Elcometer 1537 User manual

English
Elcometer 1537
ISO Scratching Tool
Operating Instructions

English
R
is a registered trademark of Elcometer Instruments Ltd.
All other trademarks acknowledged.
© Copyright Elcometer Instruments Ltd. 2006.
All rights reserved. No part of this Document may be reproduced, transmitted, transcribed, stored (in a retrieval
system or otherwise) or translated into any language, in any form or by any means (electronic, mechanical,
magnetic, optical, manual or otherwise) without the prior written permission of Elcometer Instruments Ltd.
Doc.No. TMA-0359 Issue 01
Text with Cover No: 19807

R
1
CONTENTS
Section Page
1 About this instrument . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Using your scratching tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 ISO 2063 scratch test parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Technical specification. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 Related equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

R
2
Thank you for your purchase of this Elcometer 1537 ISO Scratching Tool. Welcome to Elcometer.
Elcometer are world leaders in the design, manufacture and supply of inspection equipment for coatings
and concrete. Our products cover all aspects of coating inspection, from development through application
to post application inspection.
This Elcometer 1537 ISO Scratching Tool is a world beating product. With the purchase of this product you
now have access to the worldwide service and support network of Elcometer. For more information visit our
website at www.elcometer.com
1 ABOUT THIS INSTRUMENT
The Elcometer 1537 ISO Scratching Tool is a simple but effective instrument which is used to scratch the
surface of samples in preparation for adhesion, salt spray and corrosion tests. The tool is held horizontally
and pulled across the sample to produce the scratch.
The Elcometer 1537 has a tungsten carbide blade which is set to give a 90° cutting angle with a 75° cutting edge.
This tool can be used to prepare specimens for testing to ISO 2063, ISO 7253 and NBN 755 standards.
1.1 WHAT THE BOX CONTAINS
• Elcometer 1537 ISO Scratching Tool
• Storage case
• Operating instructions
Your Elcometer 1537 ISO Scratching Tool is packed in a cardboard and foam package. Please ensure that
this packaging is disposed of in an environmentally sensitive manner. Consult your local Environmental
Authority for further guidance.

R
3
2 USING YOUR SCRATCHING TOOL
2.1 BEFORE YOU START
Ensure the blade of your Elcometer 1537 ISO Scratching Tool is sharp and undamaged.
2.2 PRODUCING A SCRATCH
1. Hold the instrument as shown below.
2. Place the cutting edge on the sample.
3. Exert slight downward pressure.
4. Pull the blade across the sample.

R
4
3 ISO 2063 SCRATCH TEST PARAMETERS
Use the tool to produce a lattice pattern of scratches in accordance with the following dimensions:
The depth of the scratch should be such that the coating is cut through to the substrate.
4 TECHNICAL SPECIFICATION
Blade material: Tungsten carbide
Cutting angle: 90°
Cutting edge: 75°
Approximate
surface covered
by the lattice
Thickness of
coating
(µm)
Distance
between
scratches
(mm)
15 mm x 15 mm ≤200 3
25 mm x 25 mm > 200 5

R
5
5 RELATED EQUIPMENT
In addition to the Elcometer 1537 ISO Scratching Tool, Elcometer produces a wide range of other coating
testing equipment.
Users of the Elcometer 1537 ISO Scratching Tool may also benefit from the following Elcometer products:
• Elcometer 1538 DIN Scratching Tool
• Elcometer Multi Function Scratch Tester
• Elcometer Continuous Humidity Chambers
• Elcometer Stackability and Internal Stress Meters
• Elcometer Elasticity and Resistance to Deformation Testers
• Elcometer Appearance Meters
• Elcometer Coating Thickness Gauges
For further information contact Elcometer or your local supplier. Details of Elcometer offices around the
world are given on the outside cover of these operating instructions. Alternatively visit the Elcometer
website, www.elcometer.com
