EK-Quantum Vector2 Strix RTX 3080 D-RGB User manual

USER GUIDE
GPU WATER BLOCK
EK-Quantum
Vector² Trio RTX 3070 Ti D-RGB

Please note the installation of the product is intended to be undertaken
by an adequately trained and experienced person. You are installing the
product at your own risk. If you are not properly trained or experienced
or feel unsure about the installation procedure, please refrain from
installing the product yourself and contact our tech support for
assistance. We disclaim our liability for any damages to the product as
well as incidental, consequential, or indirect damages incurred due to
improper or inappropriate installation.
Before you start using this product, please follow these basic guidelines:
Carefully read the manual before beginning the installation
process.
Remove your graphics card from the computer for the safest
mounting process to prevent any possible damage to your
GPU or its circuit board (PCB).
The EK Fittings require only a small amount of force to screw
them firmly in place since the liquid seal is ensured by the
rubber O-ring gaskets.
The use of corrosion inhibiting coolants is always
recommended for liquid cooling systems and mandatory for
nickel-plated water blocks!
Do not use pure distilled water! For best results, EK
recommends the use of EK-CryoFuel coolants!
To reach optimal performance, make sure to thoroughly
bleed the air out of your water block!

- 3 -
TABLE OF CONTENTS
BOX CONTENTS 4
WATER BLOCK DIMENSIONS 5
TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS 6
NICKEL PLEXI 6
PREPARING THE GRAPHICS CARD 7
REMOVING THE STOCK COOLER 7
PREPARING THE WATER BLOCK FOR INSTALLATION 7
CUTTING AND PLACING THERMAL PADS 8
APPLYING THERMAL COMPOUND 9
ATTACHING THE WATER BLOCK 9
PREPARING THE BACKPLATE 11
ATTACHING THE BACKPLATE 12
INSERTING THE GRAPHICS CARD INTO THE CHASSIS 12
FITTINGS AND TUBING 13
CONNECTING THE D-RGB LED STRIP 14
TESTING THE LOOP 14
WARRANTY 15
SUPPORT AND SERVICE 16
SOCIAL MEDIA 16

- 4 -
BOX CONTENTS
4 mm
8 mm
EK-Loop Multi Allen Key (1 pc) Allen Key 2 mm (1 pc)
Allen Key 2.5 mm (1 pc)
Thermal Pad F 1.0 mm (4 pcs)
(3830046996732)
Thermal Pad G 1.5 mm (3 pcs)
(3830046996787)
Thermal Grease (1 pc)
EK-Quantum Vector2Trio RTX 3070 Ti D-RGB
M2.5x4 AX1 Screw (13 pcs)
Terminal OR - Vector
2
14x1 mm (2 pcs)
120 mm
24 mm
120 mm
16 mm
Standoff Ø4.5/2.5 (1 pc)
Quantum Plug (2 pcs)
EK-Plug Out Spludger Tool (1 pc)
EAN: 104910
EAN: 104549
M2.5x8 AX1 Screw (1 pc)
Polyamid Washer M2.5 0.5mm (13 pcs)

- 5 -
WATER BLOCK DIMENSIONS
301 mm
177 mm
205 mm
155 mm
142.5 mm
27 mm

- 6 -
TECHNICAL SPECIFICATIONS AND WATER BLOCK PARTS
NICKEL PLEXI
- Dimensions: (LxHxW): 301 x 155 x 27 mm
- D-RGB cable length: 50 cm
- D-RGB connector 3-pin 5V digital LED header (Pinout: +5V | Data |
Blocked | Ground)
Position EAN Description Quantity
1104376 Coldplate (Nickel) 1
2104377 Top plate (Plexi) 1
3103947 FC Terminal (Acetal) 1
4104384 Backplate (Bl. Elox) 1
5103971 Standout (Acetal) 1
6100663 EK- Badge 2
7103964 Mylar sticker 2
88208 Screw M3 x 8 7991DIN 2
9103975 Bridge Plate 1
10 103962 Plexi insert 1
11 103986 Standoff M3.5-M2.5 x 11.3 mm 6
12 103988 Standoff M4-M2.5 x 3 mm 4
13 103987 Standoff M3.5-M2.5 x 3 mm 2
14 104188 Standoff fi 4.5/2.5 6
15 104187 Screw M2.5 x 8 AX1 6
16 9013 Screw M4 x 8 DIN7984 12
17 104106 Terminal O-ring 14 x 1 2
18 104216 Disc magnet 3 x 3 2
19 103942 Terminal Badge 1
20 8311 Screw M4 x 20 DIN7984 3
21 104441 Main O-ring 135 x 2 mm 1
22 104380 LED Cover (N.elox) 1
23 101556 LED D-RGB strip 500/300 mm 1
24 104903 PCB cardboard 1
19
11
15
18
17
7
8
24
20
16
12
14
3
21
1
4
2
9
22
23
13
10
5
6

