Elkay SC1515 Series User manual

GENERAL
High quality single bowl sink is seamlessly formed of #18
gauge brass, copper, or type 304 (18-8) nickel bearing stainless
steel material. Specialty Collection brass or copper sinks are
made from genuine solid, uncoated material and will naturally
tarnish. Self-rimming.
SC1515BH brass with hammered mirror finish
SC1515BM brass with mirror finish
SC1515BS brass with satin finish
SC1515CH copper with hammered mirror finish
SC1515CM copper with mirror finish
SC1515CS copper with satin finish
SC1515SH stainless steel with hammered mirror finish
SC1515SM stainless steel with mirror finish
DESIGN FEATURES
Bowl Depth: 6-1/2".
Coved Corners: 3" vertical and horizontal radii.
Underside: Sound deadening pads on sides.
Fastening Method: Brass or copper sinks come complete with
“J” channel type with the appropriate number of screws and
clamps to provide a secure installation. Stainless steel sinks
come complete with “U” channel type with the appropriate
number of screws and clamps to provide a secure installation.
OTHER
Drain Opening: 2".
Brass and copper sink models furnished complete with match-
ing drain and basket strainer.
NOTE: Unless otherwise specified, sink is furnished with 2
faucet holes as shown.
Model SC1515
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice. This specification describes an Elkay product with design, quality and functional benefits to the user. When making a comparison of other producers’ offerings, be certain these features are not
overlooked.
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
“J” Channel Type Installation Profile
for Copper and Brass Sinks
COUNTERTOP
SINK
CLAMP
PLASTIC
PAD
SEALER
“U”Channel Type Installation Profile
for Stainless Steel Sinks
COUNTERTOP
SINK
SEALER
SEE OTHER SIDE FOR PRODUCT DIMENSIONS.
Elkay 2222 Camden Court
Oak Brook, IL 60523 Printed in U.S.A. ©2005 Elkay
(Rev. 1/05) 1-168B
www.elkayusa.com
Elkay Specialty Collection™Drop-In Sinks
Model SC1515 Series
®
SPECIFICATIONS

4"
15"
3-1/2"
10"
3" R
12"
15"
6-1/2"
3" R
Model SC1515
HOLE DRILLING
CONFIGURATIONS
4"
4" 4"
1
2
3
SINK DIMENSIONS (INCHES)*
*Length is left to right. Width is front to back.
Cutout in No. of
Countertop 13/8" Dia.
(13/8" Radius Faucet Minimum Ship.
Model Overall Inside Bowl Corners) Holes Cabinet Wt.
Number L W L W D L W 4" Center Size Lbs.
SC1515BH 15 15 12 10 61⁄2143⁄8143⁄81, 2 or 3 18 9
SC1515BM 15 15 12 10 61⁄2143⁄8143⁄81, 2 or 3 18 9
SC1515BS 15 15 12 10 61⁄2143⁄8143⁄81, 2 or 3 18 9
SC1515CH 15 15 12 10 61⁄2143⁄8143⁄81, 2 or 3 18 9
SC1515CM 15 15 12 10 61⁄2143⁄8143⁄81, 2 or 3 18 9
SC1515CS 15 15 12 10 61⁄2143⁄8143⁄81, 2 or 3 18 9
SC1515SH 15 15 12 10 61⁄2143⁄8143⁄81, 2 or 3 18 8
SC1515SM 15 15 12 10 61⁄2143⁄8143⁄81, 2 or 3 18 8
Elkay 2222 Camden Court
Oak Brook, IL 60523
www.elkayusa.com
Printed in U.S.A.
©2005 Elkay
1-168B (Rev. 1/05)
Elkay Specialty Collection™Drop-In Sinks
Model SC1515 Series
®
SPECIFICATIONS
