GCS PLAMERE GPM-1000 User manual

INSTRUCTION MANUAL
For safe use, please read this manual carefully.
Use it correctly according to the contents described.
Keep this book for future to use to transferring this
Product to another person, please be sure to
deliver it together.
■INSTRUCTION⋯⋯⋯⋯⋯⋯⋯⋯⋯ 1
■CAUTION⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 2
■PRODUCT COMPOSITION⋯⋯⋯ 4
■DESIGNATION⋯⋯⋯⋯⋯⋯⋯⋯⋯ 5
■HOW TO USE⋯⋯⋯⋯⋯⋯⋯⋯⋯⋯ 6
■HOW TO CHARGE⋯⋯⋯⋯⋯⋯⋯ 8
■SPECIFICATION⋯⋯⋯⋯⋯⋯⋯⋯⋯9
■PRODUCT WARRANTY⋯⋯⋯⋯⋯9
TM
CONTENTS
PLAMERETM (MODEL:GPM-1000)

INSTRUCTION
■Pulse Mode High Frequency Lifting
•Support pulse mode of 500Hz as well
as continuous mode.
•High Frequency by pulse mode which
optimized for lifting promotes
collagen synthesis and wrinkles.
1
■Base-offer High Frequency
permeating tips and fractional
tips for cosmetic applications
•40kHz Continuous mode permeating
tips with electroporation effect.
•Fractional tips which use together with
Permeating tips to maximize
permeating effect.
LIFTING
PULSE MODE
500Hz

CAUTION
⚫Do not use or leave it near fire, pay attention of the risk of volatile gas ignition.
⚫Do not disassemble or modify the product.
⚫Do not touch or handle the body and charger with wet hands.
⚫When attaching the needle to the syringe mounted on the body, be careful not
to get stung or damage the needle.
⚫Always wipe the body and components with a dry cloth before and after use to
keep the condition as hygienic status.
⚫Exclusive film of acne tips are disposable and should never be reused.
⚫Please check the charging status before use and use it after fully charge.
⚫If you move from a cool outside to a warm inside, sudden changes in
temperature can cause condensation that can form water droplets. In this case,
please adjust the temperature for a sufficient time indoors and use after the
condensation does not occur or disappear.
⚫Do not operate the tips against metal or metal objects. There is a risk of
malfunction or damage.
⚫Do not use more than few seconds in one place during the procedure. There are
risk of skin damage if energy is concentrated too much in one place.
⚫Do not use excessive force on the buttons, motor, and charging terminals of the
product. It may cause damage or breakdown.
⚫If the product is dropped or damaged by an external shock, do not use it, only
the case of operating well before use.
⚫Never wash with water. Warranty does not apply in case of failure due to
flooding.
⚫During the procedure of operation at the time of start and break, the electric
field may intermittently increase. Please do not use it near other electronic
devices.
⚫Pregnant and breastfeeding women are prohibited to use.
⚫Do not use other than the skin surface(mucous membranes and mucus areas,
nose, mouth, genitalia, etc)
⚫Prohibited: Patients with hepatitis C virus and infection, patients with immune
system disorders(heart, liver, kidney failure), HIV/AIDS patients, local anesthesia
allergy patients, heart pacemakers or active.
2

CAUTION
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for help.
3

4
PRODUCT COMPOSITION
■Components name & Function
1. Body : Main body for High Frequency Output. To applied various tips, the 3Ø
standard collet has set up as base.
2. Charging Cable : Charging Lithium polymer battery by USB Charging cable
3. Lifting Tip : Ball-shaped tip for lifting procedures.
4. Permeating Tip : Tip used to promote cosmetic absorption.
5. Fractional Tip : Tips used to supplementary for cosmetic absorption.
6. Tip Collets : Use to fix the tip.
1. Body 2. Charging Cable
3. Lifting Tip 4. Permeating Tip 5. Fractional Tip 6. Tip Collets

❼
❺
❽➒
➓
❻
❶
❷
❸
❹
DESIGNATION
❶Collet : A part for inserting the needle tip as 3Фstandard size.
❷Head Cap : Cap for fixing needle tip.
❸Output Indicator : Indicates the state of output.
❹Shot Button : Operating button for output.
❺Mode Selection Switch : Continuous (C ) or Pulse (P) mode.
If pulse mode selected, it will be output in pulse form of 500Hz.
■When using the pulse mode, set the wheel switch 5 or less.
❻Power Indicator : Indicates Power ON/OFF status.
❼Batter Warning Light : Red is displayed when the remaining battery is low.
■If the warring light comes on, stop using it and charge it before using it.
❽Wheel Switch : Turn ON/OFF the power or adjust the output intensity.
➒Charging Indicator : Indicates charging status.(Red: charging, Green : charging
completed)
➓Charging Terminal : Terminal for connecting a micro USB type charger.
■Pressing the shot button doesn’t work during charging.
5
BODY

6
Procedure
■Lifting uses pulse mode instead of continuous mode. Select the mode switch as
Pulse(P) in main body.
•First, clean the skin before the procedure. During the lifting procedure, there are
nothing to applied to the skin. But if necessary, apply the appropriate primer,
high-frequency cream, lifting cream, etc.
•The appropriate output level is set according to the application site and purpose
to prevent unnecessary discharge.
2
Tip Installation
Rotate the head cap counterclockwise to loosen it slightly, insert the lifting tip
into the collet, and turn the head cap clockwise to secure the tip to the collet.
1
Head Cap
Lifting Tip
Dragging
Slowly massage the
wrinkles along the line.
Tapping
Move vertically and tap
Your skin like a dot.
Brushing
Touch the skin surface
like a brushing.
⚫When using the pulse (P) mode, use the output intensity in the range of
1~5 and do not use more than 5. Pulse mode has a frequency output of
500Hz specially designed for lifting, so over 5 cycles can cause unnecessary
skin irritation.
CAUTION
!
Lifting for Wrinkle Improvement
and Collagen Regeneration
HOW TO USE - PART 1 :

7
■Tip installation is same as Lifting tip installation. The procedure,
it takes 15minutes as shown below.
Tapping by Fractional Tip –5min
After installing the fractional tip first, clean the treatment are and remove the
water , Set the continuous(C) mode and the output intensity to 3~5, then move
the tip and tapping lightly.
1
■High Frequency is generated at
the multipoint part of the
fractional tip and the skin layer
is opened to prepare the
cosmetics to absorb.
Apply cosmetics
Apply cosmetics evenly.
2
1st Absorbent massage by Permeating Tip –5min
After replace with a permeating tip, Continuous(C) mode and the output
strength 5~7, then move the tip and gently massage.
3
■High Frequency is generated
between the permeating tip and
the skin surface and the
electroporation effect, cosmetic
will be penetrated into the deep
skin.
2nd Absorbent massage by Fractional Tip and Finishing –5min
After replace with a Fractional Tip, Pulse (P) mode and output strength 3~5, then
move the tip and tapping lightly.
4
■High Frequency is generated at
the multipoint part of the
fractional tip and promote the
absorption of residual active
ingredients remaining after using
the permeating tip and this is a
final stage to performs skin tissue
lifting by pulse.
PULSE
Permeating Tip for Cosmeti Absorbent +
Fractional Tip
HOW TO USE - PART 2 :

■Connecting Micro USB
•Charging starts when you Connect micro USB cable to the USB terminal of pc or
notebook or connecting micro USB cable of the micro USB type mobile phone
charger to the charging terminal of the main body.
HOW TO CHARGE
8
■Sterilizer & Cleaning
•You may clean the used needle tip through mopping by alcohol cotton or
soaking in alcohol.
•Don’t soak the body into the alcohol and wipe the surface with dry cloth
smoothly.
⚫Keep the tip after disconnecting from body after treatment. If you keep this
device with tip, it will cause from damamge
CAUTION
!
⚫General life of recharging battery’ is 500times of recharging and discharging
but it is possible to decreased depending to operation condition,
temperature or moisture etc.
⚫Don’t leave it for long hours without using. If you let it discharged
completely, battery life will be shorten.
⚫At your first trial, After Use it full charging.
⚫It takes 3 hours for full charging but there is a little difference depending on
remaining charge.
⚫While charging, the shot button doesn’t work. Do not use it during charging
and it can’t be used for user’s safety.
CAUTION
!
Micro USB Cable
Charging Terminal

■Product Name: PLAMERETM ■Model Name: GPM-1000
■Main Function: High Frequency is induced into tissues for heat, sterilization and lifting
■Output Frequency: 40kHz
■Output Level: Steps 1~9 (Analog wheel type)
■Output Mode: continuous, pulse ■Pulse Mode Frequency: 500Hz
■Treatment Tips: Lifting Tip, Permeating Tip, Fractional Tip
■Power: Internal Li-Polymer Rechargeable Battery 3.7V, 420mAh
■Charger: Micro USB (+5V) ■Life Time: Full charged, Max 3hours
■Power Consumption: Max. 6W ■Material: Body-PC/ABS Resin
■Weight: 100g
■Size: 165 x 38 x 23 mm
SPECIFICATION
9
• This product is guaranteed for one year from the date of purchase.
• If it is difficult to confirm the warranty period, the warranty period will be applied from
the date three months after the date of manufacture.
• We will repair or replace the defective product in accordance with the condition.
• Damage caused by user's negligence will not be covered by warranty even if it is within
the warranty period.
• Repairs other than designated service centers are not covered by the warranty.
• The service period will not be extended after repair or repair.
PRODUCT WARRANTY
Product Name PLAMERETM Model No. GPM-1000
Serial No.(S/N)
Purchasing Company Tel.
Date of Purchasing
Customer
Info.
Name Tel.
Add
REV.04
※ Specification are subject to change without notice
Address : #1008, 555, Dunchon - daero, Jungwon - gu,
Seongnam - si, Gyeonggi - do, Korea
Tel : + 82 - 2 -555 - 1536 | Fax : + 82 - 2 -3142 –7670
A/S: + 82 - 70 -4418 -9585
This product is based on the Fair Trade Commission Notice of Consumer Dispute
Resolution Standards Exchange or Compensation.
