Electrolux EFME617SIW User manual

Publication #5995673133 May 2016
Technical Service Manual
Front Load Electric and Gas Dryers (EFME617SIW/EFMG617SIW/
EFME517SIW/EFMG517SIW/EFME417SIW/EFMG417SIW)

2

3
Table of Contents
1. Safety Information....................................................................................5
2. Purpose of this Manual........................................................................6
3. Warnings.......................................................................................................7
4. Product Features (For Models 617, 517 and 417 Series).....8
5. Model Specifications..............................................................................9
6. Electrical Characteristics (For Models 617, 517 and 417
Series).......................................................................................................12
6.1 Electronic Control........................................................................12
6.1.1 User Interface (UI) Board.......................................................12
6.1.2 Electronic Control Board.......................................................13
6.2 Schematic Diagram....................................................................14
6.3 Wiring Diagram – EFME617SIW / EFME517SIW /
EFME417SIW......................................................................................15
6.4 Wiring Diagram – EFMG617SIW / EFMG517SIW /
EFMG417SIW...................................................................................16
7. Electrical Components (For Models 617, 517 and 417
Series)............................................................................................................17
7.1 Electrical Component Resistance and
Specification Table........................................................................17
7.2 Heating Element............................................................................19
7.2.1 General Characteristics..........................................................19
7.3 Inlet Control Thermistor.............................................................19
7.3.1 General Characteristics..........................................................19
7.4 Outlet Control Thermistor........................................................20
7.4.1 General Characteristics........................................................20
7.5 Door Switch and Drum Light..................................................21
6.5.1 General Characteristics.........................................................21
7.6 Single-Phase Induction Motor..............................................22
7.6.1 General Characteristics.........................................................22
7.7 Inlet Thermal Limiter...................................................................23
7.7.1 General Characteristics.........................................................23
7.8 Outlet Thermal Limiter...............................................................23
7.8.1 General Characteristics.........................................................23
7.9 High-Limit Thermostat...............................................................23
7.9.1 General Characteristics.........................................................23
7.10 Contact / Moisture Sensor....................................................24
7.10.1 General Characteristics.......................................................24
7.11 Mist Valve........................................................................................25
7.11.1 General Characteristics........................................................25
8. Gas Assembly Characteristics (For Gas Models
EFMG617SIW / EFMG517SIW / EFMG417SIW).......................26
8.1 Igniter.................................................................................................26
8.1.1 General Characteristics..........................................................26
8.2 Burner................................................................................................26
8.2.1 General Characteristics.........................................................26
8.3 Gas Valve........................................................................................26
8.3.1 General Characteristics........................................................26
8.4 Flame Sensor.................................................................................26
8.4.1 General Characteristics........................................................26
9. Door Accessibility..................................................................................27
9.1 Lint Filter Accessibility.................................................................27
9.2 Moisture Sensor Accessibility.................................................27
10. Top Panel Accessibility.....................................................................28
10.1 Electronic Control Board Accessibility..............................28
10.2 Vanes Accessibility.....................................................................28
11. Rear Panel Accessibility....................................................................29
11.1 Mist Valve Accessibility..............................................................29
11.2 NTC 2 (Inlet Control Thermistor) Accessibility..............30
11.3 NTC 1 (Outlet Control Thermistor) Accessibility...........30
11.4 Fire Containment Thermostat Accessibility....................30
11.5 Outlet Thermal Limiter Accessibility...................................30
11.6 Heater Assembly Accessibility (For Electrical Model –
EFME617SIW / EFME517SIW / EFME417SIW)..................31
11.6.1 Inlet Thermal Limiter Accessibility......................................31
11.6.2 High-Limit Thermostat Accessibility.................................31
11.7 Heater Assembly Accessibility (For Gas Model –
EFMG617SIW / EFMG517SIW / EFMG417SIW)...............31
11.7.1 Flame Sensor Accessibility...................................................32
11.7.2 Burner Accessibility................................................................33
11.7.3 Igniter Accessibility................................................................33
11.7.4 Inlet Thermal Limiter Accessibility....................................33
11.7.5 High-Limit Thermostat Accessibility................................33
12. Front Panel Accessibility.................................................................34
12.1 Door Switch Accessibility........................................................34
12.2 User Interface Board Assembly Accessibility...............35
13. Drum Light Accessibility...................................................................36
14. Motor Assembly Accessibility........................................................37
14.1 Belt Accessibility ........................................................................37
14.2 Motor Accessibility....................................................................37
15. Leveling Legs Accessibility.............................................................39
16. Diagnostic System (For Models 617, 517 and 417
Series).........................................................................................................40
16.1 Enter Diagnostic Mode...........................................................40
16.2 Scroll Through the Tests.........................................................40
16.3 Exit from Diagnostic Mode....................................................41
16.4 Factory Default Reset...............................................................41
16.5 Demo Mode..................................................................................41
16.6 Enter Demo Mode......................................................................41
16.7 Clear Demo Mode......................................................................41
16.8 Error Codes...................................................................................42
17. Troubleshooting Based On Alarm Codes..............................44
E41: Door Opened at Cycle Start..................................................44
E42: Door Open Sensing Error.......................................................44
E51: Drum Motor Relay Error...........................................................45
E52: Drum Motor Start Sensing Error.........................................46
E53: Drum Motor Centrifugal Switch Error................................48
E54: Drum Motor Sensing Error......................................................48
E61: Heater Relay Error.......................................................................49
E63: Heater Short Error......................................................................49
E64: Heater Open Error.....................................................................49

