Brief Instruction
Mounting of WS1 Color
Item numbers 60135-60142, 60145-46 (WS1 Color)
Warning, mains voltage! National legal regulations are to be
observed. Installation, inspection, commissioning and
troubleshooting of the device must only be carried out by a
competent electrician.
Notes on wireless equipment
When planning facilities with devices that communicate via radio, adequate radio
reception must be guaranteed. The range will be limited by legal regulation and
structural circumstances. Avoid sources of interference and obstacles between re-
ceiver and transmitter, that could disturb the wireless communication. Those
would be for example:
• Walls and ceilings (especially concrete and solar protection glazing).
• Metal surfaces next to the wireless participants (e. g. aluminium
construction of a conservatory).
• Other wireless devices and powerful local transmitters (e.g. wireless
headphones), which transmit on the same frequency. Please maintain a
minimum distance of 30 cm between wireless transmitters for that reason.
Preparing the installation location
The device must only be installed and used in dry, interior
spaces. Avoid condensation.
The device is to be installed flush to the wall surface. When selecting an installation
location, please ensure that the measurement results of the integrated temperatu-
re/humidity sensor are affected as little as possible by external influences. Possible
sources of interference include:
• Direct sunlight
• Drafts from windows and doors
• Draft from ducts which lead from other rooms to the concealed box
• Warming or cooling of the building structure on which the device is
mounted, e.g. due to sunlight, heating or cold water pipes
• Connection lines which lead from warmer or colder areas to the device
An external antenna can be connected in order to improve wireless communicati-
ons. During installation, a conduit 50 cm in length should be placed beneath the
recessed housing, in which the external antenna can be mounted (antenna dimen-
sions approx. 565 x 8 x 5, L × W × H in mm):
Preparing for installation
Wall-fitting
Cavity wall fitting
Assembling the control unit with concealed box
During electrical installation, please introduce all connection cables into the con-
cealed box through the lower or upper side wall. In the process, keep the individual
connection wires short to prevent long reserve loops.
After wiring, connect the ribbon cable to the screen board. Make sure that the
transport lock (foam) is removed and also remove the foil protecting the screen
(red flap). Screw the lower part of the housing onto the flush mounting box. Set
the frame on the lower part of the housing. To this end, the frame is first suspended
below and then clapped shut above and snapped in place.
Structure of the connector board WS1 Color
The manual with additional information about commissioning,
functions and use of the controls WS1 Color can be down-
loaded from www.elsner-elektronik.de in the menu area "Ser-
vice/Downloads".
External dimensions
of concealed box
in mm:
(depth approx. 62 mm)
Conduit angled diagonally dow-
nwards (for cable access from
above or below)
Conduit angled vertically downwards
(only for cable access from above!)
concealed concealed
45°
cable
cable
box box
M16 conduit, 50 cm in length M16 conduit,
50 cm in length
Loosen the frame on the upper corners by
pulling it forward. You can press your
thumbs on the screen while doing this.
Take the frame off at the top first, then at
the bottom.
The lower portion of the housing is moun-
ted on the flush mounting box with 2
screws: loosen the screws.
Take off the housing component with the
screen board. The screen is connected via
a ribbon cable (1) with the board in the
flush mounting box. Loosen the plug in
order to be able to remove the upper part.
Remove the transport lock (2).
Remove the circuit board from the con-
cealed box to be installed a keep it in a
place where it is protected from dirt. It
may never be exposed to dust or mo-
isture!
For fitting, screw the cover (board) on to
the concealed box with the enclosed
screws.
Clamp the concealed box to the wall with
the four enclosed screws.
Upon delivery, the pouch containing the
assembly screws can be found in the con-
trol unit’s flush-mounted casing.
or
1 Drive group 1
2 Drive group 2
3 Drive group 3
4 Drive group 4
5 Mains connection L/N/PE 230 V/50
Hz
6 Outer conductor L1
7 Multifunctional output 1
(potential-free)
8 MF output 2 (potential-free)
9 Wall button 1
(terminal 1: +12 V | 2: Up | 3: Down)
10 Wall button 2
(4: +12 V | 5: Up | 6: Down)
11 Wall button 3
(7: +12 V | 8: Up | 9: Down)
12 Wall button 4
(10:+12V|11:Up|12:Down)
13 Weather station (terminals 1-2)
Wire assignment: red = 1, black = 2,
yellow and white = not connected
14*Multifunctional input 1
(terminal 3: +12 V | 4: GND | 5: IN)
15*MF input 2
(6: +12 V | 7: GND | 8: IN)
16 Connector for flat-ribbon cable to
front board
17 Microfuse T6,3 A
* Supply voltage e. g. indoor sensor
possible via MF inputs
(No. 14, terminal 3(+), 4(-) and
No. 15, terminal 6(+), 7(-)),
max. 50 mA altogether.
1 2 3 4 5
6
7
8
9
10
11
12
13
14
15
16
17
EN

Mounting of WS1 Color 2
Mounting of WS1 Color • Version: 30.06.2020 • Technical changes and errors excepted. • Elsner Elektronik GmbH • Sohlengrund 16 • 75395 Ostelsheim • Germany • www.elsner-elektronik.de • Technical Service: +49 (0) 7033 / 30945-250
Connection diagrams
Drive and MF outputs WS1 Color:
per drive output max. 400 W,
total max. 1.5 kW
Inputs WS1 Color:
Connection examples for multifunctional outputs
Connecting 230 V consumers to MF outputs
Connecting low-voltage consumers and potential-free contacts to MF
outputs
Technical specifications Control Unit WS1 Color
The product conforms with the provisions of EU directives.
There are no drive outputs available with the model WS1-0.
multifunctional outputs 1-4 WS1000 Color/Style
multifunctional outputs 1-2 WS1 Color/Style
MF output 1 MF output 2 MF output 3
neutral conductor
heating valve 230 V
lamp 230 V
Contactor / Relay (on-site)
MF output 4
L1 / L1connector
ventilator 230 V
F1 6,3A slow-blow
radiant heater
Housing Plastic material (partially painted)
Colours • White glossy (similar to RAL 9003 Signal White)
/ light grey (similar to RAL 7035 Light Grey)
• Aluminium (similar to RAL 9006 White Aluminium)
/ graphite (similar to RAL 7024 Graphite grey)
Mounting Flush/cavity wall
Dimensions Central unit approx. 164 × 121 × 29 (W × H × D, mm),
concealed box approx. 152 × 95 × 62 (W × H × D, mm)
Ambient temperature Operation 0…+55°C, Storage -30…+70°C
Ambient humidity 5...95% RH, avoid bedewing
Operating voltage 230 V AC, 50 Hz
Power consumption Stand-by max. 10 W
Load capacity
drive outputs
per drive output max. 400 W,
total max. 1.5 kW
Frequency
wireless channels
868.2 MHz
Protection category IP 20
Measurement range
temperature
0…+55°C
Resolution (temperature) 0.1°C
Measurement range
humidity
5…95% RH
Resolution (humidity) 0.1%
multifunctional outputs 1-4 WS1000 Color/Style
multifunctional outputs 1-2 WS1 Color/Style
MF output 1 MF output 2 MF output 3 MF output 4
e.g. 24 V (ext.power supply)
heating valve 24 V other consumers 24 V
signal contact for e.g.
rain / wind / frost /
smoke detector / alarm
thermostat
(on-site)
