Electrolux E30GC74GPS1 User manual

E30GC74GPS1.tif ME30GC74GPS1.eps BRE30GC74GPS1.eps 318047111.eps
Product No. E30GC74GPS1
37766226970S1
Series 30" gas
Color stainless
Market North America
Wiring Diagram 318047111
Owner's Guide 318200687
Installation Instructions 318201475
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995533915
09/02/24
(EN/SERVICE/ECL)
377
30” GAS COOK-TOP
Model No.
E30GC74G
Copyright ©2009 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995533915 E30GC74GPS1
02/09 2
COOK TOP

E30GC74GPS1 Publication No: 5995533915
# Functional Parts 3 02/09
* Non-Illustrated Parts
COOK TOP
POS. NO PART NO. DESCRIPTION
10 7318392500 Bracket, box, (2)
12 7241603101 Label, nameplate, elux/icon
15 7318024206 Deflector, spark module
16 7318185221 Main Top Assy, frame/glass, stainless/black
19 7318285747 Panel, control, stainless
20 7318361403 Grate, top burner, black, (2), double
21 7316514800 Skirt, 5K burner, black
21A 7316515100 Skirt, 18K burner, black, (2)
21B 7316515000 Skirt, 14K burner, black
22 7316510902 Cap, 5K burner, black
22A 7316511502 Cap, 18K burner, black, (2)
22B 7316511302 Cap, 14K burner, black, (2)
26 7318363802 Bracket, channel mtg, (2)
31 7316515200 Seal, 5K burner
31A 7316515203 Seal, 18K burner, (2)
31B 7316515202 Seal, 14K burner
32 73201437 Strain relief
33 7318242225 Knob, control, (2)
33A 7318242226 Knob, control, dual, (2)
34 7318251600 Griddle
35 7318251911 Skirt, (4)
37 7316518100 Screw, ignitor assy mt, 6-32 x .62
39 7318144006 Cord, service
46 7318242810 Panel, base
47 7318241712 Panel, side, (2)
48 7318241820 Panel, rear
49 7318241904 Panel, interior side, RH
49A 7318241905 Panel, interior side, LH
57 7318286400 Panel, service
65 75303304032 Seal, rubber
69 75303300265 Screw, 8-18 X 1/2, (4)
77 7318355502 Bracket, channel mtg.
159 7318242920 Panel, bottom
162 7318245612 Brace, manifold
165 7318254300 Support, WOK
166 7318254200 Simmer Plate
* 7316459400 Pad, cleaning
* 7318163601 Cleaner-cooktop
* 7318163602 Cleaner, stainless steel
* 708016432 Screw, truss head, 8-18 x 0.375
* 75303211311 Screw, 8 x 0.500
* 75303323140 Screw, ground, 10-32 x 0.375

Publication No: 5995533915 E30GC74GPS1
02/09 4
BURNER

E30GC74GPS1 Publication No: 5995533915
# Functional Parts 5 02/09
* Non-Illustrated Parts
BURNER
POS. NO PART NO. DESCRIPTION
1 # 7318234315 Manifold Pipe
2 # 7316520700 Valve, burner, 5K
2B # 7316520703 Valve, burner, 14.2K
2D # 7316412510 Valve, top burner, 18K, dual port
3 # 7318232637 Wiring Harness, w/igntr switch
8 # 7316135701 Module, spark
* 75303323140 Screw, ground, 10-32 x 0.375
* 75303321221 Screw, 8-32 x 3/4
10 # 7316510800 Burner, sealed, 5K
10B# 7316511200 Burner, sealed, 14K
10D# 7316525400 Burner, sealed, dual, 18K
11 # 7316524800 Ignitor/orifice assy., top burner, 5K, w/holder
11B# 7316525000 Ignitor/orifice assy., top burner, 14K, w/holder
11D# 7316525100 Ignitor/orifice assy., top burner, 18K, w/holder
12 # 7318221375 Tubing, 5K, RH rear
12A# 7318221376 Tubing, 14K, LH rear
12B# 7318221377 Tubing, 18K, LH front
12C# 7318221379 Tubing, 18K, LH front
12D# 7318221378 Tubing, 18K, RH front
12E# 7318221380 Tubing, 18K, RH front
13 7318054513 Connector, manifold tube
14 # 7318122706 Regulator, pressure
24 7318054010 Elbow, fitting
* 708011955 Screw, 10-24 x 0.375, square drive
37 75303305528 Screw, 8-32 x 1/4
44 7316523504 Orifice, top burner, 5K
44B 7316523506 Orifice, top burner, 14K
44D 7316523508 Orifice, top burner, 18K
72 7316215600 Screw, valve mtg., 1/4 - 20
* # 7318127440 LP Conversion Kit
* # 7318199778 Wiring Harness, ignitor

Publication No: 5995533915 E30GC74GPS1
02/09 6
WIRING DIAGRAM
