Electrohome EAMP100 User manual

Thank you for your purchase of this Electrohome product. Please read this instruction
manual carefully before using product to ensure proper use.
Keep this manual in a safe place for future reference.
www.electrohome.com
INSTRUCTION MANUAL
4GB MP3 PLAYER
EAMP100

- 2 -
IMPORTANT INFORMATION
SAFETY
• Be sure not to short-circuit the terminals of the player
with other metallic objects.
• When using a neck strap, be careful to avoid hooking it
on objects that you pass by.
INSTALLATION
• Never use the player where it will be subjected to
extremes of light, temperature, moisture or vibration.
• Never leave the player exposed to high temperatures,
such as in a car parked in the sun or under direct sunlight.
HEADPHONE USE
ROAD SAFETY
Do not use the headphones while
driving, cycling or while operating
any motorized vehicle. It may create
a trac hazard and is illegal in many
areas. It can also be potentially
dangerous to play at a high volume
while walking, especially at pedestrian
crossings. You should exercise
extreme caution or discontinue use in
potentially hazardous situations.
SAFETY AND WARNINGS

- 3 -
PREVENTING HEARING DAMAGE
Avoid using the headphones at a
high volume. Hearing experts advise
against continuous, loud and extended
play. If you experience a ringing
in your ears, reduce the volume or
discontinue use.
CLEANING
• Clean the player's case with a soft cloth, such as an
eyeglass cleaning cloth.
• if the player's case becomes very dirty, clean it with a soft
cloth slightly moistened with water or a mild detergent
solution.
• Do not use any type of abrasive pad, scouring powder
or solvent such as alcohol or benzene as it may mar the
nish of the case.
• Clean the headphone plug periodically.
• Be careful not to let water get into the player from the
opening near the connector.
SAFETY AND WARNINGS

- 4 -
SAFETY AND WARNINGS ...............................................2
FEATURES.................................................................... 5
WHAT’S INCLUDED ....................................................... 5
BUTTONS AND CONNECTIONS ....................................... 6
SETUP ......................................................................... 7
CONNECTING WITH THE COMPUTER ...................................7
BATTERY INSTALLATION .....................................................8
COPYING FILES FROM A COMPUTER ...................................8
OPERATION ................................................................10
TURNING THE MP3 PLAYER ON/OFF ................................. 10
ADJUSTING THE VOLUME .................................................10
UNLOCKING ALL BUTTONS ............................................... 10
ENTERING THE MAIN MENU ............................................. 11
LISTENING TO MUSIC ........................................................ 12
MANAGING AUDIO FILES ..................................................15
VOICE RECORDING AND PLAYING ..................................... 16
MANAGING VOICE FILES ................................................... 21
FM RADIO ......................................................................... 22
FOLDER NAVIGATION ........................................................26
CHANGING THE PLAYER SETTINGS ................................... 26
TROUBLESHOOTING ....................................................28
SPECIFICATIONS .........................................................30
FCC STATEMENT .........................................................31
NOTES ........................................................................32
ELECTROHOME WARRANTY .........................................33
TABLE OF CONTENTS

- 5 -
FEATURES
WARNING: ALL PACKING MATERIAL SUCH AS TAPE, PLASTIC SHEETS, WIRE TIES
AND TAGS ARE NOT PART OF THIS ITEM AND SHOULD BE DISCARDED
FOR YOUR CHILD’S SAFETY.
NOTE: PLEASE KEEP THIS INSTRUCTION MANUAL, AS IT CONTAINS
IMPORTANT INFORMATION.
• Store up to 1,000 songs with 4GB of memory.
• Integrated high speed USB 2.0 connector for easy drag
and drop of les.
• Compact size and versatile functions supporting MP3,
WMA, WAV les, USB storage device, digital voice recorder,
lock function and equalizer settings.
• Enjoy 10 hours of continuous playback.
• Listen to your favorite FM radio stations while on-the-go.
• 4GB MP3 Player with Integrated USB connection
• Earphones
• AAA battery
• Instruction Manual
• Lifetime Live Customer Support
WHAT'S INCLUDED

