Electrolux EW30IC60IS - 30" Induction Cooktop User manual

318 203 636 (0909) Rev. D
Use & Care Guide
Induction Cooktop

2Finding Information
MAKE A RECORD FOR FUTURE USE
Purchase Date_____________________________________________________
Model Number_____________________________________________________
Serial Number_____________________________________________________
QUESTIONS?
For toll-free telephone support in the U.S. and Canada:
1-877-4ELECTROLUX (1-877-435-3287)
For online support and internet product information:
www.electroluxicon.com
©2009 Electrolux Home Products, Inc.
Post Ofce Box 212378, Augusta, Georgia 30917, USA
All rights reserved.
Printed in the USA
Note
The serial and model numbers may be found on the serial plate located under the cooktop.

3
Finding Information
TABLE OF CONTENTS
Finding Information............................................. 2-3
Make a Record for Future use.................................. 2
Questions? ............................................................... 2
Safety.................................................................... 4-6
Important Safety Instructions.................................... 4
Induction Cooktop Features............................... 7-8
Before Using the Cooktop ................................ 9-11
Use the Correct Cookware Type .............................. 9
Minimum Pan Size Requirements ........................... 9
Cookware Recommendations ................................ 10
Use Quality Cookware in Good Condition...............11
Setting Surface Controls ................................ 12-17
Using the Touch Controls ....................................... 12
Cooktop Main Power Pad ...................................... 12
Controls Lock Pad .................................................. 12
Minute Timer Pad ................................................... 12
Using the Glide-2-SetTM Zone Control .................... 13
Operating the Cooking Zones............................ 14-15
LED Messages or Light Indicators Displayed by
Cooking Zone Controls........................................... 15
Preheat Recommendations.................................... 16
Power Sharing........................................................ 16
Setting Power Boost Feature.................................. 17
Operational Noises................................................. 17
General Care & Cleaning ................................ 18-19
Ceramic Glass Cooktop Cleaning & Maintenance . 18
Cleaning Recommendations for
Ceramic Glass Cooktop.......................................... 19
Solutions to Common Problems.................... 20-22
Entire Cooktop Does Not Operate.......................... 20
Cooktop Turns Off While Cooking .......................... 20
Cooking Zone Does Not Heat Food ....................... 20
Cooking Zone Heats Food
Too Hot or Not Enough........................................... 21
Food Does Not Heat Evenly................................... 21
Poor Cooking Results............................................. 21
Cooktop Zone Control Displays an error code ....... 21
Cooking zones inner LEDs continuously rotating
around digital display.............................................. 21
Metal Marks on Ceramic Cooktop Glass................ 22
Scratches or Abrasions on
Ceramic Cooktop Glass.......................................... 22
Brown Streaks or Specks on Ceramic
Cooktop Surface..................................................... 22
Area of Discoloration with Metallic Sheen
on Ceramic Cooktop Glass..................................... 22
Warranty Information ........................................... 23

4Safety
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this appliance. Save these instructions for future reference.
This manual contains important safety symbols and instructions. Please pay attention to these
symbols and follow all instructions given.
!
WarNiNg
This symbol will help alert you to situations that may cause serious bodily harm, death or property
damage.
!
CautioN
This symbol will help alert you to situations that may cause bodily injury or property damage.
This unit has been tested and found to comply with the limits for a class B digital device,
pursuant to Part 18 of the FCC rules. These limits are designed to provide reasonable pro-
tection against harmful interference in a residential installation. This unit generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However there
is no guarantee that interference will not occur in a particular installation. If this unit does
cause harmful interference to radio or television reception, which can be determined by
turning the unit off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
• Reorient or relocate the receiving antennae.
• Increase the distance between the unit and receiver.
• Connect the unit into an outlet or a circuit different from that to which the receiver is
connected.
• Removealltapeandpackagingwrapbeforeusingtheappliance.Destroythecarton
and plastic bags after unpacking the appliance. Never allow children to play with
packaging material.
•ProperInstallation.Besureyourapplianceisproperlyinstalledandgroundedbya
qualiedtechnicianinaccordancewiththeNationalElectricalCodeANSI/NFPANo.
70-latesteditionintheUnitedStates,orCSAStandardC22.1,CanadianElectrical
Code, Part 1, in Canada, and local code requirements. Install only per installation
instructions provided in the literature package for this appliance.
!
CautioN
Persons with a pacemaker or similar medical device should exercise caution using or standing near an
induction unit while it is in operation, as the electromagnetic eld may affect the working of the pacemaker
or similar medical device. It would be advisable to consult your Doctor or the pacemaker or similar medical
device manufacturer about your particular situation.
!
WarNiNg
To reduce the risk of re, electrical shock, or injury when using your electric cooktop, follow basic
precaution including the following:

