Elba GAS COOKERS Installation and operating instructions

Made in Italy
HOME APPLIANCES
10 0%
ELBA QUALITY
MADE IN ITALY
GAS COOKERS
Instructions for the use - Installation advices

2
Dear Customer,
Thank you for having purchased and given your preference to
our product.
The safety precautions and recommendations reported below
are for your own safety and that of others. They will also provide
a means by which to make full use of the features offered by your
appliance.
Please preserve this booklet carefully. It may be useful in
future, either to yourself or to others in the event that doubts
should arise relating to its operation.
This appliance must be used only for the task it has explicitly
been designed for, that is for cooking foodstuffs. Any other
form of usage is to be considered as inappropriate and
therefore dangerous.
The manufacturer declines all responsibility in the event of
damage caused by improper, incorrect or illogical use of the
appliance.

3
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS
IMPORTANT: This appliance is designed and manufactured
solely for the cooking of domestic (household) food and is
not suitable for any non domestic application and therefore
should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used
within a non domestic environment i.e. a semi commercial,
commercial or communal environment.
Read the instructions carefully before installing and using
the appliance.
• After having unpacked the appliance, check to ensure that it is not
damaged and that the oven door closes correctly.
In case of doubt, do not use it and consult your supplier or a
professionally qualied technician.
• Packing elements (i.e. plastic bags, polystyrene foam, nails, packing
straps, etc.) should not be left around within easy reach of children,
as these may cause serious injuries.
• Some appliances are supplied with a protective lm on steel and
aluminium parts. This lm must be removed before using the
appliance.
• IMPORTANT: The use of suitable protective clothing/gloves is
recommended when handling or cleaning this appliance.
• Do not attempt to modify the technical characteristics of the
appliance as this may become dangerous to use. The manufacturer
declines all responsibility for any inconvenience resulting from the
inobservance of this condition.
• CAUTION: this appIiance must only be installed in a permanently
ventilated room in compliance with the applicable regulations.
• Do not carry out cleaning or maintenance operations on the
appliance without having previously disconnected it from the electric
power supply.
• WARNING: Ensure that the appliance is switched off before
replacing the oven lamp to avoid the possibility of electric shock.
• Do not use a steam cleaner because the moisture can get into the
appliance thus make it unsafe.

4
• Do not touch the appliance with wet or damp hands (or feet).
• Do not use the appliance whilst in barefoot.
• If you should decide not to use this appliance any longer (or
decide to substitute another model), before disposing of it, it is
recommended that it be made inoperative in an appropriate manner
in accordance to health and environmental protection regulations,
ensuring in particular that all potentially hazardous parts be made
harmless, especially in relation to children who could play with
unused appliances.
• The various components of the appliance are recyclable. Dispose
of them in accordance with the regulations in force in your country.
If the appliance is to be scrapped, remove the power cord.
• After use, ensure that the knobs are in the off position.
• Children less than 8 years of age shall be kept away unless
continuously supervised.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance shall not
be made by children without supervision.
• The manufacturer declines all liability for injury to persons or damage
to property caused by incorrect or improper use of the appliance.
• WARNING: During use the appliance and its accessible parts
become hot; they remain hot for some time after use.
– Care should be taken to avoid touching heating elements (on the
hob and inside the oven).
– The door is hot, use the handle.
– To avoid burns and scalds, young children should be kept away.
• Make sure that electrical cables connecting other appliances in the
proximity of the cooker cannot come into contact with the hob or
become entrapped in the oven door.
• WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in re. NEVER try to extinguish a re
with water, but switch off the appliance and then cover ame e.g.
with a lid or a re blanket.

