Electrolux T5190 User manual

EN
GB,IE
Operatingmanual
Tumbledryer
T5190
TypeN1190..
4389096-20/EN
Originalinstructions2013.03.08

Contents
Contents
1SafetyPrecautions.............................................................................................................5
1.1Symbols......................................................................................................................6
2Programdescription...........................................................................................................7
2.1General.......................................................................................................................7
2.2Programdescription...................................................................................................7
2.3Optionbuttons............................................................................................................10
3Handling.............................................................................................................................11
3.1Load............................................................................................................................11
3.2Howtostartthemachine............................................................................................12
3.2.1Panelwithbuttonsandcontrolknob...................................................................12
3.2.2Panelwithoutbuttons.........................................................................................14
3.2.3Coinoperatedmachines.....................................................................................16
3.3Additionalfunctions....................................................................................................18
3.4Whenprogramhasended..........................................................................................19
4Errorcodes.........................................................................................................................20
5Maintenance.......................................................................................................................21
5.1General.......................................................................................................................21
5.2Timeformaintenance.................................................................................................21
5.3Everyday....................................................................................................................22
5.4Freshairintakeandfanmotor....................................................................................23
5.5Machineswithresidualmoisturecontrol(RMC).........................................................23
5.6Maintenancetobecarriedoutbyqualiedservicepersonnel....................................23
Themanufacturerreservestherighttomakechangestodesignandcomponentspecications.

SafetyPrecautions5
1SafetyPrecautions
Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswithreducedphysical,
sensoryormentalcapabilitiesorlackofexperienceandknowledgeiftheyhavebeengivensupervisionor
instructionconcerninguseoftheapplianceinasafewayandunderstandthehazardsinvolved.Children
shallnotplaywiththeappliance.Cleaningandusermaintenanceshallnotbemadebychildrenwithout
supervision.
Childrenoflessthan3yearsshouldbekeptawayunlesscontinuouslysupervised.
Themachineisnottobeusedifindustrialchemicalshavebeenusedforcleaning.
Donotdryunwasheditemsinthemachine.
Itemsthathavebeensoiledwithsubstancessuchascookingoil,acetone,alcohol,petrol,kerosene,spot
removers,turpentine,waxesandwaxremoversshouldbewashedinhotwaterwithanextraamount
ofdetergentbeforebeingdriedinthemachine.
Itemssuchasfoamrubber(latexfoam),showercaps,waterprooftextiles,rubberbackedarticlesand
clothesorpillowsttedwithfoamrubberpadsshouldnotbedriedinthemachine.
Fabricsoftenersorsimilarproductsshouldbeusedasspeciedbythefabricsoftenerinstructions.
Thenalpartofadryingcycleoccurswithoutheat(cooldowncycle)toensurethattheitemsareleftata
temperaturethatensuresthattheitemswillnotbedamaged.
Removeallobjectsfrompocketssuchaslightersandmatches.
WARNING.Neverstopthemachinebeforetheendofthedryingcycleunlessallitemsarequicklyremoved
andspreadoutsothattheheatisdissipated.
Adequateventilationhastobeprovidedtoavoidthebackowofgasesintotheroomforappliances
burningotherfuels,includingopenres.
Exhaustairmustnotbedischargedintoauewhichisusedforexhaustingfumesfromappliancesburning
gasorotherfuels.
Themachinemustnotbeinstalledbehindalockabledoor,aslidingdoororadoorwithahingeonthe
oppositesidetothatofthemachine.
Ifthemachinehasalinttrapthishastobecleanedfrequently.
Thelintmustnotbeaccumulatedaroundthemachine.
DONOTMODIFYTHISAPPLIANCE.
AllexternalequipmentwhichisconnectedtothemachinemustbeCE/EMC-approvedandconnectedusing
anapprovedshieldedcable.
Allexternalequipmentmustbeconnectedaccordingtotheinstructionsintheinstallationmanual.
Inordertopreventdamagetotheelectronics(andotherparts)thatmayoccurastheresultofcondensation,
themachineshouldbeplacedinroomtemperaturefor24hoursbeforebeingusedforthersttime.
Servicingshallbecarriedoutonlybyauthorizedpersonnel.
Onlyauthorizedsparepartsshallbeused.
Whenperformingserviceorreplacingparts,thepowermustbedisconnected.

6SafetyPrecautions
Gasheatedtumbledryer:
Beforeinstallation,checkthatthelocaldistributionconditions,natureofgasandpressureandthe
adjustmentoftheappliancearecompatible.
Themachineisnottobeinstalledinroomscontainingcleaningmachineswithperchloroethylene,
TRICHLOROETHYLENEorCHLOROFLUOROCONTAININGHYDROCARBONSascleaningagents.
Ifyoucansmellgas:
•Donotswitchonanyequipment
•Donotuseelectricalswitches
•Donotusetelephonesinthebuilding
•Evacuatetheroom,buildingorarea
•Contactthepersonresponsibleforthemachine
1.1Symbols
Caution
Caution,hotsurface
Readtheinstructionsbeforeusingthemachine

