUNCTIONS
Lowering the indoor humidity to a comfortable humidity.
Reduction of indoor humidity or preventing the condensation and mildewing on the ceiling or walls.
Dehumidification for the wardrobe.
Small space dehumidification.
Indoor air filtration.

eng 10
SPECIFICATIONS
eng
Model TIBO 10
Dehumidifying capacity 10 L/DAY (30 °C, 80%), 5 L/DAY (27 °C, 60%)
Power supply AC 220-240 V/50 Hz
Input power 220 V
Rated current 1.35 A
Water tank capacity 2.2 Л
Refrigerant R134 a
Application scope 5-32 °C
Net weight 9 kg
Overall dimensions 480х280х240 mm
Note: The above technical specifications are subject to change without notice.

11
OPERATION AND EFFICIENCY
DEFROSTING OPERATION
A) When the room temperature ≥24 °C is detected, continuous operation, no defrosting.
B) When the room temperature from 18 °C up to 23 °C is detected, the defrosting is performed for 5 minutes after
each 120 minutes of dehumidification.
C) When the room temperature is from 12 °C up to 18 °C, the defrosting will be carried out for 5 minutes after 25
minutes of dehumidification.
D) When room temperature is from 5 °C up to 12 °C, defrosting will be carried out for 5 minutes after 20 minutes
of dehumidification.
During the defrosting operation, the dehumidification and air purification functions may intermit.
Don’t turn off the switch or pull out the power plug of the dehumidifier during the defrosting operation.
This dehumidifier can’t be applicable to keep extreme low temperature.
The purpose of this dehumidifier is to pump off the unpleasant high humidity in daily life and dry the wet things. But it can’t
be used to keep extreme low temperature.
THE ROOM TEMPERATURE INCREASES DURING THE OPERATION
This dehumidifier doesn’t have cooling function. It will produce heat during the operation and increase the room
temperature from 1 to 4 °C. This temperature rise may be very distinct in the cabinet or other similar spaces. In
addition, the door and windows closed and other appliances in the room can give out heat as well as the radiation
of the sun can raise the room temperature.

OPERATION AND EFFICIENCY
eng 12 eng
DEHUMIDIFYING CAPACITY
The illustration below shows the daily dehumidifying capacity of the dehumidifier. This capacity is based on the
30°C of room temperature, 80% of relative humidity and upon condition that the air outlet is fully open. At dierent
temperatures and relative humidity, this device may have dierent dehumidifying capacities.
With the same room temperature, the dehumidifying capacity is higher at higher relative humidity and the
dehumidifying capacity is lower at lower relative humidity. In the same relative humidity, the dehumidifying
capacity is higher at higher temperature and the dehumidifying capacity is lower at lower temperature.
If the dehumidifier is placed in the cabinet, its dehumidifying capacity may highly reduce in a short period after
operating, that is, the humidity in the cabinet has been highly reduced.
10
8
6
4
2
0 5 10 15 20 25 30
Dehumidifying
capacity
Humidity 80%
Room temperature

13
PARTS NAMES AND FUNCTIONS
ACCESSORY
Antibacterial air purification filter (one piece)
FRONT BACK
Power switch Handle
Air Inlet Air Outlet
Water Tank

eng 14
PARTS NAMES AND FUNCTIONS
INSTALLATION
The following space must be maintained to ensure the operating eciency of the dehumidifier.
NOTE!
If the dehumidifier gets interference from the household appliances, such as television and radio cassette player,
keep the equipment away from the dehumidifier for over 70 cm.
eng
Top: 30 cm or more
Right: 20 cm or more
Left: 20 cm or more
Front: 20 cm or more
Back: 30 cm or more
Air Outlet

15
PREPARATIONS WHILE BEGINNING THE OPERATION
CONFIRM THE TANK IS INSTALLED IN POSITION
The dehumidifier can’t operate if the water in the tank is full or isn’t installed well.
1. How to move the water tank.
Hold the water tank sides and pull out.
2. Method to empty out the water tank.
1) Pull out the water tank from the dehumidifier.
2) Incline the water tank according to the indication direction and empty out the water slowly.
3) Install the water tank back into the dehumidifier.
REMARK
After the dehumidification process, the tank may hold water, and after the water is full, the dehumidifier operates
automatically and the “Full” indictor light is on.

