EL-4KHDBT-TXRX-70-E-ARC-IRS
User Manual
HDMI Loop Out
Ethernet
HDMI In
(ARC)
Optical Out
Audio Out
L
R
EL-4KHDBT-TX-70-E-ARC-IRS
IR TX IR RX
NON-ARC
ARC
HDBT OUT
Power
15V
2A
RS-232
HDBT In
IR TX IR RX ARC
Optical
RS-232 15V
Power
2A
EL-4KHDBT-RX-70-E-ARC-IRS
Ethernet 1HDMI OutOptical In Ethernet 2 Ethernet 3
HDBT In
IR TX IR RX ARC
Optical
RS-232 15V
Power
2A
EL-4KHDBT-RX-70-E-ARC-IRS
Ethernet 1HDMI OutOptical In Ethernet 2 Ethernet 3
HDMI Loop Out
Ethernet
HDMI In
(ARC)
Optical Out
Audio Out
L
R
EL-4KHDBT-TX-70-E-ARC-IRS
IR TX IR RX
NON-ARC
ARC
HDBT OUT
Power
15V
2A
RS-232

EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
02
www.elanhomesystems.com
Introduction 03
Features 03
Panel Descriptions 04
Terminating HDBaseT CAT Cables 05
Understanding TX/RX Status Lights 05
Infrared Distribution 06
Application Diagram 07-08
Specifications 09
Package Contents 09
Maintenance 09
Certifications 10
Contents
Surge protection device
recommended
This product contains sensitive electrical compo-
nents that may be damaged by electrical spikes,
surges, electric shock, lightning strikes, etc. Use
of surge protection systems is highly recom-
mended in order to protect and extend the life of
your equipment.
Safety And
Performance Notice
The transmission distances of HDMI over UTP
cables are measured using TE CONNECTIVITY
1427071-6
EIA/TIA-568-B termination (T568B) of cables is
recommended for optimal performance.
To minimize interference of the unshielded
twisted pairs in the CAT5e/6 cable do not run
the HDBaseT/Cat5e/6/6a cabling with or in close
parallel proximity to mains power cables.
Do not substitute or use any other power supply
other than the enclosed unit, or a ELAN approved
replacement.
Do not disassemble either the Transmitter or
Receiver units for any reason. Doing so will void
the manufacturer’s warranty.
Thank you for purchasing
this product.
For optimum performance and safety, please
read these instructions carefully before con-
necting, operating or adjusting this product.
Please keep this manual for future reference.

03
contact [e-mail]
EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
Our range of HDBaseT products offer the very best in performance and flexibility. The
EL-4KHDBT-RX-70-E-ARC-IRS HDBaseT Receiver and EL-4KHDBT-TX-70-E-ARC-IRS
HDBaseT Transmitter are industry leading 4K HDBaseT solution delivering HDMI with
HDCP 2.2 support, Bi-directional IR, RS-232 and PoH (PoE) up to lengths of 70m at
4K (100m at 1080p) over a single CAT cable. The EL-4KHDBT-RX-70-E-ARC-IRS
HDBaseT Receiver and EL-4KHDBT-TX-70-E-ARC-IRS HDBaseT Transmitters also
provide enhanced features including HDMI loop-out on the Transmitter, ARC via HDMI
or Optical (S/PDIF) and an integrated 3-port Ethernet switch.
Introduction
Features:
• Advanced HDBaseT technology offering uncompressed video and audio with zero latency
• Extends 1080p HDMI up to a distance of 100m over single CAT cable
• Supports 4K UHD video up to 70m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
• Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
• Supports 3D signal display
• Features 1x HDMI loop out for integrating local displays or cascading to multiple devices
• Supports ARC (Audio Return Channel) from display via HDMI and Optical digital inputs
(ARC feature supports distance of up to 90m)
• Supports audio return to HDMI, Optical digital and analog L/R audio outputs (DAC PCM only)
• Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus
and DTS-HD Master Audio transmission
• Integrated 3-port ethernet switch (LAN Serving)
• Bi-directional RS-232 pass through
• Bi-directional IR from all input and output locations
• Bi-directional PoH (Power over HDBaseT) to power extenders from either transmitter or receiver end
• HDCP 2.2 support

EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
04
www.elanhomesystems.com
Panel Description EL-4KHDBT-TX-70-E-ARC-IRS
Panel Description EL-4KHDBT-RX-70-E-ARC-IRS
1IR TX port - Connect to ELAN 5V Emitter. Connection is used
to control the local display device from control processor or IR
sensor located at the source/transmitter end.
2IR RX port - Connect included 5v to 12v IR converter cable to
allow the IR signal received by Xantech, Niles, or SpeakerCraft,
as well as other, 12v IR receivers to be received. Connection is
used to control sources devices located at thea end.
3RS-232 port - Bi-directional RS-232 with
E L- 4 K H D B T-TX-70-E-ARC-IRS RS-232 port.
4Audio return selection switch - Switch between ARC and
TOSLINK (Optical) when using the Audio Return feature.
1 3 4 5 6 7 8 9 10 2
5HDBaseT input - RJ45 connector. Connect to HDBaseT output on
E L- 4 K H D B T-TX-70-E-ARC-IRS.
6Power LED indicator
7Power port - Connect ELAN 15V DC power supply only.
Note - HDBaseT extender kit can be powered from either the
Transmitter or Receiver by using the power over cable (POH)
feature.
8Optical audio input - TOSLINK audio input. Connects to the
Optical output of the local display device for Audio Return feature.
9HDMI Output - Connect to the HDMI input on local display device.
qEthernet ports x3 - RJ45 connectors. Connect to local network
products to extend 10/100 network from HDBaseT Transmitter.
1IR TX port - Connect to IR Emitter. Connection is used to control
the local source device from ELAN IR Receiver connected at the
EL-4KHDBT-RX-70-E-ARC-IRS.
2IR RX port - Connect included 5v to 12v IR converter cable
to allow the 12v IR signals, such as the IR output on ELAN
system controllers or from the IR output on a Xantech, Niles, or
SpeakerCraft IR connecting block.
3RS-232 port - Bi-directional RS-232 with
EL-4KHDBT-RX-70-E-ARC-IRS RS-232 port.
4Audio output selection switch - Audio source selection for Analog
L/R audio outputs (connections). Select between ARC and audio
breakout of local HDMI input. When ARC feature is used, selection
between Optical and HDMI audio ARC is via dip-switch on the
EL-4KHDBT-RX-70-E-ARC-IRS (see below).
5HDBaseT output - RJ45 connector. Connect to HDBaseT input on
EL-4KHDBT-RX-70-E-ARC-IRS.
6Power LED indicator
7Power port - Connect ELAN 15V DC power supply only. Note -
HDBaseT extender kit can be powered from either the Transmitter
or Receiver by using the power over cable (POH) feature.
8Analog audio 2CH L/R output - Connects to third party audio
amplifier for audio breakout of either local HDMI or Audio Return
Channel from EL-4KHDBT-RX-70-E-ARC-IRS. Note: Audio format
must be 2ch PCM.
9Optical audio output - TOSLINK audio output. Connects to local
AV amplifier when using Audio Return Channel (ARC) feature.
qHDMI input - Connect to the HDMI output of the local
source device or Matrix output to be extended to the
EL-4KHDBT-RX-70-E-ARC-IRS.
wHDMI output - Loop-through of HDMI input signal. Used for
connection to local display or to daisy-chain HDMI devices.
eEthernet ports - RJ45 connector. Connect to local network switch
to extend 10/100 network to HDBaseT Receiver ethernet ports.
1 3 4 5 6 7 8 9 10 211 12
HDMI Loop Out
Ethernet
HDMI In
(ARC)
Optical Out
Audio Out
L
R
EL-4KHDBT-TX-70-E-ARC-IRS
IR TX IR RX
NON-ARC
ARC
HDBT OUT
Power
15V
2A
RS-232
HDBT In
IR TX IR RX ARC
Optical
RS-232 15V
Power
2A
EL-4KHDBT-RX-70-E-ARC-IRS
Ethernet 1HDMI OutOptical In Ethernet 2 Ethernet 3
HDBT In
IR TX IR RX ARC
Optical
RS-232 15V
Power
2A
EL-4KHDBT-RX-70-E-ARC-IRS
Ethernet 1HDMI OutOptical In Ethernet 2 Ethernet 3
HDMI Loop Out
Ethernet
HDMI In
(ARC)
Optical Out
Audio Out
L
R
EL-4KHDBT-TX-70-E-ARC-IRS
IR TX IR RX
NON-ARC
ARC
HDBT OUT
Power
15V
2A
RS-232

