Elettronica Santerno Sinus Penta Series Instructions for use

• 15Q0102B00 •
SINUS PENTA
MULTIFUNCTION AC DRIVE
REGENERATIVE
APPLICATION
Updated on 27/09/2007
R.03
Software Version 1.65x
Elettronica Santerno S.p.A.
Via G. Di Vittorio, 3 - 40020 Casalfiumanese (BO) Italy
Tel. [phone] - Fax [phone]
www.elettronicasanterno.it [email protected]
•This manual is integrant and essential to the product. Carefully read the instructions contained herein as they
provide important hints for use and maintenance safety.
•This device is to be used only for the purposes it has been designed to. Other uses should be considered improper
and dangerous. The manufacturer is not responsible for possible damages caused by improper, erroneous and
irrational uses.
•Elettronica Santerno is responsible for the device in its original setting.
•Any changes to the structure or operating cycle of the device must be performed or authorized by the Engineering
Department of Elettronica Santerno.
•Elettronica Santerno assumes no responsibility for the consequences resulting by the use of non-original spare-
parts.
•Elettronica Santerno reserves the right to make any technical changes to this manual and to the device without prior
notice. If printing errors or similar are detected, the corrections will be included in the new releases of the manual.
•Elettronica Santerno is responsible for the information contained in the original version of the Italian manual.
•The information contained herein is the property of Elettronica Santerno and cannot be reproduced. Elettronica
Santerno enforces its rights on the drawings and catalogues according to the law.
English

REGENERATIVE SINUS PENTA
APPLICATION
2/140
0
1
2
3
4
0. TABLE OF CONTENTS
0. TABLE OF CONTENTS ................................................................................................................ 2
0.1. Figures ......................................................................................................................................4
0.2. Tables .......................................................................................................................................4
1. OVERVIEW ................................................................................................................................. 5
1.1. THE REGENERATIVE APPLICATON ..............................................................................................5
2. INSTALLATION INSTRUCTIONS ................................................................................................. 6
2.1. OVERVIEW.................................................................................................................................6
2.2. DIMENSIONING THE REGENERATIVE DRIVE ...............................................................................9
2.2.1. Light Applications (Overload up to 120%) 380-500Vac Power Supply.................................10
2.2.2. Standard Applications (Overload up to 140%) 380-500Vac Power Supply...........................12
2.2.3. Heavy Applications (Overload up to 175%) 380-500Vac Power Supply...............................14
2.2.4. Strong Applications (Overload up to 200%) 380-500Vac Power Supply ..............................16
2.2.5. Light Applications (Overload up to 120%) 200-240Vac Power Supply.................................18
2.2.6. Standard Applications (Overload up to 140%) 200-240Vac Power Supply...........................19
2.2.7. Heavy Applications (Overload up to 175%) 200-240Vac Power Supply...............................20
2.2.8. Strong Applications (Overload up to 200%) 200-240Vac Power Supply ..............................21
2.2.9. Light Applications (Overload up to 120%) 575-690Vac Power Supply.................................22
2.2.10. Standard Applications (Overload up to 140%) 575-690Vac Power Supply...........................22
2.2.11. Heavy Applications (Overload up to 175%) 575-690Vac Power Supply...............................23
2.2.12. Strong Applications (Overload up to 200%) 575-690Vac POWER SUPPLY...........................23
2.3. SPECIFICATIONS FOR THE REGENERATIVE DRIVE.....................................................................24
2.3.1. 4T Class Regenerative Drive .............................................................................................24
2.3.2. 2T Class Regenerative Drive .............................................................................................26
2.3.3. 5T & 6T Class Regenerative Drive .....................................................................................28
2.4. CHECKING THE REGENERATIVE DRIVE DIMENSIONING...........................................................29
2.5. APPLICATIONS OF THE REGENERATIVE DRIVE ..........................................................................32
2.5.1. Motors Having a Different Supply Voltage than the Mains Supply Voltage ...........................32
2.6. WIRING...................................................................................................................................33
2.6.1. Power Wiring for the Regenerative Drive Up to Size S64 included .......................................33
2.6.2. Power Wiring for the Regenerative Drive - Size S74............................................................34
2.6.3. Signal Wiring for the Regenerative Drive ...........................................................................36
2.7. EXTERNAL COMPONENTS .......................................................................................................37
2.7.1. Power Cable Cross-sections and Electromechanical Components of the Power Circuit .........37
2.7.2. Cross-section of the Power Cables and Size of the Safety Components for 2T Class Drives ..38
2.7.3. UL-Approved Fuses - 2T Class ..........................................................................................40
2.7.4. Cross-section of the Power Cables and Size of the Safety Components for 4T Class Drives ..42
2.7.5. UL-Approved Fuses – 4T Class..........................................................................................44
2.7.6. Power Cable Cross-section and Size of the Safety Components for 5T-6T Class Drives ........46
2.7.7. UL-Approved Fuses – 5T & 6T Classes ..............................................................................47
2.7.8. Regenerative Reactance for 200-240VAC Supply Voltage...................................................48
2.7.9. Regenerative Reactance for 380-480VAC Supply Voltage...................................................49
2.7.10. Regenerative Reactance for 500-690VAC Supply Voltage...................................................50
2.7.11. Filter Reactance for 200-240VAC Supply Voltage ..............................................................51
2.7.12. Filter Reactance for 380-480VAC Supply Voltage ..............................................................52
2.7.13. Filter Reactance for 500-690VAC Supply Voltage ..............................................................53
2.7.14. Regenerative Reactance Ratings ........................................................................................54
2.7.15. Filter Reactance Ratings....................................................................................................55
2.7.16. Interface Panel.................................................................................................................56
2.8. Additional Components for the Braking Unit Application ............................................................65
2.8.1. Isolation Transformer .......................................................................................................65
2.8.2. DC-Bus Diode .................................................................................................................65
2.8.3. Example: Dimensioning the Regenerative Drive as a Braking Unit.......................................65
2.9. Electromagnetic Compatibility...................................................................................................66
2.10. COMMISSIONING...................................................................................................................68

