Elba ELIO 95-565 CG Installation and operating instructions

Made in Italy
100%
ELBA QUALITY
MADE IN ITALY
BUILT-IN GAS ON GLASS COOKING HOBS
Installation advices - Instructions for the use
GB

22
Dear Customer,
Thank you for having purchased and given your preference to
our product.
The safety precautions and recommendations reported below
are for your own safety and that of others. They will also provide
a means by which to make full use of the features oered by your
appliance.
Please preserve this booklet carefully. It may be useful in future,
either to yourself or to others in the event that doubts should
arise relating to its operation.
This appliance must be used only for the task it has
explicitly been designed for, that is for cooking foodstus.
Any other form of usage is to be considered as inappropriate
and therefore dangerous.
The manufacturer declines all responsibility in the event
of damage caused by improper, incorrect or illogical use of
the appliance.
DECLARATION OF CE CONFORMITY
• This appliance has been designed to be used only for cooking.Any other use (such as
heating a room) is improper and dangerous.
• This appliance has been designed, constructed, and marketed in compliance with:
-Safety requirements of the “Gas” Regulation (EU) 2016/426;
-Safety requirements of the “Low voltage” Directive 2014/35/EU;
-Safety requirements of the “EMC” Directive 2014/30/EU;
-Requirements of EU Directive 93/68/EEC;
-Requirements of EU Directive 2011/65/EU.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT
IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EC.
At the end of its working life, the product must not be disposed of as
urban waste. It must be taken to a special local authority di󰀨erentiated
waste collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health deriving from
inappropriate disposal and enables the constituent materials to be
recovered to obtain signicant savings in energy and resources. As a
reminder of the need to dispose of household appliances separately,
the product is marked with a crossed-out wheeled dustbin.
GB

33
IMPORTANT SAFETY PRECAUTIONSAND RECOMMENDATIONS
IMPORTANT: This appliance is designed and manufactured
solely for the cooking of domestic (household) food and is
not suitable for any non domestic application and therefore
should not be used in a commercial environment.
The appliance guarantee will be void if the appliance is used
within a non domestic environment i.e. a semi commercial,
commercial or communal environment.
Read the instructions carefully before installing and using
the appliance.
• This appliance has been designed and manufactured in
compliance with the applicable standards for the household
cooking products, including those for surface temperatures.
Some people with sensitive skin may have a more pronounced
temperature perception with some components although these
parts are within the limits allowed by the norms.
Thecomplete safety ofthe appliance alsodepends on thecorrect
use, we therefore recommend to always pay a extreme attention
while using the product, especially in the presence of children.
• After having unpacked the appliance, check to ensure that it is
not damaged.
In case of doubt, do not use it and consult your supplier or a
professionally qualied technician.
• Packing elements (i.e. plastic bags, polystyrene foam, nails,
packing straps, etc.) should not be left around within easy reach
of children, as these may cause serious injuries.
• Some appliances are supplied with a protective lm on steel and
aluminium parts. This lm must be removed before using the
appliance.
• IMPORTANT: The use of suitable protective clothing/gloves is
recommended when handling or cleaning this appliance.
• Do not attempt to modify the technical characteristics of
the appliance as this may become dangerous to use. The
manufacturer declines all responsibility for any inconvenience
resulting from the inobservance of this condition.

44
• CAUTION: this appIiance must only be installed in a permanently
ventilated room in compliance with the applicable regulations.
• Do not operate your appliance by means of an external timer or
separate remote-control system.
• Do not carry out cleaning or maintenance operations on the
appliance without having previously disconnected it from the
electric power supply.
• Do not use a steam cleaner because the moisture can get into
the appliance therefore making it unsafe.
• Do not cover the hob with aluminium foils.
• Do not touch the appliance with wet or damp hands (or feet).
• Do not use the appliance whilst in bare feet.
• If you should decide not to use this appliance any longer (or
decide to substitute another model), before disposing of it, it
is recommended that it be made inoperative in an appropriate
manner in accordance to health and environmental protection
regulations, ensuring in particular that all potentially hazardous
parts be made harmless, especially in relation to children who
could play with unused appliances.
• Thevariouscomponentsoftheappliancearerecyclable.Dispose
oftheminaccordancewiththeregulationsinforceinyourcountry.
If the appliance is to be scrapped, remove the power cord.
• After use, ensure that the knobs are in the o󰀨 position.
• Children less than 8 years of age shall be kept away unless
continuously supervised.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.