- 6 -
BUTTONS AND CONNECTIONS
1
2
3
4
5
6 8
7 9
10
11 12

- 7 -
BUTTONS AND CONNECTIONS
1. Battery compartment
2. Headphone input
3. Microphone
4. [ ] Enter submenu for each mode; Exit button; press
and hold to turn the player on/o
5. USB cap for USB connector
6. Display screen
7. [ ► ] Left/Previous button
8. [
►
] Volume up
9. [ ►] Right/Next button
10. [ ►| | ]Play/Pause button; Press and hold to enter the
main menu or unlock all buttons
11. [
►
] Volume down
12. Neck strap
CONNECTING WITH THE COMPUTER
SYSTEM REQUIREMENTS
Your computer system must meet the following requirements:
• Pentium 200MHz or above
• Microsoft Windows 2000/ XP/Vista
• 120 MB of available hard disk space
• USB port supported
SETUP

- 8 -
SETUP
BATTERY INSTALLATION
1. Remove the USB cap.
2. Remove the battery cover on the back of the player by
sliding it in the direction of the arrow as shown on
the player.
3. Insert one AAA battery into the battery compartment.
4. Push the battery cover back into the player.
Battery level indication - The approximate power levels of your
battery are indicated as follows:
COPYING FILES FROM A COMPUTER
Files can be transferred directly into the player by using the
USB connector:
1. Turn on the computer.
2. Pull o the USB cap.
3. Push the USB connector into a free USB port on your PC.
FULL TWO-THIRDS HALF-FULL LOW EMPTY
FULL

- 9 -
SETUP
4. The computer system will detect "New hardware" and
will begin to install the driver automatically. Wait for the
system to nish the installation. When it has nished,
a new "Removable Disk" will be created in
"My Computer".
5. Drag and drop the les on your computer to the
"Removable Disk".
6. To disconnect the MP3 player from the computer, double
click the Safely Remove Hardware icon on the task
bar. Click the USB Mass Storage Device, and then click
OK. You can then unplug the MP3 player safely.
Note: Please do not disconnect the MP3 player from
the computer during le transferring. It may cause a
malfunction of the MP3 player and of the les.

- 10 -
OPERATION
TURNING THE MP3 PLAYER ON/OFF
Make sure the battery is charged and the headphones
are connected.
1. Press and hold the [ ] button to turn the MP3 player
ON.
2. To turn OFF the MP3 player, press and hold the [ ]
button.
ADJUSTING THE VOLUME
1. To increase the volume, press the [
►
] button while
playing music.
2. To decrease the volume, press the [
►
] button while
playing music.
UNLOCKING ALL BUTTONS
All the buttons will on the MP3 player will automatically
lock when not in use (length of time can be pre-set in SETUP
menu). This prevents you from accidentally pressing a button
while using the MP3 player on the move.
• Press and hold the [ ►|| ] button to unlock all of the
buttons.

- 11 -
OPERATION
ENTERING THE MAIN MENU
1. Press and hold the [►||] button to enter the main
menu while in STANDBY or PLAY mode.
2. Press the [
►
] or [
►
] button to select: Music, Record,
Voice, Radio, Folder and Setting.
3. Press the [►||] button to enter the desired setting.
MAIN MENU ITEMS DESCRIPTION
Music Play music tracks
Record Voice recording
Voice Listen to voice recordings
Radio Listen to FM radio; FM recording
Folder View folders
Setting Customize the MP3 settings

- 12 -
LISTENING TO MUSIC
PLAYING MUSIC
Make sure the battery is charged and the headphones
are connected.
1. Access MAIN MENU.
2. Select music with [ ► ]/[►]. Press [ ►|| ].
OPERATION