SINUS PENTA REGENERATIVE
APPLICATION
3/140
0
1
2
3
4
2.10.1. Commissioning of the Drive Used as a Regenerative Feeder.......................................................68
2.10.2. Commissioning of the Drive Used as a Regenerative Braking Unit ......................................71
3. PROGRAMMING INSTRUCTIONS ............................................................................................. 74
3.1. MENU TREE .............................................................................................................................74
3.2. MEASURES MENU....................................................................................................................75
3.2.1. Overview.........................................................................................................................75
3.2.2. Menu n.1 – General Measures..........................................................................................76
3.2.3. Menu n.2 – ADE Measures ...............................................................................................80
3.2.4. Menu n.3 – DC Measures.................................................................................................83
3.2.5. Menu n.4 – Digital Inputs .................................................................................................84
3.2.6. Menu n.5 – Outputs .........................................................................................................84
3.2.7. Menu n.6 – Temperatures from PT100 ..............................................................................85
3.2.8. List of the Operating Conditions of the Regenerative Sinus Penta........................................85
3.3. REFERENCE AND REGULATORS MENU.....................................................................................86
3.3.1. Overview.........................................................................................................................86
3.3.2. List of Programmable Parameters P500 to P522 ................................................................87
3.4. ADE REGISTERS MENU.............................................................................................................91
3.4.1. Overview.........................................................................................................................91
3.4.2. List of Programmable Parameters P530 to P540 and I003 .................................................92
3.5. SETTING DC MEASURES MENU................................................................................................97
3.5.1. Overview.........................................................................................................................97
3.5.2. List of Programmable Parameters P545 and P546 .............................................................97
3.6. MAINS MONITOR MENU .........................................................................................................98
3.6.1. Overview.........................................................................................................................98
3.6.2. List of Programmable Parameters P550 to P574 ................................................................98
3.7. ANALOG OUTPUTS MENU ....................................................................................................105
3.7.1. Overview.......................................................................................................................105
3.8. DIGITAL OUTPUTS MENU ......................................................................................................106
3.8.1. Overview.......................................................................................................................106
3.8.2. List of Programmable Parameters P580 and P581 ...........................................................106
3.9. AUXILIARY DIGITAL OUTPUTS MENU .....................................................................................108
3.9.1. Overview.......................................................................................................................108
3.9.2. List of Programmable Parameters P582 to P593 ..............................................................108
3.10. SETTING MEASURES FROM PT100 MENU...............................................................................110
3.10.1. Overview.......................................................................................................................110
3.10.2. List of Programmable Parameters P320 to P327 ..............................................................110
3.11. FIELDBUS MENU....................................................................................................................112
3.11.1. Overview.......................................................................................................................112
3.11.2. List of Programmable Parameters P330 and P331 ...........................................................113
3.11.3. Exchanged Parameters ...................................................................................................114
3.11.4. From the Master to the Sinus Penta .................................................................................114
3.11.5. From the Sinus Penta to the Master .................................................................................117
3.12. MAINS PARAMETERS MENU ...................................................................................................121
3.12.1. Overview.......................................................................................................................121
3.12.2. List of Programmable Parameters C500 to C503.............................................................122
3.13. CONTROL METHOD MENU...................................................................................................124
3.13.1. Overview.......................................................................................................................124
3.14. DIGITAL INPUTS MENU..........................................................................................................125
3.14.1. Overview.......................................................................................................................125
3.14.2. Factory Setting of the Digital Inputs .................................................................................125
3.14.3. ENABLE (Terminal MDI2)................................................................................................126
3.14.4. RESET (Terminal MDI3)...................................................................................................126
3.14.5. List of Programmable Parameters C164 to C166.............................................................127
3.15. RESISTOR BRAKING MENU.....................................................................................................129
3.15.1. Overview.......................................................................................................................129
3.15.2. List of Programmable Parameters C211 and C212..........................................................129