5
Safety
Ask your dealer to recommend a qualied technician and an authorized repair service. Know
how to disconnect the electrical power to the appliance at the circuit breaker or fuse box in
case of an emergency.
• UserServicing.Donotrepairorreplaceanypartoftheapplianceunlessspecically
recommendedin the manuals.All other servicing should be done only by a qualied
technician to reduce the risk of personal injury and damage to the appliance.
• Nevermodifyoraltertheconstructionofanappliancesuchasremovalofpanels,
wirecoversoranyotherpermanentpartoftheproduct.
• StorageonAppliance.Flammablematerialsshouldnotbestorednearoronthecook-
ingsurface.This includes paper, plastic and cloth items, such as cookbooks, plasticware
and towels, as well as ammable liquids. Do not store explosives, such as aerosol cans,
on or near the appliance. Flammable materials may explode and result in re or property
damage.
!
CautioN
Do not store items of interest to children in the cabinets above the appliance. Children climbing on the
cooktop to reach items could be seriously injured.
• Donotleavechildrenalone.Childrenshouldnotbeleftaloneorunattendedinthe
areawhereanapplianceisinuse.They should never be allowed to sit or stand on any
part of the appliance.
!
CautioN
DO NOT TOUCH COOKING ZONES OR AREAS NEAR THESE SURFACES. Cooking Zones may be hot from
residual heat even though they are dark in color. Areas near the Cooking Zones may become hot enough to
cause burns. During and after use, do not touch, or let clothing or other ammable materials touch these areas
until they have had sufcient time to cool.
!
WarNiNg
Never use your appliance for warming or heating a room.
• Wear Proper Apparel. Loose-tting or hanging garments should never be worn
whileusingtheappliance.Do not let clothing or other ammable materials contact hot
surfaces.
• DoNotUseWaterorFlouronGreaseFires.Smothertherewithapanlid,oruse
bakingsoda,adrychemicalorfoam-typeextinguisher.
• Whenheatingfatorgrease,watchitclosely.Fat or grease may catch re if allowed to
become too hot.
•UseOnlyDryPotholders.Moistordamppotholdersonhotsurfacesmayresultin
burnsfromsteam.Do not let the pot holders touch hot surface units. Do not use a towel
or other bulky cloth instead of a pot holder.
•DoNotHeatUnopenedFoodContainers.Buildupofpressuremaycausethecontainer
toburstandresultininjury.