55
• The manufacturer declines all liability for injury to persons or
damage to property caused by incorrect or improper use of the
appliance.
• WARNING: During use the appliance and its accessible parts
become hot; they remain hot for some time after use.
– Care should be taken to avoid touching heating elements on
the hob.
– To avoid burns and scalds, young children should be kept
away.
• Make sure that electrical cables connecting other appliances in
the proximity of the cooktop cannot come into contact with the
hob.
• WARNING: Unattended cooking on a hob with fat or oil can be
dangerous and may result in re. NEVER try to extinguish a re
with water, but switch o󰀨 the appliance and then cover ame e.g.
with a lid or a re blanket.
• WARNING: Danger of re: do not store items on the cooking
surfaces.
• Do not place or leave empty pans on the glass ceramic hob.
• Do not allow heavy or sharp objects to drop on the glass ceramic
hob.
• Do not scratch the hob with sharp objects. Don’t use the hob as
a work surface.
• WARNING: If the hob is cracked or otherwise damaged by falling
objects etc., disconnect the appliance from the electrical power
supply to avoid the possibility of electric shock and call Customer
Service.
• WARNING: When correctly installed, your product meets all
safety requirements laid down for this type of product category.
However special care should be taken around the underneath
of the appliance as this area is not designed or intended to be
touched and may contain sharp or rough edges, that may cause
injury.
• CAUTION: The cooking process has to be supervised. A short
term cooking process has to be supervised continuously.

66
• If the power supply cable is damaged, it must be replaced only
by an authorized service agent in order to avoid a hazard.
• If the appliance is not tted with a supply cord and a plug, or with
other means for disconnection from the supply mains having a
contactseparationinallpolesthatprovidefulldisconnectionunder
overvoltage category III conditions, means for disconnection
must be incorporated in the xed wiring in accordance with the
wiring rules.
• WARNING: The appliance and its accessible parts become hot
during use.
Care should be taken to avoid touching heating elements.
Children less than 8 years of age shall be kept away unless
continuously supervised.
• WARNING: Use only hob guards designed by the manufacturer
of the cooking appliance or indicated by the manufacturer of the
appliance in the instructions for use as suitable or hob guards
incorporated in the appliance. The use of inappropriate guards
can cause accidents.
ENERGY LABELLING/ECODESIGN
• Commission regulation (EU) No 66/2014 (implementing Directive 2009/125/EC of the
European Parliament and of the Council).
Reference to the measurement and calculation methods used to establish compliance with
the above requirements:
• Standard EN30-2-1 (hobs: gas red burners).
USE OF THE APPLIANCE, ENERGY SAVING TIPS
HOB
GAS FIRED BURNERS
• It is important that the diameter of the pot be suitable to the size of the burner so as
not to compromise the high output of the burners and therefore energy waste. A small
pot on a large burner does not give you a boiling point in a shorter amount of time
since the capacity of heat absorption of a liquid mass depends on the volume and the
surface of the pot.
• Avoid keeping a burner on without something on it (without pot).

