Elan STROBE-400-LEDMINI-RGB User manual

STROBE-400-LEDMINI-RGB
Thank you for purchasing a product from our STROBE-400-LEDMINI-RGB. Every suit has
been thoroughly tested and shipped in perfect condition. Carefully check the shipping carton
for damage that may have occurred during shipping. If the carton appears to be damaged,
carefully inspect your unit for any damage and be sure all accessories necessary to operate
the unit has arrived intactly. In the case damage has been found or parts are missing, please
contact Acson Comercial or your local supplier for further instructions. Do not return this unit
without any warning.
USER’S MANUAL

2
Contents
FOR YOUR OWN SAFETY, PLEASE READ
THIS USER MANUAL CAREFULLY BEFORE
POWERING OR INSTALLING. SAVE IT FOR
FUTURE REFERENCE
1. Safety Instructions........................................................................................3
2. Preparation For Use ....................................................................................3
3. DMX-512 Control Connection ......................................................................3
4. Specifications...............................................................................................4
5. Operation.....................................................................................................5
6. DMX Control Summary................................................................................6
7. DMX Functions and Values .........................................................................6
8. Cleaning And Maintenance .........................................................................8
9. Installation ...................................................................................................9
10. Technical Specifications ............................................................................9

3
1. Safety Instructions
2. Preparation For Use
3. DMX-512 Control Connection
• This device has left the factory in perfect condition. In order to maintain this condition and to ensure a
safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes
written in this user manual.
• This device falls under protection-class I. Therefore it is essential that the device should be earthed.
• The electric connection must carry out by qualified person.
• If the external flexible cable or cord of this luminaire is damaged, it shall be exclusively replaced by the
manufacturer or his service agent or a similar qualified person in order to avoid a hazard.
• Make sure that the available voltage is not higher than stated at the end of this manual.
• Make sure the power cord is never crimped or damaged by sharp edges. If this would be the case,
replacement of the cable must be done by an authorized dealer.
• Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle the
power cord by the plug. Never pull out the plug by tugging the power cord.
Warning!
Never look directly into the light source, as sensitive persons may
suffer an epileptic shock.
!
UNPACKING
Thank you for choosing ELAN Lighting
Unpack the device, inside the box you should find:
• The fixture device
• One power cable
• One XLR connection cable
• This manual
Please check carefully that there is no damage caused by transportation. Should there be any, consult your
dealer and don’t install this device.
For installations where the DMX cable has to run a long distance or is in an electrically noisy environment,
such as in a discotheque, it is recommended to use a DMX terminator. This helps in preventing corruption of
the digital control signal by electrical noise. The DMX terminator is simply an XLR plug with a 120 OHM re-
sistor connected between pins 2 and 3, which is then plugged into the output XLR socket of the last fixture
in the chain.

4
AC Power Connection
• The auto-ranging power supply automatically adjusts to AC power from 110-240 volts nominal at 50/60
Hz.
• The current required by the STROBE-400-LEDMINI-RGB is 4.5 amps. To avoid overload, allow one 4.5
amp branch circuit per fixture to operate the STROBE-400-LEDMINI-RGB model at full power.
• Use 2.5 mm2 (14 AWG) or larger power feed cables and keep runs as short as possible.
• Do not link more than 4 fixtures for the one single power chain.
4. Specifications
Please note:
The brightness will decrease gradually when the led temperature is
over 55ºC, and if over 70ºC, then will black out.
Light Source
324pcs RGB/White 5050 LED, no ultraviolet
radiation
Life Time
More than 50000 hours for the LED light source
Output
35000 for white version,15000lm for RGB version
DMX mode
1/3/4/6/7/16
Dimmer
16Bit Dimmer
Operating Mode
DMX Mode /Master-slave mode
Power
AC110-240V 50/60Hz 300W
Cooling
Diecasting heatsink , Convection cooling, no fans,
no noise
Over Heat Protect
With temperature sensor to extend the lamp life
LED Scan Rate
7000Hz LED scan rate
Size
Compact size, 2.8kg
Effects:
• 9 segments LED/ 3 segments for RGB version,
can be controlled separately, with 16bit dimmer
• Flash duration can be set from 0 to 650ms in
DMX mode(except 1 channel mode) 0-30 flas-
hes per second
• Ramp up effect: Light gradually increases in
intensity, then blacks out
• Ramp down effect: Light flashes to full intensity,
then gradually fades.
• Ramp up-down effect: Light gradually increases
and decreases
• Radom flash effect: Light flashes randomly with
variable rate and intensity. Multiple units flash
independently of each other.
• Blinder effect: the light remains on (Lamp power
is electronically regulated to prevent the lamp
from overheating)
• Lightning effect: the flashes simulate lightning,
duration is not adjustable.
• Spikes: the lamp remains dimly illuminated
between flashes, set flash intensity, duration and
rate as normal.

