Setup Manual
Important: Please read this Setup Manual and the User’s Manual stored on the CD-
ROM carefully to familiarize yourself with safe and effective usage. Please
retain this manual for future reference.
Installationshandbuch
Wichtig: Lesen Sie dieses Installationshandbuch und das Benutzerhandbuch (auf der
CD-ROM) aufmerksam durch, um sich mit der sicheren und effizienten
Bedienung vertraut zu machen. Bewahren Sie dieses Handbuch zum
späteren Nachschlagen auf.
Manuel d’installation
Important : Veuillez lire attentivement ce manuel d’installation, ainsi que le manuel
d’utilisation inclus sur le CD-ROM, pour vous familiariser avec une utilisation
efficace et en toute sécurité. Veuillez conserver ce manuel pour référence
ultérieure.
Manual de instalación
Importante: Lea detenidamente este Manual de instalación y el Manual del usuario (en el
CD-ROM) para familiarizarse con las normas de seguridad y procedimientos
de uso. Conserve este manual para consultas posteriores.
Manuale di installazione
Importante: si consiglia di leggere con attenzione il presente Manuale di installazione e il
Manuale dell’utente (sul CD-ROM in dotazione) per acquisire le informazioni
necessarie per un utilizzo sicuro ed efficace. Conservare il manuale per
consultazioni future.
Installationshandboken
Viktigt: Läs den här installationshandboken och bruksanvisningen som finns på CD-
skivan noggrant så att du känner dig säker och får ett effektivt användande
av produkten. Behåll manualen för framtida behov.
Εγχειρίδιο εγκατάστασης
Σημαντικό: Διαβάστε προσεκτικά αυτό το εγχειρίδιο εγκατάστασης και το εγχειρίδιο
χρήσης που είναι αποθηκευμένο στο CD-ROM για να εξοικειωθείτε με την
ασφαλή και αποτελεσματική χρήση της μονάδας. Διατηρήστε αυτό το
εγχειρίδιο για μελλοντική χρήση.
Руководство по установке
Важно! Внимательно прочитайте настоящее Руководство по установке и
Руководство пользователя на диске CD-ROM для получения сведений о
безопасной и эффективной эксплуатации. Сохраните это руководство
для справки.
设定手册
重要事项： 请仔细阅读储存在光盘片中的设定手册和用户手册，以便熟悉安全有效使用本
显示器的信息。请保留本手册，以便今后参考。

English
Setup Manual
Important: Please read this Setup Manual and the User’s Manual stored on the CD-
ROM carefully to familiarize yourself with safe and effective usage. Please
retain this manual for future reference.

2
English
TroubleshootingSetting/AdjustmentInstallationPrior to use
FlexScan® HD2441W
Speakers
(with built-in amplifier)
Allows you to enjoy sound from a
connected PC or AV equipment, etc.
• Connection methods ..............page 10
NOTE
• Enables you to adjust the speaker
volume connected to the monitor
using the volume adjustment function
of the monitor. .......................page 13
• Enables you to enjoy sound by
connecting a headphone to the
headphone jack. .....................page 10
USB devices
Keyboard
• Connection methods ...............page 9
(Also available to connect a printer or a
scanner, etc.)
Attention
• Use a PC/OS applicable to USB devices.
[Applicable OS]
- Windows 2000/XP/Vista
- Mac OS 8.5.1 or later
Mouse
PC
Enables you to use as a monitor by connecting to
a Windows PC or a Macintosh.
• Applicable resolution ............page 3
• Connection methods ..............page 8
Attention
• The USB setting is required to change
depending on a PC used. ......page 13
HD2441W
AV equipment
HDMIconnector
DVDplayer,etc.
Game,etc.
Enables you to display projected images by
connecting a DVD, Video, game, etc.
• Applicable signal format ............. page 3
• Connection methods ................... page 10
HD2441W can be connected to the following devices.