77
ADVICEADVICE
for thefor the
INSTALLERINSTALLER

88
IMPORTANT:
• The appliance is designed and approved for domestic use only and should not be
installed in a commercial, semi commercial or communal environment.
Your product will not be guaranteed if installed in any of the above environments
and could a󰀨ect any third party or public liability insurances you may have.
• This appliance is to be installed, regulated and adapted to function only by an authorised
person in compliance with the current local regulations in force and in observation of the
instructions supplied by the manufacturer.
Failure to comply with this condition will render the guarantee invalid.
• The appliance must be installed in compliance with regulations in force in your country
and in observation of the manufacturer’s instructions.
• Installation technicians must comply to current laws in force concerning ventilation and
the evacuation of exhaust gases.
• Incorrect installation, for which the manufacturer accepts no responsibility, may cause
personal injury or damage.
• This appliance shall only be serviced by authorised personnel.
• Always disconnect the appliance from mains power supply before carrying out any
maintenance operations or repairs.
• Important: The use of suitable protective clothing/gloves is recommended when
handling or installing this appliance.
• These tops are designed to be embedded into kitchen xtures measuring 600
mm in depth, working surface 30 to 40 mm thick.
• The appliance must be housed in heat-resistant units.
• The walls of the units must not be higher than work top and must be capable of
resisting temperatures of 105°C above room temperature.
• We would point out that the adhesive which bonds the plastic laminate to the
furniture must withstand temperatures not less than 150°C to avoid delamination.
• Standard installation (not ush): Do not seal the cooktop into the benchtop with
silicone or glue; this makes future servicing di󰀩cult. The manufacturer will not
cover the costs of removing the cooktop, or of damage caused by this removal.
• Do not install the appliance near inammable materials (eg. curtains).
WARNING!
When correctly installed, your product meets all safety requirements laid down for
this type of product category. However special care should be taken around the
underneath of the appliance as this area is not designed or intended to be touched
and may contain sharp or rough edges, that may cause injury.

99
INSTALLATION
1
TECHNICAL INFORMATION FOR THE INSTALLER
In order to install the cooker top into the kitchen xture, a hole with the dimensions shown
in g. 1.1a or 1.1b has to be made, bearing in mind the following:
■30cm wide models:
• A 40mm ventilation gap must be provided between the bottom of the appliance
and any cabinetry, draw unit or appliance.
• If the base of the cooktop is accessible through a cupboard or drawer space after
installation, a thermal protection barrier is not required.
• If the cooktop is installed above an oven, the two appliances shall be connected
to the gas and/or electrical supply with independent connections.
■60cm wide models:
• A 40mm ventilation gap must be provided between the bottom of the appliance
and any cabinetry, draw unit, thermal protection barrier or appliance.
• If the cooktop is installed directly above an oven (which does not have a cooling
fan motor) a thermal protection barrier must be installed below the base of the
cooktop as indicated in g. 1.1d.
• If the base of the cooktop is accessible through a cupboard or drawer space after
installation or if the oven installed below the cooktop has a cooling fan motor, the
thermal protection barrier is not required.
• If the cooktop is installed above an oven, the two appliances shall be connected
to the gas and/or electrical supply with independent connections.
■75cm wide models:
• A 40mm ventilation gap must be provided between the bottom of the appliance
and any cabinetry, draw unit, thermal protection barrier or appliance.
• If the cooktop is installed directly above an oven (which does not have a cooling
fan motor) or if its base is accessible through a cupboard or drawer space after
installation, a thermal protection barrier must be installed below the base of the
cooktop as indicated in g. 1.1d.
• If the oven installed below the cooktop has a cooling fan motor, the thermal
protection barrier is not required.
• If the cooktop is installed above an oven, the two appliances shall be connected
to the gas and/or electrical supply with independent connections.
■90cm wide models:
• A 40mm ventilation gap must be provided between the bottom of the appliance
and any cabinetry, draw unit, thermal protection barrier.
• If the base of the cooktop is accessible through a cupboard or drawer space after
installation, a thermal protection barrier must be installed below the base of the
cooktop as indicated in g. 1.1d.
■All models:
• The cooker top must be kept no less than 200 mm away from any side wall (from
side edge of cutout - gs. 1.1a, 1.1b, 1.1c).
• The hob must be installed at least 60 mm from the wall (from rear edge of cutout
- g. 1.1a, 1.1b).
• There must be a distance of at least 650 mm between the hob and any wall
cupboard or extractor hood positioned immediately above (see g. 1.1c).