5
5. Operation
Display Menu
Menu Sub-menu
Address Set DMX Address 001-512
Auto
Mode 1 Auto Mode 1
Mode 2 Auto Mode 2
Mode 3 Auto Mode 3
Mode 4 Auto Mode 4
Mode 5 Auto Mode 5
Mode6 Auto Mode 6
Speed 000-031 Auto Run Speed
Color
W1/Red 0-255
W2/Green 0-255
W3/Blue 0-255
Test LED
All on
All On + Individual LED Segment Testing
White1 /Red1 on
White2 /Red2 on
White3 /Red3 on
White4/Green1 on
White5/Green2 on
White6/Green3 on
White7/Blue1 on
White8/Blue2 on
White9/Blue3 on
Temp <ENTER> Internal Temperature
Time <ENTER> Total Run Time
Config
DMX Status
Value Hold
Holds the last DMX values if signal is lost
Value Clear
Clears the DMX values if signal is lost
Display Mode LCD Display ON or Auto OFF
Temp Unit CS Celsius degree and Fahrenheit degree for selection
Factory Settings W1-W9
Channel Mode
Channel 1 (1ch DMX mode)
Channel 3 (1ch DMX mode)
Channel 4 (1ch DMX mode)
Channel 6 (1ch DMX mode)
Channel 7 (1ch DMX mode)
Channel 16 (1ch DMX mode)
Pixel 3 (3ch DMX pixel control)
Pixel 9 (9ch DMX pixel control)
Key Mode
Key Lock
Menu buttons lock after 30sec of inactivity (push
more than once to temporarily unlock buttons).
Key Unlock
Menu buttons are not locked.
Load Default Load Default Resets all values to default

6
6. DMX Control Summary
7. DMX Functions and Values
Intensity
Flash intensity can be set from minimum (blackout) to maximum in all DMX modes except 1 channel mode
(where it is always at maximum intensity). A special pixel mode enables the fixture to be used as a blinder,
where the intensity of blinder colour can be set.
Duration
Flash duration can be set from 0 to 650 ms on 50 Hz power supplies, or 0 to 530 ms on 60 Hz power su-
pplies in 3, 4, 6 or 7 channel DMX modes. Flash duration is fixed in 1-channel DMX.
Rate
Flash rate can be set from 0 flashes per second to 25 flashes per second on 50 Hz power supplies or from
0 to 30 flashes per second on 60 Hz power supplies, when the fixture is set to 3, 4, 6 or 7 channel DMX
mode. The flash rate is also controllable in 1-channel DMX mode.
Programmed Effects
Six programmed effects are available in 4 and 7 channel DMX modes. The effects may be altered using the
inten¬sity, duration, and rate controls
1 Channel Mode
CH Values Functions
1 0-255 Strobe rate(0-30HZ)
3 Channel Mode
CH Values Functions
1 0-255 Master Dimmer (0-100%)
2 0-255 Flash duration(0-full on)
3 0-255 Strobe rate(0-30HZ)
4 Channel Mode
CH Values Functions
1 0-255 Master Dimmer (0-100%)
2 0-255 Flash duration(0-full on)
3 0-255 Strobe rate(0-30HZ)
4
0-5 No effect
6-42 Ramp up effect
43-85 Ramp down effect
86-128 Ramp up-down effect
129-171 Random effect
172-214 Lightning effect
215-255 Spike effect
6 Channel Mode
CH Values Functions
1 0-255 Master Dimmer (0-100%)
2 0-255 Red/Segment1-3 Dimmer(0-100%)

