Elko Rf touch-b User manual

WIRELESS TOUCH

CONTROL UNIT

USER'S MANUAL

RF Touch user manual

We want to thank you for your purchase of the RF Touch control unit, which is an element of

wireless RF Control system.

RF Touch allows: you to control many devices trough touch screen

- heating control

- dimming lights

- switching of electrical appliances and equipment

- blinds

- a combination of detectors

- function timers

- Group control of electrical equipment

everything with clear visualization

wireless communication without the need for cabling

RF Touch user manual

Before you start

The instruction manual is intended for installation and use of the equipment. Instructions are always included in the product packaging.

Installation and connection can only make personnel with appropriate qualifications, in compliance with all applicable laws, who are

perfectly familiar with this instructions and functions. Trouble free function is also dependent on transportation, storage and handling.

In case of any signs of damage, deformation, malfunction or missing parts, do not install this product and return it to the seller.

Product and its parts must be at the end of its lifetime handled as electronic waste. Before installation, make sure that all wires, connected

parts or terminals are not live. During the installation and maintenance is necessary to follow safety regulations, standards, guidelines

and special provisions for working with electrical equipment.

Contents:

Before you start .......................

Overview of wireless devices ...

Characteristics of RF Touch .....

Technical specications ...........

Installation of RF-Touch W .......

RF Touch Installation-B ............

Description of Control icons ....

Basic Steps ...............................

Settings

- Default setting .........................

- Menu(creating and naming) ...

- Programming ...........................

- Assign a new receivers .......

- Assigned receiver ...............

- Detectors ............................

- Quick Control .....................

- Display .....................................

- Other ........................................

Control

- Temperature regulation ..........

- Switching .................................

- Dimming ..................................

- Blinds .......................................

- Detectors .................................

- Quick control............................

What to do if ............................

Installation Form .....................

JA-80P

JA-81M

JA-82M

Overview of wireless RF Control devices

RFWB-20/G

2-channel wireless

switch in the design

LOGUS90

RFWB-40/G

4-channel Wireless

switch in the design

LOGUS90

RFJA-12B/230V

blind actuator

2 x 8A switching

relay protection

230V AC

RFJA-12B/24V DC

blind actuator

contactless switching

12-24V DC

RFDAC-71B

actuator with analog

output 0 (1) - 10 V

1 x switch contact 16 A

7 functions, 230V AC

Thermo-control

of heating valves

supplied on request

with the product RFDAC-71B

Dimmable ballast

for dimming of uorescent

lamps

supplied on request

with the product RFDAC-71B

RF KEY

4-channel remote

controller - key pendant

RFIM-20B

universal transmitter module

under the switch or button

wall box installation

RFIM-40B

universal transmitter module

under the switch or button

wall box installation

RFSG-1M

Transmitting module

1-module

230 V AC

RF Touch-W

for surface mounting

100 - 230V AC or

adapter (external)

12 V DC

RF Touch-B

for mounting

in the installation

box

100 - 230V AC

All actuators of the RF Control

System can be controlled by

wireless central unit and all

transmitters of the system

simultaneously.