4
E65: Thermostat Open......................................................................50
E67: Heater Sensing Error..................................................................51
E71: NTC 1 Error.......................................................................................51
E72: NTC 1 Error......................................................................................51
E73: NTC 2 Error....................................................................................52
E74: NTC 2 Error....................................................................................52
E91: User Interface Communication Error..................................53
E92: User Interface Protocol Incongruence Error..................53
E93: Machine Configuration Checksum Error..........................53
E94: Cycle Configuration Checksum Error................................54
E97: Missing Program On CTF Error.............................................54
E9C: User Interface Configuration Checksum Error..............54
E9E: User Interface Touch Sensor Not Working.....................54
EH1: Power Supply Frequency Out of Range...........................55
EH2: Power Supply Amplitude Out of Range...........................55
EH3: Power Supply Amplitude Out of Range..........................55
EH4: Line Wiring Error........................................................................55
EBD: Line Safe Relay Short Circuit Error.....................................56
EBE / EBF: Line Safe Error / Line Safe Sensing Error.............56
EF1: Ventilation Blocked Error..........................................................56
EF6: Safety Reset Error.......................................................................57
Table of Contents

5
Read the entire Manual before attempting to service this product. Pay attention to all Warnings, Cautions and
Notes. Failure to do so could result in serious personal injury and / or equipment damage.
DEFINITIONS
WARNING
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION
Used with the safety alert symbol, indicates a hazardous situation which, if not avoided, could result in
minor or moderate injury.
NOTE
Used to address practices not related to personal injury.
IMPORTANT
Information that requires special attention from the user.
1. Safety Information

6
2. Purpose of this Manual
The purpose of this Manual is to provide information regarding repair procedures of Dryer (Both Electric and
Gas Models) fitted with the Electronic Control System. This Manual is intended for the use of Service Engineers of
Electrolux.
The Manual includes the following topics:
• Product Features, Model Specifications
• Electrical Characteristics and Specifications
• Accessibility of the Electrical and Mechanical Components
• Diagnostics Systems
• Error Codes and Troubleshooting

7
3. Warnings
• Any work on Electrical Appliances must be carried out by a qualified professional.
• Confirm that the Power System is operational before working on the Appliance.
• Ensure that the gas pipelines are connected properly as mentioned in the Installation section for Gas Dryer
Models.
• Check that the Appliance is restored to its original safety condition after the operation is complete.
• Take the plug out of the socket to disconnect the power supply before you access
internal components. This platform is not fitted with an ON / OFF switch.
• Replace the heating element with the one that has the same characteristics to
maintain safety measures for the Appliance (See Figure).
• Always empty the Appliance before laying it on its side for any servicing.
• Always wear gloves before servicing any components.
• The resistance values of the components shown in this Service Manual (SM) are purely indicative and
approximate.
• The Sensors located on the Display Board could be at a potential of 220 Volts (If applicable).
• Do not place any container under the Appliance to avoid collecting drops of water.
WARNING
Certain internal parts are intentionally not grounded and may present a risk of electric shock only during
servicing. Do Not Contact any part while the Appliance is energized. For example, Water Valve.
Heating Element with
different Specification

