Elmdene G240xNU User manual

1
Technical Support: [phone] (option 3) PAK200566 01B ©2016 ELMDENE INTERNATIONAL LTD
27.6V DC S WITCH M ODE P OWER S UPPLY M ODULES
M
odel
s
:
G240x U
Where ‘x’ is max load current: 1A, 2A, 3A or 5A.
F EATURES
High efficiency cost effective power supply ideal for use in Fire, Access Control and General Security
applications. Featuring a regulated 27.6Vdc output supplying continuous full rated current to load and up to
an additional 0.5A for charging 2 x 12V standby batteries. The universal mains input voltage enables the
power supply to be used across a wide geographical area. The highly efficient switch mode design ensures
low operating costs while generating less heat. The modular construction simplifies maintenance.
•Universal mains input voltage 90-264vac
•Additional 0.5A to charge 2 x 12V standby batteries
•High efficiency electronics for reduced running costs and lower
operating temperatures
•Continuous full rated current to load
•Modular construction for ease of maintenance & installation
•Installer safe design with all high voltage electronics fully shrouded
•Reverse battery connection protection
•Full electronic short circuit and overload protection on load output
•Mains transient protection circuit
•Green Mains present LED
•Yellow Fault LED
Elmdene International Ltd Tel: [phone]
3 Keel Close, Interchange Park, Fax: [phone]
Portsmouth, Hampshire, PO3 5QD, UK  Web: www.elmdene.co.uk

2
Technical Support: [phone] (option 3) PAK200566 01B ©2016 ELMDENE INTERNATIONAL LTD
S PECIFICATIO
Input Specification
Voltage (rat
ed)
100
-
240Vac
Voltage (operating)
90
-
264Vac
Frequency
50
-
60Hz
Ma
x Current
See Model Specification Table
Mains Input Fuse
See Model Specification Table
Max standby Power
0.8W (n
o load
and no battery
connected)
Output Specification
Voltage
27.0 – 28.0Vdc (27.6vdc nominal) on mains power
21.0 – 24.7Vdc on battery standby
Max load current
See Model Specification Table
Ripple
10
0 mV pk
-
pk max
Load output Fuse
See Model Specification Table below
Overload
Electronic shutdown until overload or short ci
rcuit removed
(under mains power only)
Local Indicators
MAINS LED (Green)
Mains present
FAULT LED (
Yellow
)
Fault present: Output or battery fuse fail (requires load &
battery to be connected), loss of mains, output short circuit
or low output voltage.
Standby Batteries
Battery Type
2 x 12V Valve Regulated Lead Acid
Battery Charging Fuse protection
F630mA 20mm glass
Mechanical
Model G2401 U G2402 U G2403 U / G2405 U
Module
Dimensions
w x h x d (mm / external) 134 x 84 x 42 152 x 106 x 52 157 x 143 x 55
Recommended Batteries 2 x 12V NP7 or NP17
Weight
G2401 U G2402 U G2403 U / G2405 U
240g 280g 650g
Environmental
Temperature -10 to +40°C (operating) 95% RH non-condensing
-20 to +80°C (storage)
Connections
+O/P +ve voltage O/P to load equipment
-O/P -ve voltage O/P to load equipment
+BATT Red lead to standby battery 1
-BATT Black lead to standby battery 2

