Elektra Beckum SPA 1100 User manual

®
115 162 9250 / D/GB/F/NL/DK/N/S/FIN/I/E/P / 1901 - 2.3
Montage- und Betriebsanleitung für
Späneabsauganlage
Assembly and operating instructions for the
chipping suction device
Notice de montage et de service
Dispositif d'aspiration des copeaux
Handleiding voor montage en bediening van de
Spaanderafzuiginstallatie
Monterings- og driftsvejledning Spånudsugningsanlæg
Monterings- og driftsinstruks for sponavsugsanlegg
Monterings- och driftanvisning för
spånutsugsanläggning
Asennus- ja käyttöohje Lastunimuri
Istruzioni per il montaggio e per l'uso dell'impianto di
aspirazione trucioli
Instrucciones de servicio y montaje para la instalación
de aspiración de virutas
Instruções de montagem e Manual de instruções para
sistema de aspiração de aparas
SPA 1100
D
ENG
F
NL
Achtung! Lesen Sie diese Anleitung vor der Installation und Inbetriebnahme aufmerksam durch.
Attention! Carefully read through these instructions prior to installation and commissioning.
Attention! Prière de lire attentivement la présente notice avant l'installation et la mise en service.
Attentie! Lees deze instructies voor de installatie en ingebruikname aandachtig door.
Bemærk! Læs denne vejledning opmærksomt igennem inden installationen og idrifttagningen.
Se opp! Vær så vennlig å først gjennomlese nøyaktig denne veiledningen før installasjonen og idriftsettelsen.
Observera! Var god och läs noga igenom denna handledning före installering och idrifttagande.
Huomio! Lue tämä ohje huolellisesti läpi ennen asennusta ja käyttöönottoa.
Attenzione! Prima dell'installazione e della messa in esercizio, leggete attentamente e completamente queste istruzioni.
Atención! Lea atentamente estas instrucciones antes de la instalación y puesta en marcha.
Atenção! Faça favor der ler atentamente estas instruções antes da instalação e colocação em funcionamento.
DK
S
D
NL
F
GB
I
E
FIN
N
P
NO
SV
IT
FIN
ES
PT
DA

2
DMontage- und Betriebsanleitung Seite 4 - 6
ENG Assembly and operating instructions Page 7 - 9
FNotice de montage et de service Page 10 - 12
NL Handleiding voor montage en bediening Pagina 13 - 15
DA Monterings- og driftsvejledning Side 16 - 18
NO Monterings- og driftsinstruks Side 19 - 21
SV Monterings- och driftanvisning Sida 22 - 24
FIN Asennus- ja käyttöohje Sivu 25 - 27
IT Istruzioni per il montaggio e per l'uso Pagina 28 - 31
ES Instrucciones de servicio y montaje Pagina 32 - 34
PT Instruções de montagem e Manual de instruções Páginas 35 - 37