5
• WARNING: Danger of re: do not store items on the cooking
surfaces.
• WARNING: When correctly installed, your product meets all safety
requirements laid down for this type of product category. However
special care should be taken around the rear or the underneath of
the appliance as these areas are not designed or intended to be
touched and may contain sharp or rough edges, that may cause
injury.
• FIRST USE OF THE OVEN - it is advised to follow these instructions:
– Furnish the interior of the oven as described in the chapter
“CLEANING AND MAINTENANCE”.
– Switch on the empty oven on max to eliminate grease from the
heating elements.
– Disconnect the appliance from the electrical power supply, let
the oven cool down and clean the interior of the oven with a cloth
soaked in water and neutral detergent; then dry carefully.
• CAUTION: Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.
• Do not line the oven walls with aluminium foil. Do not place baking
trays or the drip tray on the base of the oven chamber.
• FIRE RISK! Do not store ammable material in the oven or in the
storage compartment.
• Always use oven gloves when removing the shelves and food trays
from the oven whilst hot.
• Do not hang towels, dishcloths or other items on the appliance or its
handle – as this could be a re hazard.
• Clean the oven regularly and do not allow fat or oils to build up in
the oven base or tray. Remove spillages as soon as they occur.
• Do not stand on the cooker or on the open oven door.
• Always stand back from the appliance when opening the oven door
to allow steam and hot air to escape before removing the food.
• SAFE FOOD HANDLING: Leave food in the oven for as short a time
as possible before and after cooking. This is to avoid contamination
by organisms which may cause food poisoning. Take particular care
during warmer weather.
• WARNING: Take care NOT to lift the cooker by the door handle.

6
GAS BURNERS
1. Auxiliary burner (A) 1,00 kW
2. Semi-rapid burner (SR) 1,75 kW
3. Rapid burner (R) 3,00 kW
4. Triple-ring (TR) 3,50 kW
Fig. 1.1
CAUTION:
Gas appliances produce heat and humidity in the environment in which they are installed.
Ensure that the cooking area is well ventilated by opening the natural ventilation grilles or
by installing an extractor hood connected to an outlet duct.
CAUTION:
If the appliance is used for a prolonged time it may be necessary to provide further ventilation
by opening a window or by increasing the suction power of the extractor hood (if tted).
1
4
3
2 2
COOKING HOB
1

7
CONTROLS DESCRIPTION
1. Gas oven/grill thermostat control knob
2. 60’ alarm control knob
3. Front left burner control knob
4. Rear left burner control knob
5. Central burner control knob
6. Rear right burner control knob
7. Front right burner control knob
Pushbuttons
8. Electric ignition
9. Rotisserie
10. Oven light
Fig. 2.1
2 3 4 5 6 71
10
9
8
CONTROL PANEL
2

8
Fig. 3.1
Caution!
The cooking hob becomes very hot
during operation.
Keep children well out of reach.
N.B. When the cooker is not being
sed, set the gas knobs to their closed
positions and also close the cock
valve on the gas bottle or the main gas
supply line.
GAS BURNERS
Gas ow to the burners is adjusted by
turning the knobs (illustrated in g. 3.1)
which control the safety valves.
Turning the knob, so that the indicator line
points to the symbols printed on the control
panel, achieves the following functions:
- symbol closed valve
- symbol maximum
aperture or ow
- symbol minimum
aperture or ow
√The maximum aperture position
permits rapid boiling of liquids, whereas
the minimum aperture position allows
slower warming of food or maintaining
boiling conditions of liquids.
√ To reduce the gas ow to minimum
rotate the knob further anti-clockwise
to point the indicator towards the small
ame symbol.
√Other intermediate operating
adjustments can be achieved by
positioning the indicator between the
maximum and minimum aperture
positions, and never between the
maximum aperture and closed
positions.
Fig. 3.2
USE OF THE HOB BURNERS
3