3
English
TroubleshootingSetting/AdjustmentInstallationPrior to use
Compatible Resolutions/Signal Format
The monitor supports the following resolutions and signal format.
PC Input
Resolution Frequency Remarks Digital Input Signal Analog Input Signal
Dot Clock (~ 162 MHz) Dot Clock (~ 162 MHz)
640 × 400 70 Hz NEC PC-9821 — 
640 × 480 67 Hz Apple Macintosh — 
640 × 480 ~75 Hz VGA, VESA  (60Hz) 
720 × 400 70 Hz VGA TEXT  
720 × 480 60 Hz VESA  
848 × 480 60 Hz VESA  
800 × 600 ~75 Hz VESA  (60Hz) 
832 × 624 75 Hz Apple Macintosh — 
1024 × 768 ~75 Hz VESA  (60Hz) 
1152 × 864 75 Hz VESA — 
1152 × 870 75 Hz Apple Macintosh — 
1280 × 768 *160 Hz VESA CVT RB — 
1280 × 768 *1~75 Hz VESA CVT — 
1280 × 960 60 Hz VESA  
1280 × 960 75 Hz Apple Macintosh — 
1280 × 1024 ~75 Hz VESA  (60Hz) 
1360 × 768 60 Hz VESA — 
1600 × 1200 60 Hz VESA  
1680 × 1050 *160 Hz VESA CVT  
1680 × 1050 *160 Hz VESA CVT RB  
1920 × 1200 *1 *260 Hz VESA CVT RB  
1280 × 720p *350, 60 Hz 720p  
1920 × 1080p *350, 60 Hz 1080p  
*1 When displaying the wide format input signal, a graphics board in conformance with VESA CVT standard is required.
*2 Recommended resolution (Set this resolution.)
*3 Resolution for some AV equipment
HDMI Input
• Video signal
– 525i (480i) / 525p (480p) / 1125i (1080i) / 750p (720p) / 1125p (1080p) : 60Hz
– 625i (576i) / 625p (576p) / 1125i (1080i) / 750p (720p) / 1125p (1080p) : 50Hz
• Audio signal
2ch linear PCM (32kHz / 44.1kHz / 48kHz / 88.2kHz / 96kHz / 176.4kHz / 192kHz)

4
English
SAFETY SYMBOLS
This manual uses the safety symbols below. They denote critical information. Please read them carefully.
WARNING
Failure to abide by the information in a WARNING
may result in serious injury and can be life threatening.
CAUTION
Failure to abide by the information in a CAUTION
may result in moderate injury and/or property or
product damage.
Indicates a prohibited action.
Indicates a mandatory action that must be followed.
PRECAUTIONS
WARNING
If the unit begins to emit smoke, smells like
something is burning, or makes strange
noises, disconnect all power connections
immediately and contact your dealer for
advice.
Attempting to use a malfunctioning unit may result in
fire, electric shock, or equipment damage.
Use the enclosed power cord and connect to
the standard power outlet of your country.
Be sure to remain within the rated voltage of the power
cord. Not doing so may result in fire or electric shock.
"Power Supply: 100-120/200-240 Vac 50/60Hz"
Keep small objects or liquids away from the
unit.
Small objects accidentally falling through the
ventilation slots into the cabinet or spillage into the
cabinet may result in fire, electric shock, or equipment
damage. If an object or liquid falls/spills into the
cabinet, unplug the unit immediately. Have the unit
checked by a qualified service engineer before using it
again.
Set the unit in an appropriate location.
Not doing so may result in fire, electric shock, or
equipment damage.
• Do not place outdoors.
• Do not place in the transportation system (ship,
aircraft, trains, automobiles, etc.).
• Do not place in a dusty or humid environment.
• Do not place in a location where the steam comes
directly on the screen.
• Do not place near heat generating devices or a
humidifier.
The equipment must be connected to a grounded main outlet.
Not doing so may result in fire or electric shock.
CAUTION
Do not block the ventilation slots on the
cabinet.
• Do not place any objects on the ventilation slots.
• Do not install the unit in a closed space.
• Do not use the unit laid down or upside down.
Blocking the ventilation slots prevents proper airflow
and may result in fire, electric shock, or equipment
damage.
Use an easily accessible power outlet.
This will ensure that you can disconnect the power
quickly in case of a problem.
TroubleshootingSetting/AdjustmentInstallationPrior to use

