Elan EL-4KHDBT-TXRX-40-IRS User manual

EL-4KHDBT-TXRX-40-IRS
User Manual
EL-4KHDBT-RX-40-IRS
HDBT In
Standard
Upgrade
LINK POWER
12V
2A
HDMI Out
HDMI
LINK
RS-232 IR RX IR TX
EL-4KHDBT-RX-40-IRS
HDBT In
Standard
Upgrade
LINK POWER
12V
2A
HDMI Out
HDMI
LINK
RS-232 IR RX IR TX
L/R Coaxial
Out Link Power
EDID Mode
HDBT Out
TX
EL-4KHDBT-TX-40-IRS
12V
2A
RS-232 HDMI In HDMI Out
Link Link IR RX IR TX
L/R Coaxial
Out Link Power
EDID Mode
HDBT Out
TX
EL-4KHDBT-TX-40-IRS
12V
2A
RS-232 HDMI In HDMI Out
Link Link IR RX IR TX

EL-4KHDBT-TXRX-40-IRS USER MANUAL
02 www.elanhomesystems.com
Surge protection device
recommended
This product contains sensitive electrical compo-
nents that may be damaged by electrical spikes,
surges, electric shock, lightning strikes, etc. Use
of surge protection systems is highly recom-
mended in order to protect and extend the life of
your equipment.
Safety And
Performance Notice
The transmission distances of HDMI over UTP
cables are measured using TE CONNECTIVITY
1427071-6
EIA/TIA-568-B termination (T568B) of cables is
recommended for optimal performance.
To minimize interference of the unshielded
twisted pairs in the CAT5e/6 cable do not run
the HDBaseT/Cat5e/6/6a cabling with or in close
parallel proximity to mains power cables.
Do not substitute or use any other power supply
other than the enclosed unit, or a ELAN approved
replacement.
Do not disassemble either the Transmitter or
Receiver units for any reason. Doing so will void
the manufacturer’s warranty.
Thank you for purchasing
this product.
For optimum performance and safety, please
read these instructions carefully before con-
necting, operating or adjusting this product.
Please keep this manual for future reference.
Contents
Introduction 03
Features 03
Panel Descriptions 04
Terminating HDBaseT CAT Cables 05
Understanding The Signal Status Lights 05
EDID Control 06
Infrared Distribution 07
Application Diagram 08
Specifications 09
Package Contents 09
Maintenance 09
Certifications 10

03
contact [e-mail]
EL-4KHDBT-TXRX-40-IRS USER MANUAL
The ELAN line of HDBaseT products offers market leading features at an
outstanding value. The EL-4KHDBT-RX-40-IRS and EL-4KHDBT-TX-40-IRS are
industry leading 4K HDBaseT solutions, delivering HDMI with HDCP 2.2 support,
bi-directional IR, RS-232, and PoH (PoE) up to lengths of 40m at 4K (70m at
1080p) over a single CAT cable.
Introduction
• Advanced HDBaseT technology offering uncompressed video and audio with zero latency
• Extends HDMI up to a distance of 70m over a single CAT cable
• Supports 4K UHD video up to 40m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports 3D signal display
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master
Audio transmission
• Bi-directional IR pass-through
• Supports bi-directional PoH (Power over HDBaseT™) to power extenders from either Transmitter or Receiver end
• HDCP 2.2 compliant
Features:

EL-4KHDBT-TXRX-40-IRS USER MANUAL
04 www.elanhomesystems.com
EL-4KHDBT-RX-40-IRS
HDBT In
Standard
Upgrade
LINK POWER
12V
2A
HDMI Out
HDMI
LINK
RS-232 IR RX IR TX
L/R Coaxial
Out Link Power
EDID Mode
HDBT Out
TX
EL-4KHDBT-TX-40-IRS
12V
2A
RS-232 HDMI In HDMI Out
Link Link IR RX IR TX
L/R Coaxial
Out Link Power
EDID Mode
HDBT Out
TX
EL-4KHDBT-TX-40-IRS
12V
2A
RS-232 HDMI In HDMI Out
Link Link IR RX IR TX
Panel Description EL-4KHDBT-RX-40-IRS
Panel Description EL-4KHDBT-TX-40-IRS
1RS-232 / serial connector
2HDMI output
3HDMI link indicator
4IR RX jack (to IR sensor)
5IR TX jack (to IR emitter)
8EDID DIP switch (UP=0, DOWN=1) - see page 6 for further
details
9Mode DIP switch
qAnalog audio Left/Right output (3.5mm stereo jack) -
de-embedded from HDMI input. Only supports stereo PCM
audio feeds
wCoaxial digital output - de-embedded from HDMI input
eHDBaseT signal link indicator
rHDBaseT output
tPower status indicator
yDC12V screw type connector
6Standard / Upgrade mode switch
7HDBaseT signal link indicator
8HDBaseT input
9Power status indicator
qDC 12V screw type connector
1RS-232 / serial connector
2HDMI input
3HDMI link indicator
4HDMI loop output
5HDMI link indicator
6IR RX jack (to IR sensor)
7IR TX jack (to IR emitter)
MODE
7654321
1 2 3 4 5 6 7 8 9 q w e r t y
8 9
EL-4KHDBT-RX-40-IRS
HDBT In
Standard
Upgrade
LINK POWER
12V
2A
HDMI Out
HDMI
LINK
RS-232 IR RX IR TX
q

