USER GUIDE
GPU WATER BLOCK
EK-Quantum
Vector² Master RTX 4080 D-RGB

Please note the installation of the product is intended to be undertaken
by an adequately trained and experienced person. You are installing the
product at your own risk. If you are not properly trained or experienced
or feel unsure about the installation procedure, please refrain from
installing the product yourself and contact our tech support for
assistance. We disclaim our liability for any damages to the product as
well as incidental, consequential, or indirect damages incurred due to
improper or inappropriate installation.
Before you start using this product, please follow these basic guidelines:
Carefully read the manual before beginning with the
installation process.
Remove your graphics card from the computer for the safest
mounting process to prevent any possible damage to your
GPU or its circuit board (PCB).
The EK Fittings require only a small amount of force to screw
them firmly in place since the liquid seal is ensured by the
rubber O-ring gaskets.
The use of corrosion-inhibiting coolants is always
recommended for liquid cooling systems and mandatory for
nickel-plated water blocks!
Do not use pure distilled water!
For best results, EK recommends the use of EK-CryoFuel
coolants! To reach optimal performance, make sure to
thoroughly bleed the air out of your water block!

- 3 -
TABLE OF CONTENTS
BOX CONTENTS 4
WATER BLOCK DIMENSIONS 5
TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS 6
NICKEL PLEXI 6
PREPARING THE GRAPHICS CARD 7
REMOVING THE STOCK COOLER 7
GeForce RTX™ 4080 GAMING OC 7
PREPARING THE WATER BLOCK FOR INSTALLATION 8
CUTTING AND PLACING THERMAL PADS 8
APPLYING THERMAL COMPOUND 9
ATTACHING THE WATER BLOCK 10
INSTALLING THE BACKPLATE 12
ATTACHING THE BACKPLATE 13
INSERTING THE GRAPHICS CARD INTO THE CHASSIS 13
FITTINGS AND TUBING 14
CONNECTING THE D-RGB LED STRIP 14
TESTING THE LOOP 15
WARRANTY 15
SUPPORT AND SERVICE 16
SOCIAL MEDIA 16

- 4 -
6 mm
Thermal Grease (1 pc)
BOX CONTENTS
4 mm
8 mm
10 mm
Allen Key 2.5 mm (1 pc) Allen Key 2 mm (1 pc)
EK-Loop Multi Allen Key (1 pc)
M2.5x8 AX1 Screw (1 pc)
M3x10 AX1 Screw (1 pc)EK-Quantum Vector2Master RTX 4080 D-RGB
M2.5x4 AX1 Screw (7 pcs)
Polyamid Washer M2.5
0.5mm (7 pcs)
M2.5x6 AX1 Screw (2 pc)
Standoff Ø4.5/2.5 (1 pc) Quantum Plug (2 pcs) Terminal OR 14x1 mm (2 pcs)
EK-Plug Out Spludger Tool (1 pc)
Standoff M2.5-M3 x 6.6mm
(1 pc)
Nut M2.5 (2 pcs)
EAN: 106236
EAN: 106046
Thermal Pad F 1.0 mm (5 pcs)
(3830046996732)
Thermal Pad G 2.0 mm (2 pcs)
(3830046996794)
Thermal Pad G 1.0 mm (4 pcs)
(3830046996770)
120 mm
16 mm
120 mm
24 mm
120 mm
24 mm

- 5 -
WATER BLOCK DIMENSIONS
272 mm
96 mm
124 mm
133 mm
142.5 mm
155 mm
27 mm
25.5 mm