8
4. Product Features (For Models 617, 517 and 417 Series)
Burner Assembly
Model Description
EFME617SIW / EFME517SIW /
EFME417SIW Electrical Heater Assembly
EFMG617SIW / EFMG517SIW /
EFMG417SIW Gas Burner Assembly
Drum Light
Adjustable
Leveling Legs
Control Lock
LED Display
Cycle Selector
3 Drum Vanes
(2 Tumbling)
(1 Mixing)
Lint Filter
Door Latch
Door Strike
Exhaust Channel
Outlet
Reversible Door
Wide-Angle
Door Hinge
Front Mounted
Moisture Sensor
(See Detail View)
Front Mounted
Moisture sensor
Heavy Duty
Drying Rack*
Stacking Kit for Mounting
on Matching Washer*
Detail View
*Not all models come with Drying Rack and Stacking Kit from the factory.
They may be purchased as accessories.

9
5. Model Specifications
Description EFME617SIW EFMG617SIW EFME517SIW EFMG517SIW EFME417SIW EFMG417SIW
Capacity
D.O.E. 8.0 Cu. Ft. 8.0 Cu. Ft. 8.0 Cu. Ft. 8.0 Cu. Ft. 8.0 Cu. Ft. 8.0 Cu. Ft.
Features
Controls Ready-
Select® Ready-Select® - - - -
Dryer Drum
Interior
Stainless
Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel Stainless Steel
Interior Light Yes Yes Yes Yes Yes Yes
Door Trim Chrome Chrome - - - -
Ready
Steam™ Option Option - - - -
Perfect Steam Yes Yes Yes Yes Yes Yes
Eco Yes Yes Yes Yes Yes Yes
DrySense™
Technology Yes Yes - - - -
Wrinkle
Release
Technology
Yes Yes Yes Yes Yes Yes
Shrink Gaurd Yes Yes - - - -
Anti Static Yes Yes Yes Yes No No
TimeWise®
Technology Yes Yes - - - -
Extended
Tumble Yes Yes Yes Yes No No
Precision
Moisture
Sensor
Yes Yes Yes Yes Yes Yes
Time
Remaining
Display
Yes Yes Yes Yes Yes Yes
Cycle Status
Display Yes Yes Yes Yes Yes Yes
Cycle Signal Chime Chime - - - -
Cycle Signal
“ON / OFF ” Yes Yes Yes Yes Yes Yes
Control Lock Yes Yes Yes Yes Yes Yes
Start / Pause
/ Cancel
Buttons
Yes Yes Yes Yes Yes Yes

10
Description EFME617SIW EFMG617SIW EFME517SIW EFMG517SIW EFME417SIW EFMG417SIW
Energy Saver
Option Yes Yes Yes Yes Yes Yes
Delay Start 1 to 12 Hours 1 to 12 Hours 1 to 12 Hours 1 to 12 Hours 1 to 12 Hours 1 to 12 Hours
Tumble
Speed (RPM) 50 50 50 50 50 50
Reversible
Door Yes Yes Yes Yes Yes Yes
Lint Screen Yes Yes Yes Yes Yes Yes
Sound
Package
Silent
Design™ Silent Design™ - - - -
Adjustable
Leveling Legs Yes Yes Yes Yes Yes Yes
Cycles
Dry cycles 9 9 8 8 7 7
Specialty
Cycles 1 1 1 1 1 1
Options
Temperature
Selections 5 5 5 5 4 4
Dryness Level
Selections 5 5 5 5 4 4
Timed Dry 30, 45, 60,
75, AUTO
30, 45, 60, 75,
AUTO
30, 45, 60, 75,
AUTO
30, 45, 60, 75,
AUTO
30, 45, 60,
AUTO
30, 45, 60,
AUTO
Optional
Accessories
Dryer
Stacking Kit
PN #
STACKIT4X
PN #
STACKIT4X
PN #
STACKIT4X
PN #
STACKIT4X
PN #
STACKIT4X
PN #
STACKIT4X
White
Pedestal
P/N
EPWD157SIW
P/N
EPWD157SIW
P/N
EPWD157SIW
P/N
EPWD157SIW
P/N
EPWD157SIW
P/N
EPWD157SIW
Titanium
Pedestal
P/N
EPWD157STT
P/N
EPWD157STT
P/N
EPWD157STT
P/N
EPWD157STT
P/N
EPWD157STT
P/N
EPWD157STT
LP Gas
Conversion
Kit
NA P/N PCK4200 NA P/N PCK4200 NA P/N PCK4200
Drying Rack PN #
137067300
PN #
137067300 - - - -
Certifications
NSF® Certified
Sanitize No No No No No No
Model Specifications

