Elektron Technology Henson 9000 User manual

Henson 9000
Perimeter
Quic -Start Guide
Please read before
taking the product
out of the box
Small footprint, ease of use,
performance and speed of operation
have all influenced the new Henson
design.
The Henson 9000 combines fast
screening with the latest and fastest
threshold test (ZATA) plus standard
printouts that match those used in
most Hospital Eye Services. The
modern and ergonomic design offers a
comfortable headrest plus an optional
motorised chinrest. There are multiple
PC configuration options, enabling
practices of any size to flexibly
accommodate the unit.
This quick-start guide is a simplified set-up
guide for the Henson 9000.
Once the software and literature are
installed please read the full manual before
operating the device.
Product Make: Henson 9000
Product Model: Henson 9000
Medical Device Class I
CE/CB certified and FDA approved
Specifications are subject to change without notice.
www.elektron-healthcare.com
[email protected]
© Elektron Technology UK Ltd.
Accessories it content includes:
Patient response button
Occluder
Dust cover
Mains cable
Dual USB cable
USB flash drive

Product handling
and set-up
Open the box
If the shock label is red,
please inform the
distributor of this fact.
1
2
3
4
1
3
4
Ta e the Henson
9000 out of the
box
Always lift and move the
device from the base.
Setup the
Henson 9000
Connect the dual USB
cable, the patient
response button and the
mains cable to the
Henson 9000.
NOTE: Do not connect the USB cables to the computer
until after you have installed the software.
Switch on the
Henson 9000
Software installation
Install the software before plugging in the
dual USB cable between the Henson 9000
and the computer.
Plug in the USB
cables
Once the software is
installed plug in the dual
USB cable between the
Henson 9000 and the
computer.
Plug in the USB device
you will use for database
backups (if required)
Open the Henson 9000
Options program
Double click the Henson 9000 Options
icon on the desktop.
Wait for the program to detect the
Henson and start up.
Click the Computer tab and check there
is a device listed.
Click the Address tab and fill in the practice address details.
Click the Backup tab and make sure the USB flash drive
letter is selected.
Click the Video tab and ensure there is a message saying
“defaults have been downloaded from the Henson 9000…”
If a built in webcam picture is displayed, select the Henson
camera from the drop-down device list.
Click Save.
2
*System requirements
Microsoft® Windows® 7 or 8.X Professional (32 or 64 bit)
Insert the supplied USB
flash drive
emove all USB devices from
the computer.
Insert the supplied USB flash drive into the computer and
wait for the prompt.
Select Open folder to view files.
Open the folder called Software and double click on the
Software EXE file.
Follow the on screen instructions to install the software.
Open the Henson 9000 software
Double click the Henson 9000 icon on the desktop. (To make
the Henson 9000 software start up automatically when the
computer is started add it to your startup folder)
You will see the Henson 9000 main menu.
5Installation complete
Note: to save records and use the database you will need
to have the free Adobe® eader® software installed. This
can be obtained from the website www.adobe.com
For further information on the Henson 9000 and
other ophthalmic products visit:
www.ele tron-healthcare.com
Contact us for further information, service and
support on info@ele tron-healthcare.com
Further information