1010
STANDARD INSTALLATION
E
60 mm
D
E
60 mm
D
200 mm
B
A
C
B
A
C
E1
D1
R7
6
200 mm
Fig. 1.1a
Fig. 1.1b
XX=8 mm
X=4 mm
XX=4 mm
FLUSH INSTALLATION (MODELS WITHOUT METAL TRIM/S AND X=4 ONLY)
If you wish to install the hob ush with the work surface, it is neccessary to execute/carry
out a miling in the hole of the cut-out as indicated in gs. 1.1b.
E
60 mm
D
E
60 mm
D
200 mm
B
A
C
B
A
C
E1
D1
R7
6
200 mm
E1A
E1B

1111
650 mm
500 mm
450 mm
Fig. 1.1c
Cooktop
installed
200mm
40 mm
Space for
connections
Clearance
Door
Thermal
protection
barrier
The thermal protection barrier must
be:
• removable with the use of a
tool for installation and service;
• heat-resistant;
• made from low thermal
conductivity material.
Fig. 1.1d
Measures (mm)
Description A (*) B (*) C (**) D D1 (***) E E1 (***) E1A (***) E1B (***)
30cm wide models 300 520 50 (1)
54 (2)
or 60 (2) for
ush
installation
270 305
480
525 21 24
60cm wide models 600 510 560 605 515 10 25
75cm wide models 750 510 560 755 515 10 25
90cm wide models 900 510 840 905 515 10 25
(*) For models with metal trim/s add 4mm to the measurement for each trim.
Example: front metal trim= B+4mm.
(**)from the top of countertop to bottom of cooktop.
(***) ush installation.
X(1) X=8 mm
(2) X=4 mm

1212
F
F
F
F
R
R
R
F
F
R
R
F
F
FF
R
R
R
F
F
R
RFig. 1.2b
Fig. 1.2c
G
G1
G2
Fig. 1.2e
Fig. 1.2d
R
F
R
F
Fig. 1.2a
G
FASTENING THE COOKTOP
Each cooktop is provided with an installation kit
including brackets and screws for fastening the
cooktop to benches from 30 to 40mm thick.
30, 60 and 75cm wide models (g. 1.2a, 1.2b):
The kit includes two “F” type brackets (for the
front of the cooktop), two “R” type brackets (for
the rear of the cooktop) and four self-threading
screws “S”.
90cm wide models (g. 1.2c): The kit includes
four “F” type brackets (for the front of the cooktop),
three “R” type brackets (for the rear of the cooktop)
and seven self-threading screws “S”.
• Cut the unit according to the dimensions in
g. 1.1a or 1.1b.
• Models in fig. 1.1, 1.2, 1.3, 1.5, 1.9, 1.10, 1.11
of page 25, 26
: stretch gasket “G” over the
edge of the hole made, being careful to
overlay the junction edges (fig. 1.2d, 1.2e).
• Models in fig. 1.4, 1.6, 1.7, 1.8 of page 25, 26 :
spread the longer seal “G1” around the left,
rear and right sides (g. 1.2f).
• Fasten the brackets “F” and “R” to the
appropriate socket holes, without tightening
the screws “S” for the moment. Make sure
that the tabs are mounted correctly, as
shown (gs. 1.2h, 1.2i). Rotate the tabs so
that the cooktop can be put into the cutout.
For the models in gs. 1.4, 1.6, 1.7, 1.8 of page
25, 26, stretch the tightest gasket "G2" along
the entire perimeter of the cooktop. (g. 1.2g).
• Put the cooktop into the cutout and position
it correctly.
• Put the brackets “F” and “R” into place; tooth
“A” of the brackets should go into the hole
(gs. 1.2h, 1.2i).
• Tighten screws “S” until the cooktop is
completely secured to the bench.
• Using a sharp cutter or trimmer knife, trim
the excess sealing material around the edge
of the cooktop.
Take care not to damage the workbench.
• In case to install the hob ush with the work
surface, ll any gaps between the glass and
along the perimeter of the work surface with
insulating silicone, and wipe away any excess.