11
Description EFME617SIW EFMG617SIW EFME517SIW EFMG517SIW EFME417SIW EFMG417SIW
Product
Specifications
A - Height
(Single) 38" 38" 38" 38" 38" 38"
Height
(Stacked) 75.75" 75.75" 75.75" 75.75" 75.75" 75.75"
B - Width 27" 27" 27" 27" 27" 27"
C - Depth 31.5" 31.5" 31.5" 31.5" 31.5" 31.5"
Depth with
Door Open
90˚
53.5" 53.5" 53.5" 53.5" 53.5" 53.5"
Pedestal
Dimensions
A - Height 15.25” 15.25" 15.25" 15.25" 15.25" 15.25"
B – Width 27" 27" 27" 27" 27" 27"
C - Depth 26-1/2" 26-1/2" - - - -
Depth with
Drawer Fully
Extended
42-1/2" 42-1/2" - - - -
Model Specifications

12
6. Electrical Characteristics (For Models 617, 517 and 417
Series)
6.1 Electronic Control
The Electronic Control is made up of the following components:
1. User Interface (UI) Board
2. Electronic Control Board
6.1.1 User Interface (UI) Board
The User Interface (UI) PCB contains the selector dial and buttons to adjust temperature, dry level, dry time, and
options.
User Interface (UI) Board Assembly

13
6.1.2 Electronic Control Board
The Electronic Control Board supplies the power supply voltage to the User Interface (UI) Board and all other
electrical components.
The commands acquired by the User Interface (by turning the selector, selecting an option, and so on.) are sent
to the Electronic Control Board, which powers all the electrical components (Thermistor, Thermal Limiter, High-
Limit Thermostat, Burner Assembly and the User Interface (UI) Board).
1. It controls the Temperature of Exhaust air via the Thermistor sensor.
2. It senses opening and closing of the Door.
3. It controls the speed of the Motor.
4. It controls Thermal Limiter, Thermistors, High-Limit Thermostat ands so on.
5. Its controls Heater Assembly.
Electronic Control Board
Electrical Characteristics (For Models 617, 517 and 417 Series)

14
6.2 Schematic Diagram
User Interface Board
Electrical Characteristics (For Models 617, 517 and 417 Series)
Main Control Board

15
6.3 Wiring Diagram – EFME617SIW / EFME517SIW / EFME417SIW
REAR
Door Safety
Interlock (12V)
LED Drum Light
Heating Element
Heater Sensing
Belt Control
Start Sensing
TRIAC 1A
TRIAC 1A
TRIAC 1A
TRIAC 1A
Edge Connector Pitch 2, 5 mm
Edge Connector Pitch 5 mm
Tab Header Connector
Edge Connector Pitch 2, 5 mm
Edge Connector Pitch 5 mm
Tab Header Connector
CAUTION
Disconnect electric current before servicing.
Electrical Characteristics (For Models 617, 517 and 417 Series)

16
6.4 Wiring Diagram – EFMG617SIW / EFMG517SIW / EFMG417SIW
Door Safety
Interlock (12V)
REAR
Heater Sensing
Belt Control
Start Sensing
TRIAC 1A
TRIAC 1A
TRIAC 1A
TRIAC 1A
Edge Connector Pitch 2, 5 mm
Edge Connector Pitch 5 mm
Tab Header Connector
Edge Connector Pitch 2, 5 mm
Edge Connector Pitch 5 mm
Tab Header Connector
LED Drum Light
Humidity Sensor
CAUTION
Disconnect electric current before servicing.
Electrical Characteristics (For Models 617, 517 and 417 Series)