9
CHOICE OF THE BURNER
On the control panel, near every knob
there is a diagram that indicates which
burner is controlled by that knob.
The suitable burner must be chosen
according to the diameter and the capacity
used.
As an indication, the burners and the pots
must be used in the following way:
DIAMETERS OF PANS WHICH MAY
BE USED ON THE BURNERS
BURNERS MINIMUM MAXIMUM
Auxliliary 12 cm 14 cm
Semi-rapid 16 cm 24 cm
Rapid 24 cm 26 cm
Triple-ring 26 cm 28 cm
do not use pans with concave or
convex bases
Fig. 3.4
It is important that the diameter of the pot
be suitable to the potentiality of the burner
so as not to compromise the high output
of the burners and therefore energy waste.
A small pot on a large burner does not give
you a boiling point in a shorter amount of
time since the capacity of heat absorption
of a liquid mass depends on the volume
and the surface of the pot.
Fig. 3.3
LIGHTING THE BURNERS
To ignite the burner, the following
instructions are to be followed:
1. Press in the corresponding knob and
t
urn counter-clockwise (g. 3.2 ) to the
full ame position marked by the
symbol (g. 3.1).
2. Press the ignition button marked by
the symbol (g. 3.3).
The sparks produced by the electrodes
situated next to the burner will light the
selected burner.
In the case of a mains failure light the
burner with a match or lighted taper.
3. Adjust the gas to the desired position.
To turn it off, turn the knob towards the
right, up to the safety click.
If your local gas supply makes it difcult
to light the burner with the knob set to
maximum, set the knob to minimum and
repeat the operation.

10
The glass on the oven door reaches
high temperatures during operation.
Keep children away.
Models with glass lid: The cooker lid
must be kept open when the gas oven/
grill is in use.
GENERAL FEATURES
The oven is furnished completely clean; it
is advisable however, upon rst use, to turn
the oven on to the maximum temperature
(position 10) to eliminate possible traces of
grease from the oven burner.
The same operation should be followed for
grill burner.
The gas oven is provided with two burners:
• One gas burner (wattage: 6,20 kW),
located at the bottom, providing safety
device and electric ignition.
• One gas grill (wattage: 4,65 kW),
placed on the top, providing safety
device and electric ignition.
WARNING:
The door is hot, use the handle.
During use the appliance becomes hot.
Care should be taken to avoid touching
heating elements inside the oven. THERMOSTAT GRADE TABLE
Thermostat
indicator
Oven
temperature
1 150 °C
2 165 °C
3 180 °C
4 195 °C
5 210 °C
6 225 °C
7240 °C
8 255 °C
9270 °C
10 285 °C
Fig. 4.1
Table 4.2
OVEN BURNER
It carries out normal “oven cooking”.
The gas ow to the burner is regulated by
a thermostat which allow to maintain the
oven temperature constant.
The control of the temperature is assured
by a thermostatic probe positioned inside
the oven.
The probe must be always kept in its
housing, in a clean condition, as an
incorrect position or encrustment may
cause an alteration in the control of the
temperature.
THERMOSTAT
The numbers 1to 10 printed on the control
panel (g. 4.1) indicate the increasing oven
temperature value (see table 4.2).
The temperature is kept constant on the
regulated value.
To regulate the temperature, make the
indicator of the knob (g. 4.1) match with
the chosen number on the control panel.
The thermostat which regulates the ow
of gas to the oven burner has a safety
valve which automatically shuts off the gas
supply when the ame goes out.
USE OF THE GAS OVEN
4

11
IGNITION OF THE OVEN BURNER
ATTENTION: Never turn the control
knob before opening the oven door.
To ignite the oven burner:
1. Open the oven door to the full extent.
WARNING: Risk of explosion! The
oven door must be open during this
operation.
2. Press the button marked with a star
symbol (g. 4.3) and keep pressed
until the oven burner ignites.
3. Press in the oven control knob and turn
counter-clockwise (g. 4.4) to position
10 (g. 4.1). Keep the knob pressed.
In the case of a mains failure, to light
the oven burner manually, approach
a ame to the hole “A” of the oven
oor (g. 4.5). Never turn the gas
thermostat before approaching a
ametothehole“A”oftheoor.
4. Never continue this operation for
more than 15 seconds. If the burner
has still not ignited, wait for about
1 minute prior to repeating the
ignition.
5. After lighting the burner, wait a few
seconds before releasing the knob
(until the safety valve stays open).
6. Check the burner is lit, then gently close
the oven door and set the oven control
knob to the required temperature.
If the ame extinguishes for any reason,
the safety valve will automatically shut off
the gas supply to the burner.
To re-light the burner, rst turn the oven
control knob to position “0” , wait for
at least 1 minute and then repeat the
lighting procedure.
Fig. 4.3
A
Fig. 4.5
Fig. 4.4