DETECTORSANALOGUE ACTUATOR

RF Control system CENTRAL WIRELESS UNIT

TRANSMITTERS BLIND ACTUATORS

RF Pilot

remote controller,

colours: white,

anthracite

CONTROLLER

Overview of wireless RF Control devices

RFSA-11B

single channel

single function

switching actuator

1 x switching

contact 16 A

230V AC

RFSA-61B

single channel

multifunction

switching actuator

1 x switching

contact 16A

230V AC

RFSAI-61B

single-channel

multi-function

switching actuator

with option of

connecting an

external wired

controller

RFSA-62B

2 channel

multifunction

switching actuator

2 x 8A switching

contact

6 functions

230V AC

RFUS-11

single-channel

single-function

switching actuator

1 x switching 16A

230V AC,

protection IP65

RFUS-61

single-channel

multi-function

switching actuator

1 x switching 16A

230V AC,

protection IP65

RFSA-61M

single channel

Multifunction

switching actuator

1x changeover

contact 16 A

6 functions

230V AC

RFSC-11

RFSC-11 single-

channel, single-

function switched

socket

1 x switching 16A

230V AC

RFSA-66M

six-channel

Multifunction

switching actuator

3 x 8 AND NO

3 x changeover

contact 8A

6 functions 230V AC

RFSC-61

single-channel,

multifunction

switched socket

6 functions

1 x switching 16A

230V AC

Angle antenna

for plastic

switchboards

supplied as standard

for RFSA-61M,

FSA-66M, RFSG-1M

Angle Antenna

for metal

switchboard

can be ordered for

RFSA-61M,

RFSA-66M, RFSG-1M

SWITCHING ACTUATORS

RFSTI-11B

wireless switching actuator

with temperature sensor

in design to installation box,

230V AC

RFSTI-11/G

wireless switching actuator

with temperature sensor

with manual

control buttons directly

on the unit, 230V AC

RFTI-10B

wireless temperature sensor

1 x CR 2477 3V battery

RFTC-10/G

digital temperature

controller

2 x 1.5V AAA batteries

TEMPERATURE ACTUATOR

Overview of wireless RF Control devices

RFDA-11B

single function

dimming actuator

1 light scene,

function OFF, 230V AC

RFDSC-11

single-function dimmed

socket

1 lighting scene

function OFF, 230V AC

RFDEL-71B

multifunction dimming

actuator

7 functions, 230 V AC /

250VA

Dimmed load: R, L, C,

LED, ESL

RFDA-73M/RGB

used to dim LED strips and

RGB LED strips, possible

other LED loads

RFDA-71B

multifunctional dimming actuator

7 functions,

AC 230V / 250V

RFDSC-71

multifunction dimmed socket

7 functions,

230 V AC / 250VA

DIMMING ACTUATORS

RFATV-1

measures the temperature in

the given zone and provides

wireless control of the radiator

(heater) valve

Characteristics of RF Touch

Control Unit of the wireless system RF Control - RF Touch provides intelligent control of the RF units.

It can be used for:

Central control of all units from one place

Complete overview (visualization) of the current status of units (appliances / equipment)

Features:

sends command to temperature, switching, dimming and shutter actuators

accepts commands from the transmitters, actuators, temperature sensors and detectors

processing programs for heating and regulation

Design:

RF Touch-B ts in the round installation box with a supply voltage of 100 - 230 V AC

RF Touch-W for surface mounting with power supply from the back side: 100 - 230 V AC or from the side (via jack):

12 V DC

3.5 inch color touch screen - no mechanical buttons

RF Touch frames in the base plastic (white, black) or luxurious design Logus90 (glass, metal)

Color of the interframes - white, ivory, ice, mother of pearl, aluminum, silver

Colors of the boxes (only for RF touch-W) - white, ivory, dark gray, light gray

Backup time in case of power failure is 48 hours

40 actuators and 30 OASIS detectors can be assigned to each RF Touch unit

RF Touch can be combined with units of RF Control marked as Oasis & Touch Compatible

Technical parameters

RF Touch-B RF Touch-W

Connection

push-in

screwless terminal

push-in or jack

2.1 mm

Max. cross section of wires: max. 2.5 mm2/ 1.5 mm2with socket

Operating conditions

Operating temperature: 0 ... +50°C

Storage temperature: - 20 ... +70°C

Protection: IP 20

Overvoltage category: III.