- 6 -
TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS
NICKEL PLEXI
- Dimensions: (L x H x W): 272 x 155 x 27 mm
- D-RGB LED count: 14
- D-RGB cable length: 50 cm
- D-RGB connector 3-pin 5V digital LED header
(Pinout: +5V | Data | Blocked | Ground)
Position EAN Description Quantity
1106159 Coldplate (Nickel) 1
2106162 Backplate (BL. ELox) 1
3106400 Top plate (Plexi) 1
4103975 Bridge Plate 1
5103962 Plexi insert 1
6105975 LED Cover (Nat. Elox) 1
7105976 Main OR - 140 x 2 mm 1
8103971 Stand Out (Acetal) 1
9103964 Mylar sticker 2
10 100663 EK - Badge 2
11 8208 Screw M3 x 8 7991DIN 2
12 104188 Standoff 4.5/2.5 mm 6
13 104187 Screw M2.5 x 8 AX1 6
14 103986 Standoff M3.5-M2.5 x 11.3 mm 7
15 103987 Standoff M3.5-M2.5 x 3 mm 1
16 103988 Standoff M4-M2.5 x 3 mm 4
17 9013 Screw M4 x 8 DIN7984 14
18 103947 FC Terminal (Acetal) 1
19 8311 Screw M4 x 20 DIN7984 3
20 103942 Terminal Badge 1
21 104216 Disc magnet 3 x 3 2
22 104106 Terminal OR - 14 x 1 mm 2
23 105978 PCB cardboard 1
24 101556 LED D-RGB strip 500/300 mm 1
20
16
12
10
11
8
19
1
23
2
17
7
14
21
18
9
22
3
24
15
4
5
13
6

- 7 -
PREPARING THE GRAPHICS CARD
REMOVING THE STOCK COOLER
GeForce RTX™ 4080 GAMING OC
Important! Before starting, make sure to have a clean,
flat surface to work on. It is recommended to put foam or
soft material to lay the graphics card on.
STEP 1
First, unscrew the thirteen
(13) screws in order to remove
the stock cooler from the
GPU PCB. After removing the
screws, the connectors must
be unplugged.
STEP 2
After connectors are unplugged, an additional seven (7) Screws
must be removed from the front side of the GPU PCB. Finally,
unscrew four (4) I/O Bracket screws from the side of the GPU PCB.
Remove the stock backplate and I/O Bracket. I/O Bracket and five (5)
screws will be reused later. Make sure to remove all the thermal pads
and thermal grease from the GPU PCB.
STEP 1
STEP 2
Phillips Head Screwdriver
For this step, you will need:
Phillips Head Screwdriver
For this step, you will need:
SAVE FOR LATER STEPS

- 8 -
Phillips Head Screwdriver
PREPARING THE WATER BLOCK FOR INSTALLATION
STEP 1
Unscrew six (6) Screws AX1 M2.5 x 8 mm. Remove the backplate
together with the Screws and backplate standoffs. Standoffs must
stay on Screws AX1 M2.5 x 8 mm. Remove PCB cardboard. Save the
removed parts for later steps.
Do not remove standoffs from screws! In case the
standoff detaches from the screw, replace it with a spare
one. When replacing the standoff make sure that you
screw it on the AX1 M2.5 x 8 screws. Do not push the
standoff onto the screw AX1 M2.5 x 8 mm.
STEP 1
For this step, you will need:
BACK PL AT E
M2.5 x 8 AX1
BACK PL AT E
STAN DO FF
DO NOT REMOVE
STANDOFFS
FROM SCREWS!
PCB CARDBOARD
STEP 1
CUTTING AND PLACING THERMAL PADS
STEP 1
The GPU water block comes with thermal pads that have to be cut
into smaller pieces to cover all the VRM components, such as COILs,
MOSFETs, and drivers.
Remove the protective foil from both sides of the thermal
pad before installation.
Replacement thermal pads:
Thermal Pad F 1.0 mm – (120 x 16 mm) EAN:3830046996732
Thermal Pad G 1.0 mm – (120 x 24 mm) EAN: 3830046996770
Thermal Pad G 2.0 mm – (120 x 24 mm) EAN: 3830046996794
Thermal Pad F – 1.0 mm (120 x 16 mm)
120 mm
16 mm
1 mm
Thermal Pad G – 1.0 mm (120 x 24 mm)
120 mm
24 mm
1.0 mm
Thermal Pad G – 2.0 mm (120 x 24 mm)
120 mm
24 mm
2 mm