REGENERATIVE SINUS PENTA
APPLICATION
4/140
0
1
2
3
4
3.16. AUTORESET MENU........................................................................................................130
3.16.1. Overview.......................................................................................................................130
3.16.2. List of Programmable Parameters C255 to C261.............................................................130
3.17. EXPANSION BOARD CONFIGURATION MENU.......................................................................132
3.17.1. Overview.......................................................................................................................132
3.17.2. List of Programmable Parameters R021 to R023..............................................................132
3.18. RGN DRIVE ALARMS...............................................................................................................133
3.18.1. Overview.......................................................................................................................133
3.18.2. Alarm Codes .................................................................................................................133
4. SOFTWARE DOWNLOAD FOR APPLICATION PROGRAMMING .............................................. 138
4.1. FIRMWARE UPGRADE.............................................................................................................139
0.1. Figures
Figure 1: Mains-side current obtained when a regenerative drive is used.......................................................7
Figure 2: Block-diagram of the regenerative drive. .......................................................................................8
Figure 3: Wiring diagram for the electromechanical components of the regenerative drive up to Size S64
included............................................................................................................................................33
Figure 4: Wiring diagram for electromechanical components for the regenerative drive, Size S74 included. ..34
Figure 5: Signal wiring diagram for the regenerative drive..........................................................................36
Figure 6: Block-diagram of the interface panel...........................................................................................56
Figure 7: Dimensions and fixing holes of the interface panel.......................................................................57
Figure 8: Menu tree for the regenerative drive............................................................................................74
0.2. Tables
Table 1: Default values of parameters C500 and C501 (electric mains). .....................................................68
Table 2: Codification of Measure M515. ...................................................................................................78
Table 3: Bits of measure M516. ................................................................................................................79
Table 4: Bits of measure M517. ................................................................................................................79
Table 5: Codification of the digital inputs...................................................................................................84
Table 6: Codification of the digital outputs.................................................................................................84
Table 7: Codification of the operating conditions of the Regenerative Sinus Penta........................................85
Table 8: List of parameters P500 to P522. .................................................................................................87
Table 9: List of parameters P530 to P540 and I003....................................................................................92
Table 10: List of parameters P550 to P574. ...............................................................................................98
Table 11: Items allocated to the analog outputs. ......................................................................................105
Table 12: List of parameters P580 and P581. ..........................................................................................106
Table 13: Functions implemented by digital outputs MDO1 and MDO2. ...................................................107
Table 14: List of parameters P582 to P593. .............................................................................................108
Table 15: List of parameters P330 and P331. ..........................................................................................113
Table 16: List of the programmable measures for P330/P331. .................................................................113
Table 17: Operating mode of the motor drive Enable command. .............................................................121
Table 18: List of Parameters C500 to C503.............................................................................................122
Table 19: Factory-setting of the terminal board........................................................................................125
Table 20: Unprogrammable functions. ....................................................................................................125
Table 21: Programmable functions..........................................................................................................125
Table 22: List of parameters C164 to C166.............................................................................................127
Table 23: List of parameters C211 and C212..........................................................................................129
Table 24: List of parameters C255 to C261............................................................................................130
Table 25: List of parameters R021 to R023. .............................................................................................132
Table 26: List of the alarms for the Regenerative Sinus Penta. ...................................................................133

SINUS PENTA REGENERATIVE
APPLICATION
5/140
0
1
2
3
4
1. OVERVIEW
Special software that can be used for particular applications is supplied with the drives of the Sinus Penta
series. The menu tree, the programming mode and navigation mode of the Sinus Penta are used; parameters
or menus will be added/(removed) whether required/(not required) for your application.
This manual covers the wiring diagrams and the parameters relating to the Regenerative application; for any
detail concerning option control boards and parameters common to the Sinus Penta, please refer to the Sinus
Penta’s Installation Instructions and Programming Instructions manuals.
Download of the application files for the standard Penta drive is detailed on the last pages of this manual.
Download, however, is not normally required, because the drive is already factory-set for the Regenerative
application.
1.1. THE REGENERATIVE APPLICATON
The Regenerative Penta drive allows exchanging ingoing-outgoing power with sinusoidal currents (weak
current harmonics) and with a unitary power factor. The Regenerative application allows tuning the DC-bus
voltage: when the Penta is used to power one or multiple inverters for motor control, this allows recovering the
kinetic energy of the connected motor(s) during the braking stage, and delivering energy to the mains (thus
avoiding using braking resistors, which also cause overheating). When the motor drive is powered by the DC-
bus through the regenerative function, motors having greater voltage ratings than the mains voltage can be
controlled by the Penta.
Also, the regenerative drive can be used as a braking unit.

REGENERATIVE SINUS PENTA
APPLICATION
6/140
0
1
2
3
4
2. INSTALLATION INSTRUCTIONS
2.1. OVERVIEW
The drives of the SINUS PENTA series can be used as regenerative feeders.
The Penta becomes a feeder absorbing or delivering sinusoidal current to the grid with a unitary power factor;
it is called a regenerative feeder because a bidirectional power flow can be obtained. The regenerative feeder
has a DC link output which is used for the power supply of one or more Elettronica Santerno inverters through
the DC-bus terminals.
The following benefits can be obtained:
Absorption from the current mains with weak harmonic currents and unitary power factor;
Recovery of the kinetic energy of the connected motor(s) during the braking stage (thus avoiding using braking
resistors, which also cause overheating);
Possibility of controlling connected motors having greater voltage ratings than the mains voltage (see Motors
Having a Different Supply Voltage than the Mains Supply Voltage);
The following pages explain how drives can be connected to the mains; current waveforms and harmonic
currents are also given. As you will see, the Penta used as a regenerative drive allows obtaining great benefits.
NOTE
Current harmonics depend both on mains voltage distortion (the weaker the
distortion, the weaker the current harmonics) and on drive power ratings (rated
power ensures the best harmonic currents percentage).

SINUS PENTA REGENERATIVE
APPLICATION
7/140
0
1
2
3
4
TYPE OF INSTALLATION: Using a regenerative drive
MAINS-SIDE CURRENT: Drive operating at rated current
MAINS-SIDE CURRENT SPECTRUM
Figure 1: Mains-side current obtained when a regenerative drive is used.

REGENERATIVE SINUS PENTA
APPLICATION
8/140
0
1
2
3
4
Figure 2 shows the block-diagram for the connection of a SINUS PENTA used as a regenerative feeder
powering a SINUS PENTA used as a motor controller.
Figure 2: Block-diagram of the regenerative drive.
An inductance filtering PWM voltage from the output terminals of the drive and transforming output current
into sinusoidal current is to be installed between the regenerative drive and the mains.
Using the drive as a regenerative feeder is particularly useful when the motor connected to the drive frequently
operates as a generator (e.g. lifting applications, test benches, etc.). Energy is then delivered to the mains
under a sinusoidal waveform and with a unitary power factor, thus ensuring energy saving and avoiding using
braking resistor units.
NOTE Output power is intended for the supply of one or more SINUS K inverters/PENTA
drives. Any other applications must be authorized by Elettronica Santerno.

