Elkay EZH2O Refrigerated Surface
Mount Bottle Filling Station(s)
series EZ8WS & LZ8WS
USE AND CARE GUIDE

EZ8WSLSMC_1G EZ8WSSSMC_1G LZ8WSLSMC_1G LZ8WSSSMC_1G
[phone] Elkay Manufacturing Company
1000006140 (Rev. A - 03/21)
Page 13
Cooler Parts List
ITEM
NO.
PART NO. DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
-
28551C
36208C
*36322C
0000000238
55996C
56092C
66703C
98773C
98775C
98776C
98777C
98778C
28525C
28528C
2000000075
2000000076
1000006133
See Filter
Table
Hanger Bracket
Power Cord
Compressor Serv. Pak EMIS70HHR
Kit - Electricals /OL/Relay/Cvr
Strainer (See "General Instructions")
Tubing - Poly (Cut To Length)
Drier
Kit - Cold Control/Screws
Kit - Fan Motor Assy/Blade/Motor/Shroud/Nut
Kit - Condenser/Drier
Kit - Compr Mtg Hdwe/Grommets/Clips Studs
Kit - Heat Exchanger/Drier
Panel - Right Rear
Panel - Left Rear
Kit - Basin Cover
Kit - Basin Assembly
Panel - Front Cover
Water Filter Kit (When Provided)
*Replace With Same Compressor Used in Original Assembly.
Note: All correspondence pertaining to any of the above
components for repair parts MUST include Model
No. and Serial No., name and part number of
replacement part.
Bottle Filler Parts List
ITEM
NO.
PART NO. DESCRIPTION
18
19
20
21
22
98543C
98544C
1000004573
98546C
98547C
Kit - Electrical Package
Kit - IR Sensor
Kit - Solenoid Valve Replacement
Kit - Aerator Replacement
Kit - Top Cover Replacement