a
15
6
2
48
7
3
3

ENG
7
General
The SPA 1100 chipping suction device is suitable for
vacuuming planing, milling and sawing chippings, as well
as wood dust.
The entire machine assembly is packed in a packaging
unit.
If after reading these operating instructions, you should
have further queries about the SPA 1100 chipping suc-
tion device, please contact the:
Elektra Beckum AG, Customer Service,
Postfach 13 52, D-49703 Meppen.
We supply 12 months guarantee this for products in ac-
cordance with the legal/country specific regulations.
Please make sure that the guarantee is valid from the
date of purchase and can be proven by means of a re-
ceipt.
Damage which occurs as a result of natural wear, over-
load, improper use or negligence of maintenance work
is not covered by our guarantee.
Complaints can only be accepted if the apparatus/the
machine is returned to your dealer in one piece (with all
accessories) or the complaints are registered there im-
mediately.
Product liability/guarantee
The SPA1100 chipping suction device may only be used
for its intended purpose.
Possible applications not described in these operating
instructions require the written consent of Elektra
Beckum AG.
Proper use
The SPA1100 chipping suction device serves to vacuum
planing, milling and sawing chippings (only wood and
plastics) or wood dust on work working machinery.
Any other use is considered unacceptable. We are not
liable for any damage resulting from any alterations to
the SPA 1100 chipping suction device caused by such
improper use, or carried out by the user himself.
Flammable gases (e.g. paint fumes) and explosive me-
dia may not be vacuumed.
Use in industrial firms, in technical colleges and schools,
etc. is not permitted.
Safety notes
When improperly used electrical machines may lead to
dangerous situations. Therefore, please always observe
the safety notes below.
•In case of malfunctioning, immediately pull out the
plug. Never switch on the machine without the dust
bag.
•Never allow children or young people to operate the
machine.
•Never use the machine if the electrical motor, on/off
switch, fan casing or connection cable is damaged.
•Never vacuum any sources of ignition.
•Only use the machine to vacuum wood working
machines.
Assembly
Fig. : Place fan housing 2with motor facing down on
workbench or other sturdy support and use a
wooden block or similar to support it in a level
position.
Attach side panels 3and 4, with labels facing
outward, with thread cutting screw 1supplied to
the fan housing.
Fig. : Installcrossplate5withcupsquareneckscrews,
washers and hexagon flange nuts between side
panels.
Fig. : Install a castor socket on each corner of the
base plate. Fit three each cup square neck
screws 6M 5 x 20 through bottom panel and
castor socket 7, and secure with washers 8and
hexagon flange nuts 9. Afterwards push twin
caster 10 into castor socket.
Fig. : Put the so pre-assembled base plate onto the
side panels as shown, and secure with cup
square neck screws and hexagon flange nuts.
Afterwards check that all screw connections are
tight and stand machine on the casters.
Fig. : Fit hose clamp 11 to end of suction hose 12,
then push hose on the suction port below the
motor, tighten hose clamp.
Fig. : Fit dust bag 14 to dust collection opening.
Use dust bag of appropriate size (e. g. 600 x 900
mm), and clamp to opening with tightening strap
13.
Tip: Fit opening of dust bag tight around dust
collection opening and fold overlapping section.
Pull tightening strap over it and tighten.
Fig. : Bent the two flexible rods 15 into a “U“and fit
their ends into the four holes on the neck of the
housing’s filter bag opening.
At the vertex secure the rods crosswise with a
cable tie.
Fit dust bag 16 and tightening strap 17 over the
filter bag opening and tighten strap.
1
2
3
4
5
6
7

Lay out the connection cable and use it to connect the
machine to the mains.
Switch on the electric motor and wait a few seconds
until the fan has reached maximum speed.
If the upper dust bag does not automatically expand with
air after a few seconds, pull it up.
Only switch on the wood working machine when you
are sure the dust bag is blown up, and start the wood
working process.
Allow the chipping suction device to run at least 10 sec-
onds after switching off the wood working machine.
Note: We recommend a switch-on coupling to the suc-
tion device with more intense daily use of your
wood working machine. This brings about the
delayed switching on/off of the chipping suction
device as soon as the wood working machine
has been switched on/off.
This automatic switching on/off device is available from
Elektra Beckum in two different designs (see section on
special accessories).
Electrical connection
Caution! Compare the data on the nameplate of the
SPA 1100 with that of the mains prior to
commissioning. The mains frequency must
correspond to the figure on the nameplate.
Connection cable
Only use oil-resistant connection cable H07 RN-F. The
cross section of the cable must measure at least 1.0
mm2.
Fuse
Warning! Hazard due to electrical shocks. For your
own protection only operate the machine
over a 30 mA fault current breaker.
Safeguard the plug to which the machine is connected
with a 10 A fuse (slow-blow).
Static electricity
The chipping suction device SPA 1100 is not composed
of electrically conductive components. If the machine is
connected to electrically conductive parts (e.g. metallic
suction hoods or suction pipes), these must be addi-
tionally earthed to conduct any electrostatic energy.
Never replace any plastic components of the SPA 1100
with metal parts. The suction hose, in particular, must
not have any metal spirals. Small metallic parts such as
screws and hose band clips are completely harmless.
Always use original spare parts from Elektra Beckum.
These are especially designed for the SPA 1100.
Overload protection
To protect the electrical motor against overload, there is
a motor protective device.
If the motor is overheated or overloaded this device
switches off the machine. The machine can be switched
on again after the electrical motor has been allowed to
cool down for a few minutes.
Note: If the machine switches off a few times in a row
(2 - 3 times) as a result of the motor protective
device, the machine must be overhauled by a
qualified electrician before trying to switch on
again.
8
Operation
Position the SPA 1100 next to the wood working ma-
chinery without hindering the operation of the latter.
Connect the suction hose to the chipping suction sup-
ports of the wood working machine.
Storage
To store the chipping suction device the suction hose is
placed over the motor once and the end of the hose is
pushed into the opening of the bottom plate.
Maintenance/cleaning/storage
The SPA 1100 does not require any maintenance.
However, prior to starting up the machine always check
the following:
1. Check all screw connections! Tighten any loose
connections.
2. Is the switch casing, electrical motor or fan casing
damaged? Have any damaged parts replaced by an
electrician.
3. Is the dust bag or suction hose damaged. Replace
any damaged parts.
Cleaning
Clean the subframe and fan casing with a damp cloth.
Only clean the electrical motor and on/off switch with a
dry cloth.
Tap out any dirt from the dust bag (make sure that a
chipping collection bag is suspended below the ma-
chine).
Replace the chipping collection bag below the machi-
ne as soon as it is about 4/5 full. The maximum filling
height can also be seen from the side panels. (Arrow in
Fig. ).
There is a horizontal slit in the plate for this purpose.
8