12
OVEN COOKING
To cook, before introducing the food, preheat
the oven to the desired temperature.
When the oven has reached the desired
temperature, introduce the food, control
the cooking time and turn off the oven
5 minutes before the theoretical time to
recuperate the stored heat.
For efcient oven preheating, we
recommend that grill trays and racks
are removed from the oven and
replaced after about 15 minutes.
DISHES TEMPERATURE
Lasagne 190°C
B aked pasta 190°C
Pizza 220°C
C reole rice 190°C
B aked onions 190°C
S pinach crêpes 185°C
Potatoes baked in milk 185°C
S tuffed tomatoes 180°C
C heese soufflé 170°C
R oast veal 180°C
Grilled veal chops 210°C
C hicken breasts with tomato 180°C
Grilled chicken - roast chicken 190°C
Veal loaf 175°C
R oast beef 170°C
Fillet of sole 175°C
Aromatic hake 170°C
B eignets 160°C
R ing cake 150°C
Plum tart 170°C
J am tartlets 160°C
S ponge cake 170°C
S weet dough 160°C
S weet puffs 170°C
Plain sponge cake 170°C
COOKING EXAMPLES
Temperatures are approximate as they
vary depending on the quality and amount
of food.
Remember to use ovenproof dishes and to
adjust the oven temperature during cooking
if necessary.

13
IGNITION OF THE GRILL BURNER
ATTENTION: Never turn the control
knob before opening the oven door.
To ignite the grill burner:
1. Open the oven door to the full extent.
WARNING: Risk of explosion! The
oven door must be open during this
operation.
2. Press the button marked with a star
symbol (g. 4.6) and keep pressed
until the grill burner ignites.
3. Press in the grill control knob and
turn clockwise (g. 4.7) to the position
marked by the symbol (g. 4.1).
Keep the knob pressed.
In the case of a mains failure, to light
the grill burner manually, approach a
ame to the pipe of the burner (g.
4.8). Never turn the gas thermostat
before approaching a ame to the
burner.
4. Never continue this operation for
more than 15 seconds. If the burner
has still not ignited, wait for about
1 minute prior to repeating the
ignition.
5. After lighting the burner, wait a few
seconds before releasing the knob
(until the safety valve stays open).
6. Check the burner is lit. Do not close
completely the oven door.
The grill must always be used with
the oven door slightly open and
withshield“A”mounted(Fig.4.9).
 See specic instructions in the section
‘USE OF THE GRILL’.
If the ame extinguishes for any reason,
the safety valve will automatically shut off
the gas supply to the burner.
To re-light the burner, rst turn the oven
control knob to position “0” , wait for
at least 1 minute and then repeat the
lighting procedure.
Fig. 4.6
Fig. 4.8
Fig. 4.7

14
OVEN LIGHT
The cooker is equipped with a light that
illuminates the oven to enable visually
controlling the food that is cooking.
The light switches on by pressing the
pushbutton indicated in g. 4.10.
Fig. 4.10
USE OF THE GRILL
Very important: The grill must always be
used with the oven door slightly open
andwithshield“A”mounted(Fig.4.9).
Mount shield “A” (g. 4.9) which serves to
protect the control panel from the heat.
Turn on the grill, as explained in the
preceding paragraphs and let the oven
preheat for about 5 minutes with the door
ajar.
Introduce the food to be cooked, positioning
the rack as close to the grill as possible.
The dripping pan should be placed under
the rack to catch the cooking juices and
fats.
Note: It is recommended that you do not
grill for longer than 30 minutes at any
one time.
Attention: The oven door becomes very
hot during operation.
Keep children away.
A
Fig. 4.9
WARNING:
Hot part allow to cool
before removing