6
iMPortaNt SaFetY NotiCe
The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to
publish a list of substances known to the state to cause cancer, birth defects or other reproductive harm,
and requires businesses to warn customers of potential exposure to such substances.
Safety
IMPORTANTSAFETYINSTRUCTIONSFORUSINGYOURCOOKTOP
• KnowwhichtouchkeypadscontrolseachsurfaceoftheCookingZones.
• Cleantheapplianceregularlytokeepallpartsfreeofgreasethatcouldcatchre.
Exhaust fan ventilation hoods and grease lters should be kept clean. Do not allow grease
to accumulate on hood or lter. Greasy deposits in the fan could catch re. When aming
food under the hood, turn fan on. Refer to hood manufacturer’s instructions for cleaning.
• UseProperPanSize. This appliance is equipped with one or more Cooking Zones of dif-
ferent sizes. Select utensils having at bottoms large enough to cover the Cooking Zones.
The pan detection sensors will not allow the affected Cooking Zones to operate without a
pan present.
•Utensil Handles Should Be Turned Inward and Should Not Extend Over Adjacent
CookingZones. To reduce the risk of burns, ignition of ammable materials, and spillage
due to unintentional contact with the utensil.
•NeverLeavePreparedFoodontheCookingZones. Boilovers cause smoking and greasy
spillovers that may ignite, or a pan that has boiled dry may melt or become damaged.
•ProtectiveLiners. Do not use aluminum foil to line any part of the cooktop. Only use alu-
minum foil as recommended after cooking process, if used as a cover to be placed over
the food. Any other use of aluminum foil may result in the risk of electric shock, re or short
circuit.
• GlazedCookingUtensils. Only certain types of glass, glass/ceramic, ceramic, earthen-
ware, or other glazed utensils are suitable for range top service without breaking due to the
sudden change in temperature. Check the manufacturer’s recommendations for cooktop
use.
• Ventilatinghood.The ventilating hood above your cooking surface should be cleaned
frequently, so the grease from cooking vapors does not accumulate on the hood or lter.
FORCERAMIC-GLASSCOOKTOPONLY
• DoNotCleanorOperateaBrokenCooktop.If cooktop should break, cleaning solutions
and spillovers may penetrate the broken cooktop and create a risk of electric shock. Contact
a qualied technician immediately.
• CleanCooktopwithCaution.If a wet sponge or cloth is used to wipe spills on a hot cook-
ing area, be careful to avoid a steam burn. Some cleaners can produce harmful fumes if
applied to a hot surface.
• DoNotPlaceHotCookwareonColdCooktopGlass. This could cause glass to break.
• DoNotSlidePanAcrosstheCooktopSurface.They may scratch the cooktop surface.
• DoNotLetPansBoilDry. This may cause permanent damage in the form of breakage,
fusion, or marking that can affect the ceramic-glass cooktop. (This type of damage is not
covered by your warranty).

7
InductionCooktopFeatures
INDUCTION COOKTOP FEATURES
1. Left Rear Cooking Zone.
2. Center Rear Cooking Zone
(36” model only).
3. Right Rear Cooking Zone.
4. Left Front Cooking Zone Double Element
(36" model only).
5. Right Front Cooking Zone.
6. Left Front Cooking Zone (30" model only)
7. Left Rear Cooking Zone Control Pads.
8. Center Rear Cooking Zone Control Pads.
(36” model only)
9. Right Rear Cooking Zone Control Pads.
10. Left Front Cooking Zone Control Pads.
11. Right Front Cooking Zone Control Pads.
12. Main Cooktop Controls.
3
3
1
1
5
5
2
6
4
12
12
10
10
7
78
9
9
11
11
ACOOLERCOOKTOP - A unique feature of the Induction Cooktop is whether turned ON
or OFF, the cooktop surface remains cooler than standard ceramic cooktops.
!
CautioN
The Cooking Zones may appear to be cool while turned ON and after they have been turned OFF. The glass
surface may be HOT from residual heat transferred from the cookware and burns may occur.
MAGNETICDETECTOR - The coil sensor automatically detects whether the pan is
magnetic and eliminates accidental “turn-ONs.”
PANSIZEDETECTION - The pan recognition sensor automatically detects and adapts the
Cooking Zones to the pan sizes in use.
EFFICIENT - Induction cooking heats faster while using less energy. Induction power levels
are quick to boil and delicate when simmering.
READTHESEINSTRUCTIONSCAREFULLYBEFOREUSINGTHECOOKTOP