SINUS PENTA REGENERATIVE
APPLICATION
9/140
0
1
2
3
4
2.2. DIMENSIONING THE REGENERATIVE DRIVE
Basically, when dimensioning the regenerative drive, the power delivered from the drive used to control the
motor is compared to the power that the drive can deliver when overloaded and when operating in continuous
mode; also, the drive performances are considered. If two identical drives are used (one as a feeder and one
as a motor controller), failures could occur, because the minimum carrier frequency required for the
regenerative application is 5kHz up to S30 included, and 4kHz for other drive sizes.
The application tables are shown below. Based on the motor power and the type of application (light,
standard, heavy, strong), they contain the size of the drive that controls the motor and the size of the
regenerative drive, depending both on the rated motor voltage and the mains voltage.

REGENERATIVE SINUS PENTA
APPLICATION
10/140
0
1
2
3
4
2.2.1. LIGHT APPLICATIONS (OVERLOAD UP TO 120%) 380-
500VAC POWER SUPPLY
Rated Motor Voltage:
380÷415VAC
Rated Motor Voltage:
440÷460VAC
Rated Motor Voltage:
480÷500VAC
SIZE MOTOR
DRIVE
REGENERATIVE
DRIVE
MOTOR
DRIVE
REGENERATIVE
DRIVE
MOTOR
DRIVE
REGENERATIVE
DRIVE
Max.
Applicable
Motor Power
MOTOR
Drive Size
Size of
REGENERATIVE
SINUS PENTA with
380+/-10 %
Power Supply
Max.
Applicable
Motor Power
Size of
MOTOR
SINUS K/
PENTA
Size of
REGENERATIVE
SINUS PENTA with
440+/-10 % Power
Supply
Max.
Applicable
Motor
Power
Size of
MOTOR
SINUS K/
PENTA
Size of
REGENERATIVE
SINUS PENTA with
480+/-10 %
Power Supply
(kW) (HP)
380
+/-10 %
400
+/-10%
(kW) (HP)
(kW)
(HP)
4.5 6 0005 0005 0005 5.5 7.5 0005 0005 6.5 9 0005 0007
5.5 7.5 0007 0007 0007 7.5 10 0007 0009 7.5 10 0007 0009
7.5 10 0009 0009 0009 9.2 12.5 0009 0009 9.2 12.5 0009 0009
7.5 10 0011 0011 0011 9.2 12.5 0011 0011 11 15 0011 0016
S05
7.5 10 0014 0014 0014 9.2 12.5
0014 0014 11 15 0014 0016
11 15 0016 0016 0016 15 20 0016 0016 15 20 0016 0017
15 20 0017 0017 0017 18.5 25 0017 0025 18.5 25 0017 0017
15 20 0020 0020 0020 18.5 25 0020 0025 18.5 25 0020 0020
22 30 0025 0038 0035 22 30 0025 0025 22 30 0025 0025
22 30 0030 0038 0035 22 30 0030 0030 25 35 0030 0030
S10
22 30 0035 0038 0035 22 30 0035 0035 28 38 0035 0038
11 15 0016 0016 0016 15 20 0016 0016 15 20 0016 0017
15 20 0017 0017 0017 18.5 25 0017 0025 18.5 25 0017 0017
15 20 0020 0020 0020 18.5 25 0020 0025 18.5 25 0020 0020
22 30 0025 0034 0025 22 30 0025 0025 22 30 0025 0025
22 30 0030 0034 0030 22 30 0030 0030 25 35 0030 0030
30 40 0034 0034 0034 30 40 0034 0034 37 50 0034 0034
S12
30 40 0036 0036 0036 37 50 0036 0036 37 50 0036 0036
30 40 0038 0038 0038 37 50 0038 0038 45 60 0038 0038
37 50 0040 0040 0040 45 60 0040 0040 50 70 0040 0040
S15
45 60 0049 0049 0049 50 70 0049 0049 55 75 0049 0049
50 70 0060 0067 0060 55 75 0060 0060 65 90 0060 0067
55 75 0067 0067 0067 65 90 0067 0074 75 100 0067 0074
65 90 0074 0074 0074 75 100 0074 0074 85 115 0074 0086
S20
75 100 0086 0113 0086 90 125
0086 0113 90 125 0086 0086
100 135 0113 0113 0113 110 150 0113 0113 132 180 0113 0113
110 150 0129 0162 0129 125 170 0129 0129 140 190 0129 0129
120 165 0150 0179 0162 132 180 0150 0162 150 200 0150 0179
S30
132 180 0162 0179 0179 150
200 0162 0179 175 238 0162 0179
160 220 0179 0179 0179 200 270 0179 0179 220 300 0179 0250
200 270 0200 0312 0312 220 300 0200 0312 250 340 0200 0312
220 300 0216 0312 0312 250 340 0216 0312 260 350 0216 0312
S40
230 315 0250 0312 0312 260
350 0250 0312 280 380 0250 0312

SINUS PENTA REGENERATIVE
APPLICATION
11/140
0
1
2
3
4
280 380 0312 0366 0312 315 430 0312 0312 355 480 0312 0366
315 430 0366 0399 0366 370 500 0366 0457 400 550 0366 0457
S50
355 480 0399 0457 0457 400 550
0399 0457 450 610 0399 0457
400 550 0457 0457 0457 450 610 0457 0457 500 680 0457 0457
S60 450 610 0524 0598 0524 500 680
0524 0524 560 760 0524 0524
500 680 0598 0598 0598 560 760 0598 0598 630 860 0598 0748
560 760 0748 0748 0748 630 860 0748 0748 710 970 0748 0831
S64
710 970 0831 0964 0964 800 1090
0831 0964 900 1230 0831 0964
900 1230 0964 0964 0964 1000 1360 0964 0964 1100 1500 0964 0964
1000 1360 1130 1130 1130 1170 1600 1130 1296 1270 1730 1130 1130
S74
1170 1600 1296 (*) 1296 1340
1830 1296 (*) 1460 1990 1296 (*)
(*) Please contact Elettronica Santerno.

