Electrolux ICON RH30WC60GS User manual

RH30-36WC60G Cover.eps RH30-36WC60G-2 Parts.eps SE1Q5A.eps
UNIVERSAL/MULTIFLEX
Product No. RH30WC60GSA RH36WC60GSA
Market North America North America
Color stainless steel stainless steel
Exhaust-CFM 600 CFM 600 CFM
Volts 120 120
Owner's Guide 316488522 316488522
Installation Instructions 316488522 316488522
Wiring Diagram 5995572608 5995572608
Electrolux Major Appliances
P.O. BOX 8020
CHARLOTTE, NC 28262
Publication No.
5995572608
10/08/25
(EN/SERVICE/KC)
099
RANGE HOOD
Model No.
RH30WC60G /
RH36WC60G

Publication No: 5995572608 RH30WC60G / RH36WC60G
08/10 2
REPLACEMENT PARTS

RH30WC60G / RH36WC60G Publication No: 5995572608
# Functional Parts 3 08/10
* Non-Illustrated Parts
REPLACEMENT PARTS
Model Index: ARH30WC60G (RH30WC60GSA)
BRH36WC60G (RH36WC60GSA)
POS. NO PART NO. DESCRIPTION
1 5304466257 A B Chimney, duct cover, lower flue
1A 5304466256 A B Chimney, duct cover, upper flue
2 5304466258 A B Damper, exhaust
3 # 5304464261 A B Capacitor
4 # 5304464262 A B Transformer
5 # 5304464263 A B Power Board, pcb, w/spacers
6 # 5304466260 A B Blower Assembly
7 # 5304464264 A - Canopy, 30 inch, glass
7 # 5304466262 - B Canopy, 36 inch, glass
8 # 5304464201 A B Control Panel, display, LCD
9 # 5304464265 A B Filter, grease
10 # 5304464266 A B Lampholder, socket, w/housing, lamp
11 5304466263 A B Screw Kit, assembly
14 5304480606 A B Seal Kit, glass, w/mtg brackets
17 5304464286 A B Installation Kit, w/hardware, instructions
20 # 5304472119 A B Switch, on/off
* # 5304466255 A B Filter, charcoal, recirculation
* 5304466744 A B Recirculation Kit, chimney/wall

Publication No: 5995572608 RH30WC60G / RH36WC60G
08/10 4
WIRING DIAGRAM