5
English
TroubleshootingSetting/AdjustmentInstallationPrior to use
Package Contents
Check that all the following items are included in the packaging box. If any items are missing or damaged, contact your local
dealer.
NOTE
• Please keep the packaging box and materials for future movement or transport of the monitor.
□ Monitor
□ Power cord
□ Digital signal cable (FD-C39)
□ Analog signal cable (MD-C87)
□ EIZO HDMI cable (00M0J261/00M0J262)
□ EIZO USB cable (MD-C93)
□ EIZO LCD Utility Disk (CD-ROM)
• User’s Manual
□ Setup Manual (this manual)
□ Limited warranty
□ Recycling Information
□ Mounting Screws (M4 x 12, 4 pcs)
About Setup Manual and User’s Manual
Setup Manual
(this manual)
Describes basic information ranging from connection of the monitor to
external equipment, such as a PC, etc., to using the monitor.
User’s Manual
(• PDF file on the CD-ROM*)
Describes application information such as screen adjustments, settings,
and specifications.
* Installation of Adobe Reader is required.
• Product specifications vary with sales areas. Confirm that the manual is written in the language of the area of purchase.
About EIZO LCD Utility Disk (CD-ROM)
● Disk Contents
• Disk contents and software overview
The following is included in the disk. Refer to the “Readme.txt” or the “Readme” file on the disk for software startup
procedures or file access procedures.
Item Overview For Windows For Macintosh
A “Readme.txt” or “Readme” file  
Color Profiles (ICC Profiles) Color profiles  
Screen Adjustment Program Available for easy adjustments of
the monitor screen by following
adjustment patterns and procedures
on the screen.
 
ScreenManager Pro for LCD (for
Windows)
A utility software program to control
monitor adjustments from a PC using
its mouse and keyboard.
−
WindowMovie Checker Software*WindowMovie is a function of
ScreenManager Pro for LCD.
For more information, refer to the
User’s Manual of ScreenManager Pro
for LCD on the disk.
User’s Manual of this monitor (PDF file)
* WindowMovie Checker Software is not applicable to Windows Vista.
● To use ScreenManager Pro for LCD
For the installation and use of ScreenManager Pro for LCD, refer to its User’s Manual on the disk.

6
English
TroubleshootingSetting/AdjustmentInstallationPrior to use
Controls and Functions
1 Sensor Detects the environmental brightness. BrightRegulator function (see page
15).
2 Input Signal Selection Switch
( ) *2
• Displays/Quits the Input Selection menu.
• When touching for approx. 2 sec. while using the PC input signal, a video
display appears on the monitor. PinP (Picture in Picture) function.
3 Slide bar *2• Uses when the setting/adjustment is performed on each menu.
• When touched it while the menu is not displayed, the Volume menu appears.
4 Menu switch ( ) *2Displays/Quits the Setting menu.
5 Power switch ( ) Turns the power on or off.
6 Power indicator Indicates monitor’s operation status.
Blue : The screen is displayed Orange : Power saving
Off : Power off
7 Security lock slot Complies with Kensington’s MicroSaver security system.
8 Audio output terminal [Stereo mini jack] Connects the built-in amplifier speakers, etc.
9 Input signal connectors
(VIDEO 1/2)
[HDMI connector × 2] Connects AV equipment.
10 Input signal connector (PC 1) [DVI-D connector] Connects a PC.
11 Input signal connector (PC 2) [D-Sub mini 15-pin connector] Connects a PC.
12 USB ports (Up) [Upstream × 2] Connects a PC.
13 Headphone jack [Stereo mini jack] Connects headphones.
14 USB ports (Down) [Downstream × 2] Connects a peripheral USB device.
15 ArcSwing 2 Stand Used to adjust the height and angle of the monitor screen.
16 Cable holder Covers the monitor cables.
*1 ScreenManager ® is an EIZO’s nickname of the Setting menu.
(In this manual, the setting/adjustment item names in the Setting menu are put in angle brackets < >. (ex. : <Color>))
*2 When touching while the power turns off, the monitor turns on.
7
1 2 3 4 5 6 111098
15
16
13
14
12
Setting menu
(ScreenManager ® *1)
Power connector

7
English
TroubleshootingSetting/AdjustmentInstallationPrior to use
Using the Operation Switch
Operationpanel
There are three methods of
operation:
• Touching the switch
• Tapping the slide bar
• Tracing the slide bar
 Turning the power On/Off
 Displaying/Quitting a menu
InputSelectionmenu Settingmenu
Volumemenu
(Whenthemenuisnotdisplayedonthescreen)
 Selecting a menu item
Setting and Adjusting
*Theincrease/decreasespeedofthe
adjustmentvaluemaychange
dependingonthetracingspeedof
theslidebar.
Atfineadjustment
*Tappingoncechangestheadjustmentvaluetoonestepupordown.
Touchingtheslidebarcontinuouslymaychangethevalueserially.
 Fixing an item
Deciding the setting and adjusting value
PowerOff:Touch .
PowerOn:Touchanyofthekeystoturnonthemonitor.
Touch . Touch .
Taptheslidebar.
Tracetheslidebarleftandright.
Tapeitherendoftheslidebar,markedwith and .
Taptheslidebar.

