Elite Security Products Enterview 5 User manual

VIDEO DOOR ENTRY SYSTEM INSTRUCTIONS
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 1

2
Table of contents
Enterview 5 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Wiring Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 Door Wiring Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Maximum Wiring Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Additional Keypad and Magnetic Lock Wiring . . . . . . . . . . . . . . . . . . . . . . . . . 7
Additional Keypad and Yale-release Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Keypad Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Technical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Additional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 2

3
1
2
3
1 3 2 4
1 3 2 4
2
3
1
2
3
1
2
3
Enterview 5 Overview
I4 Handsets maximum per-system
I2 Audio-Only handsets maximum per-system
IEach handset requires supplied PSU (1 PSU per handset required)
IKeypad Camera requires suppIied PSU
IStandard Camera requires EVBPS for door release facility
IFor a voltage-free contact: Keypad Camera requires a12VDC relay (not supplied)
CAT5e cable specified for maximum distances
I100 Meters maximum distance between outdoor station and furthest handset
I10 Meters maximum distance between handset and supplied PSU - Note: 2 pairs of
CAT5e must be used to achieve this distance
1 – Camera
2 – Speaker
3 – Call Button
1 – Opens Camera Channel
2 – Door Release
3 – Call Transfer
4 – Opens 2-way Audio
EVH5C-HF
Keypad Camera
Standard Camera
EVH5
EVH5AOEVHF10B / EVHF10W
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 3

AC240 AC240
Wiring Configuration
Standard Camera
Keypad Camera
See additional wiring instructions for Keypad
4
LOCK
LOCK
AC240 AC240
AC240 Keypad PSU provided
1
2
3
4
5
6
Handset PSUs
provided
Handset PSUs
provided
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 4

NOTE:
J1 AND J2 – DO NOT REMOVE
J3 – ONLY REMOVE FOR MULTIWAY
OUTDOOR STATION CONNECTION
5
LOCK
1
2
3
4
5
6
LOCK
AC240
AC240
Keypad PSU
provided
See additional wiring instructions for keypad
AC240 AC240
Handset PSUs
provided
Handset Connections
2 Door Wiring Configuration
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 5

6
Maximum
Wiring
Configuration
AC240 AC240 AC240 AC240 AC240
AC240
LOCK
See additional wiring instructions for keypad
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 6

7
Additional Keypad and Magnetic Lock Wiring
EGR Ov COM
N.C
EXIT
BUTTON
EMERGENCY
BREAK
GLASS
AC240
Keypad PSU provided
*For a voltage-free contact: Keypad requires
and additional 12VDC relay (not supplied)
Back of Keypad camera
–
+
MAGLOCK
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 7

8
Additional Keypad and Yale-release Wiring
EGR Ov COM
N.O
EXIT
BUTTON
AC240
Keypad PSU provided
*For a voltage-free contact: Keypad requires
and additional 12VDC relay (not supplied)
Back of Keypad camera
–
+
Yale Release
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 8

9
Keypad Commands
Default master code: 1234
Entering Programming mode
1 Press * then 4 digit master code
2 If successful three tones will sound and the LED will flash
Adding user codes
1 Enter programming mode
2 lnput the code group O1-31 for normal operation, 32-40 for latching mode.
3 Enter the 4 digit code, if successful three tones sound if not 2 tones sound.
4 Press* to exit
Deleting a user code
1 Enter programming mode
2 Enter group code O1-40
3 Press # to delete code
4 If successful three tones will sound
5 Press * to exit
Deleting a code from an unknown group
1 Enter programming mode
2 Press # two tones will sound
3 lnput 4 digit code to be deleted
4 Three tones will sound if successful
5 Press * to exit
Deleting all codes
1 Enter programming mode
2 Press # two tones will sound
3 Press # again to hear a further two tones
4 Press # seven times to default all codes and settings (the master code will remain)
5 The system will resume after five seconds
Changing the master code
1 Down powerthe unit
2 Hold * and power up the unit, a long tone will sound
3 When the tone stops, a short tone will sound and input the new 4 digit
programming code
Set the lock time
1 Enter programming
2 Enter O0
3 Enter the lock/delay operation time (O1-99 seconds)
4 Press * to exit
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 9

10
Installation Guide
EVH5
EVH5C
EVH5C-HF / EVHF10W / EVHF10B
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 10

11
Installation Guide
EV5 CAM
EV5 CCAM
EV5KPCAM
EV5CKPCAM
*Recommended installation height 150cm
Enterview 5 Manual_Layout 2 09/10/2012 14:53 Page 11

Elite Security Products
Unit 7, Target Park, Shawbank Rd
Lakeside, Redditch B98 8YN
Telephone: [phone]
email: inf[email protected]om
Technical Specication
Additional Accessories
EV-BPS – 12VDC 2 amp Multi output boxed power supply
EV-EBG – Emergency break glass
EV-EXIT – Push to exit button
EV-ML-250 – Electromagnetic lock
Enterview 5
Power 14.5 DC
Video Output 1-1VP-P 750hm B/W PAL
Operating Temp. -10/55ºC
Consumption 800ma
Dimensions (mm) 205x220x50
Enterview 5C
Power 14.5 DC
Video Output 1-1VP 750hm PAL
Operating Temp. -10/55ºC
Consumption 800ma
Dimensions (mm) 205x220x50
Enterview 5C-HF
Power 14.5 DC
Video Output 1-1VP 750hm PAL
Operating Temp. -10/55ºC
Consumption 800ma
Dimensions (mm) 240x175x38
EVHF10B / EVHF10W
Power 14.5 DC
Video Output 1-1VP 750hm PAL
Operating Temp. -10/55ºC
Consumption 800ma
Dimensions (mm) 340x210x38
Enterview 5 CAM
Power 14.5 DC
Video Output 1-1VP-P 750hm B/W PAL
Min. Illumination 1 Lux
Operating Temp. -10/55ºC
Consumption 150ma
Dimensions (mm) 55x130x40
Enterview 5 C-CAM
Power 14.5 DC
Video Output 1-1VP-P 750hm PAL
Min. Illumination 1 Lux
Operating Temp. -10/55ºC
Consumption 150ma
Dimensions (mm) 55x130x40
Enterview 5 KP
Power 14.5 DC
Video Output 1-1VP-P 750hm B/W PAL
Min. Illumination 1 Lux
Operating Temp. -10/55ºC
Consumption 150ma
Dimensions (mm) 75x190x45
Enterview 5 CKP
Power 14.5 DC
Video Output 1-1VP-P 750hm PAL
Min. Illumination 1 Lux
Operating Temp. -10/55ºC
Consumption 150ma
Dimensions (mm) 75x190x45
