USER GUIDE
EK-Loop
Fan FPT 120/140 FAN

Please note the installation of the product is intended to be undertaken
by an adequately trained and experienced person. You are installing the
productatyourownrisk.Ifyouarenotproperlytrainedorexperiencedorfeel
unsure about the installation procedure, please refrain from installing the
product yourself and contact our tech support for assistance. We disclaim
our liability for any damages to the product and incidental, consequential,
or indirect damages incurred due to improper or inappropriate installation.
Before you start using this product, please follow these basic guidelines:
Carefully read the manual before beginning with the installation
process.

- 3 -
TABLE OF CONTENTS
BOX CONTENTS 4
TECHNICAL SPECIFICATIONS AND DIMENSIONS 4
120 mm FAN 4
140 mm FAN 5
INSTALLING THE FAN DIRECTLY 5
INSTALLING THE FAN ON THE RADIATOR 6
EK-QUANTUM SURFACE RADIATOR 6
CONNECTING THE FANS 6
BASIC INFORMATION’S 6
SUPPORT AND SERVICE 10
SOCIAL MEDIA 10

- 4 -
BOX CONTENTS
EK-Loop Fan FPT 120 / 140 FAN
Extension cable (1 pc) FAN Self tapping screw (4 pcs)
TECHNICAL SPECIFICATIONS AND DIMENSIONS
105 mm
119.8 mm
119.8 mm
105 mm
26 mm
27 mm
120 mm FAN
- Max Air Flow: 77 CFM = 130.82 m³/h
- Static Pressure: 2.7 mm H20 = 26.81 Pa
- Noise Level: 36 dBA (max. RPM)

- 5 -
STEP 1
EK provides the four (4) self-tapping screws with each Fan. Use
the Phillips head screwdriver to tighten the screws (in a clockwise
direction). Don’t use excessive force while tightening the screws.
EK recommends using the EK-Loop Torque Screwdriver - 0.6Nm:
https://www.ekwb.com/shop/ek-loop-torque-screwdriver-0-6nm
INSTALLING THE FAN DIRECTLY
STEP 1
SELF-TAPPING
SCREW
FPT FAN
125 mm
139.5 mm
125 mm
139.5 mm
27 mm
26 mm
140 mm FAN
- Max Air Flow: 118.01 CFM = 200.5 m³/h
- Static Pressure: 3.57 mm H20 = 35 Pa
- Noise Level: 44.56dBA (max. RPM)

- 6 -
BASIC INFORMATION’S
CONNECTING THE FANS
FAN
CONNECTOR
FEMALE CONNECTOR
FEMALE CONNECTOR
MALE CONNECTOR
D-RGB
CONNECTOR
EK-QUANTUM SURFACE RADIATOR
In the case of using the EK-Quantum Surface radiators, selecting
the M4 x 30 Screws (enclosed with the radiator) is recommended to
secure the fans.
The number of enclosed screws depends on the radiator model.
Use the Phillips Head Screwdriver to tighten the screws in a clockwise
direction. Don’t use excessive force while tightening the screws.
INSTALLING THE FAN ON THE RADIATOR
M4 x 30 PHILLIPS
HEAD SCREW
EK-LOOP FAN
FPT
STEP 1
EK-QUANTUM
SURFACE RADIATOR

- 7 -
STEP 1
Connect the female connector from the extension cable to the
male connector from the fan.
Make sure to turn the Female connector correctly.
FEMALE
CONNECTOR
MALE CONNECTOR
STEP 1

- 8 -
STEP 1
*In case of using multiple fan-s, connect fan-s in series with the
“daisy-chain”.
Make sure to turn the female connector correctly.
FEMALE
CONNECTOR
MALE CONNECTOR
STEP 1
STEP 2
After connecting the extension cable with the fan, connect the
4-pin fan connector from the extension cable directly to the CPU
fan header on the motherboard.
Always use the CPU fan header. On the majority of
motherboards, these headers usually offer the best
PWM regulation.
STEP 2
FAN CONNECTOR

- 9 -
STEP 3
Plug the 3-pin D-RGB connector from the extension cable into the
D-RGB header on the motherboard.
Please ensure that the arrow indicated on the connector is
plugged into the +5V line as indicated on your motherboard.
If you put LED Diode to the 12V RGB HEADER you can
damage the LEDs.
D-RGB HEADER
RGB HEADER
STEP 3

In case you need assistance or wish to order spare parts or a new
mounting mechanism, please contact:
https://www.ekwb.com/customer-support/
EKWB d.o.o.
Pod lipami 18
1218 Komenda
Slovenia - EU