REGENERATIVE SINUS PENTA
APPLICATION
12/140
0
1
2
3
4
2.2.2. STANDARD APPLICATIONS (OVERLOAD UP TO 140%)
380-500VAC POWER SUPPLY
Rated Motor Voltage:
380÷415VAC
Rated Motor Voltage:
440÷460VAC
Rated Motor Voltage:
480÷500VAC
SIZE MOTOR
DRIVE
REGENERATIVE
DRIVE
MOTOR
DRIVE
REGENERATIVE
DRIVE
MOTOR
DRIVE
REGENERATIVE
DRIVE
Max.
Applicable
Motor
Power
Max.
Applicable
Motor
Power
Max.
Applicable
Motor
Power
(kW)
(HP)
Size of
MOTOR
SINUS K/
PENTA
Size of REGENERATIVE
SINUS PENTA with
380+/-10 % Power
Supply
Size of REGENERATIVE
SINUS PENTA with
400+/-10%
Power Supply
(kW) (HP)
Size of
MOTOR
SINUS K/
PENTA
Size of REGENERATIVE
SINUS PENTA with
440+/-10 % Power
Supply
(kW) (HP)
Size of
MOTOR
SINUS K/
PENTA
Size of
REGENERATIVE
SINUS PENTA with
480+/-10 % Power
Supply
4 5.5 0005 0005 0005 4.5
6 0005 0005 5.5 7.5 0005 0005
4.50
6 0007 0007 0007 5.5 7.5 0007 0007 6.5 9 0007 0007
5.50
7.5 0009 0009 0009 7.5 10 0009 0009 7.5 10 0009 0009
7.50
10 0011 0011 0011 9.2 12.5 0011 0011 9.2 12.5 0011 0011
S05
7.5 10 0014 0014 0014 9.2
12.5 0014 0014 11 15 0014 0016
9.2 12.5 0016 0016 0016 11 15 0016 0016 15 20 0016 0016
11 15 0017 0017 0017 11 15 0017 0025 15 20 0017 0017
15 20 0020 0020 0020 15 20 0020 0025 18.5 25 0020 0020
18.5 25 0025 0025 0025 18.5 25 0025 0025 22 30 0025 0025
22 30 0030 0038 0035 22 30 0030 0030 25 35 0030 0030
S10
22 30 0035 0038 0035 25
35 0035 0038 28 38 0035 0038
9.2 12.5 0016 0016 0016 11 15 0016 0016 15 20 0016 0016
11 15 0017 0017 0017 11 15 0017 0025 15 20 0017 0017
15 20 0020 0020 0020 15 20 0020 0025 18.5 25 0020 0020
18.5 25 0025 0025 0025 18.5 25 0025 0025 22 30 0025 0025
22 30 0030 0034 0030 22 30 0030 0030 25 35 0030 0030
25 35 0034 0034 0034 30 40 0034 0034 30 40 0034 0034
S12
30 40 0036 0036 0036 30
40 0036 0036 37 50 0036 0036
25 35 0038 0038 0038 30 40 0038 0038 37 50 0038 0038
30 40 0040 0040 0040 37 50 0040 0040 40 55 0040 0040
S15
37 50 0049 0049 0049 45
60 0049 0049 45 60 0049 0049
45 60 0060 0060 0060 55 75 0060 0060 55 75 0060 0060
55 75 0067 0067 0067 60 80 0067 0067 65 90 0067 0067
65 90 0074 0074 0074 70 95 0074 0074 75 100 0074 0074
S20
75 100 0086 0113 0086 75
100 0086 0086 85 115 0086 0086
90 125 0113 0113 0113 90 125 0113 0113 90 125 0113 0113
100 135 0129 0129 0129 110 150 0129 0129 110 150 0129 0129
110 150 0150 0150 0150 132 180 0150 0150 150 200 0150 0162
S30
132 180 0162 0179 0179 150
200 0162 0179 160 220 0162 0179
150 200 0179 0179 0179 160 220 0179 0179 185 250 0179 0179
160 220 0200 0200 0200 185 250 0200 0200 200 270 0200 0216
200 270 0216 0312 0312 220 300 0216 0312 250 340 0216 0312
S40
220 300 0250 0312 0312 260
350 0250 0312 260 350 0250 0312
250 340 0312 0312 0312 315 430 0312 0312 330 450 0312 0312
280 380 0366 0366 0366 355 480 0366 0399 375 510 0366 0366
S50
315 430 0399 0457 0399 375
510 0399 0457 400 550 0399 0457

SINUS PENTA REGENERATIVE
APPLICATION
13/140
0
1
2
3
4
400 550 0457 0457 0457 450 610 0457 0457 500 680 0457 0457
S60 450 610 0524 0524 0524 500
680 0524 0524 560 770 0524 0524
500 680 0598 0598 0598 560 760 0598 0598 630 860 0598 0598
560 760 0748 0748 0748 630 860 0748 0748 710 970 0748 0748
S64
630 860 0831 0831 0831 780
1060 0831 0831 800 1090 0831 0831
800 1090 0964 0964 0964 900 1230 0964 0964 1000 1360 0964 0964
900 1230 1130 1130 1130 1100 1500 1130 1296 1170 1600 1130 1130
S74
1100 1500 1296 (*) 1296 1240
1690 1296 1296 1340 1830 1296 1296
(*) Please contact Elettronica Santerno.

