ELPRO SP205+ Quick start guide

SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
1
• Two separate 1x5 video and stereo audio sections
• Possibility of 1x5 dual or 1x10 single configuration
• Suitable for composite or Y/C signals
• Suitable for unbalanced stereo audio or mono balanced
si
g
nals
Ed. 1 11/12/2008

1
SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
2
INSTALLATION AND USE OF THE SP205+
SUMMARY
1.0 Overview 3
2.0 Power supply 4
3.0 Installation 5
4.0 Technical data 9
5.0 Notes 10
When installing the SP205+ unit, please read this handbook carefully.
The manufacturer shall not be held responsible for damage due to use, even
correct, of its products.
The data and characteristics of the product may be modified without prior
notice.
All updates and news regarding this products are published on our site
www.elprovideolabs.com

SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
3
1.0 OVERVIEW
Thank you for purchasing this product. Check the contents of the packaging
carefully. It contains:
 The SP205+ unit
 This handbook and the certificate of conformity
 The power cord
The SP205+ is a dual 1x5 video and stereo audio distributor that can, if
necessary, be configured as a single 1x10 distributor.

1
SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
4
2.0 POWER SUPPLY
The SP205+ must be powered at 90÷240 Vac 50/60Hz using the cable
provided. The socket of the cable must be inserted in the related panel plug
to the left on the back of the unit.
The panel plug is equipped with a fuse
holder for 5X20 fuses. If the fuse blows,
replace it with one of the same rating
that’s 1AT.
All operations must be carried out by qualified personnel only,
who must be informed of the risks of electric shock.
In some countries, the plug of the cable must be adapted to local standard
types. The wires are coded as follows:
Brown PHASE Identified by the letter L, may be red
Blue NEUTRAL Identified by the letter N, may be black
Yellow/green GROUND Identified by the letter E, may be green
WARNING
A ground connection is compulsory

SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
5
3.0 INSTALLATION
3.1 Video section
3.1.1 Dual 1x5 distributor
To use the unit as dual 1x5 distributor with two sources, proceed as follows:
a) Make sure that all the units to be installed are OFF.
b) Set the switch on the front panel to the “DUAL 1x5” position
remembering that this setting acts not only on the video but also on the
audio.
c) Connect the first video source to one of the two IN1 connectors and the
second source to one of the two IN2 connectors.
d) If the input signal is not terminated at 75Ω, set the matching switch to
the ON position. If the signal is already terminated at 75Ω, set the
switch to OFF. The switch of input IN1 is located to the left of the
respective BNCs, that of input IN2 is located to the right.
e) The input BNC not used can be left free or can be used, if necessary, to
send the video signal to other units. In this case, remember that
termination at 75Ωmust be carried out at only one point of the chain,
preferably at the end of this. Therefore, in this case, the 75 Ohm switch
must be set to a OFF.
f) Connect the destinations to BNCs 1÷5 “VIDEO OUT” on both sections.
The BNCs at the top refer to section 1, those at the bottom refer to
section 2.
g) Power the SP205+ and other system units.

1
SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
6
3.1.2 Single 1x10 distributor
To use the unit as 1x10 single distributor, proceed as follows:
a) Make sure that all the units to be installed are OFF.
b) Set the switch on the front panel to the “1x10” position remembering
that this setting acts not only on the video but also on the audio.
c) Connect the video source to one of the two IN1 connectors
d) If the input signal is not terminated at 75Ω, set the switch referring to
the IN1 input (located to the left of the related BNCs) to the ON position.
If the signal is already terminated at 75Ω, set the switch to OFF. The
position of the switch relating to IN2 is not significant in this operating
mode.
e) The BNC not used, relating to input IN1, can be left free or can be used,
if necessary, to send the video signal to other units. In this case,
remember that termination at 75Ωmust be carried out at only one point
of the chain, preferably at the end of this. Therefore, in this case, the 75
Ohm switch must be set to a OFF.
f) As the two IN2 connectors are not used in this operating mode,
connection of these is not significant.
g) Connect the destinations to the “VIDEO OUT” BNCs.
h) Power the SP205+ and other system units.

SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
7
3.2 Audio section
3.2.1 Dual 1x5 distributor
To use the unit as dual 1x5 distributor with two sources, proceed as follows:
a) Make sure that all the units to be installed are OFF.
b) Set the switch on the front panel to the “DUAL 1x5” position
remembering that this setting acts not only on the video but also on the
audio.
c) Connect the first audio source to the AUDIO IN1 connectors and the
second source to the AUDIO IN2 connectors. If the source is mono, only
one of the two channels (L or R) can be used.
d) Connect the destinations to the AUDIO OUT1 and AUDIO OUT2
connectors respectively.
e) Power the SP205+ and other system units.
3.2.2 Single 1x10 distributor

1
SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
8
To use the unit as single 1 x10 distributor, proceed as follows:
a) Make sure that all the units to be installed are OFF.
b) Set the switch on the front panel to the “1x10” position remembering
that this setting acts not only on the video but also on the audio.
c) Connect the audio source to the AUDIO IN1 connectors. If the
source is mono, only one of the two channels (L or R) can be used.
As the AUDIO IN2 connectors are not active in this configuration,
their connection is not significant.
d) Connect the destinations to the AUDIO OUT1 and AUDIO OUT2
connectors.
e) Power the SP205+ and other system units.

SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
9
4.0 TECHNICAL DATA
4.1 Video
Input type AC coupled
Input ret.loss 32 dB @ 5 MHz worst case
Input level Max 2 Vpp on 75Ω
Output gain 0 dB
Output ret.loss 44 dB @ 5 MHz worst case
Frequency response 0.10 dB @ 9 MHz
0.15 dB @ 10 MHz
±3 dB @ 120 MHz
Delay 18 ns
Differential gain 0.3%
Differential phase 0.2°
Hum & noise -84 dB unweighted
Crosstalk 45dB (two sections) @5MHz, worst case
Hum & noise -84 dB unweighted
4.2 Audio
Input AC coupled
Input impedance 56KΩ
Input level +10dBm Max
CMRR 36dB at 5KHz
Output impedance 150Ω
Output gain 0 dB
Frequency response ±0.10 dB from 7 Hz to 330 KHz
± 3 dB up to 6MHz
Harmonic distorsion <0.05%@ 10dBm
Hum & noise -74 dB unweighted
Crosstalk 54 dB (two sections) at 16KHz worst case
51 dB (left/right) at 16KHz worst case

1
SP205+ DUAL 1x5 VIDEO & AUDIO DISTRIBUTION AMPLIFIER
ELPRO Video Labs s.r.l.
Str.da della Pronda, 45/B 10142 TORINO - ITALY
Tel.[phone] – Fax [phone]
10
4.3 General characteristics
Main input 230Vac
Power consumption 5VA
Size (WXDXH) 483x149x44mm
Weight 2.0Kg
Operating temp. Range 0 ÷45°C
Safety according to EN 60065
EMC according to EN 55103-1 and EN 55103-2
5.0 NOTES
This product is warranted for 5 years from the date of purchase.
If the fault in the product is due to improper use or
operations carried out by third parties, the warranty is forfeited.
During the warranty period, Elpro will repair the faulty units free of charge.
The faulty units must be sent CARRIAGE FREE to the Elpro offices in Turin
with a regular accompanying note.
The units repaired will be returned CARRIAGE FORWARD to the addressee.
Outside the warranty period, Elpro will repair the faulty units EX its Turin
offices, charging the cost of the repair to the customer.
For any problems during installation of the SP205+,
call the Elpro hot-line Tel. [phone]
or e-mail: [email protected]