7
7 Channel Mode
CH Values Functions
1 0-255 Master Dimmer (0-100%)
2 0-255 Red/Segment1-3 Dimmer(0-100%)
3 0-255 Green/Segment4-6 Dimmer(0-100%)
4 0-255 Blue/Segment7-9 Dimmer(0-100%)
5 0-255 Flash duration(0-full on)
6 0-255 Strobe rate(0-30HZ)
7
0-5 No effect
6-42 Ramp up effect
43-85 Ramp down effect
86-128 Ramp up-down effect
129-171 Random effect
172-214 Lightning effect
215-255 Spike effect
16 Channel Mode
CH Values Functions
1 0-255 Master Dimmer (0-100%)
2 0-255 Red/Segment1-3 Dimmer(0-100%)
3 0-255 Green/Segment4-6 Dimmer(0-100%)
4 0-255 Blue/Segment7-9 Dimmer(0-100%)
5 0-255 Flash duration(0-full on)
6 0-255 Strobe rate(0-30HZ)
7
0-5 No effect
6-42 Ramp up effect
43-85 Ramp down effect
86-128 Ramp up-down effect
129-171 Random effect
172-214 Lightning effect
215-255 Spike effect
8 0-255 Red1/Segment1 Dimmer(0-100%)
9 0-255 Green1/Segment2 Dimmer(0-100%)
10 0-255 Blue1/Segment3 Dimmer(0-100%)
11 0-255 Red2/Segment4 Dimmer(0-100%)
12 0-255 Green2/Segment5 Dimmer(0-100%)
13 0-255 Blue2/Segment6 Dimmer(0-100%)
14 0-255 Red3/Segment7 Dimmer(0-100%)
15 0-255 Green3/Segment8 Dimmer(0-100%)
16 0-255 Blue3/Segment9
Dimmer(0-100%)
3 0-255 Green/Segment4-6 Dimmer(0-100%)
4 0-255 Blue/Segment7-9 Dimmer(0-100%)
5 0-255 Flash duration(0-full on)
6 0-255 Strobe rate(0-30HZ)

8
Pixel Mode
3 Channel Values Blinder intensity
10-5 Blackout
6-255 Segment 1
20-5 Blackout
6-255 Segment 2
30-5 Blackout
6-255 Segment 3
Pixel Mode (White)
9 Channel Values Blinder intensity
10-5 Blackout
6-255 Segment 1 Dimmer
20-5 Blackout
6-255 Segment 2 Dimmer
30-5 Blackout
6-255 Segment 3 Dimmer
40-5 Blackout
6-255 Segment 4 Dimmer
50-5 Blackout
6-255 Segment 5 Dimmer
60-5 Blackout
6-255 Segment 6 Dimmer
70-5 Blackout
6-255 Segment 7 Dimmer
80-5 Blackout
6-255 Segment 8 Dimmer
90-5 Blackout
6-255 Segment 9 Dimmer
Please note:
When the lighting is under the Pixel mode, the brightness will be only
40% of Maximum power, and it can be used as wash/flood lighting.
8. Cleaning And Maintenance
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never
use alcohol or solvents!
Caution!
Disconnect from mains before starting maintenance operation.
!

9
The device must only be installed at a vibration-free, oscilation-free and fire-resistant location.
• There are no servicable parts inside the device. Maintenance and service operations are only to be
carried out by authorized dealers.
• If you need any spare parts, please use genuine parts.
• If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers
only in order to avoid hazards.
• If you have further questions, please contact your dealer.
9. Installation
10. Technical Specifications
Power supply
110V~240V AC 50 Hz /60Hz
Power consumption
max. 300 W
Waterproof grade
IP 20
Net weight
2.8 KGS

Note: All information is subject to change without prior notice.
IMPORTANT INFORMATION!
In order to optimize the recovery and recycling of the materials that old appliances contain
and reduce the impact on human health and the environment, please make sure that this
product is recycled at the end of its life.