- 13 -
While music is playing, you can:
• Pause/Resume Playing: Press [►||] button to pause
playing. To resume, press [►||] button again.
• Skipping Tracks: Press [ ► ] or [►] button to skip to
previous/next track.
• Searching: Press and hold [ ► ] button to fast rewind
within a track; Press and hold [►] button to fast
forward within a track.
• Adjust Volume: Press [
►
] or [
►
] button to increase/
decrease the volume.
• Power o: Press and hold [ ] button to power o
the player.
OPERATION

- 14 -
OPERATION
DISPLAY
1. Bit rate 2. File name
3. Battery status 4. Tracknumber/Total tracks
5. Music repeat mode 6. Time elapsed/Total time
1
2
3
4 5 6

- 15 -
OPERATION
SET MUSIC PLAYING MODE
While the music is playing, press the [ ] button, there
will pop up a window for you to set the music repeat
mode, equalizer and tempo rate.
1. Press the [ ► ] or [►] button to select from Repeat,
Equalizer, Exit.
2. Press [►||] button to enter.
Repeat Use [ ► ] or [►] button to select from:
Normal, Repeat One, Repeat All,
Random, and Intro.
Equalizer Use [ ► ] or [►] button to select from:
Natural, Rock, Pop, Classic, Soft, Jazz.
Exit Exit and return to music playing mode.
MANAGING AUDIO FILES
While the music is stopped, press the [ ] button,
there will pop up a window for you to manage the MP3
audio les.
1. Press the [ ► ] or [►] button to select from Local
folder, Delete le, Delete all and Exit.
2. Press [►||] button to enter.

- 16 -
OPERATION
Local folder Use [ ► ] or [►] button to select an
audio le or a folder, and then press
[►||] button to select the le and enter
music playing mode.
Delete le Use [ ► ] or [►] button to select "YES"
or "NO", and then press [►||] button
to conrm.
Delete all To delete all les stored in the local folder,
use [ ► ] or [►] button to select "YES"
or "NO", and then press [►||] button
to conrm.
Exit Exit and return to music playing mode.
VOICE RECORDING AND PLAYING
RECORDING A VOICE
1. Access MAIN MENU by pressing and holding [►||].

- 17 -
2. Select Record with [ ► ] / [►] then [►||]. Press
[►||] to start recording.
While recording a voice you can:
Pause/Resume
recording
Press [►||] button to pause
recording. To resume recording,
press [►||] button again.
Save the
recording
Press and hold [►||] button to
save the recording.
Power o Press and hold [ ] button to
save the recording and power o
the player.
OPERATION

- 18 -
OPERATION
DISPLAY
1. Recording Number/Total
recordings
2. File name
3. Battery status 4. Time elapsed/Total time
5. Recording mode
PLAYING A VOICE
1. Access MAIN MENU by pressing and holding [►||].
1
2
3
4 5

- 19 -
2. Select Voice with [ ► ] / [►] then [►||]. Press [►||]
to start recording.
While playing a voice you can:
Pause/Resume
recording
Press [►||] button to pause playing.
To resume playing, press [►||] button
again.
Skipping Tracks Press [ ► ] or [►] button to skip to
previous/next track.
Searching Press and hold the [ ► ] button to fast
rewind within a track; Press and hold
the [►] button to fast forward within
a track.
Adjust Volume Press the [
►
] or [
►
] button to
increase/decrease the volume.
Power o Press and hold [ ] button to power
o the player.
OPERATION

- 20 -
OPERATION
DISPLAY
1. Recording Number/Total
recordings
2. File name
3. Battery status 4. Time elapsed/Total time
5. Voice mode
SET VOICE PLAYING MODE
While the voice is playing, press the [ ] button, there
will pop up a window for you to set the voice repeat
mode.
1. Press the [ ► ] or [►] button to select from Repeat
and Exit.
2. Press [►||] button to enter.
1
2
3
4 5