REGENERATIVE SINUS PENTA
APPLICATION
14/140
0
1
2
3
4
2.2.3. HEAVY APPLICATIONS (OVERLOAD UP TO 175%) 380-
500VAC POWER SUPPLY
Rated Motor Voltage:
380÷415VAC
Rated Motor Voltage:
440÷460VAC
Rated Motor Voltage:
480÷500VAC
SIZE
MOTOR
DRIVE
REGENERATIVE
DRIVE
MOTOR
DRIVE REGENERATIVE DRIVE
MOTOR
DRIVE REGENERATIVE DRIVE
MOTOR
DRIVE
Max.
Applicable
Motor
Power
Size of
MOTOR
SINUS K/
PENTA
Size of
REGENERATIVE SINUS
PENTA with 380+/-
10 % Power Supply
Size of
REGENERATIVE SINUS
PENTA with 400+/-
10% Power Supply
Max.
Applicable
Motor Power
Size of
MOTOR
SINUS K/
PENTA
Size of REGENERATIVE
SINUS PENTA with
440+/-10 % Power
Supply
Max.
Applicable
Motor
Power
Size of
MOTOR
SINUS K/
PENTA
Size of
REGENERATIVE SINUS
PENTA with 480+/-
10 % Power Supply
(kW) (HP) (kW) (HP) (kW) (HP)
3 4 0005 0005 0005 3.7 5 0005 0005 4.5 6 0005 0005
4 5.5 0007 0007 0007 4.5 6 0007 0007 5.5 7.5 0007 0007
4.5 6 0009 0009 0009 5.5 7.5 0009 0009 7.5 10 0009 0009
5.5 7.5 0011 0011 0011 7.5 10 0011 0011 9.2 12.5 0011 0011
S05
7.5 10 0014 0014 0014 9.2 12.5 0014 0014 11 15 0014 0016
9.2 12.5 0016 0016 0016 11 15 0016 0016 12.5 17 0016 0016
9.2 12.5 0017 0017 0017 11 15 0017 0017 12.5 17 0017 0017
11 15 0020 0020 0020 15 20 0020 0020 15 20 0020 0020
15 20 0025 0025 0025 18.5 25 0025 0025 18.5 25 0025 0025
18.5 25 0030 0030 0030 22 30 0030 0030 22 30 0030 0030
S10
22 30 0035 0038 0035 25 35 0035 0038 28 38 0035 0038
9.2 12.5 0016 0016 0016 11 15 0016 0016 12.5 17 0016 0016
9.2 12.5 0017 0017 0017 11 15 0017 0017 12.5 17 0017 0017
11 15 0020 0020 0020 15 20 0020 0020 15 20 0020 0020
15 20 0025 0025 0025 18.5 25 0025 0025 18.5 25 0025 0025
18.5 25 0030 0030 0030 22 30 0030 0030 22 30 0030 0030
22 30 0034 0034 0034 25 35 0034 0034 28 38 0034 0034
S12
25 35 0036 0036 0036 30 40 0036 0036 30 40 0036 0036
25 35 0038 0038 0038 30 40 0038 0038 30 40 0038 0038
25 35 0040 0040 0040 30 40 0040 0040 37 50 0040 0040
S15
30 40 0049 0049 0049 37 50 0049 0049 45 60 0049 0049
37 50 0060 0060 0060 45 60 0060 0060 50 70 0060 0060
45 60 0067 0067 0067 50 70 0067 0067 55 75 0067 0067
50 70 0074 0074 0074 55 75 0074 0074 65 90 0074 0074
S20
55 75 0086 0086 0086 65 90 0086 0086 75 100 0086 0086
75 100 0113 0113 0113 75 100 0113 0113 90 125 0113 0113
80 110 0129 0129 0129 90 125 0129 0129 110 150 0129 0129
90 125 0150 0150 0150 110 150 0150 0150 132 180 0150 0150
S30
110 150 0162 0162 0162 132 180 0162 0162 140 190 0162 0162
120 165 0179 0179 0179 150 200 0179 0179 160 220 0179 0179
132 180 0200 0200 0200 160 220 0200 0200 185 250 0200 0200
160 220 0216 0216 0216 185 250 0216 0216 200 270 0216 0216
S40
185 250 0250 0250 0250 220 300 0250 0312 220 300 0250 0250

SINUS PENTA REGENERATIVE
APPLICATION
15/140
0
1
2
3
4
220 300 0312 0312 0312 260 350 0312 0312 300 400 0312 0312
250 340 0366 0366 0366 300 400 0366 0366 330 450 0366 0366
S50
280 380 0399 0399 0399 330 450 0399 0399 355 480 0399 0399
315 430 0457 0457 0457 370 500 0457 0457 450 610 0457 0457
S60
355 480 0524 0524 0524 450 610 0524 0524 500 680 0524 0524
400 550 0598 0598 0598 500 680 0598 0598 560 760 0598 0598
500 680 0748 0748 0748 560 760 0748 0748 630 860 0748 0748
S64
560 760 0831 0831 0831 630 860 0831 0831 710 970 0831 0831
710 970 0964 0964 0964 800 1090 0964 0964 900 1230 0964 0964
800 1090 1130 1130 1130 900 1230 1130 1130 1000 1360 1130 1130
S74
900 1230 1296 1296 1296 1100 1500 1296 1296 1170 1600 1296 1296