Pollution degree: 2

Operating position: arbitrary

Installation: installatin a box wall box installation

Dimensions: 94 x 94 x 12 mm 94 x 94 x 24 mm

Weight **: 127 g 175 g

Standards: EN 60730-1

* adapter is included for RF Touch-W

** weight with plastic frame

Technical parameters

RF Touch-B RF Touch-W

Display

Type: color TFT LCD

Resolution: 320 x 240 pixels / 262,144 colors

Aspect ratio: 3 : 4

Visible area: 52.5 x 70 mm

Backlight: active (white LED)

Touch screen: resistive 4-wire

Display: 3.5”

Control: Touch sensitive

Power supply

Voltage /

specic current: 100 - 230 V AC

from the back side

100 - 230 V AC

from the side 12 DC *

Power consumption: max. 5 W

Power supply connector: A1 - A2

Control

Range up to: 100 m

Minimal range

RF Touch – actuator: 1 m

Frequency: 868 MHz

Technical specifications

100 - 230V AC

RF Touch-W

adapter included with RFTouch-W

POWER SUPPLY OVER ADAPTERPOWER SUPPLY OVER TERMINALS

FITTING ON THE SURFACE

AC 230V

RF Touch-B

FITTING TO THE INSTALLATION BOXPOWER SUPPLY OVER TERMINALS

abc

A/a

a/1

0-10V

Description of Control Icons

RF Touch version Information

and number of assigned units

settings

back to the home screen

step back

delete

name/adressof the actor(s)

Basic

add

edit/remove

scroll up

scroll down

conrm

Setup Menu

yes/selected

no/not selected

conrm

dot

letters

small/capital letters

space

switch - the letters / numbers

Temperature regulation

Switching

Dimming

Blinds

Detectors

Quick kontrol

Main menu

erase previous

Keyboard

temperature

Switching

impuls

button

time function

- delayed switch on

- delayed switch o

Heating

switch ON

switch OFF

switch ON

switch OFF

dimming

light inclination

light declination

Dimming

lower blinds

rise blinds

Blinds

conrm

regulation





 

Basic Steps for Successful Programming

Keep in mind that the radio signal range of RF installation

depends ON building construction, materials and placing of all

units.

1st Step – Placing of the RF Touch and RF units

- device name that you want to manage (to create a menu)

- the names of units (for the correct classification of the

group, for example: RFSA-61B)- addresses of units (to

identify the actuator, for example: 577515)

Installation form can be found at the end of this manual.

2nd Step - Fill Installation Form

Name

Adress

Create a list of names of the controlled device in the

Settings / Menu (create name).

3nd Step - Set menus (create names)

Programming of the RF units with RF Touch is carried out in

the Settings / Programming menu.

4rd Step – Programming

brick wall

60-90 %

Wooden structures

with plasterboard

plates

80-95 %

reinforced concrete

20-60 %

metal plates

0-10 %

standard glass

80-90 %

E.g. RFSA-61B

E.g. 577515

Transmission of radio-frequency signals through various materials.

fig. 1

fi 1

fig

. 1

fig. 4

fig. 6

fi 6

fig. 6

fig. 7

fig. 8

fi 8

fig. 8

Settings (Fig.7-8):

Date and Time

automatic

transition between

winter / summer

time (for time

Zone GTM +01:00)

Format settings

hours (12h / 24h

mode)

To save Settings

press OK .

Date and time

SETUP

Selection of required

Language - Figure 6.

Save setting by

pressing OK .

Language

The settings menu can be opened by touch in the upper

right corner screen on the symbol

and insertion of

password (it´s setting from production – 1111) (g. 4-6),

which you can change

everywhen.

Main Menu / Settings

When the RF Touch is switched on for the rst time, you will be automatically redirected to the display calib-

ration screen. Touch screen can be controlled by the light touch (of about0.5-1s) in the desired location. On the

screen (Fig. 1) then appears cross in each corner of the screen, which need to be pressed twice. This will calibrate

the device. The display then shows the RF logo icon and then touch icon signalizing scanning of the actuators.

Initial setup

date

time (touch in the upper right corner of the display will switch between analog

- digital clocks (Figure 2 - Figure 3)

display at the bottom of the screen is customable, eg: heating mode, a often used device ...

