Electrolux EI30GF55G - 30" Gas Range User manual

Gas Freestanding Ranges
EI30GF55G S, EI30GF55G W, EI30GF55G B
30" GAS FREESTANDING RANGES
Sabbath Mode (Star-K®Certified)
Control Panel Features
IQ-Touch™Electronic Oven Control
Professional-Grade Burner Controls
Glass Front Display
Electronic Clock & Timer
Temperature Display
Automatic Oven (Delay, Cook & Off)
Cooktop Features
Sealed Power Burner – 16,000 BTU
Sealed Power Burner – 14,000 BTU
Sealed Precision Burner – 9,500 BTU
Sealed Precision Burner – 5,000 - 500 BTU
Linear Flow Burner Valves
Seamless Cooktop
Continuous Grates with Deep-Well Top
Electric Pilotless Ignition
Oven Features
Capacity
Hidden Bake Burner
Bake Burner – 18,000 BTU
Broil Burner – 13,500 BTU
Convection Burner – 350 Watts
Cobalt Blue Interior
Self-Clean Options with Door Lock
Perfect Convect3™with Variable 2-Speed Fan
Cooking Modes –
Bake, Broil, Convection Bake, Convection Roast,
Keep Warm, Slow Cook
Cooking Options –
Dehydrate, Bread Proof, My Favorites,
Rapid Preheat, Delay Bake, Convection Convert
Luxury-Design™Lighting with Dual 40W Halogen Bulbs
Luxury-Glide™Racks
Conventional Racks
Convection Roasting Rack
Additional Features
Signature Soft-Arc Oven Door and Handle Design
Luxury-Hold™Oven Door
Extra-Large Glass Window
Warmer Drawer
Fully Extendable Drawer Glides
Adjustable Leveling Legs
Accessories
Porcelain Broiler Pan and Insert
Grill/Griddle
Wok Ring – 318254307
Simmer Plate – 318254206
LP Conversion Kit
Specifications
Oven Cavity Dimensions –
Height
Width
Depth
Overall Exterior Dimensions –
Height
Width
Depth (to Center of Arc)
(with 90° Door Open)
Gas/Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @120 Volts‡
Product Weight
Shipping Weight (Approx.)
‡For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate
ground wire. Appliance must be grounded for safe operation.
NOTE: Always consult local and/or national electric and gas codes. Refer to Product Installation Guide
for detailed installation instructions on the web at www.electroluxappliances.com.
Specifications subject to change.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
1
1
2
1
Yes
Yes
3
Yes
5.1 Cu. Ft.
Yes
Yes
Yes
Yes
Yes
3
Yes
6
6
Yes
1
2
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Included
Included
Optional
Optional
Included
18-5/8"
24-5/16"
19-1/2"
47-1/2"
29-7/8"
26-27/32"
47"
Right Bottom Rear
120V/60Hz/15A
1.8
260 Lbs.
300 Lbs.
Five Sealed Burners
Powerful 16,000 BTU sealed burner with 4 additional
sealed burners including a precise 5,000 BTU to
500 BTU simmer burner option. Continuous grates
provide a stable cooking surface, allowing pots
and pans to be easily moved from burner to burner.
Sure-2-Fit™Convection Oven
with Hidden Bake Burner
Adjustable Luxury-Glide™oven racks are so smooth
and extend effortlessly. Luxury-Design™Lighting
ramp-up designer halogen lighting is as beautiful
as it is functional. Exclusive Luxury-Hold™oven
door stays put at whatever angle you place it.
Versatile Cooking Option
Self-clean oven with versatile cooking option
features 6 cooking modes and 6 cooking options.
Warmer Drawer
Keeps food or plates warm and ready to serve.
It’s the perfect solution when dinner is delayed,
or when multi-course meals are on the menu.
electroluxappliances.com
Wall OvensWarmer DrawersCooktopsBuilt-In Ranges
Freestanding
Ranges
MicrowavesVent HoodsDishwashersRefrigerators
FreezersUnder Counter

Gas Freestanding Ranges
EI30GF55G S, EI30GF55G W, EI30GF55G B
High standards of quality at Electrolux Major Appliances mean we are
constantly working to improve our products. We reserve the right to change
specifications or discontinue models without notice.
USA
•250 Bobby Jones Expressway •Augusta, GA 30907 •1-877-4electrolux (1-877-435-3287) •
electroluxappliances.com
CANADA
•5855 Terry Fox Way •Mississauga, ON L5V 3E4 •1-800-265-8352 •
electroluxappliances.ca
EI30GF55G 01/08 © 2008 Electrolux Major Appliances, NA Printed in the U.S.A.
Side
Overall depth
including oven
door in 90°open
position – 47"
285/8"
263/8"
Front
357/8"
Adjustable
to
361/8"
297/8"
115/8"
471/2"
30"min.
13"
max.
25"
24"
5"min.
to nearest
combustible
wall (either
side of unit)
above 36"
height
301/8"
2"
15"
111/2"
Area allows for flush
installation with through-
the-floor connection
of pipe stub/shutoff valve
Area allows for flush
installation with through-
the-wall connection of
pipe stub/shutoff valve
and rear wall120V outlet
C
L
101/2"
7"
23"
18"min.
36"
stand.
34"
min.
Gas
connection
and power
supply
location
(right bottom
rear)
30" Gas Freestanding Range Specifications
•
Product Weight – 260 Lbs.
•
Voltage Rating –120V/60Hz/15 Amps
•
Connected Load (kW Rating) @120 Volts = 1.8kW
(For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded
for safe operation.)
•
Amps @120 Volts = 15 Amps
•
Always consult local and/or national electric and gas codes.
•
Range ships with 3/4" factory regulator.
•
Overhead cabinetry should not exceed a 13" maximum depth.
•
Allow 30" minimum clearance between top of rangetop and bottom of
unprotected wood or metal overhead cabinetry.
•
Absolute minimum horizontal distance between overhead cabinets
installed to either side of appliance must be no less than maximum width
of appliance.
•
Allow 24" minimum clearance when bottom of wood or metal overhead
cabinet is protected by not less than 1/8" flame-retardant millboard
covered with not less than No.28 MGS sheet steel, 0.015" stainless
steel, 0.024" aluminum or 0.020" copper.
•
Allow 5" minimum clearance from edge of rangetop to nearest
combustible wall on either side of unit.
•
To reduce risk of fire when using overhead cabinetry, install range hood
that projects horizontally a recommended minimum of 5" beyond bottom
of cabinets.
Note: For planning purposes only. Refer to Product Installation Guide
on the web at electroluxappliances.com for detailed instructions.
Optional Accessories
•
Wok Ring – (318254307).
•
Simmer Plate – (318254206).