8
English
TroubleshootingSetting/AdjustmentPrior to use Installation
Connecting Cables
1 Check that the monitor is powered off.
2 Connect a PC.
Attention
• When replacing the current monitor with an HD2441W monitor, be sure to change the PC settings for
resolution and vertical frequency to those which are available for the HD2441W monitor referring to
the resolution table (see page 3) before connecting the PC.
1. Check that the PC is powered off.
2. Connect the monitor to the PC with a signal cable that matches the connectors.
After connecting the cable connectors, tighten the screws of the connectors to secure the coupling.
MacintoshWindows
Macintosh
Windows
Connectors on the
PC
DVI connector
D-Sub mini 15-pin
connector
Connectors on the
monitor
Signal cable FD-C39 (supplied)
Signal cable MD-C87 (supplied)
Digital connection
Analog connection
DVI-D connector
D-Sub mini 15-pin
connector

9
English
TroubleshootingSetting/AdjustmentPrior to use Installation
3. Connect the USB cable to the USB ports on the PC (downstream) and the monitor (upstream).
Be sure to connect to the USB port (upstream) that complies to the PC (PC 1/PC 2).
• DVI-D connector (PC 1): PC 1 USB port is used.
• D-Sub mini 15-pin connector (PC 2): PC 2 USB port is used.
Connectors on the
PC
Downstream
Connectors on the
monitor
Upstream
USB cable MD-C93 (supplied)*
* When connecting two PCs to the
monitor, please purchase another cable.
Attention
• When connecting the monitor to a PC using a USB cable, the USB setting on the monitor should be
changed corresponding to the PC used (see page 13).
NOTE
• The monitor is equipped with the USB audio function. You may enjoy sound from PC with speakers by
connecting the USB cables.
3 Connects USB devices.
1. Connect USB devices (keyboard, mouse, etc.) to the USB port (downstream) on the monitor.
Attention
• After connecting the USB devices and turning on the monitor, the USB function is set up
automatically.
• This monitor may not work properly depending on the PC, OS or USB devices used. (For USB
compliance of the respective devices, consult their manufacturers.)
Connectors on the
monitor
Downstream
Keyboard
Mouse

10
English
4 Connect AV equipment.
1. Check that the AV equipment is powered off.
2. Connect the monitor to the AV equipment with a HDMI signal cable.
TroubleshootingSetting/AdjustmentPrior to use Installation
Connectors on the
AV equipment
(Output)
HDMI connector
Connectors on the
monitor
HDMI cable 00M0J261/00M0J262 (supplied)*
* When connecting two AV equipment with
HDMI output, please purchase another
cable.
5 Connect speakers.
1. Connect the monitor to the speaker with an audio cable that matches the connectors.
Connectors on the
speakers
(Input)
(Pin jack)
R L
Stereo mini jack
Connector on the
monitor
Stereo mini jack
Audio cable*
Audio cable*
6 Plug the power cord of the monitor into a power outlet.
1. Plug the power cord into a power outlet and the Power connector on the monitor.
HDMI connector
* Please purchase the cable.
NOTE
• When using headphones, connect the headphones
to the headphone jack on the monitor. Headphone
Headphone jack

11
English
TroubleshootingSetting/AdjustmentPrior to use Installation
Adjusting the Screen Height and Angle
Adjust the screen height, tilt and swivel the screen to the best condition for working.