Touch the clock area to enter the Main menu. If you want to get to the main menu from

sleep mode, you need to touch the screen anywhere.

Content of the main screen

fig. 2

fi 2

fig. 2

fig. 3

fi 3

fig. 3

fig. 2

fig. 5

SETUP

fig. 1

fig. 2

fig. 3

fi 3

fig. 3

fig. 4

fig. 5

Note: Actuator RFTI-10B can be connected with two temperature sensors. For each sensor, you can create your own name.

Press the Add icon (Fig. 2) to show a selection of sections (Fig. 3):

Temperature regulation Dimming Blinds Switching Control Speed Detectors

Choose the section where you want to add the device name and type your own text (max. 20 characters).

Example 1: If you want to control the blinds - Place the name to the section of the blinds (Fig.3-5).

Example 2: If you want to control a group of blinds together, first create all the blinds names in the blinds section and then create new name for group control in Quick

control section.

Menu (create name) / Add

Menu (create name) is used to add, edit or remove the names of the controlled device. In this menu (Figure 1) you need to first

create your own device names for the sections you want to control.

Creating names is important for successful programming of the RF Touch. For each actuator, which is involved in the installation

you have to create unique name.

The content of this menu is not set at the factory.

Menu (create name)

Edit button is used to change or modify the name in the crea-

ted menu.

Press the Edit icon (Fig.1), a menu appears, select the se-

ction in which you want to edit created name (Fig. 2). Mark

selected name by touching it (Fig. 3) and then edit with dis-

played keyboard.

Press OK to confirm (Fig. 4). The modified name is stored.

Menu (create name) / Edit

Remove button can delete unit name.

PresstheRemove icon (Fig. 5)following menu appears,se-

lectthe sectionfromwhichyouwanttoremovethename(Fig.

6). Pick the device you want to delete by touching it.(Fig. 7) .

Press to confirm the selection (Fig. 8). Selected name

will be deleted from menu.

Menu (create name) / Remove

SETUP

fig. 1

fig. 2

fi 2

fig. 2

fig. 3

fig. 4

fi 4

fig. 4

fig. 5

fig. 6

fi 6

fig. 6

fig. 7

fi 7

fig. 7

fig. 8

fig

. 8

SETUP

fig. 1

fi 1

fig. 1

fig. 3

Programming

Programming is used to assign or remove the actuators / detectors to menu you created.

The Programming Menu can be entered by entering a password (default - 1111).

Actuators are divided into sections for which they are intended. According to the actuator's type you have to select appropriate

section - see table (eg programming actuator RFSTI-11B - find it in the Temperature regulation section).

Temperature

regulation

Switching Dimming Blinds Detectors

RFSTI-11B/G RFSA-11B RFDA-11B RFJA-12B/230V JA-81M / 82M

RFTI-10B INxRFSA-6x* RFDA-71B RFJA-12B/24V DC JA-80P

RFTI-10B OUTxx RFDAC-71B RFDAC-71B

RFTC-10/G RFSAI-61B RFDEL-71B

RFATV-1 RFUS-11 RFDSC-11

RFUS-61 RFDSC-71

RFSC-11

RF Control actuators divisions

M / 82M

x internal sensor

xx external sensor

* RFSA-61B, RFSA-62B,RFSA-61M and RFSA-66M

It is used to assign a name to the actuator in the menu. In the required section (heating, dimming ...) select Assign new (Fig. 1). A

list of selected sections actuators will be shown. (Fig. 2). Select the name of the actuator which you want to associate with the

RF Touch. Enter the address of actuator you want to assign( Figure 3) as indicated on the actuator. Confirm with OK . From the

menu you created, select the name to which the actuator will be assigned (Fig. 4).

- Only one name can be assigned for each actuator.

- When programming, actuator must be connected with the installation.

Communication test (Fig. 6) is used to detect and display the current status of the RF signal between the RF Touch and progra-

mmed actuator.