- 7 -
PREPARING THE WATER BLOCK FOR INSTALLATION
STEP 1
Unscrew six (6) Screws M2.5 x 8 AX1. Remove the backplate
together with six (6) Screws M2.5 x 8 AX1 and backplate standoffs.
Standoffs must stay on Screws M2.5 x 8 AX1. Remove cardboard.
Save the backplate for later steps.
Do not remove standoffs from screws! In case the
standoff detaches from the screw, replace it with a
spare one. When replacing the standoff make sure
that you screw it on the AX1 M2.5 x 8 screws. Do not
push the standoff onto the screw AX1 M2.5 x 8!
STEP 1
For this step, you will need:
Phillips Head Screwdriver
M2.5 x 8 AX1
SCREW
BACK PL AT E S TAND OF F
DO NOT REMOVE
STANDOFFS
FROM SCREWS!
BACK PL AT E
PCB
CARDBOARD
PREPARING THE GRAPHICS CARD
REMOVING THE STOCK COOLER
Place your graphics card on the flat surface and carefully remove
the stock cooler. Do not forget to unplug all the LED and fan
connectors. Pay attention to the following steps in order to install
the EK-Quantum Vector2 Trio RTX 3070 Ti water block onto the
graphics card.

- 8 -
CUTTING AND PLACING THERMAL PADS
Thermal Pad G – 1.5 mm (120 x 24 mm)
120 mm
24 mm
1.5 mm
Your EK-Quantum Vector2TRIO RTX 3070 Ti D-RGB block comes
with Thermal Pads that have to be cut into smaller pieces to cover all
the VRM components. EK made sure to provide you with more than
an adequate quantity of Thermal Pads to complete this Step.
CAUTION: You must remove the protective foil from both
sides of the thermal pad before installation.
Replacement thermal pads:
Thermal Pad F 1.0 mm – (120 x 16 mm) EAN: 3830046996732
Thermal Pad G 1.5 mm – (120 x 24 mm) EAN: 3830046996787
For this step, you will need:
Scissors
Thermal Pad F – 1.0 mm (120 x 16 mm)
120 mm
16 mm
1 mm
STEP 2
The cardboard is printed in scale 1:1. Cut Thermal Pads to the
size printed on the cardboard. Once cut to the size, Thermal Pads
should be placed on the GPU PCB, as shown in the picture.
STEP 2
Thermal Pad - 120 x 16 x 1.0 mm
F1
STEP 1
F1
F1
F1
F1
F1

- 9 -
Thermal Grease
STEP 1
Apply the enclosed EK-TIM Ectotherm thermal grease (thermal
compound) on the GPU heat spreader – IHS – as shown in the
image. The layer of the thermal compound must be thin and even
over the entire surface of the IHS.
The excessive or uneven application of thermal grease
may lead to poor performance!
STEP 1
APPLYING THERMAL COMPOUND
For this step, you will need:
ATTACHING THE WATER BLOCK
STEP 1
Carefully position the water block with preinstalled standoffs on
the graphics card. During this process, make sure you have aligned
mounting holes of the PCB with holes of the water block.
Before placing the Water Block, make sure all the Thermal
Pads are placed correctly!
STEP 1

- 10 -
M2.5 PVC WASHER
Screws must be present in the places marked on the picture.
For this step, you will need:
Phillips Head Screwdriver
STEP 2
Use six (6) M2.5 x 4 AX1 Screws and PVC washers to tighten the
PCB on the water block. Tighten the screws evenly using the
Phillips head screwdriver.
EK recommends you start tightening the screws around the GPU core
first, and then continuing outward to prevent damage to the GPU.
STEP 2
M2.5 x 4 AX1 SCREW