eng 16
OPERATION MANUAL
1. Connect the power supply of the dehumidifier.
2. Press “STAND-BY”, direction ON.
a. Notice: please confirm the water tank has been installed correctly. The full indicator light is on (orange light) if it
isn’t installed in position or the water is full.
b. The machine unit is electrified and the fan begins to operate.
3. Continuously press «TIMER», select the time. Timing can be set from 0-12 hours’ cycle.
4. Press «DEHUMIDIFICATION», select dehumidification(DH) or ventilation(FA); Ventilation mode(FA)can’t set humidity.
Press «HUMIDITY”, set desired humidity. The setting range is 30% -80%. Or continuous operation (CO).
5. Press “STAND-BY”, direction OFF. The unit machine stops running.
6. FULL indication. The compressor stops running, and the fan goes on running*
WARNING!
Don’t catch the power line in the door to avoid damaging it.
NOTICE!
Keep the children away from the dehumidifier, if it is used in the cabinet.
eng

17
MAINTENANCE NOTICES
WARNING!
Don’t plug in with wet hands to avoid electric shock.
NOTICE!
Cut off the power supply before daily cleaning and maintenance.
Don’t dismantle the floater from the water tank.
IF THE MACHINE UNIT IS NOT IN USE FOR EXTENDED PERIODS
1. Empty out the water in the tank, wipe up the water tank and install it back.
2. Clean the filter.
3. Place the machine unit upright and avoid the direct sunlight.
REQUIREMENT!
Place the machine unit upright to avoid misoperation and unusual sound.

eng 18
MAINTENANCE NOTICES
MACHINE BODY
Wipe up the dehumidifier with wet cloth (put it into the water and wring it out). Don’t clean the control unit with
wet cloth.
Don’t clean the machine unit with gasoline, thinner or liquid detergent to avoid
deformation and fission of the machine unit.
The cloth containing chemicals may change the color of the machine unit.
WARRANTY INFORMATION
The manufacturer provides warranty in accordance with the legislation of the customer’s own country of residence,
with a minimum of 1 year (Germany: 2 years), starting from the date on which the appliance is sold to the end user.
The warranty only covers defects in material or workmanship.
The repairs under warranty may only be carried out by an authorized service center.
When making a claim under the warranty, the original bill of purchase (with purchase date) must be submitted.
The warranty will not apply in cases of:
Normal wear and tear.
Incorrect use, e.g. overloading of the appliance, use of non-approved accessories.
Use of force, damage caused by external influences.
Damage caused by non-observance of the user manual, e.g. connection to an unsuitable mains supply or non-
compliance with the installation instructions.
eng

19
MAINTENANCE NOTICES
CLEANING THE FILTER NET
Should be maintained every two weeks.
The dehumidifying capacity may reduce when the filter net is clogged with defilement. The dust collector is always
used to clean the dust. If the filter net is too dirty, it should be cleaned.
CONTINUOUS DRAINAGE
When you are not at home but need unit to make long-term operation, you can use the continuous drainage feature.
Pull the plug, then insert the pipe.
Continuous Drain Hose (included)
Length: 30 cm
Inner Diameter: 17 mm
Outer Diameter: 19 mm

MALFUNCTION DISPOSALS
eng 20
BEFORE CALLING FOR SERVICE
Please check each item first before applying for maintenance.
Malfunction Possible causes Solutions
Not working Electric power is switched o Link the appliance to an electrical outlet
The condenser tank is overflowing Drain the tank
Condenser tank was installed incorrectly Install your appliance in the correct
position
Small dehumidifying capaty The filter is clogged Clean the filter
Obstruction with alien objects blocking
the air inlet/outlet
Remove the object blocking the air inlet/
outlet or move the dehumidifier to ensure
sucient air inlet and outlet
Bin noises The appliance is installed incorrectly/
аppliance is unstable
Install your appliance in the correct
position
Stop during the dehumidifying process Too low or too high temperature, over the
operational temperature range of a dryer
The appliance will start working
automatically when temperature levels
out to the operational temperature range
The clothing can’t be dried fast Too low indoor temperature The wet clothing may dry more slowly at
low temperatures
eng