1313
30 mm min. 40 mm max.
S
A
F
G (G2)
30 mm min.
40 mm max.
40 mm min.
40 mm min.
S
A
R
G (G1)
30 mm min. 40 mm max.
S
A
F
G (G2)
30 mm min.
40 mm max.
40 mm min.
40 mm min.
S
A
R
G (G1)
Fig. 1.2h Fig. 1.2i
Rear Fixing Brackets Front Fixing Brackets
G
G1 Fig. 1.2f
G2
Fig. 1.2g

1414
VENTILATION REQUIREMENTS
The appliance must be installed in compliance with applicable local regulations
concerning ventilation and the evacuation of exhaust gases.
Intensive and prolonged use may require extra ventilation, e.g. opening a window,
or more e󰀩cient ventilation increasing the mechanical suction power if this is tted.
CHOOSING SUITABLE SURROUNDINGS
The room where the gas appliance is to be installed must have a natural ow of air so that
the gas can burn (in compliance with applicable local regulations).
The ow of air must come directly from one or more openings made in the outside walls
with a free area of at least 100 cm2(or refer to applicable local regulations).
The openings should be near the oor and preferably on the side opposite the exhaust for
combustion products and must be made so that they cannot be blocked from either the
inside or the outside.
When these openings cannot be made, the necessary air can come from an adjacent
room which is ventilated as required, as long as it is not a bed room or a danger area (in
compliance with applicable local regulations).
In this case, the kitchen door must allow the passage of the air.
DISCHARGING PRODUCTS OF COMBUSTION
Extractor hoods connected directly to the outside must be provided, to allow the products
of combustion of the gas appliance to be discharged (g. 1.3).
If this is not possible, an electric fan may be used, attached to the external wall or the
window; the fan should have a capacity to circulate air at an hourly rate of 3-5 times the
total volume of the kitchen (g. 1.4).
Thefan canonly be installed if the room hassuitable ventsto allow air to enter, asdescribed
under the heading “Choosing suitable surroundings”.
H min 650 mm
Extractor hood
for products of
combustion
Air vent Air vent
Electric fan to
extract products of
combustion
Fig. 1.4
Fig. 1.3

1515
GAS SECTION
2
GAS INSTALLATION REQUIREMENTS
Important !
• This appliance must be installed and serviced only by a suitably qualied,
registered installer. The installer shall refer to the local standards in force.
• Failure to install the appliance correctly could invalidate any manufacturer’s
warranty.
• Before installation, make sure that the local distribution conditions (gas type and
pressure) and the adjustment of this appliance are compatible. The appliance
adjustment conditions are given on the plate or the label.
• If the gas pressure (for which the appliance is to be used) is variable or if it is
not within the values indicated on the rating plate, it is mandatory to install a
proper gas pressure regulator which must be adjusted to guarantee the correct
operating pressure to the appliance (as per rating plate).
The regulator must be installed, adjusted and tested by a qualied technician.
• WARNING: Using the appliance with a wrong and/or variable gas pressure may
be extremely dangerous and may result in serious injury to the user. Damage to
the appliance could occur if not observing this condition.
The manufacturer declines every responsibility for any inconvenience resulting
from the inobservance of this condition.
This appliance is supplied for use on LPG (check the gas regulation label attached on the
appliance). OR
This appliance is supplied for use on Natural gas or LPG (check the gas regulation label
attached on the appliance).
• Appliances supplied for use on Natural gas: they are adjusted for this gas only and
cannot be used on any other gas (LPG) without modication. The appliances are
manufactured for conversion to LPG.
• Appliances supplied for use on LPG: they are adjusted for this gas only and cannot
be used on any other gas (Natural gas) without modication. The appliances are
manufactured for conversion to Natural gas.
If the Natural gas/LPG conversion kit is not supplied with the appliance this kit can be
purchased by contacting the After-Sales Service.
FOR SOUTH AFRICA ONLY
The appliance is predisposed and adjusted to operate with the gas G30/G31 (LPG USE).
Operating pressure: 2,8 kPa.
This appliance is manufactured for conversion to G20 (NATURAL GAS) if required and is
supplied with a conversion kit.
This appliance must only be connected to NATURAL GAS after a NATURAL GAS
conversion kit has been tted.

