Gen5 POD MCIO Edition Assembly Reference
0004674 - R1.3
Page 1 of 5
Item Part
Number Part Description Qty
1 4631 POD Main Unit 1
24679 Host/Device Cable Adaptor Tray 2
3 4693 MCIO Device PCBA 1
4 4694 MCIO Host PCBA 1
CAUTION :
Failure to do the following may DAMAGE the interposer and VOID the warranty.
•Secure adapters as shown in this guide
•Do NOT change adapters while powered
•Do NOT hot plug
•Turn on interposer power BEFORE host power
3
2
1
4
2

Gen5 POD MCIO Edition Assembly Reference
0004674 - R1.3
Page 2 of 5
POD Main Unit
Slide the Host/Device Cable Adaptor Tray into the slot on the HOST side on
the underside of the POD Main Unit at an angle of about 60~.
Rotate the Cable Adaptor Tray so it is horizontal and tighten the M3 Captive
Panel Screws to the POD Main Unit, ensuring not to over tighten.
Host/Device Cable Adaptor Tray
M3 Captive Panel Screw

Gen5 POD MCIO Edition Assembly Reference
0004674 - R1.3
Page 3 of 5
MCIO Device PCBA
M3 Captive Screw
Raise M3 Captive Screws till it resists and screw thread clears the
underside of PCBA, then slide the MCIO Device PCBA into the
connector on the DEVICE side of the POD Unit and secure in position
on the Host/Device Cable Adaptor Tray with the M3 Captive Screws
POD Main Unit
Host/Device Cable Adaptor Tray

Gen5 POD MCIO Edition Assembly Reference
0004674 - R1.3
Page 4 of 5
Slide the Host/Device Cable Adaptor Tray into the slot on the HOST side
on the underside of the POD Main Unit at an angle of about 60~.
Rotate the Cable Adaptor Tray so it is horizontal and tighten the M3
Captive Panel Screws to the POD Main Unit, ensuring not to over tighten.
POD Main Unit
Host/Device Cable Adaptor Tray
M3 Captive Panel Screw

Gen5 POD MCIO Edition Assembly Reference
0004674 - R1.3
Page 5 of 5
M3 Captive Screw
Raise M3 Captive Screws till it resists and screw thread clears the
underside of PCBA, then slide the MCIO Host PCBA and connect to the
HOST side of the POD Unit. Secure in position on the Host/Device
Cable Adaptor Tray with the M3 Captive Screws
MCIO Host PCBA
POD Main Unit
Host/Device Cable Adaptor Tray