12
English
Prior to use Installation TroubleshootingSetting/Adjustment
Displaying the Screen
1 Touch to turn on the monitor.
The monitor’s Power indicator lights up blue.
2 Turn on the external equipment.
3 Switch the input signal to display the desired image sent from the equipment.
1. Touch .
The Input Selection menu appears.
2. Trace the slide bar left and right to select the input
signal and tap the slide bar.
The screen image appears.
4 After the image appears on the screen, perform the following operations
according to the monitor status.
 When receiving an analog signal from the PC (at PC 2 input selection) [Auto Screen/Range
Adjust]
Perform the auto adjustment function. The screen (clock, phase, position) and the signal output range
are adjusted automatically.
The auto adjustment function is not required when digital signals are input (at PC 1 input selection)
because images are displayed correctly based on the preset data of the monitor.
1. Touch .
The Setting menu appears.
2. Select the <Screen> icon and tap the slide bar.
The <Screen> menu appears.
3. Select the <Auto Screen Adjust> icon and tap the
slide bar.
A message window appears.
4. Select “Yes” and tap the slide bar.
The Auto Screen Adjust function is activated and clock,
phase and screen position are adjusted automatically.
5. Select the <Auto Range Adjust> icon and tap the
slide bar.
A message window appears.
6. Select “Yes” and tap the slide bar.
The Auto Range Adjust function is activated and the
signal output range is adjusted automatically.
7. Touch .
The Setting menu quits.
Attention
• The Auto Screen Adjust function works correctly when an image is fully displayed over the display
area of the monitor.
It does not work properly when an image is displayed only on a part of the screen (DOS prompt
window, for example) or when a black background (wallpaper, etc.) is in use.
The Auto Screen Adjust function may not work properly with some graphics boards.
Input Selection menu
Screen menu

13
English
 When connecting a PC with USB connection [USB]
Switch the USB setting of the monitor to either “PC 1” or “PC 2”, according to the PC used.
If it is not set properly, the USB devices connected to the monitor may not work or no sound may come
out from the speakers.
Attention
• When switching the USB setting, a message window may appear.
Message:
“If the USB setting is changed, the USB connection to the selected PC will be lost. Do you change the setting?”
When the message is displayed, note the following.
- When connecting a memory device such as a USB memory to the monitor, do not change the
setting. The data may be lost and damaged. Be sure to change the USB setting after removing the
memory device.
- When an application such as a sound playback, etc. works, do not change the setting. The sound
may not output when the setting is returned to the original. Be sure to change the USB setting after
exiting from the application.
1. Touch .
The Setting menu appears.
2. Select the <USB> icon and tap the slide bar.
The <USB> menu appears.
3. Trace the slide bar left and right to select the setting.
4. After the setting is completed, tap the slide bar.
The USB setting is completed.
5. Touch .
The Setting menu quits.
 Sound volume is too high/too low [Volume]
Adjust the volume.
1. Tap the slide bar.
The Volume menu appears.
2. Trace the slide bar left and right to adjust the volume.
Tracing the slide bar to the left makes the sound volume
low and right makes it high.
Attention
• Turn off the monitor if you do not use the monitor for a long time. Unplugging the power cord
completely shuts off power supply to the monitor.
USB menu
Volume menu
Prior to use Installation TroubleshootingSetting/Adjustment

14
English
Prior to use Installation TroubleshootingSetting/Adjustment
Selecting Display Mode
Switching the color mode allows you to set the appropriate display mode easily.
Color Mode
(For PC input signal)
Text Suitable for displaying text for word processing or spreadsheets.
Picture Suitable for displaying images such as photos or picture images.
Movie Suitable for playing back animated images.
Custom (PCx*)Available for making desired settings.
sRGB Suitable for color matching with sRGB compatible peripherals.
(For VIDEO input signal)
Standard Standard video display.
Soft Suitable for cinema effect, etc.
Dynamic Suitable for a clearly outlined image.
Custom
(VIDEOx*)Available for making desired settings.
* The input selected at that time is displayed.
1 Touch .
The Setting menu appears.
2 Select the <Color> icon and tap the slide bar.
The <Color> menu appears.
3 Select the <Color Mode> icon and tap the slide
bar.
The <Color Mode> menu appears.
4 Trace the slide bar left and right to select the
mode.
5 Tap the slide bar at the desired color mode.
The selected mode is set.
6 Touch .
The Setting menu quits.
Color menu
Color Mode menu

15
English
Prior to use Installation TroubleshootingSetting/Adjustment
Adjusting Brightness
BrightRegulator
The screen brightness is automatically adjusted corresponding to both the brightness of the image and the environmental
brightness detected by the sensor at the lower side of the monitor.
Manual Setting
1 Touch .
The Setting menu appears.
2 Select the <Color> icon and tap the slide bar.
The <Color> menu appears.
3 Select the <Brightness> icon and tap the slide
bar.
The <Brightness> menu appears.
4 Trace the slide bar left and right to adjust the
brightness.
Tracing the slide bar to the left makes the brightness dark and
right does it bright.
5 Tap the slide bar at the desired brightness.
The specified brightness is saved.
6 Touch .
The Setting menu quits.
Attention
• Do not cover the sensor.
Color menu
Brightness menu
The basic settings and adjustments are completed. For advanced settings/adjustments,
refer to the User’s Manual on the CD-ROM.