REGENERATIVE SINUS PENTA
APPLICATION
16/140
0
1
2
3
4
2.2.4. STRONG APPLICATIONS (OVERLOAD UP TO 200%) 380-
500VAC POWER SUPPLY
Rated Motor Voltage:
380÷415VAC
Rated Motor Voltage:
440÷460VAC
Rated Motor Voltage:
480÷500VAC
SIZE MOTOR
DRIVE
REGENERATIVE
DRIVE
MOTOR
DRIVE REGENERATIVE DRIVE
MOTOR
DRIVE REGENERATIVE DRIVE
MOTOR
DRIVE
Max.
Applicable
Motor
Power
Size of
MOTOR
SINUS K/
PENTA
Size of REGENERATIVE
SINUS PENTA with
380+/-10 % Power
Supply
Size of REGENERATIVE
SINUS PENTA with
400+/-10% Power
Supply
Max.
Applicable
Motor
Power
Size of
MOTOR
SINUS K/
PENTA
Size of REGENERATIVE
SINUS PENTA with
440+/-10 % Power
Supply
Max.
Applicable
Motor
Power
Size of
MOTOR
SINUS K/
PENTA
Size of REGENERATIVE
SINUS PENTA with
480+/-10 % Power
Supply
(kW) (HP) (kW) (HP) (kW) (HP)
2.2 3 0005 0005 0005 3 4 0005 0005 3.7 5 0005 0005
3 4 0007 0007 0007 3.7 5 0007 0007 4.5 6 0007 0007
4 5.5 0009 0009 0009 4.5 6 0009 0009 5.5 7.5 0009 0009
4.5 6 0011 0011 0011 5.5 7.5 0011 0011 7.5 10 0011 0011
S05
5.5 7.5 0014 0014 0014 7.5
10 0014 0014 9.2 12.5 0014 0014
7.5 10 0016 0016 0016 9.2 12.5 0016 0016 11 15 0016 0016
7.5 10 0017 0017 0017 9.2 12.5 0017 0017 12.5 17 0017 0017
9.2 12.5 0020 0020 0020 11 15 0020 0020 12.5 17 0020 0020
11 15 0025 0025 0025 15 20 0025 0025 15 20 0025 0025
15 20 0030 0030 0030 18.5 25 0030 0030 18.5 25 0030 0030
S10
18.5
25 0035 0035 0035 22 30 0035 0035 28 38 0035 0035
7.5 10 0016 0016 0016 9.2 12.5 0016 0016 11 15 0016 0016
7.5 10 0017 0017 0017 9.2 12.5 0017 0017 12.5 17 0017 0017
9.2 12.5 0020 0020 0020 11 15 0020 0020 12.5 17 0020 0020
11 15 0025 0025 0025 15 20 0025 0025 15 20 0025 0025
15 20 0030 0030 0030 18.5 25 0030 0030 18.5 25 0030 0030
18.5 25 0034 0034 0034 22 30 0034 0034 22 30 0034 0034
S12
22 30 0036 0036 0036 25 35 0036 0036 28 38 0036 0036
22 30 0038 0038 0038 25 35 0038 0038 28 38 0038 0038
22 30 0040 0040 0040 25 35 0040 0040 30 40 0040 0040
S15
25 35 0049 0049 0049 30 40 0049 0049 37 50 0049 0049
30 40 0060 0060 0060 37 50 0060 0060 45 60 0060 0060
32 45 0067 0067 0067 40 55 0067 0067 50 70 0067 0067
37 50 0074 0074 0074 45 60 0074 0074 55 75 0074 0074
S20
45 60 0086 0086 0086 55 75 0086 0086 65 90 0086 0086
55 75 0113 0113 0113 65 88 0113 0113 75 100 0113 0113
65 90 0129 0129 0129 75 100 0129 0129 85 115 0129 0129
75 100 0150 0150 0150 90 125 0150 0150 90 125 0150 0150
S30
90 125 0162 0162 0162 110
150 0162 0162 110 150 0162 0162
100 135 0179 0179 0179 120 165 0179 0179 132 180 0179 0179
110 150 0200 0200 0200 132 180 0200 0200 150 200 0200 0200
120 165 0216 0216 0216 150 200 0216 0216 160 220 0216 0216
S40
132 180 0250 0250 0250 185
250 0250 0250 200 270 0250 0250

SINUS PENTA REGENERATIVE
APPLICATION
17/140
0
1
2
3
4
185 250 0312 0312 0312 220 300 0312 0312 250 340 0312 0312
200 270 0366 0366 0366 250 340 0366 0366 260 350 0366 0366
S50
220 300 0399 0399 0399 260
350 0399 0399 300 400 0399 0399
280 380 0457 0457 0457 330 450 0457 0457 375 510 0457 0457
S60 315 430 0524 0524 0524 375
510 0524 0524 400 550 0524 0524
355 480 0598 0598 0598 400 550 0598 0598 450 610 0598 0598
400 550 0748 0748 0748 500 680 0748 0748 560 760 0748 0748
S64
450 610 0831 0831 0831 560
760 0831 0831 630 860 0831 0831
560 770 0964 0964 0964 710 970 0964 0964 800 1090 0964 0964
710 970 1130 1130 1130 800 1090 1130 1130 900 1230 1130 1130
S74
800 1090
1296 1296 1296 900 1230 1296 1296 1000 1360 1296 1296