05
EL-4KHDBT-TXRX-40-IRS USER MANUAL
contact [e-mail]
Terminating HDBaseT CAT cable
It is important that the interconnecting CAT cable between the ELAN HDBaseT products is terminated using the correct RJ45 pin configuration. The
link CAT cable MUST be a ‘straight’ (pin-to-pin) CAT cable and it is advised that this is wired to the T568B wiring standard as this format is less
prone to EMI (Electro-Magnetic Interference).
When installing CAT cables it is advised that you use the best possible CAT cable quality possible. HDMI distribution products will only work if used
with CAT5e standard cable or above. ELAN recommends using a CAT6 cable for your installations, especially when running over longer distances,
in areas of high EMI, or for 4K signal distribution.
RJ45 Wiring -
T568B
Understanding the signal status lights
The ELAN extender solutions include status LED indicators on both the Transmitter and Receiver products to show all connections are active and to
help diagnose possible problems.
Understanding the status lights:
Receiver:
• The HDMI signal link light will be off when there is no connection with a display/sink
• The HDMI link light will be on when there is an active connection with a display
• The HDBaseT link light will be off when there is no CAT cable/active HDBaseT connection on the RJ45 HDBaseT input
• The HDBaseT link light will blink if there is an unstable connection between the Transmitter/Matrix and Receiver
• The HDBaseT link light will be lit when a CAT cable is connected to the HDBaseT RJ45 output on the Transmitter/Matrix and an active
connection is achieved with the Receiver.
Transmitter:
• The Input HDMI signal link light will be off when there is no connection with a source device
• The Output HDMI signal link light will be off when there is no connection with a display/sink
• The Input HDMI link light will be on when there is an active connection with a source device
• The Output HDMI link light will be on when there is an active connection with a display/sink
• The HDBaseT link light will be off when there is no CAT cable/active HDBaseT connection on the RJ45 HDBaseT output
• The HDBaseT link light will blink if there is an unstable connection between the Transmitter and Receiver/Matrix
• The HDBaseT link light will be lit when a CAT cable is connected to the HDBaseT RJ45 output on the Transmitter and an active connection is
achieved with the Receiver/Matrix.

EL-4KHDBT-TXRX-40-IRS USER MANUAL
06 www.elanhomesystems.com
EDID (Extended Display Identification Data) is a data structure that is used between a display and a source. This data is used by the
source to find out what audio and video resolutions are supported by the display, from this information the source will discover what the
best audio and video resolutions need to be outputted.
While the objective of EDID is to make connecting a digital display to a source a simple plug and play procedure, issues do arise when
multiple displays or video matrix switching is introduced because of the increased number of variables.
By pre-determining the video resolution and audio format of the source and display device you can reduce the time needed for EDID hand
shaking thus making switching quicker and more reliable.
Configuration of extender EDID settings can be achieved using the product dip-switches on the end of the EL-4KHDBT-TX-40-IRS. EDID
dip-switch settings are shown below.
Note: You must power cycle the product after making EDID changes. For some sources it may be necessary to power cycle the source
after EDID changes have been made for the source to update its video & audio output settings.
EDID Control
DIP ON ▼/OFF▼ SWITCHING POSITIONS
EDID TYPE3 2 1 0
OFF OFF OFF ON 1080p/2.0CH
OFF OFF ON OFF 1080p/5.1CH
OFF OFF ON ON 1080p/7.1CH
OFF ON OFF OFF 1080i/2.0CH
OFF ON OFF ON 1080i/5.1CH
OFF ON ON OFF 1080i/7.1CH
OFF ON ON ON 4K60Hz 4:2:0/2.0CH
ON OFF OFF OFF 4K60Hz 4:2:0/5.1CH
ON OFF OFF ON 4K60Hz 4:2:0/7.1CH
ON OFF ON OFF 4K30Hz 4:4:4/2.0CH
ON OFF ON ON 4K30Hz 4:4:4/5.1CH
ON ON OFF OFF 4K30Hz 4:4:4/7.1CH
ON ON OFF ON DVI 1280x1024
ON ON ON OFF DVI 1920x1080
ON ON ON ON DVI 1920x1200
OFF OFF OFF OFF Copy EDID
GlobalEDIDsettings
Dip-switch position ‘0’ = Off
Dip-switch position ‘1’ = On
RS232 HDMI In HDMI Out
Link Link
Rx Tx
IR
Transmitter
L/R Coaxial
Out
Link Power
EDID
HDBT Out
DC 12V
HEX70ED-TX-V2
MODE