Technical data
Motor output: 0,37 kW
Mains voltage/frequency: 230 V/50 Hz
Permissible max. volume flow: 550 m3/h
Generated underpressure: 740 Pa
Length of suction hose: 2500 mm
Diameter of suction hose: 100 mm
Suction hose connection: 100 mm
Dust bag volume: 80 dm3
Weight (with empty chipping
collection bag): 25 kg
Measuring points: 1m distance; 1.6 m height
Polyester-needled felt dust bag: SCHUPES 450 BIA "G"
tested.
Dust bag filtering surface: 1.2 m2.
A- sound pressure level LpA = 77 dB(A)
A- acoustic power level LWA = 83 dB(A)
Special accessories
Automatic switching on device
For delayed switching on/off of the chipping suction de-
vice once the wood working machine has switched on/
off.
Automatic switching on device ALV 1
Order no. 091 301 4626
Automatic switching on device ALV 10, 3~400 V,
1~230 V
Order no. 091 301 4634
Filter cartridge
Retains the finest dust particles. Filtering surface: 5.2
m2.
Order no. 091 300 5058
9
Measuring conditions
Length/diameter of suction hose: 2 m/100 mm
Air speed in suction hose: 16 m/s
Noise emission
The below noise levels below are recorded in accord-
ance with the following measuring method:
DIN 45 635 Part 1.
Item Description Size DIN Order No.
1 Bottom plate 138 222 3043
2 Side panel - right 138 222 3086
3 Side panel - left 138 222 3051
4 Cross arm 138 222 3060
5 Wheel double roller 727 003 3142
6 Double roller seat 138 122 3074
7 Chipping collection bag 091 301 7617
8 Clamping ban Ø275 701 408 1628
9 Spiral hose Ø100x2500 785 401 8544
10 Hose clip SG 90-110 781 103 6697
11 Transition ring 139 100 6179
12 Dust bag with hook Ø400/274x950 139 918 7989
13 Clamping band Ø280 701 442 1119
14 Round bar 138 122 1314
15 Fan wing and fan hood 138 163 0710
16 Condenser 12 µF/450 V 805 001 1799
17 On/off switch 811 260 8924
18 Anti-spray device 811 960 8938
19 SPA motor with rocker button and supply line 0,37 kW 101 363 0492
20 Motor terminal box - lower part 133 140 9657
21 Motor terminal box cover 133 163 0736
22 Rubber cable with plug 840 213 0025
23 Casing - upper part 139 101 8487
24 Bucket wheel 239 107 1457
25 Casing - lower part 139 100 7078
500 Hexagon sheet metal screw B 4,8x25 7976 617 102 8084
501 Mushroom-head square neck bolt M 5x16 603 611 012 5036
502 Washer A 6,4 125 630 001 6365
503 Flange nut M 5 620 962 0098
504 Hexagon nut self-locking M 8 985 620 200 2305
505 Washer B 8,4 9021 630 500 2486
506 Hexagon head screw M 8x25 933 610 300 1194
507 Washer B 6,4 9021 630 500 2087
508 Oval head screw M 5x16 7985 612 300 2057
509 Saucer-head screw Plastite 5x20 618 901 1421
510 Thread-forming screw M 4x12 7516 617 560 4837
7000 Fused Plug BS 1363 821 514 8077
Spare parts list