8
13. Cooktop Power Key Pad.
14. Controls Lock Key Pad.
15. Minute Timer ON/OFF Key Pad.
16. Minute Timer Setting " - " Pad.
17. Minute Timer Setting " + " Pad.
18. Minute Timer Display (displays up to 99
minutes.
19. Cooktop Power Indicator Light.
20. Controls Lockout Indicator Light.
21. Cooking Zone " - " Pad (for each Cooking
Zone).
22. Cooking Zone ON/OFF Key Pad (for each
Cooking Zone).
23. Cooking Zone " + " Key Pad (for each Cooking
Zone).
24. Keep Warm Setting Key Pad (for each
Cooking Zone).
25. Glide-2-Set™ Rotary Touch Slider Zone
Control (for each Cooking Zone.
26. Cooking Zone Power Level Display (for each
Cooking Zone).
InductionCooktopFeatures
INDUCTION COOKTOP FEATURES (CONT’D)
13 14 15
16 17
18
Main Cooktop Controls
Cooking Zone Controls
21
19 20
22 23
24
25
26

9
BeforeUsingtheCooktop
USE THE CORRECT COOKWARE TYPE
The magnetic Cooking Zone sensors located below the cooktop surface
require the use of cookware made with magnetic material in order to start the
heating process on any of the Cooking Zones.
When purchasing pans, look for cookware specically identied by the
manufacturer for use with Induction cooktops. If you are not sure, use a
magnet to test whether the cookware type will work. If a magnet sticks to the
bottom of the cookware, the material type is correct for Induction cooking
(See Fig. 1).
It is recommended to always use heavier high quality stainless steel cookware on your Induction Cooktop surface.
This will greatly reduce the possibility of developing scratches on the ceramic surface.
Even quality cookware can scratch the cooktop surface, especially if cookware is slid over the ceramic cooktop
surface without being lifted up. Over time sliding ANY type of cookware over the ceramic cooktop will likely alter
the overall appearance of the cooktop. Eventually the buildup of scratches will make cleaning the surface difcult
and degrade the overall appearance of the cooktop.
Fig. 1
MINIMUM PAN SIZE REQUIREMENTS
USETHECORRECTSIZECOOKWARE
- The Cooking Zones available on the
Induction Cooktop require a MINIMUM
pan size to be used at each location. The
inner ring of each Cooking Zone is your
guide to the correct MINIMUM pan size.
The pan bottom must FULLY cover the
inner ring for proper cooking to occur.
The thicker outer ring at each Cooking
Zone is helpful to determine the pan
MAXIMUM size. After centering the
cookware on the cooktop, make sure
the cookware does not extend more
than 1/2” beyond the thicker line on the
Cooking Zone. The pan must make FULL
contact on the glass surface without the
bottom of the pan touching the metal
cooktop trims.
NOTE: If a pan made of the correct
material is centered properly on any of
the active Cooking Zones but is TOO
SMALL, the LEDs around the digital part
of the display will start rotating around
the affected Cooking Zone Display and
the pan will not heat.
NOTE: Pan
bottom should
not exceed 1/2”
(13mm) from
outer Cooking
Zone (Induction)
rings
NOTE: Pan
bottom should
not exceed 1/2”
(13mm) from
outer Cooking
Zone (Induction)
rings

10 BeforeUsingtheCooktop
COOKWARE RECOMMENDATIONS
INCORRECT CORRECT
PLEASENOTE-ANYoneoftheincorrectconditionslistedaboveinFig.1maybe
detectedbythesensorslocatedbelowtheceramiccooktopsurface.Ifthecookware
doesnotmeetanyoftheseconditions,oneormoreoftheCookingZones will not
heatindicatedbyrotatingLEDssurroundingthedigitaldisplayforthataffectedzone.
Correcttheproblemsbeforeattemptingtoreactivatethecooktop.
• Cookware not centered on Cooking
Zone surface.
•Cookware centered correctly on
Cooking Zone surface.
• Curved or warped pan bottoms or
sides.
• Flat pan bottom & straight sides.
•Pan does not meet the minimum
size required for the Cooking Zone
used.
• Pan size meets or exceeds the
recommended minimum size for the
Cooking Zone.
•Pan bottom rests on cooktop trim
or does not rest completely on the
cooktop surface.
•Pan rests completely on the Cooktop
surface.
• Heavy handle tilts pan. •Pan is properly balanced.
Fig. 1