- 9 -
STEP 2
Once cut to the size, Thermal Pads should be placed on the PCB, as
shown in the picture:
Before attaching the PCB to the Water Block, make sure
all the Thermal Pads are placed correctly!
STEP 2
Thermal Pad - 120 x 16 x 1.0 mm
F1
Thermal Grease
STEP 1
Apply the enclosed thermal grease (thermal compound) on the GPU
heat spreader – IHS – as shown in the image. The layer of the thermal
compound must be thin and even over the entire surface of the IHS.
The excessive or uneven application of thermal grease
may lead to poor performance!
APPLYING THERMAL COMPOUND
For this step, you will need:
STEP 1

- 10 -
ATTACHING THE WATER BLOCK
STEP 1
The factory-provided I/O Bracket must be reused before placing the
water block onto the GPU PCB.
STEP 1
STEP 2
Carefully position the water block with preinstalled standoffs on the
graphics card. During this process, make sure you have aligned the
mounting holes of the PCB with the holes of the water block.
Pay attention not to use too much force when pressing
the block down to the PCB since chip dies are prone
to cracking.
Before attaching the PCB to the Water Block, make sure
all the Thermal Pads are placed correctly!
STEP 2
Phillips Head
Screwdriver
I/O Bracket Screw
(5 pcs) I/O Bracket
For this step, you will need:
FACTORY-
PROVIDED I/O
BRACKET SCREW
FACTORY-
PROVIDED I/O
BRACKET SCREW

- 11 -
Screws must be present in the places marked on the picture.
6 mm
STEP 3
Use five (5) M2.5 x 4 AX1 Screws and five (5) PVC washers to tighten
the PCB on the water block. An additional one (1) M2.5 x 6 AX1 Screw
must be used without the PVC Washer (Marked in the picture).
Tighten the screws evenly using the Phillips-head screwdriver. EK
recommends you start tightening the screws around the GPU core
first, and then continuing outward to prevent damage to the GPU.
M2.5 x 4 AX1 SCREW M2.5 PVC WASHER
For this step, you will need:
Polyamide Washer
(5 pcs)
M2.5 x 4 AX1
Screw (5 pcs)
M2.5 x 6 AX1
Screw (1 pc)
4 mm
Phillips Head
Screwdriver
STEP 3
M2.5 x 6 AX1 SCREW
WITHOUT PVC WASHER
WITHOUT PVC WASHER

- 12 -
STEP 2
Apply the thermal pads onto the backplate as shown in the image.
STEP 2
INSTALLING THE BACKPLATE
STEP 1
STEP 1
After attaching the water block, a few more thermal pads need to be
cut into smaller pieces to cover all the necessary components. EK
made sure to provide you with more than an adequate quantity of
thermal pads to complete this step.
CAUTION: You must remove the protective foil from both
sides of the thermal pad before installation.
Replacement thermal pads:
Thermal Pad F 1.0 mm – (120 x 16 mm) EAN:3830046996732
Thermal Pad G 1.0 mm – (120 x 24 mm) EAN: 3830046996770
Thermal Pad G 2.0 mm – (120 x 24 mm) EAN: 3830046996794
Thermal Pad - 120 x 24 x 1.0 mm
G1
Thermal Pad - 120 x 24 x 2.0 mm
G2
G1
G1
G1
G2
G2
G1
G2
Thermal Pad F – 1.0 mm (120 x 16 mm)
120 mm
16 mm
1 mm
Thermal Pad G – 1.0 mm (120 x 24 mm)
120 mm
24 mm
1.0 mm
Thermal Pad G – 2.0 mm (120 x 24 mm)
120 mm
24 mm
2 mm