1616
CONNECTING THE COOKTOP TO THE GAS SUPPLY
The gas connection tting (g. 2.1) is made up of:
• the oating nut;
• the elbow;
• the gaskets;
The gas connection must be carried out by an authorised person according to the
relevant local standards.
• If using a exible hose, make sure it does not come into contact with moving parts.
• The rear of the chassis is recessed to provide a channel for the appliance inlet pipe.
• The gas connection tting can be turned in the direction required (but never in a vertical
or horizontal position) after loosening the elbow and oating nut connection.
• Never attempt to turn the elbow without having rst loosened the oating nut.
• The supplied gaskets guarantee a good seal for the gas connection. We recommend
that you replace the gaskets on the slightest sign of wear, deformation or imperfection.
• After connecting to the gas mains, check that the couplings are correctly sealed, using
soapy solution, but never a naked ame.
Fig. 2.1
Gasket
Floating nut
Appliance inlet pipe
Rigid pipe or exible
hose
Gasket
Elbow
ISO 228-1 (male) 1/2”
cylindrical
ISO 228-1 (male) 1/2”
cylindrical

1717
ADDITIONAL GAS CONNECTION REQUIREMENTS
When connecting the cooktop to the gas supply with rigid pipes or a exible hose, make
sure that:
• You use rigid pipes or a exible hose compliant with applicable local regulations. The
exible hose shall be of the correct construction for the type of gas being used and of
the correct size to maintain the heat output of the appliance.
• The connection with rigid metal pipes does not cause stress or pressure to the gas
piping.
• The exible hose is not under tension, twisted, kinked, or too tightly bent, neither while
the cooktop is in use nor while it is being connected or disconnected.
• The exible hose is not longer than 2000 mm (or refer to applicable local regulations)
and does not come into contact with sharp edges, corners, or moving parts, as these
may cause abrasion. Use a single exible hose only; never connect the cooktop with
more than one exible hose.
• The exible hose can easily be inspected along its entire length to check its condition;
if it has an expiry date, it should be replaced before that date.
• If using a exible hose which is not entirely made of metal, make sure that it does not
come into contact with any part of the cooktop with a surface temperature of 70°C or
above (or refer to applicable local regulations).
• The rigid pipe or exible hose is replaced if it shows signs of damage.
• The exible hose is not subject to excessive heat by direct exposure to ue products
or by contact with hot surfaces.
• The socket into which the plug of the exible hose t is permanently attached to a rmly
xed gas installation pipe and is positioned so that the hose hangs freely downwards.
• The plug of the exible hose is accessible after installation, so that it can be
disconnected for service or removal.
• You inform the customer that the rigid pipe or exible hose should not be subjected to
corrosion by cleaning agents.
GAS MAINTENANCE
Some models - for the gas category check the data label attached on the appliance
TABLE FOR THE CHOICE OF THE INJECTORS
Cat: I 3+ G30/G31
28-30/37 mbar
BURNERS Nominal
Power [kW] Reduced Power [kW] Ø injector [1/100 mm]
Auxiliary (A) 1,00 0,40 50
Semi-rapid (SR) 1,75 0,45 66
Rapid (R) 3,00 0,75 87
Double-ring compact (DRC) 3,50 1,50 92
Double-ring (DR) 3,80 1,50 98
Dual (DB) - inner crown 0,80 0,40 46
Dual (DB) - outer crown 3,40 1,50 65 (x2)