15
ROTISSERIE
This is used for spit roasting under the grill
and comprises:
• an electric motor tted to the rear of
the oven;
• a stainless steel skewer provided with
slide-out heatless handgrip and two
sets of adjustable forks;
• a skewer support to be tted in the
middle runner.
The rotisserie motor is operated by pressing
the pushbutton indicated in g. 4.11.
The rotation direction of the rotisserie can
be either clockwise or counterclockwise.
Fig. 4.11
USE OF THE ROTISSERIE (Fig. 4.12)
• Insert the tray into the lowest rack
holders of the oven and insert the
rod support into the intermediate rack
holders.
• Put the meat to be cooked onto the
rod, being careful to secure it in the
center with the special forks.
• Insert the rod into the side gear
opening “P” (g. 4.12).
• Remove the grip “H” by turning it to the
left.
• Insert completely the rotisserie
support; the shaft “S” must be inserted
in the spit motor collar “G”.
• Fit the heat shield and switch on the
grill and turnspit. The rotation direction
of the rotisserie can be either clokwise
or counterclockwise.
Very important: The rotisserie must
always be used with the oven door ajar
andwithshield“A”mounted(g.4.9).
Attention: The oven door becomes very
hot during operation.
Keep children away.
It is recommended that you do not grill
for longer than 30 minutes at any one
time.
G
S
H
P
Fig. 4.12

16
MINUTE COUNTER
The minute counter is a timed acoustic
warning device which can be set for a
maximum of 60 minutes.
The knob (Fig. 5.1) must be rotated
clockwise as far as the 60 minute position
and then set to the required time by rotating
it anticlockwise.
IMPORTANT WARNING: This is only a
mechanical timer.
Remember to turn off the oven/grill
manually.
Fig. 5.1
60’ ALARM
5

17
Do not shut lid when
burner alight.
ATTENTION
Do not lower the glass lid when the
gas burners are still hot or when
the oven is working or still hot.
Do not lay on the glass lid hot pans
and heavy kitchen utensils.
Dry off any liquid whitch may have
spilt on the cover before opening it.
Models with glass lid
S
D
R
Fig. 6.1
SOME MODELS ONLY
CLEANING AND MAINTENANCE
6
MODELS WITH GLASS LID ONLY
For cleaning purposes, the lid can be easily
removed upwards once taken to the upright
position.
Should the hinges slip off, replace them in
their housing being careful that:
• The right housing must receive the
hinge marked “D” while the left housing
must receive the hinge marked “S”
(Fig. 6.1).
REGULATING OF THE BALANCE
Lower the lid and check the correct balance.
While opened at 45° it should hang up.
The springs of the hinges can be adjusted
if necessary by turning the screws “R”
clockwise (g. 6.1).