- 13 -
For this step, you will need:
Phillips Head Screwdriver
ATTACHING THE BACKPLATE
STEP 1
STEP 1
Position the Backplate (including screws and standoffs) onto
the GPU PCB. Make sure all the holes are aligned. Tighten the
screws evenly.
Before attaching the backplate, make sure all the Thermal Pads
are placed correctly!
Do not use excessive force!
INSERTING THE GRAPHICS CARD INTO THE CHASSIS
Carefully lift your graphics card with the installed water block and
insert it into your PC’s motherboard PCI Express expansion slot.
Please keep in mind that your graphics card is heavier than before it
was equipped with the water block.
You need to be very careful when handling the graphics
card. Avoid all unnecessary manipulation of the water block
assembly that might damage your card or water block.
BACK PL AT E

- 14 -
CONNECTING THE D-RGB LED STRIP
STEP 1
Plug the 3-pin connector of the distribution plate D-RGB LED
light to the D-RGB HEADER on the motherboard. The LED will
work if the pin layout on the header is as follows: +5V, Digital,
Empty, Ground.
Incorrect installation or installation to a wrong header can
damage the LED strip or the header itself!
STEP 1
D-RGB HEADER
RGB HEADER
FITTINGS AND TUBING
Screw in two (2) G1/4 threaded male fittings. Attach the liquid
cooling tubes and connect the water block to the cooling loop.
Do not forget to plug the remaining two openings using
the enclosed EK-Plug G1/4 or its equivalent.
EK recommends using EK fittings with all EK water blocks.
CAUTION: When using connectors other than EK fittings,
pay special attention to the length of the fittings’ male G1/4”
thread – 5mm is the maximum G1/4” thread length allowed!
TUBING
EK- PLUG G1/4
EK-FITTING
For this step, you will need:
EK-Loop Multi Allen Key

- 15 -
Our products are warranted against defects of materials and quality
for a period of 24 months, starting with the date of delivery to the
end-user. During this period, products will be repaired or have parts
replaced at our discretion, provided that 1) the product is returned
to the agent from whom it was purchased; 2) the product has been
purchased by the end-user and has not been used for commercial
purposes; 3) the product has not been misused, handled
carelessly, or used in a manner other than the way described in
the instruction’s manual. This warranty does not confer rights
other than those expressly set out above and does not cover any
claims for consequential loss or damage. This warranty is offered
as an extra benefit and does not affect your statutory rights as a
consumer. This warranty is voided if the product comes in contact
with aggressive UV additives or other improper liquids. EK Water
blocks are sealed with a warranty-voiding circular label, proving
the water block has withstood a pressure leak test. Removing the
label will void the leak-free guarantee, but not the guarantee on
the product itself. Any other RMA issues can be reported to EK
Customer Support at www.ekwb.com/support for further analysis.
WARRANTY
To make sure the installation of EK components was successful, we
recommend you perform a leak test for 24 hours. When your loop
is complete and filled with coolant, connect the pump to a PSU
outside of your system. Do not connect power to any of the other
components. Turn on the PSU and let the pump run continuously.
It is normal for the coolant level to drop during this process as air
collects in the distribution plate. Inspect all parts of the loop, and in
the eventuality, that the coolant leaks, fix the issue and repeat the
testing process. Ensure that all hardware is dry before the system is
powered on in order to prevent any damage.
TESTING THE LOOP

In case you need assistance or wish to order spare parts or a new
mounting mechanism, please contact:
https://www.ekwb.com/customer-support/
For spare parts orders, refer to the page with “TECHNICAL
SPECIFICATIONS AND WATER BLOCK PARTS” where you can find
the EAN number of each part you might need.
Include the EAN number with quantity in your request. Mounting
Mechanism EAN can be found under “BOX CONTENTS”
Thermal pads are readily available in the EK shop
EKWaterBlocks
@EKWaterBlocks
ekwaterblocks
ekwaterblocks
EKWBofficial
SUPPORT AND SERVICE
SOCIAL MEDIA