17
7. Electrical Components (For Models 617, 517 and 417 Series)
7.1 Electrical Component Resistance and Specification Table
S.No. Component Specification
1
Heating Element
(For Electric Model Only)
(137114000)
Wattage: 4700 W ± 3%,
Resistance Across the Terminals: 10.39 Ω ± 3%.
2
Inlet Control Thermistor
(For Both Gas and Electrical
Model) (134711200)
Parameter Specification Test Condition
Upper Category Temperature 300 °C -
Lower Category Temperature 10 °C -
Rated Resistance Rn3359 Ω ± 2% -
Rated Temperature 100 °C -
B-Value: B (0/100) 3970 K ± 1% -
B-Value: B (100/200) 4159 K -
Resistance at 25 °C 50000 Ω ± 5% -
Dissipation Factor 2 mW/K AIR
Thermal Cooling Time Constant 20 secs AIR
B-Value: B(200/300) 4267 K -
3
Outlet Control Thermistor
(For Both Gas and Electrical
Model) (134711300)
Parameter Specification Test Condition
Upper Category Temperature 90 °C -
Lower Category Temperature 0 °C -
Rated Resistance Rn5000 Ω ± 2% -
Rated Temperature 25 °C -
B-Value: B (0/100) 3450 K ± 1% -
Dissipation Factor 3 mW/K AIR
Thermal Cooling Time Constant 50 secs AIR
4
Door Switch
(For Both Gas and Electrical
Model) (134813600)
Contact Rating To Meet – 10 A, 1/3 hp, 125/250 V AC.
5
Drum Light
(For Both Gas and Electrical
Model) (A03824001)
LED Diode: Everlight LED, ELSW-F91C1-OLPGS-C6500,
Maximum LED Current: 350 mA, Power: 1 W,
Minimum Flux: 35 lumen ( 55 Typical),
White LED (Cold White) Typical 6500 K.

18
S.No. Component Specification
6
Motor
(For Both Gas and Electrical
Model) (134693300)
Performance Specifications
Voltage - cycles 115V-60 Hz
Breakdown torque, ft - oz 26.0 nom
Locked rotor current, amps 46.5 max.
Full load torque, ft - oz 16.2 nom
Full load current, amps 5.1 nom
Full load, watts 400 nom
Full load, rpm 1685 nom
Horse power 1/3 hp output
Locked rotor trip time 3-6 secs
7
Inlet Thermal Limiter
(For Electric Model Only)
(137032600)
U.L. and C.S.A. Rated: 125/250 V AC, 25 A Resistive, 125 V AC, 20 F.L.A.,
60 L.R.A. Inductive, 240 V AC, 10 F.L.A., 60 L.R.A. Inductive,
Opening Temp: 275 º ± 10.8 ºF, Closing Temp: -31 ºF.
8
Inlet Thermal Limiter
(For Gas Model Only)
(137539200)
UL and C.S.A. Rated: 125/250 V AC, 25 A Resistive, 125 V AC, 20 F.L.A.,
60 L.R.A. Inductive, 240 V AC, 10 F.L.A., 60 L.R.A Inductive,
Opening Temp: 314 º ± 6 ºF, Closing Temp: -31 ºF.
9
Outlet Thermal Limiter
(For Both Gas and Electrical
Model) (134711401)
U.L. Rated : 240 V, 10 A F.L.A and 60 A L.R.A at 350 ºF,
C.S.A. Rated: 120 V, 15 A Resistive,
Opening Temp: 180 º ± 8 ºF,
Closing Temp: -31 ºF.
10
High-Limit Thermostat
(For Gas Model Only)
(137116700)
240 V, 25 Amp Resistance,
Opening Temp: 200 ± 6 ºF,
Closing Temp: 130 ± 7 ºF,
Maximum Temperature: 350 ºF.
11
High-Limit Thermostat
(For Electrical Model Only)
(14516000)
240 V, 25 Amp Resistance,
Opening Temp: 260 ± 8 ºF,
Closing Temp: 190 ± 11 ºF,
Maximum Temperature: 350 ºF.
12
Fire Containment Thermostat
(For Both Gas and Electrical
Model) (137116700)
240 V ,25 Amp Resistance,
Opening Temp: 180 ± 8 ºF,
Closing Temp: -31 ºF,
Maximum Temperature: 350 ºF.
13
Mist Valve
(For Both Gas and Electrical
Model) (137544800)
Electrical Rating: 120 V, -60 Hz or 105 V -50 Hz, 5 Watts,
Flow rate: 140 cc ± 8% @ 20-120 psi and / or ± 5% @ 50 psi for 7.5 secs.
14
Igniter
(For Gas Model Only)
(137524000)
Steady State Current to be 3.90 to 5.00 A @ 132 ± 1 V AC and 75 º ± 5 ºF
Ambient, time to reach 2000 ºF: 16 secs Max. @ 115 ± 1 V AC and 75 º ±
5 ºF Ambient Temp, Igniter Must Not Exceed 3100 ºF in 10 secs at
132 ± 1 V AC and 75 º ± 5 ºF Ambient.
Electrical Components (For Models 617, 517 and 417 Series)