05
EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
contact [e-mail]
Terminating HDBaseT CAT cable
It is important that the interconnecting CAT cable between the ELAN HDBaseT products is terminated using the correct RJ45 pin configuration.
The link CAT cable MUST be a ‘straight’ (pin-to-pin) CAT cable and it is advised that this is wired to the T568B wiring standard as this format is
less prone to EMI (Electro-Magnetic Interference).
When installing CAT cables it is advised that you use the best possible CAT cable quality possible. HDMI distribution products will only work if
used with CAT5e standard cable or above. ELAN recommends using a CAT6 cable for your installations, especially when running over longer
distances, in areas of high EMI, or with 4K signal distribution.
RJ45 Pin-Out
T568B
1 2 3 4 5 6 7 8
Understanding the EL-4KHDBT-TXRX-70-E-ARC-IRS
HDBaseT status lights
The ELAN Matrix and HDBaseT extender solutions include status LED indicators on both the Transmitter and Receiver products to show all
connections are active and to help diagnose possible problems.
Understanding the status lights:-
ELAN EL-4KHDBT-TX-70-E-ARC-IRS :
• The Yellow HDBaseT status link light will be off when the output has been turned off or there is a problem with the HDBaseT output.
• The Yellow HDBaseT status link light will blink when the output is on and working
• The Green HDBaseT link light will blink if there is an unstable connection between the ELAN HDBaseT Transmitter and HDBaseT Receiver
• The Green HDBaseT link light will be lit when a there is an active HDBaseT Receiver connected to the Transmitter
• The Green HDBaseT link light will be off when a there is no connection with a HDBaseT receiver
• The HDMI link light will be off when there is no connection with a source device
• The HDMI link light will be on when there is an active connection with asource device
ELAN EL-4KHDBT-RX-70-E-ARC-IRS :
• The HDMI link light will be off when there is no connection with a display
• The HDMI link light will be on when there is an active connection with a display
• The HDBaseT link light will be off when there is no CAT cable/active HDBaseT connection on the RJ45 HDBaseT input
• The HDBaseT link light will blink if there is an unstable connection between the ELAN Transmitter and HDBaseT Receiver
• The HDBaseT link light will be lit when a CAT cable is connected to the HDBaseT RJ45 output on the Transmitter and an
active connection is achieved with the ELAN HDBaseT Receiver.

EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
06
www.elanhomesystems.com
The ELAN range of HDBaseT products include multiple options for control and routing of IR.
IMPORTANT: The ELAN HDMI Platinum, Matrix, & HDBaseT product lines output 5 volts to power an IR Receiver on the IR Input and
include an EL-4KACC-IR-CAB, 3.5mm Mono to 3.5mm Stereo 5v to 12v IR converter cable. This cable is required when using 12v IR
products from Xantech, Niles, and SpeakerCraft.
Each ELAN Matrix and HDBaseT receiver is supplied with all necessary IR hardware required and includes:
Infrared (IR) Distribution
IR Control Cable - EL-4KACC-IR-CAB
ELAN IR Control cable 3.5mm Mono to 3.5mm Stereo for linking
third party IR Receivers to ELAN Platinum, Matrix, and HDBaseT
HDMI Series products.
Compatible with 12v IR third party products.
Note: Cable is directional as indicated
IR Receiver - Stereo 3.5mm
Signal
Power
Ground
Infrared 3.5mm Pin-Out
IR Emitter - Mono 3.5mm
Signal
Ground

07
contact [e-mail]
EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
Application Diagram EL-4KHDBT-TXRX-70-E-ARC-IRS
Cat 5/6 Network Connection RS232 HDMI Optical Digital Audio Stereo Audio IR Cable
TV AND AVR SUPPORT ARC
EL-4KHDBT-TX-70-E-ARC-IRS POSITION SWITCHER MODE SELECTION Transmitter ARC Receiver ARC
R
A
B
C
D
A
C
D
B
AB
A
B
Audio Out
L R
IR Tx IR Rx RS 232 ARC HDBT Out DC 15V
NON-ARC IR Tx IR Rx RS232 ARC HDBT In DC 15V
NON-ARC
Optical Out HDMI In Ethernet
Transmit ter
HDMI Loop Out Optical In HDMI Out Ethernet 1 Ethernet 2 Ethernet 3
EL-4KHDBT-RX-70-E-ARC-IRS
DISPLAY
(HDBaseT)
LOCAL
DISPLAY
(HDMI)
1 SOURCE
Control
Processor
100m max
HDMI
S232
IR POH
Receiver
HDMI ARC
EL-4KHDBT-TX-70-E-ARC-IRS
Cat Cable

EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
08
www.elanhomesystems.com
Cat 5/6 Network Connection RS232 HDMI Optical Digital Audio Stereo Audio IR Cable
R
A
B
C
D
A
C
D
B
Application Diagram EL-4KHDBT-TXRX-70-E-ARC-IRS
TV Without ARC, AVR Without ARC
EL-4KHDBT-TXRX-70-E-ARC-IRS
POSITION SWITCHER MODE SELECTION
Transmitter NON-ARC Receiver Optical
Audio Out
L R
IR Tx IR Rx RS 232 ARC HDBT Out DC 15V
NON-ARC IR Tx IR Rx RS232 ARC HDBT In DC 15V
NON-ARC
Optical Out HDMI In Ethernet
Transmit ter
HDMI Loop Out Optical In HDMI Out Ethernet 1 Ethernet 2 Ethernet 3
EL-4KHDBT-RX-70-E-ARC-IRS
DISPLAY
(HDBaseT)
LOCAL
DISPLAY
(HDMI)
1 SOURCE
Control
Processor
100m max
HDMI
S232
IR POH
Receiver
EL-4KHDBT-TX-70-E-ARC-IRS
Cat Cable

09
contact [e-mail]
EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
EL-4KHDBT-TX-70-E-ARC-IRS
Video Input Connectors: 1x HDMI Type A, 19-pin, female, locking
Video Output Connectors: 1x HDMI Type A, 1x HDBaseT™
RJ45 connector
Audio Output Connectors: 2x RCA (L/R) Analog, 1x Optical (TOSLINK)
RS-232 serial port: 1x DB 9 connector
Ethernet port: 1x RJ45, female
IR Input ports: 1x 3.5mm stereo jack
IR Output ports: 1x 3.5mm mono jack
Dimensions (W x H x D): 143mm x 24mm x 134mm
Shipping Weight: 0.4Kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature : -4°F to 140°F (-20°C to 60°C)
Power Supply: 1x 15V DC/2A
NOTE: Specifications are subject to change without notice.
Package Contents:
Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, paint thinner or benzene to clean this unit.
Specifications:
• 1 x EL-4KHDBT-TX-70-E-ARC-IRS
• 1x EL-4KHDBT-RX-70-E-ARC-IRS
• 2 x Mounting kits
• 1 x 15V/2A power supply
• 1 x 5v-to-12v IR Converter Cable (EL-4KACC-IR-CAB)
• 1 x User manual
EL-4KHDBT-RX-70-E-ARC-IRS
Video Input Connectors: 1x HDBaseT™ RJ45 connector
Video Output Connectors: 1x HDMI Type A
Audio Input Connector: 1x Optical (TOSLINK)
RS-232 serial port: 1x DB 9 connector
Ethernet ports: 3x RJ45, female
IR Input ports: 1x 3.5mm stereo jack
IR Output ports: 1x 3.5mm mono jack
Dimensions (W x H x D): 114mm x 24mm x 134mm
Shipping Weight: 0.4Kg
Operating Temperature: 32°F to 104°F (0°C to 40°C)
Storage Temperature : -4°F to 140°F (-20°C to 60°C)
• 1x EL-4KHDBT-RX-70-E-ARC-IRS
• 1 x Mounting kit
• 1 x 5v-to-12v IR Converter Cable (EL-4KACC-IR-CAB)
EL-4KHDBT-RX-70-E-ARC-IRS (When sold individually)

EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
10
www.elanhomesystems.com
FCC Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION - changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment.
CANADA, INDUSTRY CANADA (IC) NOTICES
This Class B digital apparatus complies with Canadian ICES-003.
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
CANADA, AVIS D’INDUSTRY CANADA (IC)
Cet appareil numérique de classe B est conforme aux normes canadiennes ICES-003.
Son fonctionnement est soumis aux deux conditions suivantes : (1) cet appareil ne doit pas causer d’interférence et (2) cet appareil doit accepter
toute interférence, notamment les interférences qui peuvent affecter son fonctionnement.
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other household wastes. To prevent possible harm to
the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the return and collection systems or contact the retailer where the
product was purchased. They can take this product for environmentally safe recycling.
Certifications

11
contact [e-mail]
EL-4KHDBT-TXRX-70-E-ARC-IRS USER MANUAL
Notes
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––

10014810 Rev-C0, 04/2017
main:
1 [phone] - US
1 [phone] - International
1 [phone] - Fax
tech support:
[email protected]
web:
elanhomesystems.com
© 2017 ELAN®is a registered trademark of Core Brands, LLC.