- Press Start (Fig. 7) to initiate the test, the current status of the signal is displayed in percentage.

- Press Return to Programming to get back to main menu of programming.

Programming / Assign new

SETUP

fig. 1

fig

. 1

fig. 1

fig. 2

fig. 3

fi 3

fig. 3

fig. 4

fi 4

fig. 4

fig. 5

fi 5

fig. 5

fig. 6

fig

. 6

fig. 7

fig

. 7

Programming / Temperature regulation / Assign New / RFTI-10B and RFTC-10/G

These two units are temperature sensors, communication test is not executed during programming.

Note: The actuator RFTI-10B is able to be connected with two temperature sensors, each sensor may have its

own name. Address of the actuator is the same for both sensors.

Programming / Associated Receivers

It serves to control or remove the actuator from the name of the menu you created.

In the selected section (Figure 1 - Temperature regulation, dimming ...) select Assigned receivers

(Fig. 2) a list of names specied in this section will be shown(Fig. 3). Touching on the name you will

assign it to the actuator (Fig. 4).

By pressing arrows you can check the name and address assigned to the actuator (Fig. 4, 5).

By touching the name or address of the actuator, you can Remove the actuator (Image 7), Change

the address (Image 8), or perform a Communications test (Image 9) and Pair with ....switching

actuators, or internal relays (Image 10).

SETUP

fig. 1

fi 1

fig

. 1

fig. 2

fi 2

fig

. 2

fig. 3

fi 3

fig

. 3

fig. 4

fi 4

fig

. 4

fig. 5

fig. 6

fi 6

fig

. 6

fig. 7

fi 7

fig

. 7

obr. 8

fig. 9

fi 9

fig. 9

obr. 10

obr. 11

b11

Correction table for oset settings inRFSTI-11 /G device

Connected power 0 VA 250 VA 500 VA 1000 VA 1500 VA 2000 VA

Oset in RF Touch settings -5 °C -3,5 °C -2 °C -1,5 °C -0,5 °C 0

Due to warming of internal relay contact in the product RFSTI-11 /G, which are caused by current ow to the connected load, it is highly

recommended to use the oset settings according to the following correction table, according to the value of controllable power. Oset

settings are done in RF Touch device, for a given heating circuit, to which the device RFSTI-11/G is assigned.

fig. 2

fi 2

fig

. 2

fig. 3

fi 3

fig

. 3

fig. 4

fi 4

fig

. 4

fig. 5

fi 5

fig

. 5

fig. 6

fi 6

fig. 6

fig. 1

fi 1

fig

. 1

Function AssignedreceiversinTemperaturereg.- RFTI-10B, RFTC-10/Gand RFATV-1are used to pair orremovetemperatureunits from theactuator.

In the Temperature regulation section, press the screen to select Assigned receivers; the list of names assigned in this section will be

displayed Press the name to display the assigned actuator. Select the name to which the RFTI-10B, RFTI-10/G or RFATV-1 is assigned

(Fig. 1-3). Use arrows to check the name and address of the assigned actuator (Fig. 4-5).

Touch the name or address of the actuator to display the menu (Fig. 6):

Remove Pair with... Paired with...

Programming / Temperature regulation / Assigned receivers / RFTI-10B, RFTC-10/G and RFATV-1

Serves to cancel the link between the temperature unit and the name from the menu Temperature regulation.

Programming / Temperature regulation / Assigned receivers / RFTI-10B, RFTC-10/G and RFATV-1/ Remove

SETUP

Note: the attached actuator RFTI-10B can be used in two ways:

For temperature measurement (without pairing with a switching actuator)

When paired with the multifunction switching actuator it can switch heating equipment on the basis of the measured temperature.

fig. 2

fi 2

fig. 2

Note: Battery indication on the display (Fig. 1) informs of low battery in one of the temperature units. Press the battery to display the unit name. Use arrows