3
Technical Support: [phone] (option 3) PAK200566 01B ©2016 ELMDENE INTERNATIONAL LTD
E
N
L
2
0m m
20mm
E
N
L
2
0m m
20mm
E
N
L
2
0m m
20mm
O PERATIO
This unit is intended for use by Service Personnel only - There are NO USER SERVICEABLE parts inside.
The Green Mains LED will be illuminated whilst the mains supply is present. In the event of a fault condition,
the Yellow Fault LED will be illuminated.
I STALLATIO A D S ET -U P
This unit is only suitable for installation as permanently connected equipment. The PSU is NOT SUITABLE for
external installation. EQUIPMENT MUST BE EARTHED. Before installation, ensure that external disconnect
device is OFF. The PSU should be installed according to all relevant safety regulations applicable to the
application.
Enclosure and Mounting
This power supply module has high voltage present and is for use by Service Personnel only. This power
supply module MUST be securely mounted within a robust enclosure having suitable means to prevent
unintentional access to the module. Suitable notices must be affixed to the outside of the enclosure to warn
of high voltages present internally.
Mounting the module
1) Mount securely in correct orientation allowing minimum clearance of 20mm all round – see diagrams
below.
2) The G2401NU and G2402NU modules have the option of either being DIN rail mounted (using the
integrated DIN rail mount) or by using appropriate fixings using the four available mounting lugs. The
G2403NU and G2405NU modules are fixed using the three available mounting points.
Mains Power Up
3) Attach correctly rated mains cable (minimum 0.5mm
2
[3A], 300/500Vac) and secure in enclosure using
cable ties.
4) Apply mains power. Check for 27.6Vdc on load outputs. Check Green Mains LED is on.
5) Disconnect mains power.
Load Output
6) Attach correctly rated load cable and secure in enclosure using cable ties. Note polarity.
7) Apply mains power. Check green Mains LED is on.
8) Verify load is operating correctly.
9) Disconnect mains power.
G2401NU G2402NU G2403NU & G2405NU
E L N
L E N
L E N

4
Technical Support: [phone] (option 3) PAK200566 01B ©2016 ELMDENE INTERNATIONAL LTD
I STALLATIO A D S ET -U P CO TI UED
Standby Battery - OTE: Ensure batteries fitted to this unit are in good condition
10) Connect battery to terminal block using minimum 32/0.2 (1.0mm
2
CSA) stranded wire.
OTE: ensure correct polarity of battery connections.
Maximum recommended total battery lead length = 500mm
11) Apply mains power. Check Green Mains LED is on.
12) Check there is no fault indication on Yellow LED.
13) Disconnect mains power. Check that the batteries continue to supply voltage and current to the load.
The Green LED should be off.
OTE: Batteries must have sufficient charge to supply the load
14) Reconnect mains power. Green LED should be on.
15) Remove Load fuse and check Yellow Fault LED is on.
16) Replace Load fuse. Check Yellow Fault LED is off.
Module Dimensions
50
19
124
52
114
R5
40,5
16
84
G2401N

5
Technical Support: [phone] (option 3) PAK200566 01B ©2016 ELMDENE INTERNATIONAL LTD
128
98
42,4
60
51
84
152
106
12
4
19
13
G2402N
157
128 7,5
128
42,4
19 60
56,5
4
135 143
12
G2403N & G2405N

6
Technical Support: [phone] (option 3) PAK200566 01B ©2016 ELMDENE INTERNATIONAL LTD
M AI TE A CE
There is no regular maintenance required of the PSU other than periodic testing and replacement of the
standby batteries. Reference should be made to the battery manufacturer’s documentation to determine
typical/expected battery life with a view to periodic replacement of the battery.
If the output of the PSU fails the cause of the failure should be investigated e.g. short circuit load. The fault
should be rectified before restoring power to the PSU. The fuses may need to be replaced. Ensure the
correct fuse rating and type is used.
Model Specification Table G2401NU G2402NU G2403NU G2405NU
Output Current 1A 2A 3A 5A
Battery Charge Current 0.5A 0.5A 0.5A 0.5A
Mains LED (Green) √ √ √ √
Fault LED (Yellow) √ √ √ √
Max Mains Input Current (at 90Vac) 1.0A 1.3A 1.4A 2.0A
F1 - Mains Input Fuse (20mm HRC) T2.0A T2.0A T3.15A T3.15A
F2 - Output Fuse (20mm) F1.0A F2.0A F3.15A F5.0A
F3 - Battery Fuse (20mm) 630mA 630mA 630mA 630mA