1818
LUBRICATION OF THE GAS TAPS
In case of di󰀩culty in the gas taps operation, call Service.
IMPORTANT
All intervention regarding installation, maintenance and conversion of the appliance
must be fullled with original factory parts.
The manufacturer declines any liability resulting from the non-compliance of this
obligation.
TABLE FOR THE CHOICE OF THE INJECTORS
Cat: II 2H 3+ G30/G31
28-30/37 mbar G20 20 mbar
Cat: II 2E+3+ G30/G31
28-30/37 mbar G20/G25 20/25 mbar
BURNERS Nominal Power
[kW]
Reduced
Power
[kW]
Ø injector
[1/100 mm] Ø injector [1/100 mm]
Auxiliary (A) 1,00 0,40 50 77
Semi-rapid (SR) 1,75 0,45 66 101
Rapid (R) 3,00 0,75 87 129
Double-ring compact (DRC) 3,50 1,50 92 139
Double-ring (DR) 3,80 1,50 98 141
Dual (DB) - inner crown 0,80 0,40 46 70
Dual (DB) - outer crown 3,40 1,50 65 (x2) 95 (x2)
AIR VENT NECESSARY FOR GAS COMBUSTION = (2 m3/h x kW)
BURNERS Air necessary for combustion [m3/h]
Auxiliary (A) 2,00
Semi-rapid (SR) 3,50
Rapid (R) 6,00
Double-ring compact (DRC) 7,00
Double-ring (DR) 7,60
Dual (DB) - inner crown only 1,60
Dual (DB) - outer crown only 6,80
Dual (DB) - inner & outer crown 8,40
Some models - for the gas category check the data label attached on the appliance

1919
J
Auxiliary,
semi-rapid
and rapid
burner
REPLACEMENT OF THE INJECTORS
If the injectors are not supplied they can
be obtained from the “Service Centre”.
Selecttheinjectorstobereplacedaccording
to the “TABLE FOR THE CHOICE OF THE
INJECTORS”.
The nozzle diameters, expressed in
hundredths of a millimetre, are marked on
the body of each injector.
REPLACEMENT OF THE
INJECTORS OF THE COOKTOP
BURNERS
To replace the injectors proceed as follows:
• Remove pan supports and burners
from the cooktop.
• Using a wrench, substitute the
injectors “J” (gs. 2.2a, 2.2b, 2.2c,
2.2d) with those most suitable for the
kind of gas for which it is to be used.
The burners are conceived in such a
way so as not to require the regulation
of the primary air.
J
J
J
J
Fig. 2.2a
Fig. 2.2b
Fig. 2.2d Fig. 2.2c
Double-ring compact
burner
Double-ring burnerDual burner
Injector for
inner crown Injectors
for outer
crown

2020
A
Fig. 2.3
SETTING THE MINIMUM OF THE
COOKTOP BURNERS
In the minimum position the ame must
have a length of about 4 mm and must
remain lit even with a quick turn from the
maximum position to that of minimum.
The ame adjustment is done in the
following way:
• Turn on the burner.
• Turn the tap to the 'MINIMUM' position.
• Take o󰀨 the knob.
• With a small at screwdriver turn the
screw “A” to the correct regulation (g.
2.3).
• Modelswithdualburner:Forthedual
burner set the minimum (as indicated
above) for both the gas valves (one for
the inner and one for the outer crown).
The operations must be carried out
one gas valve at a time.
Normally for LPG tighten up the
regulation screw.