18
GENERAL ADVICE
• Before you begin cleaning, you
must ensure that the appliance is
switched off.
• When the appliance is not being used,
it is advisable to keep the gas tap
closed.
• The periodical lubrication of the gas
taps must be done only by specialized
personnel.
• If a tap becomes stiff, do not force;
contact your local After Sales Service
Centre.
• It is advisable to clean when the
appliance is cold and especially when
cleaning the enamelled parts.
• Avoid leaving alkaline or acidic
substances (lemon juice, vinegar, etc.)
on the surfaces.
• Avoid using cleaning products with a
chlorine or acidic base.
• Important: The use of suitable
protective clothing/gloves is
recommended when handling or
cleaning of this appliance.
WARNING
When correctly installed, your product
meets all safety requirements laid
down for this type of product category.
However special care should be taken
around the rear or the underneath of
the appliance as these areas are not
designed or intended to be touched and
may contain sharp or rough edges, that
may cause injury.
ENAMELLED PARTS
All the enamelled parts must be cleaned
with a sponge and soapy water or other
non-abrasive products.
Dry preferably with a microbre or soft
cloth.
Acidic substances like lemon juice, tomato
sauce, vinegar etc. can damage the enamel
if left too long.
STAINLESS STEEL, ALUMINIUM
PARTS AND SILK-SCREEN PRINTED
SURFACES
Clean using an appropriate product.
Always dry thoroughly.
IMPORTANT: these parts must be cleaned
very carefully to avoid scratching and
abrasion. You are advised to use a soft
cloth and neutral soap.
CAUTION: Do not use abrasive
substances or non-neutral detergents
as these will irreparably damage the
surface.
Attention! The appliance gets very hot, mainly around the cooking areas. It is very
important that children are not left alone in the kitchen when you are cooking.
Do not use a steam cleaner because the moisture can get into the appliance thus
make it unsafe.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven
door glass or the glass lid (models with glass lid only) since they can scratch the
surface, which may result in shattering of the glass.

19
GAS TAPS
Periodic lubrication of the gas taps must be
carried out by specialist personnel only.
In the event of operating faults in the gas
taps, call the Service Department.
INSIDE OF OVEN
The oven should always be cleaned after
use when it has cooled down.
The cavity should be cleaned using a
mild detergent solution and warm water.
Suitable proprietary chemical cleaners
may be used after rst consulting with
the manufacturers recommendations and
testing a small sample of the oven cavity.
Abrasive cleaning agents or scouring pads/
cloths should not be used on the cavity
surface.
NOTE: The manufacturers of this appliance
will accept no responsibility for damage
caused by chemical or abrasive cleaning.
Let the oven cool down and pay special
attention no to touch the hot heating
elements inside the oven cavity.
Do not store ammable material in the
oven.
REPLACING THE OVEN LIGHT BULB
WARNING: Ensure the appliance is
switched off before replacing the lamp
to avoid the possibility of electric shock.
• Let the oven cavity and the heating
elements to cool down.
• Switch off the electrical supply.
• Remove the protective cover.
• Unscrew and replace the bulb
with a new one suitable for high
temperatures (300°C) having the
following specications: 230V or 220-
240V, E14 and same power (check
watt power as stamped in the bulb
itself) of the replaced bulb
• Ret the protective cover.
Note: Oven bulb replacement is not
covered by your guarantee.
BURNERS AND PAN SUPPORTS
These parts can be removed and cleaned
with appropriate products.
After cleaning, the burners and their ame
spreaders must be well dried and correctly
replaced.
It is very important to check that the burner
ame spreader and the cap have been
correctly positioned. Failure to do so can
cause serious problems.
Check that the electrode “S” next to each
burner (gs. 6.2, 6.4) is always clean to
ensure trouble-free sparking.
The ignition plug “S” must be very
carefully cleaned.
Note: To avoid damage to the electric
ignition do not use it when the burners
are not in place.
CORRECT REPLACEMENT OF
THE AUXILIARY, SEMI-RAPID AND
RAPID BURNERS
It is very important to check that the burner
ame distributor “F” and the cap “C” has
been correctly positioned (see gs. 6.2,
6.3) - failure to do so can cause serious
problems.
CORRECT REPLACEMENT OF THE
TRIPLE RING BURNER
The triple ring burner must be correctly
positioned (see g. 6.6); the burner rib
must be enter in their logement as shown
by the arrows (see g. 6.4).
The burner correctly positioned must not
rotate (g. 6.5).
Then position the cap “A” and the ring “B”
(gs. 6.5, 6.6).

20
Fig. 6.2 Fig. 6.3
S
F
C
A
B
S
Fig. 6.4
Fig. 6.5 Fig. 6.6