07
contact [e-mail]
EL-4KHDBT-TXRX-40-IRS USER MANUAL
The ELAN range of HDBaseT products include multiple options for control and routing of IR.
IMPORTANT: The ELAN HDMI Platinum, Matrix, & HDBaseT product lines output 5 volts to power an IR Receiver on the IR Input and
include an EL-4KACC-IR-CAB, 3.5mm Mono to 3.5mm Stereo 5v to 12v IR converter cable. This cable is required when using 12v IR
products from Xantech, Niles, and SpeakerCraft.
Each ELAN Matrix and HDBaseT extender kit is supplied with all necessary IR hardware required and includes:
Infrared Distribution
IR Control Cable - EL-4KACC-IR-CAB
ELAN IR Control cable 3.5mm Mono to 3.5mm Stereo for linking
third party IR Receivers to ELAN Platinum, Matrix, and HDBaseT
HDMI Series products.
Compatible with 12v IR third party products.
Note: Cable is directional as indicated
IR Receiver - Stereo 3.5mm
Signal
Power
Ground
Infrared 3.5mm Pin-Out
IR Emitter - Mono 3.5mm
Signal
Ground

EL-4KHDBT-TXRX-40-IRS USER MANUAL
08 www.elanhomesystems.com
Cat5e/6/7 IR Cable Audio RS232 HDMI
1 SOURCE
RS232 HDMI In HDMI Out
Link Link
Rx Tx
IR
Transmitter
L/R Coaxial
Out
Link Power
EDID
HDBT Out
DC 12V
HEX70ED-TX-V2
LOCAL DISPLAY
Control Processor
70m max
IR RX IR TX
HDMI
LINK
HDMI OutRS232
HEX70ED-RX-V2
RX
DISPLAY
A
C
D
B
HDMI RS232 IR POH
A
B
C
D
Application Diagram EL-4KHDBT-TXRX-40-IRS
EL-4KHDBT-TX-40-IRS
EL-4KHDBT-RX-40-IRS
Cat Cable

09
contact [e-mail]
EL-4KHDBT-TXRX-40-IRS USER MANUAL
Specifications
Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
EL-4KHDBT-TX-40-IRS
• Video input: 1x HDMI Type A, female
• Video output: 1x HDBaseT RJ45 connector
• IR input: 1x 3.5mm stereo jack
• IR output: 1x 3.5mm mono jack
• Mounting kit included
• Dimensions excl connections (W x D x H):
139mm x 114mm x 23mm
• Shipping weight (Kit): 0.5 kg
• Power: 12V/2A DC, screw type connector
• Operating temperature: 32°F to 104°F (0°C to 40°C)
• Storage temperature: -4°F to 140°F (-20°C to 60°C)
EL-4KHDBT-RX-40-IRS
• Video input: 1x HDBaseT RJ45 connector
• Video output: 1x HDMI Type A, female
• IR input: 1x 3.5mm stereo jack
• IR output: 1x 3.5mm mono jack
• Mounting kit included
• Dimensions excl connections (W x D x H):
110mm x 108mm x 27mm
• Shipping weight (Kit): 0.4 kg
• Power: 12V/2A DC, screw type connector
• Operating temperature: 32°F to 104°F (0°C to 40°C)
• Storage temperature: -4°F to 140°F (-20°C to 60°C)
Package Contents
EL-4KHDBT-TXRX-40-IRS
• 1 x EL-4KHDBT-TX-40-IRS
• 1 x EL-4KHDBT-RX-40-IRS
• 1 x 12V/2A DC power supply
• 1 x 5v-to-12v IR Converter Cable (EL-4KACC-IR-CAB)
• 2 x Mounting kits
• 1 x User manual

EL-4KHDBT-TXRX-40-IRS USER MANUAL
10 www.elanhomesystems.com
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION - changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
CANADA, INDUSTRY CANADA (IC) NOTICES
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
CANADA, AVIS D’INDUSTRY CANADA (IC)
Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d’interférence et (2) cet appareil doit accepter
toute interférence, notamment les interférences qui peuvent affecter son fonctionnement.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household wastes. To prevent possible harm to
the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmentally safe recycling.
Certifications

11
contact [e-mail]
EL-4KHDBT-TXRX-40-IRS USER MANUAL
Notes
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––

main:
1 [phone] - US
1 [phone] - International
1 [phone] - Fax
tech support:
[email protected]
web:
elanhomesystems.com
© 2017 ELAN®is a registered trademark of Core Brands, LLC. 10014809 Rev-C0, 04/2017