Programdescription7
2Programdescription
2.1General
Themachineisequippedwithanumberofprogramsadaptedtotherangeofusetowhichthe
machineisintended—differentmarketsusedifferentprograms.Thefollowingprogramdescription
isashortdescriptionofsomeexamplesofprogramsthatcanbeused.
Foracompleteanddetailedinformationaboutthealltheavailabledryingprograms,pleaserefer
toELSweb-site.
Itisrecommendettofollowthecarelabellingofthegarmentasfaraspossible.
Forbestpossibledryingresultitisadvisabletodrygarmentsofthesamequalityforeachdrying
cycle.
Note!
Donottumbledrywoolorsilk.
2.2Programdescription
Therearetwotypesofprograms,automaticprogramsandtimeprograms.
Automaticprogramshasmoisturedetectionandwillstopwhenselecteddrynessisachieved.
Timeprogramshasnomoisturedetectionandwillstopwhenthepresetorselectedtimehasended.
Thefollowingtableshowssomeexamplesofavailableprogramsandashortdescriptionofthose:
AutomaticprogramsDescription
NORMALCottonandterry.
Normal/mediumtemperature.
Theprogramwillstopwhenpresetdryness/selectedoptionisachieved(Extradry,Dryor
Irondry).
LOWSynthetic(exampleofsyntheticfabrics:polyester,polyamide,polyacrylicandelastan),
viscose,polycottonanddelicatefabrics.
Lowtemperature.
Theprogramwillstopwhenpresetdryness/selectedoptionisachieved(Extradry,Dryor
Irondry).
TimeprogramsDescription
NORMALCottonandterry.
Differentdryingtimescanbeselected.
Theprogramwillstopwhenthetimeisup.
LOWSynthetic(exampleofsyntheticfabrics:polyester,polyamide,polyacrylicandelastan),
viscose,polycottonanddelicatefabrics.
Differentdryingtimescanbeselected.
Theprogramwillstopwhenthetimeisup.
NOHEATINGAiringbedspreads,duvetsandbedclothes.
Differentdryingtimescanbeselected.
Theprogramwillstopwhenthetimeisup.

8Programdescription
Thefollowingtableshowssomeexamplesofdifferentprogramsthatareusedforspecialmarkets
suchashospitals,restaurants,campingsitesetc.andashortdescriptionofthose:
AutomaticprogramsDescription
NORMAL
EXTRADRY
Denimandterry.
Theprogramwillstopwhensetdrynessisachieved.
LOW
EXTRADRY
Viscoseandpolycotton.
Theprogramwillstopwhensetdrynessisachieved.
NORMAL
DRY
Cottonandterry.
Theprogramwillstopwhensetdrynessisachieved.
LOW
DRY
Synthetic(exampleofsyntheticfabrics:polyester,polyamide,polyacrylicandelastan),
viscose,polycottonanddelicatefabrics.
Theprogramwillstopwhensetdrynessisachieved.
NORMAL
IRONDRY
Cotton.
Theprogramwillstopwhensetdrynessisachieved.
LOW
IRONDRY
Synthetic(exampleofsyntheticfabrics:polyester,polyamide,polyacrylicandelastan),
viscose,polycottonanddelicatefabrics.
Theprogramwillstopwhensetdrynessisachieved.
TimeprogramsDescription
NORMALCottonandterry.
Differentdryingtimescanbeselected.
Theprogramwillstopwhenthetimeisup.
LOWSynthetic(exampleofsyntheticfabrics:polyester,polyamide,polyacrylicandelastan),
viscose,polycottonanddelicatefabrics.
Differentdryingtimescanbeselected.
Theprogramwillstopwhenthetimeisup.
NOHEATINGAiringbedspreads,duvetsandbedclothes.
Differentdryingtimescanbeselected.
Theprogramwillstopwhenthetimeisup.

Programdescription9
Thefollowingtableshowssomeexamplesofavailableprogramsusedoncoinoperatedmachines
andashortdescriptionofthose:
TimeprogramsDescription
HIGHCottonandterry.
Theprogramwillstopwhenthetimeisup.
MEDIUMCottonandterry.
Theprogramwillstopwhenthetimeisup.
LOWSynthetic(exampleofsyntheticfabrics:polyester,polyamide,polyacrylicandelastan),
viscose,polycottonanddelicatefabrics.
Theprogramwillstopwhenthetimeisup.
NOHEATINGAiringbedspreads,duvetsandbedclothes.
Theprogramwillstopwhenthetimeisup.

10Programdescription
2.3Optionbuttons
Themachineisequippedwithanumberofoptionsadaptedtotherangeofusetowhichthe
machineisintended—differentmarketsusedifferentoptions.
Thefollowingtableshowssomeexamplesofavailableoptionsandashortdescriptionofthose:
OptionbuttonDescription
ECOPROGRAMDriesusinglessenergy.
CAREPROGRAMDryingofsensitivefabrics.Onlysuitableforusewithsmallloads.
QUICKPROGRAMTheprogramwillbereadyasquickaspossible.
EXTRADRYThroughdryingofthickormultilayeredfabrics.
Dryingstopswhen“EXTRADRY”isachieved.
DRYReadytoputincupboard/closet.Throughdryingoffabricsofeven
thicknesses.
Dryingstopswhen“DRY”isachieved.
IRONDRYDamp.Readyforironing.Forthintextileswhicharetobeironed.
Dryingstopswhen“IRONDRY”isachieved.