16
English
Prior to use Installation Setting/Adjustment Troubleshooting
No-Picture Problem
If no picture is displayed on the monitor even after the following remedial action is taken, contact your local dealer.
1. Check the Power indicator.
Symptom Status Possible cause and remedy
No picture Power indicator does not light
up.
Check whether the power cord is correctly
connected.
Touch .
Power indicator lights orange. Switch the input signal with .
(When PC signal is input,)
Press a key on the keyboard or click the mouse.
Turn on the PC.
(When VIDEO signal is input,)
Turn on the AV equipment.
Power indicator lights blue. Check whether the external equipment is
properly connected to the monitor.
(When PC signal is input,)
Check the gain* setting.
(When VIDEO signal is input,)
Check the field rate* setting.
* For details of the gain adjustment and field rate setting, please refer to the User’s Manual on the CD-ROM.
2. Check the error message that remains on the screen.
These messages appear when the input signal is incorrect even if the monitor is functioning.
Symptom Status Possible cause and remedy
The frequency of the signal
sent from the PC is outside the
specification.
(Such signal frequency is
displayed in red.)
Change the mode appropriately using the
graphics board’s utility software. Refer to the
manual of the graphics board for details.
The frequency of the signal
sent from the AV equipment is
outside the specification.
(When VIDEO signal is input,)
Confirm the digital signal format by referring to
the manual of the equipment connected.

English
Setup Manual
Important: Please read this Setup Manual and the User’s Manual stored on the CD-
ROM carefully to familiarize yourself with safe and effective usage. Please
retain this manual for future reference.
Installationshandbuch
Wichtig: Lesen Sie dieses Installationshandbuch und das Benutzerhandbuch (auf
der CD-ROM) aufmerksam durch, um sich mit der sicheren und effizienten
Bedienung vertraut zu machen. Bewahren Sie dieses Handbuch zum
späteren Nachschlagen auf.
Deutsch

2
Deutsch
Fehlerbeseitigung Einstellungen/Justierung InstallationVor der Benutzung
FlexScan® HD2441W
Lautsprecher
(mit integriertem Verstärker)
Ermöglicht die Tonausgabe über einen
angeschlossenen PC oder AV-Geräte usw.
• Anschlussmethoden ............. Seite 10
HINWEIS
• Ermöglicht das Anpassen der Lautstärke der
an den Monitor angeschlossenen
Lautsprecher mithilfe der Funktion zum
Einstellen der Lautstärke des
Monitors. .............................. Seite 13
• Ermöglicht die Tonausgabe durch
Anschließen eines Kopfhörers an die
Kopfhörerbuchse. ................. Seite 10
USB-Geräte
Tastatur
• Anschlussmethoden ................ Seite 9
(Auch für den Anschluss eines Druckers
oder Scanners usw.)
Hinweis
• Verwenden Sie einen PC/ein
Betriebssystem, der bzw. das mit USB-
Geräten kompatibel ist.
[Für OS]
- Windows 2000/XP/Vista
- Mac OS 8.5.1 oder höher
Maus
PC
Ermöglicht die Verwendung eines Monitors
durch Anschließen an einen Windows-PC oder
Macintosh.
• Geeignete Auflösung .............Seite 3
• Anschlussmethoden ...............Seite 8
Hinweis
• Je nach verwendetem PC muss die USB-
Einstellung geändert werden. ...Seite 13
HD2441W
AV-Geräte
HDMI-Anschluss
DVD-Playerusw.
Spielkonsoleusw.
Ermöglicht das Anzeigen von Bildern durch
Anschließen eines DVD-/Video-Players oder einer
Spielkonsole usw.
• Geeignetes Signalformat ............. Seite 3
• Anschlussmethoden .................... Seite 10
HD2441W kann an die folgenden Geräte angeschlossen werden:
