ElectrIQ CD16LE User manual

Premium Low Energy Compressor
Dehumidifier with Digital Humidistat
CD16LE – 16 litres per day
USER ANUAL
Thank you for choosing ElectrIQ.
Please read this user manual before using this innovative Dehumidifier
and keep it safe for future reference
Visit our page www.electrIQ.co.uk for our entire range of Intelligent Electricals

1
Contents
Safety Instructions ………………..……………….. 2
Installation ………………..……………….. 4
Parts ………………..……………….. 5
Control Panel ………………..……………….. 6
Quick reference guide ………………..……………….. 7
Positioning ………………..……………….. 8
Water rainage ………………..……………….. 9
Care and Maintenance ………………..……………….. 10
Troubleshooting ………………..……………….. 12
Technical ata ………………..……………….. 13

2
SAFETY INSTRUCTIONS
Important
• Carefully read the instructions before operating the unit
• This appliance is for indoor use only and intended for use in a domestic environment only.
Any other use is not recommended by the manufacturer and may cause fire, electrical shocks
or other injury to user or property.
• Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet.
• Installation must be in accordance with regulations of the country where the unit is used.
• If you are in any doubt about the suitability of your electrical supply have it checked and, if
necessary, modified by a qualified electrician.
• This dehumidifier has been tested and is safe to use. However, as with any electrical
appliances - use it with care.
• isconnect the power plug from socket before dismantling, assembling or cleaning.
• Avoid touching any moving parts of the appliance.
• Never insert fingers, pencils or any other objects though the guard
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities. It is also not intended for use by those with a lack of
experience and knowledge, unless they have been given supervision or instruction concerning
the use of the appliance by a person responsible for their safety.
• o not leave children unsupervised with this appliance.
• o not clean the unit by spraying it or immersing it in water.
• Never connect the unit to an electrical outlet using an extension cord. If a power outlet is
not available, one should be installed by a qualified electrician.
• Never operate this appliance if the cord, power adapter or plug is damaged. Ensure the
power cord is not stretched or exposed to sharp object/edges.
• A damaged power supply cord should be replaced by the manufacturer or a qualified
electrician in order to avoid a hazard.
• Any service other than regular cleaning or filter replacement should be performed by an
authorized service representative. Failure to comply could result in a voided warranty.
• o not use the appliance for any other purposes than its intended use.
• o not tilt the unit while in use. The unit is design to work only in vertical position.
• This dehumidifier must always be stored and transported upright, otherwise irreparable
damage may be caused to the compressor; if in doubt we suggest waiting at least 24 hours
before starting the unit.
• Avoid restarting the dehumidifier unit unless 5 minutes have passed since being turned off.
This prevents damage to the compressor.
• Never use the mains plug as a switch to start and turn off the dehumidifier. Use the provided
ON/OFF switch located on the control panel.
• Always place the unit on a dry and stable surface.
• The appliance should not be installed in laundry or wet rooms where the humidity is higher
than 85% RH
• o not dry laundry above the unit to prevent water entering the dehumidifier. Place the
laundry at least 1 meter away from your dehumidifier.
• o not place the unit next to heat sources (e.g. electrical fires, fireplaces, etc.)

3
• Avoid mishandling the dehumidifier. ropping, throwing the unit can cause damage to its
internals and increases the risks of operating it.
• o not store or use gasoline, petrol, paint, solvents or other flammable vapours or liquids in
the vicinity of this dehumidifier or any other appliance.
• This dehumidifier must not be used in spaces where there is a high concentration of gases,
solvent or other volatile organic compounds; in very dusty environments; in any domestic,
commercial or industrial environment where air composition is flammable.
Energy Saving and Unit Safety Protection Tips
• o not cover or restrict the airflow from the outlet or inlet grills. o not operate and follow
troubleshoot procedure if the self-opening louvers do not open on power on.
• For maximum performance the minimum distance from a wall or objects should be 20 cm
• Keep the filters or grills of the unit clean. Under normal conditions, filters or grills should
only need cleaning once every three weeks (approximately).
Since the filters remove airborne particles, more frequent cleaning maybe necessary,
depending on the air quality. Vacuum and wash the mesh filters with hot soapy water and dry
them before placing them back in the unit.
Quick visual safety guide on where or when not to use your dehumidifier

4
Installation
Remove any water from the water tank before starting the unit. In order to save energy, do
not open windows or doors while the unit is running. Place the unit on a hard / flat surface.
On first use run the unit continuously for 24 hrs.
To reduce noise levels:
Place a piece of carpet or a rubber mat under the unit to reduce any vibrations while the unit
is running.
C 16LE dehumidifier uses compressor technology to extract water from the
environment. The compressor dehumidifiers are ideal for normal domestic or office
environment which heated during the winter months with temperatures above 12-15⁰C.
C 16LE is easy to move around on castors and is an intelligent dehumidifier which will
extract unwanted humidity while saving money due to their humidistat and power saving
logic. C 16LE features an intelligent humidistat which is adjustable in increments of 5%
from 40-80% RH insuring your room is not dried too much and power is not wasted.
Features
Your dehumidifier belongs to the ElectrIQ low energy premium dehumidifiers featuring low power
consumption, power saving logic and air purification option.
1. Easy to use to use controls
2. Low energy only uses a fraction of the electricity of similar dehumidifiers
3. Great for up to 4 bed houses
4. Cost effective way to combat mould, condensation and damp
5. ries laundry more efficiently than a tumble dryer
6. esigned to complement any modern space
7. Quiet and turbo fan speed selection for best balance between running quiet and maximum
water extraction
8. Castors and recessed handles for improved mobility
9. Intelligent CPU controlled digital humidistat with 40-80% RH and room humidity display
10. Quiet vs turbo fan operation ensures the right balance between quiet operation and
maximum dehumidification
11. 24 hours start / stop timer
12. Tank operation or permanent drainage option
13. Tank full alarm & auto-stop function
14. Air purifier function with the optional 3M filter

5
PARTS
1. Water tank 2. Front panel 3. Recessed handle
4. Louvers & ry air outlet 4. Control Panel 6. Air filter frame
7. Air Intake & grill 8. Power cord & plug 9. Castors
10. Back panel
OPTIONAL
1. Activated carbon filter (Optional ） 2. 3M filter （ Optional ）
1 2

6
CONTROL PANEL
LED INDICATORS
(A) Power ON indicator light (green)
(B) Tank full indicator light (red)
(C) Louvres swing light (green)
( ) Timer indicator light (green)
(E) Humidity Level and Timer 2 digit led display
(F) Settings light (green)
(G) Low fan speed light (green)
(H) High speed fan light (green)
KEYS
(1) Power On / Off Key
(2) Swing control key
(3) Timer settings (1-24 hrs, start/ stopping timer)
(4) Humidity / Timer Step UP / OWN Control Keys
(5) Humidity Selection (40-80% RH, incremental with 5%)
(6) Fan Speed settings Key (Low/High)
Humidity Level & Timer 2 digit display (E)
The led indicator performs the following functions:
1. When the unit is plugged in, it will indicate the room humidity level
2. When the humidity level is selected, it will indicate the set humidity
3. When the start / stop timer is programmed will show the set timer
Notes:
When humidity level is outside the normal operational parameters will show LO/HI
If ambient humidity is lower than 35%, it will show “LO”
If ambient humidity is higher than 95%, it will show “HI”

7
Quick Reference Guide
Power Key (1) Press to turn the dehumidifier on and off.
Swing control key (2) Press once to make the louvre swing and press again to lock in
position. o not operate the unit if the self-opening louvers do not open on power on.
Timer: select timer settings key (3) then use keys to adjust the timer (1-24
hrs, start/ stopping timer). In power on mode the set number will represent the number of hours
the unit will stop. This will remain unaffected if unit goes in defrost mode or tank is emptied than
reinserted. In standby mode the set number represent period in hours after the unit will start. To
cancel start / stop mode set the timer to 00.
Press humidity Settings Key (5) then to select the desired humidity level.
H umidity level can be set within a range of 40% RH (Relative Humidity) to 80% RH in 5%
increments. The humidity control key will cycle from 40-80%RH and back to 40%RH
Ideal domestic environment setting is 50-60% RH.
For drier air/ laundry mode press the key and set to a lower percent value (e.g. 40-45%).
For allowing more moisture in the air set to a higher percent relative humidity (e.g. 60-70%).
Laundry ode: for the dehumidifier to operate continuously with maximum water extraction
until the tank is full set the humidity level to 40%RH. 40% is very dry and the unit will work until
water tank is full as 40%RH is hardly achievable in UK domestic environment. Note that is
permanent drainage pipe is fitted the unit will not stop operation.
Compressor will work until desired humidity is measured than will stop; unit working in the
economical fan mode only. The fan will move the air around the room ensuring the entire air in
the room is processed and humidity correctly measured.
For allowing more moisture in the air, press the humidity control key and set to a higher percent
value (e.g. 60-70%).
Humidity set to 40% RH; set to achieve room humidity of around 40% good for quick drying boost on initial
run or emergencies, laundry mode. Not recommended for long normal operation in domestic/ office
environment
Humidity set to 50-55% RH; recommended setting, great for domestic operation and dry storage
Humidity set to 60% RH; great for personal comfort and applications where 50% RH is considered too dry
Humidity set to 70% RH; ideal for unoccupied properties or where economical run is needed without the
need to go drier than 70% RH
Other features and Indicators
Tank Full Light
Red light will be on and the unit will beep when the tank is ready to be emptied, or when the
tank is removed or not replaced in the proper position. The water level control switch shuts off
the dehumidifier when the tank is full, or when the tank is removed or not replaced in the proper
position. Empty to resume operation.

