Elan S8.6 AVP User manual



ii © ELAN Home Systems 2007 • All rights reserved.
S8.6AVP Multi-Room A/V Controller ELAN HOME SYSTEMS
Preface
Purpose of This Manual
This manual provides step-by-step installation instructions and connection examples, along with basic user informa-
tion for installation and ongoing use of the System8.6AV Integrated Multi-Room Controller. This manual is written for
the installer of this equipment.
Organization
The following information is contained in this manual:
Safety Information Provides a comprehensive list of safety practices and procedures allowing for
the safe installation and operation of ELAN Home Systems’ System8.6 Multi-
Room A/V Controller.
System8.6 Introduction Provides an introduction to ELAN Home Systems’ System8.6 Integrated Multi-
Room A/V Controller (S8.6), along with system features to include Front and
Rear panel controls, indicators and connections, along with a short descrip-
tion of each.
System8.6 System Design
Overview
Provides a system design application overview of the System8.6 Integrated
Multi-Room A/V Controller for use in audio, video and automation applica-
tions.
System8.6 Connections Provides a description of S8.6 system connections to included connections
made with an ELAN System Precision Panel (SPP) and direct connections from
the S8.6 to all other components.
Troubleshooting Provides troubleshooting tables to help fix common discrepancies that may
be associated with the S8.6.
Specifications Appendix A provides equipment specifications for the System8.6 Integrated-
Multi-Room A/V Controller.
Programming Appendix B provides a basic overview of steps necessary to download pro-
gramming information from VIA!®TOOLS Setup software to the S8.6
RS-232 Protocol Appendix C contains all information necessary to create RS-232 command
structures when controlling the S8.6 with a third-party RS-232 control device.

© ELAN Home Systems 2007 • All rights reserved. iii
ELAN HOME SYSTEMS S8.6AVP Multi-Room A/V Controller
Safety Information
RISK OF ELECTRIC SHOCK
DO NOT OPEN!
WARNING
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to
alert the user to the presence of uninsulated "dangerous voltage" within the product's
enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instruction in the literature accompanying
the appliance.
CAUTION
SOME DETACHABLE POWER CORD SOCKETS HAVE THIS FUSE SYMBOL
WHICH INDICATES THERE IS A REPLACEABLE FUSE WITHIN THE SOCKET.
FOR SAFETY PURPOSES REPLACE ONLY WITH SPECIFIED FUSE.
IMPORTANT SAFETY INFORMATION
Read Information
—All the safety and operating information should be read before the appliance is operated.
Follow Information
—All operating and use information should be followed.
Retain Information
—The safety and operating information should be retained for future reference.
Heed Warnings
—All warnings on the appliance and in the operating instructions should be heeded.
Wall Mounting
—Mounting of this appliance should be done only by an authorized installer.
Ventilation
—The appliances should be situated so that their location or position does not interfere with their proper
ventilation. These appliances should never be placed near or over a radiator or heat register. These appliances should
not be placed in a built-in installation such as a bookcase or cabinet that may impede the flow of air through the ven-
tilation openings.
Non-Use Periods
—Appliances that are left unattended and unused for long periods of time should be de-energized.
Grounding or Polarization
—Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one blade wider than the other blade. A grounding type plug has two blades and a third
grounding prong. The polarized wide blade and the third prong are provided for your safety. If the provided plug does
not fit your outlet, consult an electrician for replacement of the obsolete outlet.
Power Cord Protection—
Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles and the point where they exit from the apparatus.
Water—
Do not use the apparatus near water.

iv © ELAN Home Systems 2007 • All rights reserved.
S8.6AVP Multi-Room A/V Controller ELAN HOME SYSTEMS
Cleaning
—Unplug the apparatus from the power outlet before cleaning. Use only a dry cloth to clean the apparatus.
Power Lines
—An outdoor antenna should be located away from power lines. When installing an outside antenna
system, extreme care should be taken to avoid touching power lines or circuits, as contact with them may be fatal.
Object and Liquid Entry
—Never insert objects of any kind through the openings of these appliances, as they may
touch dangerous voltage points or short-out parts that could result in a fire or electric shock. Care should be taken so
that objects do not fall and liquids are not spilled into the appliance through openings in the enclosure.
Servicing
—Do not attempt to service these appliances yourself, as opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
Damage Requiring Service
—These appliances should be serviced by qualified service personnel when:
• A power supply connection or a plug has been damaged or
• If liquid has been spilled into the appliance or objects have fallen into the appliance or
• The appliance has been exposed to water or moisture or
• The appliance does not appear to operate normally or exhibits a marked change in performance or
• The appliance has been dropped or the enclosure damaged.
Replacement Parts—
When replacement parts are required, be sure the service technician has used replacement
parts specified by the manufacturer or that have the same characteristics as the original part. Unauthorized substitu-
tions may result in fire, electric shock, or other hazards. The Master Control Unit battery should be replaced only after
turning the power off and only by an authorized installer.
Safety Check—Upon completion of any service or repairs to this audio product, ask the service technician to perform
safety checks to determine that the audio product is in proper operating condition.
Lightning Storms—
Unplug this apparatus during lightning storms or when unused for long periods of time.
Attachments and Accessories—
Use only attachments/accessories specified by the manufacturer.
Cart, Stand, Tripod, Bracket or Table—
Use only with a cart, stand, tripod, bracket or table speci-
fied by the manufacturer, or sold with the apparatus. When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip over.
Disconnect Device—
Where the mains plug or an appliance coupler is used as the disconnect
device, the disconnect device shall remain operable.
NOTE:
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not in-stalled
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Changes or modifications not expressly approved by Elan Home Systems could void the user's authority
to operate the equipment

© ELAN Home Systems 2007 • All rights reserved. v
