Important Safety Instructions
Must be installed by a qualified technician.
Read these installation instructions. Keep these instructions for future use.
Follow all instructions. Install in accordance with manufacturer's instructions.
FAILURE TO FOLLOW INSTRUCTIONS COULD RESULT IN DEATH OR SERIOUS INJURY
FAILURE TO FOLLOW INSTRUCTIONS VOIDS
WARRANTY.
This luminaire must be mounted or supported independently of an outlet box.
Make sure electrical connections are wired correctly. Power and neutral wires must
be connected to the luminaire disconnect. Insert the power wire into the black colored
insert and the neutral wire into the white colored insert.
The ground must be connected. Do not defeat the safety purpose of the grounding
wire inside the chassis. The chassis must be grounded to avoid possible electrical shock.
CAUTION
READ ALL INSTRUCTIONS
PRIOR TO INSTALLATION
WARNING:
CAUTION:
TO PREVENT INJURY, THE MIRROR MUST
BE INSTALLED IN ACCORDANCE WITH
THE MANUFACTURER'S INSTRUCTIONS
THE ONLY USER SERVICEABLE PARTS INSIDE
ARE THE LAMPS.
OTHER COMPONENTS MUST BE SERVICED
BY QUALIFIED ELECTRICIANS. LUMINAIRE
DISCONNECT MUST BE DISCONNECTED
PRIOR TO COMPONENT SERVICING
