Ellisys SerialTek Gen5 POD SSAS User manual

Gen5 POD SSAS Edition Assembly Reference
0004646 - R1.4
Page 1 of 5
Item Part
Number Part Description Qty
1 4631 POD Main Unit 1
24679 Host/Device Cable Adaptor Tray 2
3 4235 SSAS Host PCBA 1
4 4236 SSAS Device PCBA 1
CAUTION :
Failure to do the following may DAMAGE the interposer and VOID the warranty.
•Secure adapters as shown in this guide
•Do NOT change adapters while powered
•Do NOT hot plug
•Turn on interposer power BEFORE host power
4
2
3 2
1

Gen5 POD SSAS Edition Assembly Reference
0004646 - R1.4
Page 2 of 5
Host/Device Cable Adaptor Tray
POD Main Unit
M3 Captive Panel Screw
Slide the Host/Device Cable Adaptor Tray into the slot on the DEVICE side
on the underside of the POD Main Unit at an angle of about 60~.
Rotate the Cable Adaptor Tray so it is horizontal and tighten the M3
Captive Panel Screws to the POD Main Unit, ensuring not to over tighten.

Gen5 POD SSAS Edition Assembly Reference
0004646 - R1.4
Page 3 of 5
POD Main Unit
SSAS Device PCBA
M3 Captive Screw
Raise M3 Captive Screws till it resists and screw thread clears the
underside of PCBA, then slide the SSAS Device PCBA into the
connector on the DEVICE side of the POD Unit and secure in position
on the Host/Device Cable Adaptor Tray with M3 Captive Screws.
Host/Device Cable Adaptor Tray

Gen5 POD SSAS Edition Assembly Reference
0004646 - R1.4
Page 4 of 5
POD Main Unit
Slide the Host/Device Cable Adaptor Tray into the slot on the HOST side on
the underside of the POD Main Unit at an angle of about 60~.
Rotate the Cable Adaptor Tray so it is horizontal and tighten the M3 Captive
Panel Screws to the POD Main Unit, ensuring not to over tighten.
Host/Device Cable Adaptor Tray
M3 Captive Panel Screw

Gen5 POD SSAS Edition Assembly Reference
0004646 - R1.4
Page 5 of 5
SSAS Host PCBA
POD Main Unit
M3 Captive Screw
Host/Device Cable Adaptor Tray
Raise M3 Captive Screws till it resists and screw thread clears the
underside of PCBA, then slide the SSAS Host PCBA into the connector on
the HOST side of the POD Unit and secure in position on the
Host/Device Cable Adaptor Tray with M3 Captive Screws.