19
7.2 Heating Element
WARNING
• When replacing the heating element, refer
to the code shown in the list of spare parts
relating to the Appliance.
• It is strictly forbidden to tamper with the
heating element in any way.
7.2.1 General Characteristics
For Electric Models
The Heating Element converts Electric Power into
heat through the process of resistive heating. Electric
current passing through the element encounters
resistance, resulting in heating of the element.
In Electric Dryers, heat
is generated by the
heating element. The
element is a coil of
heating wire enclosed
in a metal chamber.
Electric current flowing through the coil creates
heat and the air being pulled through the chamber
absorbs this heat and becomes hot.
For Gas Models
The Gas models are
equipped with a Gas
Valve and Burner
assemblies enclosed
in a metal chamber.
The Gas flows
through the valve and is ignited which creates heat.
Air is pulled through the chamber and becomes hot.
Component Specifications
S.No. Component Specification
1
Heater (For
Electric Model
only)
Wattage: 4700 W ± 3%,
Resistance Across the
Terminals: 10.39 Ω ± 3%.
7.3 Inlet Control Thermistor
WARNING
When replacing the Inlet Control Thermistor,
refer to the code shown in the list of spare parts
relating to the Appliance.
7.3.1 General Characteristics
The Thermistor is a type of resistor whose resistance
varies significantly with temperature.
The Thermistor measures the temperature of the air in
the Dryer and adjusts the heat accordingly. When a
Thermistor fails, it can cause the Dryer not to heat at
all or heat up to the wrong temperature.
It is used to check the temperature of air near Drum
Inlet in Rear Air Duct.
Electrical Components (For Models 617, 517 and 417 Series)

20
Component Specifications
S.No. Component Specifications
1Inlet Control Thermistor
Parameter Specification Test Condition
Upper Category
Temperature
300 °C -
Lower Category
Temperature
10 °C -
Rated Resistance Rn 3359 Ω ± 2% -
Rated Temperature 100 °C -
B-Value: B (0/100) 3970 K ± 1% -
B-Value: B (100/200) 4159 K -
Resistance at 25 °C 50000 Ω ± 5%
Dissipation Factor 2 mW/K AIR
Thermal Cooling Time
Constant
20 secs AIR
B-Value: B (200/300) 4267 K -
7.4 Outlet Control Thermistor
WARNING
When replacing the Outlet Control Thermistor, refer to the code shown in the list of spare parts relating to
the Appliance.
7.4.1 General Characteristics
AThermistor is a type of resistor whose resistance varies significantly with temperature.
The Thermistor measures the temperature of the air in the Dryer so that the Dryer knows its temperature limits.
When a Thermistor fails, it can cause the Dryer to not heat at all or heat up to the wrong temperature.
It is used to check the temperature of air between the blower and exhaust.
Electrical Components (For Models 617, 517 and 417 Series)