REGENERATIVE SINUS PENTA
APPLICATION
18/140
0
1
2
3
4
2.2.5. LIGHT APPLICATIONS (OVERLOAD UP TO 120%) 200-
240VAC POWER SUPPLY
Rated Motor Voltage: 200÷240VAC
SIZE MOTOR
DRIVE
REGENERATIVE
DRIVE
Max. Applicable Motor Power
(kW) (HP)
Size of MOTOR SINUS
K/PENTA
Size of REGENERATIVE SINUS
PENTA with 220+/-10 %
Power Supply
Size of REGENERATIVE
SINUS PENTA with 230+/-
10 % Power Supply
3 4 0007 0007 0007
3.7 5 0008 0008 0008
4 5.5 0010 0010 0010
4.5 6 0013 0013 0013
5.5 7.5 0015 0015 0015
7.5 10 0016 0016 0016
S05
9.2 12.5 0020 0020 0020
7.5 10 0016 0016 0016
9.2 13 0017 0025 0017
9.2 12.5 0020 0025 0020
12.5 17 0025 0038 0038
12.5 17 0030 0038 0038
S10
12.5 17 0035 0038 0038
11 15 0023 0023 0023
16 20 0033 0033 0033
S12
18.5 25 0037 0037 0037
18.5 25 0038 0038 0038
22 30 0040 0049 0040
S15
25 35 0049 0060 0060
28 38 0060 0067 0060
30 40 0067 0067 0067
37 50 0074 0074 0074
S20
45 60 0086 0113 0113
55 75 0113 0113 0113
65 90 0129 0129 0129
70 95 0150 0179 0150
S30
75 100 0162 0179 0179
90 125 0179 0179 0179
110 150 0200 0312 0200
120 165 0216 0312 0312
S40
132 180 0250 0312 0312
160 220 0312 0366 0312
185 250 0366 0399 0366
S50
200 270 0399 0457 0457
250 340 0457 0524 0524
S60 260 350 0524 0598 0524
300 400 0598 0598 0598
330 450 0748 0831 0748
S64
400 550 0831 0964 0964
500 680 0964 0964 0964
560 770 1130 1296 1130
S74
630 860 1296 (*) 1296
(*) Please contact Elettronica Santerno.

SINUS PENTA REGENERATIVE
APPLICATION
19/140
0
1
2
3
4
2.2.6. STANDARD APPLICATIONS (OVERLOAD UP TO 140%)
200-240VAC POWER SUPPLY
Rated Motor Voltage: 200÷240VAC
SIZE MOTOR DRIVE REGENERATIVE DRIVE
Max. Applicable Motor Power
(kW) (HP)
Size of MOTOR SINUS
K/PENTA
Size of REGENERATIVE SINUS
PENTA with 220+/-10 %
Power Supply
Size of REGENERATIVE
SINUS PENTA with 230+/-
10 % Power Supply
3 4 0007 0007 0007
3.7 5 0008 0008 0008
4 5.5 0010 0010 0010
4.5 6 0013 0013 0013
5.5 7.5 0015 0015 0015
7.5 10 0016 0016 0016
S05
9.2 12.5 0020 0020 0020
5.5 7.5 0016 0016 0016
7.5 10 0017 0017 0017
9.2 12.5 0020 0025 0020
11 15 0025 0025 0025
12.5 17 0030 0038 0035
S10
12.5 17 0035 0038 0035
9.2 12.5 0023 0023 0023
11 15 0033 0033 0033
S12
15 20 0037 0037 0037
15 20 0038 0038 0038
18.5 25 0040 0040 0040
S15
22 30 0049 0049 0049
25 35 0060 0060 0060
30 40 0067 0067 0067
37 50 0074 0074 0074
S20
40 55 0086 0086 0086
45 60 0113 0113 0113
55 75 0129 0129 0129
65 90 0150 0179 0150
S30
75 100 0162 0179 0179
80 110 0179 0179 0179
90 125 0200 0200 0200
110 150 0216 0312 0312
S40
132 180 0250 0312 0312
150 200 0312 0312 0312
160 220 0366 0366 0366
S50
185 250 0399 0457 0457
220 300 0457 0457 0457
S60 260 350 0524 0524 0524
300 400 0598 0748 0598
330 450 0748 0831 0748
S64
400 550 0831 0964 0964
450 620 0964 0964 0964
560 770 1130 1296 1130
S74
630 860 1296 (*) 1296
(*) Please contact Elettronica Santerno.

REGENERATIVE SINUS PENTA
APPLICATION
20/140
0
1
2
3
4
2.2.7. HEAVY APPLICATIONS (OVERLOAD UP TO 175%) 200-
240VAC POWER SUPPLY
Rated Motor Voltage: 200÷240VAC
SIZE MOTOR DRIVE REGENERATIVE DRIVE
Max. Applicable Motor Power
(kW) (HP)
Size of MOTOR SINUS
K/PENTA
Size of REGENERATIVE SINUS
PENTA with 220+/-10 %
Power Supply
Size of REGENERATIVE
SINUS PENTA with 230+/-
10 % Power Supply
1.8 2.5 0007 0007 0007
2.2 3 0008 0008 0008
3 4 0010 0010 0010
3.7 5 0013 0013 0013
4 5.5 0015 0015 0015
4.5 6 0016 0016 0016
S05
5.5 7.5 0020 0020 0020
5.5 7.5 0016 0016 0016
5.5 7.5 0017 0017 0017
7.5 10 0020 0020 0020
9.2 12.5 0025 0025 0025
11 15 0030 0030 0030
S10
12.5 17 0035 0035 0035
7.5 10 0023 0023 0023
11 15 0033 0033 0033
S12
15 20 0037 0037 0037
15 20 0038 0038 0038
15 20 0040 0040 0040
S15
18.5 25 0049 0049 0049
22 30 0060 0060 0060
25 35 0067 0067 0067
30 40 0074 0074 0074
S20
32 45 0086 0086 0086
45 60 0113 0113 0113
50 70 0129 0129 0129
55 75 0150 0150 0150
S30
65 90 0162 0179 0162
75 100 0179 0179 0179
80 110 0200 0200 0200
90 125 0216 0216 0216
S40
110 135 0250 0312 0312
132 180 0312 0312 0312
150 200 0366 0366 0366
S50
160 220 0399 0399 0399
200 270 0457 0457 0457
S60 220 300 0524 0524 0524
250 340 0598 0598 0598
280 380 0748 0748 0748
S64
330 450 0831 0831 0831
400 550 0964 0964 0964
450 620 1130 1130 1130
S74
560 770 1296 1296 1296