Explosionszeichnung / Explosion drawing / Dessin éclaté / Explosietekening / Eksploderet
tegning / Oversiktstegning over delene / Explosionsritning / Sinkopiirustus / Disegno
esploso / Plano de despiece / Ignição de explosão
38

D A
Elektra Beckum AG, Daimlerstraße 1, D-49716 Meppen Tel.: [phone], Fax: [phone]
uMetabo Power Tools Pty. Ltd., 28 Laser Drive,
Rowville, 3178, Victoria, Australia, Phone: [phone], Fax: [phone]
GMetabo UK Ltd., 25 Majestic Road, GB-SO 16 OYT
Tel.: [phone], Fax: [phone]
FLurem MACHINES à BOIS,
Zone Industriell/BP 1, F-617000 Domfront Tel.: [phone], Fax: [phone]
BMetabo Belgium, t Hofveld 3-5,
B-1702 Groot Bijgaarden Tél.: [phone], Fax: [phone], e-mail: [email protected]
HMetabo Nederland b. v.,
Keulschevaart 8, NL-3621 MX Breukelen, Postbus 180, NL-3620 AD Breukelen, Tel.: [phone], Fax: [phone], e-mail: [email protected]
CMetabo (Schweiz) AG, Kundendienst,
Lindaustrasse 17, 8317 Tagelswangen Tel.: [phone], Fax: [phone], e-mail: [e-mail] www.elektra-beckum.ch
ICarlo Stechel & Figli S.R.L.,
Via Buozzi 22, I-20097 San Donato Milanese (MI) Tel.: [phone], Fax: [phone], e-mail: [email protected]
EHerramientas Metabo, S.A.,
Polígono Ind. N°6, Parcela 16, E-28935 Móstoles (Madrid) Tel.: [phone], Fax: [phone], e-mail: [email protected] Kestra S.A. Soldadura, Polg. Ind. La Ferreria, C.Del Treball, No. 19, E- 08110 Montcada I Reixac, Tel.: [phone], Fax: [phone]
PBolas - Máquinas e Ferramentas de Qualidade, S.A.,
Rua 8, Lotes 8, 10, 12, P.O. Box 53, P-7001 Évora-Codex Tel.: [phone], Fax: [phone], e-mail: [email protected]c.pt
KMetabo Danmark A/S,
Marielundvej 48 C, DK-2730 Herlev Tel.: [phone], Fax: [phone], e-mail: [email protected]
NMetabo Norge A/S,
Postboks 1296, N-3205 Sandefjord Tlf.: [phone], Fax: [phone] e-mail: [e-mail]
SHDF-Paulsson AB,
Box 525, Svaravaregatan 5, S-30180 Halmstad Tel.: [phone], Fax: [phone]
JNofa OY, P.O.Box 28,
Hannuksentie 1, FIN-02270 Espoo Tel.: [phone], Fax: [phone]
pMetabo Polska Sp. z.o.o.,
ul. Gdyńska 28, PL-73110 Stargard Szczeciński
Tel.: [phone], Fax: [phone]
e-mail: [email protected] Internet: www.metabo.pl
hEB Nefro KFT,
Futo U. 70, HU-3508 Miskolc Tel.: [phone], Fax: [phone]
aExtra Industrial Goods,
Rr. Fadil Rada 88, AL-Tirana Tel.: [phone], Fax: [phone]
eAS Mecro,
Peterburi tee 44, EST-11415 Tallinn Tel.: [phone], Fax: [phone]
rITA Ltd.,
Balakirevskij Pereulok 19, str. 1, RUS-Moscow Tel.: [phone], Fax: [phone], e-mail: [email protected]
cMetabo s.r.o.,
Kralovicka 544, CZ-25001 Brandys nad Labem Tel.: [phone], Fax: [phone], e-mail: [email protected], Internet: http://www.metabo.cz
sSTAMET Bratislava spol. s.r.o.,
M.R. Stefanika 28, SK-90201 Pezinok Tel.: [phone], Fax: [phone] e-mail: [e-mail]
RS.C. Agent Trade S.R.L.,
Splalui Unirii 253-237, RO- 74299 Bucuresti 3 Tel.: [phone], Fax: [phone]
e-mail: [email protected]
ODilex d.o.o.,
Orginceva ut. 17, SLO-51113 Ljublijana Tel.: [phone], Fax: [phone]
EB_Adr3C.fm