- 11 -
PREPARING THE BACKPLATE
STEP 1
After attaching the water block, a few more thermal pads need to be
cut into smaller pieces to cover all the necessary components.
EK made sure to provide you with more than an adequate quantity of
thermal pads to complete this step.
CAUTION: You must remove the protective foil from both
sides of the thermal pad before installation.
Replacement thermal pads:
Thermal Pad F 1.0 mm – (120 x 16 mm) EAN: 3830046996732
Thermal Pad G 1.5 mm – (120 x 24 mm) EAN: 3830046996787
For this step, you will need:
Scissors
Thermal Pad G – 1.5 mm (120 x 24 mm)
120 mm
24 mm
1.5 mm
Thermal Pad F – 1.0 mm (120 x 16 mm)
120 mm
16 mm
1 mm
STEP 2
Apply the thermal pads onto the GPU PCB as shown in the image.
STEP 2
STEP 1
Thermal Pad - 120 x 16 x 1.0 mm
F1
Thermal Pad - 120 x 24 x 1.5 mm
G1.5
F1
F1 F1
G1.5 G1.5
F1

- 12 -
For this step, you will need:
Phillips Head Screwdriver
ATTACHING THE BACKPLATE
STEP 1
STEP 1
Place the backplate with six (6) M2.5 x 8 AX1 Screws and Standoffs
onto the PCB. Make sure all the holes are aligned.
INSERTING THE GRAPHICS CARD INTO THE CHASSIS
Carefully lift your graphics card with the installed water block and
insert it into your PC’s motherboard PCI Express expansion slot.
Please keep in mind that your graphics card is heavier than before it
was equipped with the water block.
You need to be very careful when handling the graphics
card. Avoid all unnecessary manipulation of the water block
assembly that might damage your card or water block.
BACK PL AT E

- 13 -
FITTINGS AND TUBING
STEP 1
Screw-in two (2) G1/4 threaded male fittings. Attach the liquid
cooling tubes and connect the water block to the cooling loop.
Do not forget to plug the remaining two openings using
the enclosed EK-Plug G1/4 or its equivalent.
EK recommends using EK fittings with all EK water blocks.
CAUTION: When using connectors other than EK
fittings, pay special attention to the length of the fittings’
male G1/4” thread – 5mm is the maximum G1/4” thread
length allowed!
STEP 1
TUBING
EK- PLUG G1/4
EK-FITTING For this step, you will need:
EK-Loop Multi Allen Key

- 14 -
CONNECTING THE D-RGB LED STRIP
STEP 1
Plug the 3-pin connector of the distribution plate D-RGB LED
light to the D-RGB HEADER on the motherboard. The LED will
work if the pin layout on the header is as follows: +5V, Digital,
Empty, Ground.
Incorrect installation or installation to a wrong header can
damage the LED strip or the header itself!
STEP 1
D-RGB HEADER
RGB HEADER
To make sure the installation of EK components was successful, we
recommend you perform a leak test for 24 hours. When your loop
is complete and filled with coolant, connect the pump to a PSU
outside of your system. Do not connect power to any of the other
components. Turn on the PSU and let the pump run continuously.
It is normal for the coolant level to drop during this process as air
collects in the distribution plate. Inspect all parts of the loop, and
in the eventuality that coolant leaks, fix the issue and repeat the
testing process. Ensure that all hardware is dry before the system is
powered on in order to prevent any damage.
TESTING THE LOOP

- 15 -
Our products are warranted against defects of materials and
quality for a period of 24 months, starting with the date of delivery
to the end-user. During this period, products will be repaired
or have parts replaced at our discretion, provided that 1) the
product is returned to the agent from whom it was purchased;
2) the product has been purchased by the end-user and has not
been used for commercial purposes; 3) the product has not been
misused, handled carelessly, or used in a manner other than the
way described in the instructions manual. This warranty does not
confer rights other than those expressly set out above and does not
cover any claims for consequential loss or damage. This warranty
is offered as an extra benefit and does not affect your statutory
rights as a consumer. This warranty is voided if the product
comes in contact with aggressive UV additives or other improper
liquids. EK water blocks are sealed with a warranty-voiding circular
label, proving the water block has withstood a pressure leak test.
Removing the label will void the leak-free guarantee, but not the
guarantee on the product itself. Any other RMA issues can be
reported to EK Customer Support at www.ekwb.com/support
for further analysis.
WARRANTY

In case you need assistance or wish to order spare parts or a new
mounting mechanism, please contact:
https://www.ekwb.com/customer-support/
For spare parts orders, refer to the page with “TECHNICAL
SPECIFICATIONS AND WATER BLOCK PARTS” where you can find
the EAN number of each part you might need.
Include the EAN number with quantity in your request. Mounting
Mechanism EAN can be found under “BOX CONTENTS”
Thermal pads are readily available in the EK shop
EKWaterBlocks
@EKWaterBlocks
ekwaterblocks
ekwaterblocks
EKWBofficial
SUPPORT AND SERVICE
SOCIAL MEDIA
