Electrolux 44" Stainless Steel User manual

44” Stainless Steel Gas Grill

Please record grill information for future reference and service work:
Model #: ________________________________________________________
Serial #: ________________________________________________________
Date of Purchase: ________________________________________________
Gas Type: ______________________________________________________
Welcome & Congratulations
1
Please retain this manual for future reference
© 2004 Electrolux Home Products, Inc All rights reserved
Congratulations on your purchase of a new grill! We at Electrolux Home Products are very proud of
our product and we are completely committed to providing you with the best service possible.
Your satisfaction is our #1 priority.
Please read this Use & Care Manual very carefully. It contains valuable information on how to
properly maintain your new grill.
We know you’ll enjoy your new grill and thank you for choosing our product. We hope you consider
us for future purchases.
PLEASE READ AND SAVE THESE INSTRUCTIONS
This Use & Care Manual provides specific operating instructions for your model. Use your grill only
as instructed in this manual. These instructions are not meant to cover every possible condition and
situation that may occur. Common sense and caution must be practiced when installing, operating
and maintaining any appliance.
Please record your model and serial numbers below for future reference. This information is found
on the serial plate located on the back of the built-in grill or on the inside of the cart door for
complete grill & cart model.
Questions?
1-800-320-0859
www.electroluxusa.com
TABLE OF CONTENTS
Welcome/Product Registration......................................................................1
General Safety Instructions ..........................................................................2
Grill Features & Components ......................................................................3-4
Grill Assembly/Built-In Instructions ............................................................5-8
Gas Requirements/Leak Testing ................................................................9-11
Lighting the Grill ............................................................................................12
Using the Grill (Rotisserie/Side Burner Usage)........................................13-15
Care & Maintenance ......................................................................................16
Troubleshooting Your Grill ........................................................................17-18
Warranty ..........................................................................................................19

General Safety Instructions 2
TESTED IN ACCORDANCE WITH ANSI
Z21.58b-2002/CGA 1.6b-M02 STANDARD FOR
OUTDOOR COOKING GAS APPLIANCES.
THIS GRILL IS FOR OUTDOOR USE ONLY.
Check your local building codes for the proper
method of installation. In the absence of local
codes, this unit should be installed in accordance
with the National Fuel Gas Code No. Z223.1-2002
and the National Electrical Code ANSI/NFPA
No. 70-1990
WARNING
DO NOT try lighting this appliance without reading
the “LIGHTING INSTRUCTIONS” section of
this manual.
FOR YOUR SAFETY
DO NOT store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
An LP cylinder not connected for use shall not be stored in
the vicinity of this or any other appliance.
IMPORTANT SAFETY INFORMATION
-Read this manual carefully before using your grill to reduce the risk
of fire, burn hazard or other injury.
-Extreme care should be used because of the high temperatures
produced by this appliance. CHILDREN SHOULD NOT BE LEFT
UNATTENDED IN AN AREA WHERE THE GRILL IS BEING OPERATED.
-This appliance must be kept clear from combustible materials, gasoline or other flammable vapors
and liquids. Do not allow flammable materials to come in contact with grate, burner or hot surfaces.
-Use only outdoors and provide good ventilation to avoid carbon monoxide build-up which could result
in injury or death.
-Do not repair or replace any part of this appliance unless it is specifically recommended in this manual.
A qualified service technician should conduct all other service.
-Follow the installation and servicing instructions provided with this product. Have your grill installed
by a qualified service technician.
-Locate the main gas supply valve so that you know how to shut the gas off to your grill.
-If you smell gas, make sure all gas connections are tight before operation. If you continue to smell
gas call a qualified technician.
-When lighting a burner,always pay close attention to what you are doing and be certain you are
pushing the igniter that lights the burner you intend on using.
-Always keep your face and body as far away as from the grill as possible when lighting to reduce the
risk of burn.
-Extinguish all flames and do not smoke while engaging gas and igniting the grill.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open grill hood.
4. If odor continues, immediately
call your gas supplier.
FOR OUTDOOR USE ONLY
This appliance is not intended to be
installed in or on recreational
vehicles or boats.
CALIFORNIA PROPOSITION 65 - WARNING:
The burning of gas cooking fuels generates some by
products which are on the list of substances which
are known by the State of California to cause cancer
or reproductive harm. California law requires busi-
nesses to warn customers of potential exposure to
such substances. To minimize exposure to these
substances, always operate this unit according to the
use and care manual, provide good ventilation when
cooking with gas.

Grill Features: E44
3
1. Roll top grill hood
2. Grilling/cooking surface
3. Side shelf
4. Control knob: back infrared burner
5. Control knobs: main burners
6. Warming drawer
7. Hood handle
8. Warming shelf
9. Infrared back burner
10. Side burner electronic igniter
11. Cart with door and drawers
12. Drip trays
13. Side burner
14. Control knob: side burner
15. Main grill and back infrared electronic
igniter
NOTE: Cart, side burner and side shelf are not included with the head only units.
2
17
8
9
13
14
10
15
12
11
5
6
4
3

Grill Assembly
5
IMPORTANT: Remove all protective plastic
film from stainless steel parts prior to
assembly/use. This film is installed at the
factory to prevent damage that could
occur during shipment and handling.
SIDE SHELF ATTACHMENT
1. Loosen the bolts on the side of the grill and attach
the shelf by allowing the bolt heads to fall through
the large opening in the bottom of the keyhole
slots. Then slide the shelves downward until the
bolts are resting against the top of the key hole
slots. Tighten all of the shelf bolts. (See Fig. 1-2)
2. Attach the four (4) wires coming out from the left
side of the grill to the igniter terminals. (See Fig. 3)
Note: It does not matter which wire goes to which
terminal on the electronic igniter
INTERIOR PARTS INSTALLATION
1. Install the bottom flavor grids in the lower cutouts
and around the igniters. (See Fig. 4)
2. Insert the top row of flavor grids with the 90
degree angled heat shield (bottom side of flavor
grid) facing the rear of the unit into cutouts with tri-
angle ridges facing up. (See Fig. 5-6)
3. Install cooking grates on the ledges provided on the
grill to create your cooking surface. (See. Fig. 7)
4. Place warming shelf on support brackets by set-
ting it flat across brackets allowing the two holes
to line up with the holes on each bracket.
(See Fig. 7)
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
Fig. 6 Bottom flavor grids
in between burners
Faces the back of
the grill
Fig. 7
Cooking Grates
Warming Shelf