8
Auto Defrost
When frost builds up on the evaporator coils, the compressor will cycle off and the unit will go in
defrost mode
When the unit is running in a room with temperature between 5⁰C and 12⁰C, it enter the defrost
mode about once every 30 minutes.
When the unit is running in a room with temperature between 12⁰C and 20⁰C, it enter the
defrost mode about once every 45 minutes.
Normal operation will resume after defrost mode.
Humidistat control and fan/ compressor operation
When the selected humidity is lower by 2% than the user selected humidistat setting; the
dehumidifier’s compressor will be shut off automatically but the fan will still move to ensure air is
not stale in the room. The unit will use only a minimal amount of energy in fan mode.
When the humidity is going back to being equal or higher than user selected humidity the
compressor will restart once the 3 minutes delay compressor protection expires.
Auto-Restart (on some models)
If the unit stops off unexpectedly due to the power cut, it will restart with the previous function
selected automatically when the power resumes.
Power
After the unit has stopped, it is not recommended to resume operation in the first at least 10
minutes. This is to protect the compressor. Operation can resume after this period lapse. When
the unit is restarted there is a 3 minutes delay before compressor will start.
Lightweight Portable Design on castors
The dehumidifier is built to be compact and lightweight. The castors on the bottom of the unit
make it easy to move from room to room. You can remove the castors if you wall mount the unit
(with the optional wall brackets).
Your C 16LE dehumidifier is advanced micro-CPU controlled device able of self-diagnostics. The
LC display may also show the error and protections codes.
Positioning the dehumidifier
A badly positioned dehumidifier will have little effect in
effectively drying the place. In positioning the dehumidifier
please ensure circulation of air in not restricted around the
unit. Please observe figure on the left in installing the unit.
Allow at least 20 cm space around the unit.
This dehumidifier is designed only for indoor residential / small
office applications and any commercial or industrial use will
invalidate the warranty.
Use in an enclosed area for maximum efficiency. Close all doors,
windows to create an effective operating environment. o not
use outdoors.
Your ELECTRIQ dehumidifier will begin to protect your space
from the harmful effects of excessive moisture as soon as it is

9
turned on. Excess moisture is dispersed throughout your home. For this reason, the dehumidifier
should be positioned in a central and clear location so that it can draw this moist air towards it from
all over the home. A warm hallway or landing is an excellent position for your dehumidifier. If possible,
leave interior doors ajar to allow air circulation.
Alternatively, if you have a serious problem in one area you can begin by positioning the dehumidifier
there and moving it to a more central location at a later date. For the most effective use, run your
dehumidifier with external doors and windows kept closed. Please note the unit should not be placed
directly against a radiator or other heat source.
When positioning your ELECTRIQ dehumidifier, ensure that it is placed clear of any obstacle that may
limit the air movement. Place the dehumidifier on a flat dry surface.
Note: o not force castors to move over carpet or uneven surfaces, nor move the unit with water in
the tank as it may tip over and spill water.
Water Drainage
When the water tank is full, the unit will stop automatically. When this happens the tank full red
code will show on the control panel.
Note: Only empty the water tank when is full or before moving or storing the unit.
There are two ways to dispense collected water.
1. Use the tank.
When the tank is full, the unit will automatically stop running, and the Full indicator light will
flash.
Slowly pull out the tank. Grip the left and right sides with both hands securely, and carefully
pull out straight so water does not spill. o not rest the tank on the floor
because the bottom of the tank is uneven and tank will fall and cause the
water to spill. Empty the water tank and reinsert it into the dehumidifier.
The tank must be in place and securely seated for the dehumidifier to
operate again.
The dehumidifier will re-start when the tank is
restored in its correct position.
NOTES:
When you remove the bucket, do not touch sensors or any
parts which are situated behind tank. oing so may damage
the product. Be sure to push the tank gently all the way into
the unit. Banging the bucket against anything or failing to
push it in securely into place may cause the unit not to
operate.
o not remove the float from the water tank. The water full
sensor will no longer be able to detect the water level
correctly without the float and water may leak from the
water tank.
